Sunsea AIoT SIMCom SIM7070 TE Series User manual

SIM7070 Series_TE kit_
User Guide_V1.00
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 22019-08-16
Document Title: SIM7070 Series_TE
kit User Guide
Version: 1.00
Date: 2019-08-16
Status: Release
Document Control ID: SIM7070 Series_TE
kit_User Guide_V1.00
General Notes
SIMCom offers this information as a service to its customers, to support application and engineering efforts
that use the products designed by SIMCom. The information provided is based upon requirements
specifically provided to SIMCom by the customers. SIMCom has not undertaken any independent search for
additional relevant information, including any information that may be in the customer’s possession.
Furthermore, system validation of this product designed by SIMCom within a larger electronic system
remains the responsibility of the customer or the customer’s system integrator. All specifications supplied
herein are subject to change.
Copyright
This document contains proprietary technical information which is the property of SIMCom Limited.,
copying of this document and giving it to others and the using or communication of the contents thereof, are
forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved in
the event of grant of a patent or the registration of a utility model or design. All specification supplied herein
are subject to change without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2019
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 32019-08-16
Version History
Date Version Description of change Author
2019-08-16 1.00 Origin Zhaosen
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 42019-08-16
Contents
Version History.......................................................................................................................................................... 3
Contents..................................................................................................................................................................... 4
1.Detail description of SIM7070 Series TE............................................................................................................... 7
2. TE Accessory......................................................................................................................................................... 9
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 52019-08-16
Figure Index
FIGURE1: TE TOPVIEW..................................................................................................................................................7
FIGURE2: TE BOTTOM VIEW........................................................................................................................................8
FIGURE3: TE ACCESSORY.............................................................................................................................................9
FIGURE4: TE AND SIMCOM-EVB ACCESSORY .......................................................................................................10
FIGURE5: USB PORTS...................................................................................................................................................11
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 62019-08-16
SCOPE
This document give the usage of SIM7070 Series TE, user can get useful information about the SIM7070 Series
TE quickly through this document.
This document applies to SIM7070 Series module.
This document is subject to change without notice at any time.
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 72019-08-16
1. Detail description of SIM7070 Series TE
Figure1: TE TopView
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 82019-08-16
Figure2: TE Bottom View
A: Module
B: MainAntenna Connector
C: GNSS Antenna Connector
D: Test Points
E: Micro USB Connector
F: Mark of TE Module direction
G: Connector
H: Connector
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 92019-08-16
2. TE Accessory
Figure3: TE Accessory
A:GNSS Antenna
B:Main and Aux Antenna
AB
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 10 2019-08-16
Figure4: TE and SIMCOM-EVB Accessory
A: STATUS / NETLIGHT / POWER LED
B: When install SIM7070 Series TE to SIMCOM-EVB, please keep arrows aligned on TE and EVB.
NETLIGHT pin status
NETLIGHT pin status
Module status
64ms ON, 800ms OFF
No registered network
64ms ON, 3000ms OFF
Registered network (PS domain registration success)
64ms ON, 300ms OFF
Data transmit (PPP dial-up state and use of data services such as
internal TCP/FTP/HTTP)
OFF
Power off or PSM mode
SIMCom Confidential File

Smart Machine Smart Decision
SIM7070 Series_TE kit User Guide_V1.00 11 2019-08-16
Figure5: USB Ports
(1). HS-USB AT Port: AT communication
(2). HS-USB Diagnostics: Used for debug and FW upgrade
(3). HS-USB NMEA: NMEA port supporting NMEA sentences output
