2008 OWNER’S MANUAL

FIJI SPAS OWNER’S MANUAL
Welcome To Ultimate Relaxation!
Thank you for choosing your new spa built for Fiji Spas. Please read the entire
Owner’s Manual before installing and using your spa. The goal of this manual is
to provide you with safety and operational information plus some tips that will
help you enjoy your spa to its fullest.
At the time of print, this manual is accurate in its information. Fiji Spas reserves
the right to change or improve its product without prior notice.
RECORD OF OWNERSHIP
Name ______________________________________________________________________
Address ____________________________________________________________________
City _____________________________________ State __________ Zip ______________
Date Purchased ______ /______ /_______
Model ______________________________ Serial #________________________________
Dealer Name________________________________________________________________
Phone # (______)________-__________
Service Tech Rep ____________________________________________________________
*SERIAL NUMBER LOCATION
The serial number for your spa is located in the filter area, on the spa system
pack, or on the listing plate on the skirting. It will start with "M" followed
by a 6-digit number. Ex. M804590
1

TABLE OF CONTENTS
Safety Instructions..................................................................................................3-10
Glossary of Spa Terminology ....................................................................................10
Electrical Installation Requirements ........................................................................11
Wiring Schematic ................................................................................................12
Site Preparation / General Guidelines ..........................................................13-14
Installation Instructions ......................................................................................15
Water Chemistry Terms You Should Know ........................................................16-17
Water Quality Maintenance Schedule......................................................................18
Spa Water Maintenance – Start-Up ....................................................................19-21
Spa Water Maintenance Trouble-Shooting Guide ..................................................22
Why Chemicals are Important in a Spa....................................................................23
Maintenance Recommendations ..............................................................................24
Winterizing Your Spa ................................................................................................25
Fiji Spa
Specifications ......................................................................................................26
Controls ..........................................................................................................27-28
Diagnostic Messages......................................................................................29-30
Spa Trouble-Shooting Guide................................................................................31-32
Regular Maintenance Procedures........................................................................33-34
Spa Care and Maintenance Record ....................................................................35-36
2

SAFETY INFORMATION
3
SAVE THESE INSTRUCTIONS
Included with your new spa is a safety sign. The sign is for you and your guest’s
protection and is suitable for outdoor use in wet locations. The sign should be placed
in a location visible to all users of the spa.
Please take time to point out the physical location of the safety sign and the importance
of the safety precautions displayed on the safety sign to all of your guests. Remember,
your safety and the safety of anyone who enjoys the use of your spa is our utmost
concern.
The sign should be mounted with screws or another type of permanent fastener.
Additional or replacement signs can be obtained from your dealer or direct from
the factory.
INTRODUCTION
It’s time to relax! You now have your very own portable spa by Fiji Spas. By fully
understanding the operation of each of the features of your new Fiji Spa, you will
be assured of many years of hassle-free, hot water therapy and fun.
Your safety is of paramount importance to the Fiji Spas family. We urge you to read
and become thoroughly familiar with all safety aspects addressed in this manual.
Through reading and totally understanding the important information in your owner’s
manual, you will realize that you now own THE ULTIMATE RELAXATION MACHINE!

SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY
INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions should be
observed including the following:
READ AND FOLLOW ALL
INSTRUCTIONS
1. WARNING - To reduce the risk of injury, do not permit children to use this
product unless they are closely supervised at all times.
2. DANGER - RISK OF CHILD DROWNING. Extreme caution
must be exercised to prevent unauthorized access by children. To avoid accidents,
ensure that children cannot use this spa unless they are supervised at all times.
*NOTE: A wire connector is provided on this unit to connect of a minimum No. 6 AWG
solid copper conductor between this unit and any metal equipment, metal enclosures of
electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit.
3. DANGER - RISK OF ELECTRIC SHOCK. Install spa at least
five (5) feet (1.5M) from all metal surfaces. A spa may be installed within five (5) feet
(1.5M) of metal surfaces if, in accordance with the National Electrical Code, each
metal surface is permanently connected by a minimum No. 6 AWG (8.4mm) solid
copper conductor attached to the wire connector on the terminal box. A grounding
lug is provided for this purpose.
4. DANGER - RISK OF INJURY. The suction fittings in this spa are
sized to match the specific water flow created by the pump. Should the need arise to
replace the suction fittings or the pump, be sure that the flow rates are compatible.
*NOTE: Never operate the spa if the suction fittings are broken or missing. Never replace
a suction fitting with one rated less than the flow rate marked on the original suction fitting.
5. DANGER - To reduce the risk of injury to persons, do not remove the suction
grate. Suction through drains and skimmers is powerful when the jets in the spa are
in use. Damaged covers can be hazardous to small children and adults with long hair.
Should any part of the body be drawn into these fittings, turn off the spa immediately.
As a precaution, long hair should not be allowed to float in the spa.

