Atmor ThermoPro Series User manual

www.atmorusa.com
Electric Tankless Water Heaters
ThermoPro Series
Models:
AT-910-18TP, AT-910-24TP, AT-910-27TP,
Hot Water on Demand

2
Important Safety Guideline
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
Denitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous
situations and your risk of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may
result in property damage.
WARNING: READ THIS INSTRUCTION MANUAL THOROUGHLY AND COMPLETELY
BEFORE INSTALLATION AND USE. FAILURE TO DO SO COULD CAUSE DAMAGE TO PROPERTY,
SERIOUS INJURY OR DEATH, AND VOID YOUR WARRANTY.
Contact service directly if you have any questions regarding your unit
Monday- Friday, 9AM-5PM EST
Phone: [phone]
Email: [email protected]
WARNING: Cancer and Reproductive Harm –
www.P65Warnings.ca.gov.
AVERTISSEMENT: Cancer et Troubles de l’appareil
reproducteur – www.P65Warnings.ca.gov.
ADVERTENCIA: Cáncer y Daño Reproductivo –
www.P65Warnings.ca.gov.
For California residents / Pour les résidents de la Californie / Para residentes en California

3
Table of Contents
1. Safety Guidelines ------------------------------------------------------------------------------------- 4
2. About Your Atmor Electric Tankless Water Heater ------------------------------------------------ 4
3.Selecting an Installation Location ------------------------------------------------------------------- 5
4. Mounting the Water Heater------------------------------------------------------------------------6-7
5. Plumbing Requirements and Precautions--------------------------------------------------------7-8
6. Plumbing Installation --------------------------------------------------------------------------------- 8
7. Electrical Requirements and Precautions ---------------------------------------------------------- 9
8. Electrical Installation---------------------------------------------------------------------------------10
9. Flow Rate --------------------------------------------------------------------------------------------12
10. Operation Guide ---------------------------------------------------------------------------------12-13
11. Care and Maintenance--------------------------------------------------------------------------13-14
12. User Interface/Controls -------------------------------------------------------------------------14-15
13. Troubleshooting----------------------------------------------------------------------------------16-17
14. Reset Unit --------------------------------------------------------------------------------------------18
Before Installing
By installing this product, you acknowledge the terms of the manufacturer’s warranty and
authorized dealer’s return policy. Once the heater is installed, do not return the product to the
place of purchase. If you have any questions regarding the warranty or the product return policies,
contact us by phone or email.

4
1. Safety Guidelines
Read this manual thoroughly before installing and using the instant water heater. Failure to comply
with the safety, installation or operating instructions will void the product warranty.
The product manufacturer and the product distributor will not be liable for any damages or injury
caused by failure to comply with the installation and operating instructions specied in this manual
or by improper use of the product. For best performance, ensure that this water heater is installed
in accordance with all electrical and plumbing codes applicable to your area, and as specied in
this guide.
This product has more than one power supply connection point. Do not attempt to install, clean,
inspect, disassemble, service or repair the water heater without rst shutting o all the power to
the unit by means of the circuit breakers on the main electrical panel..
WARNING: Failure to adhere to the safety guidelines might result in severe injury or death.
The water heater must be installed in compliance with all national, state, provincial and local
electrical and building regulations. We recommend that you consult a qualied electrician
and a qualied plumber in case you have questions about anything relating to codes for this
product.
This product is intended for household and indoor use only. Do not immerse in water.
Each breaker used to power this unit must be grounded by means of the electrical panel.
The heater must be connected directly to dedicated circuit breakers on the main electrical
panel.
Do not install the heater where it may be subjected to direct sunlight, rain, splashing water,
moisture/humidity or freezing temperatures.
This unit is intended for heating water only. Do not attempt to use the unit for heating any
other kind of liquid.
2. About Your Atmor Electric Tankless Water Heater
Congratulations on your decision to purchase one of the nest instant water heaters currently
available in the market! Your new instant water heater has advanced water ow rate and temperature
sensors that are designed to modulate power to the heating elements to maintain a user-selected
output water temperature range for 18kW/ 24kW/ 27kW: 90°F (30°C) to 122°F (50°C) (subject to
the temperature of the incoming water).
WARNING: When setting the water temperature of the instant water heater, be sure to
consider safety and energy conservation. Prolonged skin exposure to water temperatures above
120°F (49°C) can result in severe burns or death. The maximum temperature setting on this instant
water heater is 122°F (50°C). Always take precaution to feel the water before bathing or showering,
and make sure the temperatures are not too hot. You are required to read and comply with the
following Time/Temperature Relationship chart to determine the right water temperature for your
home.

