Super Guider JS8-B Assembly instructions

USER’S MANUAL GUIDE
STORAGE ELECTRIC WATER HEATER

6
1
Specification
＊ Please contact customer service if the problem remains. Meanwhile,
turn off the power before turning off water supply.
Problem Solving
No hot water
+
power
indicator
OFF
No electricity Check power supply
Call customer service
Safety switch tripped
Increase temperature
setting
Call customer service
Wrong temperature
setting
Heating element
breakdown
No water
Water outage Check water
supply system
Water outlet blockage Clean regularly by
professionals
Low water pressure
prevents water from
passing the safety valve
Adjust water supply
system pressure
No hot water
+
power
indicator
ON
Vo l tage/ F r e quen c y : 2 20V/ 6 0 H z
Cause
JS8-B
JS12-B
JS15-AE
JS20-AE
JS20-B
JS30-B
JS40-B
JS50-B
60
78
95

34
Water Connection
Connect a safety valve to the cold water inlet.
It is recommended to keep the cold water inlet faucet open at all times.
Note: It is normal if the safety valve drips during heating.
Inlet and outlet connection gauge should be the same.
Inlet water pressure should be under 1kgf/cm². Highly recommended
to install a pressure decreasing valve if it exceeds 3kgf/cm².
Connect a pressure release pipe to a pressure releasing hole on the
safety valve to avoid danger caused by pressure-releasing,
Note: Pressure releasing hole should never be blocked.
Power Connection
The power cord is either black or red. Connect green earth cord correctly.
Note: The blue dot on the inlet pipe indicates cold water inlet whereas
the red dot indicates hot water outlet. Make sure the installation is correct.
Installation
Important Reminder
Install as close to the faucet as possible to prevent heat loss in the pipe.
Ensuring the tripod or wall-mounted hook is tight when installing.
Upon completion of installation, turn on the cold water inlet valve until
water is available via the hot water outlet faucet to ensure the unit is
contained with water, and then turn on the power and press the leakage
circuit breaker to ON. (Required only for the first-time use.)
Installation should be carried out by technical personnel.
Super Guider is not liable for any harm caused by not following the
instructions in this booklet or safety regulations during installation.
Turn off the power before adjustment
Note
After installation, turn on the cold water valve. When the tank is full of
water, loosen the screw and take off the panel after hot water is out from
the pipe. Turn on the leakage circuit breaker to prevent the heater pipe
from failure.
Warranty are excluding any non - complying with the prescribed safety
requirements and Installation which is not in accordance with the manual
instructions.
Warranty is excluding the poor water quality e.g. ground water. Water
purification beforehand could extend the life span of the water heater.
Installation charge will be borne by the user.
★ Indicator light illuminates upon switching on of the
power, stays on while heating.
Temperature adjusted button.
(If overheating prevention deviceReset
Interrupt, THE RED BUTTON should be
pushed first after maintenance, and the
electricity supply will be recovered.
TEMPERATURE CONTROLLER

5
Reminder
All electrical installation should be carried out by a qualified person.
Make sure of the operation of power and water supply before contacting
the distributor.
Electrical Regulation Replacement
Heating element function
Scheduled Maintenance
Overheat Prevention Device
Please switch off the power and take off the terminal of the electrical
regulation and all wires before replacing the electrical regulation.
Ensuring the screw and nut are tightened after replacement and wires
arrangement.
Water (faucet) should be leaked off (switch-off) before replacement of
heating element function. Once installation completes, turn on both
the hot water faucet and cold water faucet then open the clean access.
Heating element function can be taken apart by a wrench.
Ensuring the rubber washer is well fixed preventing the water heater
from leaking before re-arranging the heating element function.
The heating system should be cleaned once two years ensuring the heating
quality which is highly recommended.
Scheduled cleaning the exterior of the water heater to keep intact.
Overheat Prevention Device will automatically interrupt by abnormal
overheating.
Attention: Turn off the power immediately while the power indicator is
not illuminated and contact customer service.
2
Structure
Vertical wall-mounted
Floor-Standing
Cold
water inlet
Cold water inlet
Hot water outlet
Hot
water outlet
Cleaning access
(drain valve)
Cleaning access (drain valve)
Leakage circuit breaker
Leakage circuit breaker
Power indicator
Power indicator
Temperature controller (inside)
Temperature controller (inside)
Heating element (inside)
Heating element (inside)
Safety valve
Safety valve
o
90 bend
Temperature display
Temperature dispaly