SAFETY INSTRUCTIONS
5
IMPORTANT SAFETY
INSTRUCTIONS (CONT.)
6. WARNING. Install the spa so that water can be easily drained out of the
compartment containing electrical components so as not to damage equipment.
Also, when installing spa, allow at least 2 feet of clearance around the perimeter
of the spa to provide enough room to access for servicing. Contact your local dealer
for their specific requirements.
7. WARNING - TO REDUCE THE RISK OF INJURY:
(A) Reminder - Never allow anyone to dive into a spa. Always enter feet first.
(B) Always enter and exit a spa slowly.
(C) Do not use the spa alone.
(D) Before entering the spa, always measure the water temperature with an accurate
thermometer. Tolerance of water temperature regulating devices can vary as much
as plus/minus 5° F (3° C).
(E) Persons suffering from obesity or with a medical history of heart disease, diabetes,
high or low blood pressure or circulatory system problems should consult a physi-
cian before using the spa.
(F) Since excessive water temperatures have a high potential for causing fetal damage
during early months of pregnancy, pregnant or possibly pregnant women should
limit spa water temperatures to 100° F (38° C).
(G) Excessive water temperature can be dangerous. The water in the spa should
never exceed 104° F (40° C). Water temperatures between 100°F (38˚C) and
104°F (40˚C) are considered safe for a healthy adult. Lower water temperatures
are recommended for extended use (exceeding 10 minutes) and for young
children. Long exposures at higher temperatures can result in hyperthermia.
(H) The use of alcohol, drugs, or medication before or during spa use may lead to
unconsciousness with the possibility of drowning.
(I) Persons using medication should consult a physician before using a spa since some
medication may induce drowsiness while other medication may affect heart rate,
blood pressure and circulation.

SAFETY INSTRUCTIONS
6
IMPORTANT SAFETY
INSTRUCTIONS (CONT.)
HYPERTHERMIA
Hyperthermia occurs when the internal temperature of the body reaches a level several
degrees above the normal body temperature of 98.6° F.
THE SYMPTOMS OF HYPERTHERMIA INCLUDE:
Dizziness • Fainting • Drowsiness • Lethargy • Increase in Internal Body Temperature
THE EFFECTS OF HYPERTHERMIA INCLUDE:
Unawareness of Impending Hazard • Failure to Perceive Heat • Failure to Recognize the
Need to Exit Spa • Physical Inability to Exit Spa • Fetal Damage in Pregnant Women •
Unconsciousness Resulting
in a Danger of Drowning
(I) Children’s body temperature can increase more rapidly than adults in the same
water with elevated temperatures (above 99° F). Children should spend less time in
water above body temperature than adults.
8. WARNING - The use of alcohol, drugs, or medication can greatly increase the
risk of hyperthermia.
(J) The use of alcohol, drugs, or medication before or during spa use may lead to
unconsciousness with the possibility of drowning.
(K) Persons using medication should consult a physician before using a spa since some
medication may induce drowsiness while other medication may affect heart rate,
blood pressure, and circulation.
9. Reminder: A safe temperature for swimming or aquatic exercise is around 80˚ F.
10. People with infections, sores or the like should not use the spa. Warm and hot water
temperatures may allow the growth of infectious bacteria if not properly disinfected.
11. DANGER - RISK OF ELECTRIC SHOCK. Do not permit any
electric appliance, such as a light, telephone, radio or television, within five (5) feet of
the spa. Never operate any electrical appliances from inside the spa or while wet.