5
Temperature Exposure Time Resulting in Scalding
120°F (49°C) 5 minutes of exposure
122°F (50°C) 3 minutes of exposure
If you have small children, disabled, or elderly persons in your
home, you may require a setting of 120°F (49°C) or lower to ensure
their safety. Water temperature is regulated by the knob on the front
of the water heater
3. Selecting an Installation Location
• This Water Heater is designed for indoor installation only.
• The heater should not be installed in a location where it might
be subjected to freezing temperatures, since frozen water in
the unit can cause severe and irreversible damage which is
not covered under your warranty.
• The water heater should be placed in a location that is easy to access.
• Ensure that the water heater, as well as the power supplies and water connections, are
out of the reach of children to prevent them tampering with controls or touching an extremely
hot pipe.
• Do not install the unit where it is may be exposed to excessive humidity, moisture or dust, or
where it may be splashed with water or other liquids.
• Do not install the unit below water pipes or air conditioning lines, where it is susceptible to
leaking or dripping water or other liquids.
• Do not install the unit above electrical boxes or junctions.
• If possible, avoid installation in a location that could be damaged due to leakage from the
water heater. Install a drip pan with drainage, or an active leak detector and automatic shuto
valve, to prevent damage in case of a leak.
Item # Unit dimensions (inches) Weight (lbs) Connections
ThermoPro 18 13-3/8 x 17-3/8 x 5-1/4 17 3/4”
ThermoPro 24 13-3/8 x 17-3/8 x 5-1/4 17 3/4”
ThermoPro 27 13-3/8 x 17-3/8 x 5-1/4 17 3/4”
WARNING: Water heater are heat-producing appliances. To avoid damage, injury or death,
the water heater must be installed in a manner that prevents contact with any substances
or materials, and proper care must be taken to prevent unnecessary contact (especially
by children) with the water heater. UNDER NO CIRCUMSTANCES SHOULD FLAMMABLE
MATERIALS, SUCH AS GASOLINE OR PAINT THINNER, BE USED OR STORED IN THE
VICINITY OF THIS WATER HEATER OR ANY LOCATION FROM WHICH FUMES COULD
REACH THE WATER HEATER.
•Children,disabledand
elderlyareathighriskof
beingscalded.
•Seeinstructionmanual
beforesettingyourdesired
hotwatertemperature
•Alwaysfeelwaterbefore
bathingorshowering

6
118
º
F
4. Mounting Your Water Heater
1. The instant water heater must be secured to solid mounting surface with four screws
(minimum 1” (25.4mm) long).
2. Make sure the unit is level before fastening the screws.
3. The unit must be installed in an upright position with the water inlet and outlet at the bottom
of the unit. Do not install with connections on top or the sides.
4. Do not install the unit above electrical boxes or junctions.
5. The water heater must be installed in a manner that prevents contact with ammable materials.
Keep ammable material at least two feet away from the heater and the hot water outlet pipe.
The water heater and the hot water outlet pipe must be secured, and out of children’s reach
to prevent tampering with controls or contact with an extremely hot pipe.
6. If installing the heater on an upper oor or attic, make sure installation complies with the local
codes. Install a drip pan with drainage, or a leak detector and automatic shuto valve, to
prevent damage in case of any leakage.
7. Unscrew the 4 cover screws, and remove the unit cover. (Figure 1)
8. Disconnect the cables from the PCB within the unit.(Figure 2)
9. Use 4 mounting screws that are at least 1 inch (25.4mm) in length, mount the unit on the
wall. (Figure 3)
10. Make sure the unit is leveled horizontally, with water inlet and outlet at the bottom (Figure 4)
Fig. 1 Fig. 2 Fig. 3
Fig. 4
Do not install upside down
or on its side
Fig. 5
118
º
F
Water
Filter

7
Recommended clearances: 12” (304.8mm) above and below the heater 6” (152.4mm) in front of
and to the sides of the heater
CAUTION: Keep any ammable materials at least 24” (609.6mm) away from the water heater
and hot water outlet pipe.
5. Plumbing Requirements and Precautions
• Follow all plumbing instructions carefully. This product must be installed in accordance with all
national, state, provincial, and local plumbing codes. Prior to installation, it is recommended
that you consult your municipality or a qualied plumber if you have questions relating to
plumbing codes for your area.
• The plumbing installation must be completed before the electrical installation.
• Do not solder any pipe with the unit connected to the pipe. The heat from soldering may
cause damage to the ow sensor. Doing so will void the warranty.
• The use of a temperature pressure relief valve (T&P) is not required for
most installations because the tankless water heater does not use a
storage tank. UL Standard 499 does not require the use of pressure
relief valve, although it may be needed to meet installation codes in
your area. In such cases, the pressure relief valve should be installed
in accordance with local codes. It is important to ensure that the unit
is operating correctly, and that air is purged from the valve prior to
installing the water heater.
• A T&P valve is recommended for added safety when connecting to
plumbing rated metal, ex or high-temperature CPVC piping.
NOTE: A pressure relief valve is required for installations in the Commonwealth of
Massachusetts and State of Kentucky. Check your local installation codes for any
special requirements.
• The plumbing installation requires piping that can withstand pressure up to 8 bar.
• The maximum operating water pressure for this unit is 10 bar (150 psi). Residential plumbing
systems with unstable pressure or pressure above 5 bar require the application of a pressure
reduction valve set to 4-5 bar for optimal performance.
• The water supply ow rate must be at least 0.5 gallons per minute (gpm) to ensure proper
operation.
• Flexible water hoses are recommended for use with your water heater. When connecting the
inlet water pipe to the unit, use a wrench to hold the unit’s connection, and another wrench
to tighten so that the ow sensor on the unit will not be loosened or damaged. Do not over-
tighten the water inlet and outlet connections to prevent severe internal damage to the water
heater.
Fig. 7
Do not solder any
piping to the unit’s
Connection points

