SWF EMBROIDERY MACHINE
How to Replace the Presser Foot Driving Cam
Set the presser foot 4mm T-wrench
Picture 1
Picture 2
1.Remove the Top Shaft Cover
1) Change the color to the last needle bar to secure
2) Remove the top shaft cover.
the sufficient space for the following steps.
and then use 3mm T-wrench to remove the head from the arm.
1)Remove the head face plate (U) with +driver
1
3Remove the arm protection
2Remove the head
Remove the top shaft cover
+driver, -driver Corner Driver
+driver, 3mm T-wrench
plate and side cover
2.Remove Head
driving cam
presser foot driving
cam setup JIG pin
4
[G] ARM
A. Content
DM-M-22
Order Tools Required
B. Order
C. Details
JIG /
Instruments
No.
CD CODE No:
Top Shaft Cover
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
1)Use a (-) driver to remove the arm protection
plate.
2)Use a (+) driver to remove the arm side cover B.
Refer to Picture 3
Picture 3
1)On the menu of OP Box, select "TOOL"
→ "PF UP/DOWN" in order to down the presser foot.
2) Set the angle plate to 150 degrees.
Refer to Picture 4
Picture 4 3) Insert the presser foot cam JIG pin in order of
the presser foot cam collar, the presser foot
driving cam base and the take-up driving cam base.
Refer to Picture 5
Picture 4
4) Adhere the presser foot driving cam to the side
of take-up driving cam. And then use a 4mm
T-wrench to assemble it
Refer to Picture 5, 6
Picture 5
3. Remove the Arm Protection Plate & the Side Cover
4. Set the Presser Foot Driving Cam
presser foot
cam
JIG pin
Caution ) At this time, check that the cutting
part of presser foot driving cam collar matches
with the cutting part of presser foot driving
cam.
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
5) Set the angle plate to 100 degrees. And then turn
the presser foot driving pin pulley to check that
presser foot reciprocator set smoothly moves up
and down.
Picture 6 6)On the menu of OP Box, select "TOOL"
→ "PF UP/DOWN" in order to up the presser foot.
& the Side Cover
1) Assemble them in reverse of disassembly.
1) Assemble them in reverse of disassembly.
1) Assemble them in reverse of disassembly.
5. Assemble the Arm Protection Plate
6.Assemble the Head
7.Assemble the Top Shaft Cover
Caution ) If the setting of the presser foot
driving cam is bad, the balance of machine is
broken and then the shaking may extremely occur.
So, the correct setting is needed.