SAFETY INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS (CONT.)
12. WARNING - RISK OF SUFFOCATION. If this spa is
equipped with a gas heater, it is intended for outdoor use only, unless proper v
entilation can be provided for an indoor installation.
13. WARNING - PREVENT ELECTROCUTION. Do not serv-
ice this product yourself as opening or removing covers may expose you to danger-
ous voltage or other hazards. Refer all servicing to qualified service personnel.
If the power cord is damaged, water is entering the electrical equipment compart-
ment area, the protective shield is showing signs of deterioration, or there are signs
of other potentially hazardous damage to the unit, turn off the circuit breaker from
the wall and refer servicing to a qualified service personnel.
The unit should be subjected to periodic routine maintenance once every quarter to
make sure that the unit is operating properly.
14. DANGER - RISK OF ELECTRIC SHOCK. Do not permit
any electric appliance, such as light, telephone, radio, or television, within 5 feet
(1.5m) of a spa.
15. A green coloured terminal or a terminal marked G, GR, Ground, Grounding or the
symbol shown in Figure 14.1 of UL1563 is located inside the supply terminal box or
compartment. To reduce the risk of electric shock, this terminal must be connected
to the grounding means provided in the electric supply service panel with a continu-
ous copper wire equivalent in size to the circuit conductors supplying this equipment.
16. At least two lugs marked “Bonding Lugs” are provided on the external surface or
on the inside of the supply terminal box or compartment. To reduce the risk of
electric shock, connect the local common bonding grid in the area of the spa to
these terminals with an insulated or bare copper conductor not smaller than
No. 6 AWG.
17. All field-installed metal components such as rails, ladders, drains, or other similar
hardware within 3m of the spa shall be bonded to the equipment grounding bus
with copper conductors not smaller than No. 6 AWG.
SAVE THESE INSTRUCTIONS.
7

SAFETY INSTRUCTIONS
8
WARNING: CHILDREN SHOULD NOT USE SPAS OR HOT TUBS WITHOUT ADULT
SUPERVISION
AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAX-
ATION SANS SURVEILLANCE
WARNING: DO NOT USE SPAS OR HOT TUBS UNLESS ALL SUCTION GUARDS ARE
INSTALLED TO PREVENT BODY AND HAIR ENTRAPMENT.
AVERTISSEMENT: POUR ÉVITER QUE LES CHEVEUX OU UNE PARTIE DU CORPS
PUISSENT ÊTRE ASPIRES, NE PAS UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DI PRISE
D’ASPIRATION NE SONT PAS TOUTES EN PLACE
WARNING: PEOPLE USING MEDICATIONS AND/OR HAVING AN ADVERSE MEDICAL
HISTORY SHOULD CONSULT A PHYSICIAN BEFORE USING A SPA OR HOT TUB.
AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES MÉDICAMENTS OU ONT
DES PROBLÉMES DE SANTÉ DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE
CUVE DE RELAXATION
WARNING: PEOPLE WITH INFECTIOUS DISEASES SHOULD NOT USE A SPA OR HOT TU B
AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES INFECTIEUSES NE
DEVRAIENT PAS UTILISER UNE CUVE DE RELAXATION
WARNING: TO AVOID INJURY EXERCISE CARE WHEN ENTERING OR EXITING THE SPA
OR HOT TUB.
AVERTISSEMENT: POUR ÉVITER DES BLESSURES, USER DE PRUDENCE EN
ENTRANT DANS UNE CUVE DE RELAXATION ET EN SORTANT
WARNING: DO NOT USE DRUGS OR ALCOHOL BEFORE OR DURING THE USE OF A
SPA OR HOT TUB TO AVOID UNCONSCIOUSNESS AND POSSIBLE DROWNING
AVERTISSEMENT: POUR ÉVITER L’ÉVANOUISSEMENT ET LA NOYADE
ÉVENTUELLE, NE PRENDE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAX-
ATION NI QUAND ON S’Y TROUVE
WARNING: PREGNANT OR POSSIBLY PREGNANT WOMEN SHOULD CONSULT A
PHYSICIAN BEFORE USING A SPA OR HOT TUB.
AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIR-
MÉE OU NON, DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE CUVE DE
RELAXATION