8
• It is recommended to install a manual shut-o valve (ball valve) on the inlet and outlet of
the water heater to create a convenient shut-o point if future maintenance or servicing is
required.
• Before connecting the pipes to the water heater, it is crucial to ush the lines to eliminate all
the plumbing paste or residue in the lines caused by any welding or soldering.
• It is recommended that all water pipes within 3 feet (1 meter) of the inlet and outlet connections
be rated for high-temperature applications with 150°F (66°C) minimum.
• Before proceeding to the electrical installation, run water through the unit for several minutes
to ush out any air bubbles from the water line..
6. Plumbing Installation
STEP 1: Thoroughly ush the cold water supply line of all debris.
STEP 2: Connect the hot water line to the water heater outlet. The water heater outlet is on the
left side of the heater when facing the unit. Connect the cold water line to the water heater inlet,
which is on the right side when facing the unit.
* Pre-hetead water can be connected to the cold water inlet, where this unit will act as booster.
STEP 3: After tightening both ttings on the water heater, turn on several hot water faucets to
allow water to ow through the water heater for at least 2 to 3 minutes. This process purges all the
air from the water lines and must be performed before turning on the power at the unit.
FAILURE TO PERFORM THIS STEP COULD CAUSE PERMANENT DAMAGE TO THE
HEATING ELEMENTS. (The power to the heater should be turned o and the air purged out of the
lines before turning the power on anytime maintenance is performed on the water heater or the
homes plumbing system, as air might have been introduced into the plumbing pipes.)
STEP 4: Carefully inspect all connections, units, and the pressure relief device for leaks after the
plumbing installation is completed. If there are no leaks present, you can proceed to the electrical
installation.
CAUTION: If you detect a water leak from the water heater at this point, turn o the water
supply at the shut o valve on the unit’s incoming water supply and contact service at
1-888-783-6082.
Plumbing Specications
Minimum water ow to activate the unit 0.5 gpm
Working pressure 0.5–10 bar (7–145 psi)
Tested pressure (maximum) 20 bar (290 psi)
Water connections 3/4” NPT

9
7. Electrical Requirements and Precautions
Manufacturer recommends that this product be installed in accordance with all applicable national,
state, provincial, and local electrical codes. Consult a qualied and licensed electrician if you have
questions or are unsure about anything relating to codes for this product. The heater must be
connected to a dedicated circuit breaker on the main electrical panel.
WARNING: As with all electrical appliances, it’s crucial to rst shut o all power to the unit
directly at the fuse or breaker box before attempting to install, repair or disassemble this
water heater. Ensure that the breaker is shut o. SERIOUS BODILY INJURY OR DEATH
COULD OCCUR IF YOU IGNORE THIS WARNING.
CAUTION: All wiring (wire gauge), as well as circuit protection (breaker), must comply with
the U.S. National Electrical Code (NEC) in the USA or the Canadian Electrical Code (CEC)
in Canada. Failure to do so could lead to property damage, personal injury, and void your
warranty.
Note: The Canadian Electrical Code generally requires that all supply wires and corresponding
circuit protection used for domestic hot water heating and hydronic heating applications be
sized to a minimum of 125% of the maximum current rating of the heater (check heater
specication details below)
Before installing this tankless water heater, ensure that sucient electrical power is available
in the home to handle the maximum amperage load of the applicable heater.
IMPORTANT NOTES:
18kW 24kW and 27kW heater requires 3 set of wire and ground (see wiring diagram on page 11)
• Please see electrical specications by heater input and wiring diagram on the page 11 for
additional electrical information.

10
8. Electrical Installation
STEP 1: Take the wire pair and connect to the breaker. Be sure that the breaker is connected
to one black wire and one red wire. Be sure the power to the unit is shut o using the dedicated
circuit breakers in the main electrical panel.
STEP 2: Run the correct set of power cable wires from the circuit breaker in the main electrical
panel to the water heater by utilizing a suitable wire gauge which meets all applicable electrical
codes for the size of the breaker. Then, connect the power cable to the block terminal within the
water heater.
STEP 3: Each incoming circuit requires a separate ground conductor.
STEP 4: DOUBLE CHECK The electrical connections and ensure the wire connections are
correct, tight and secure. It’s important to conrm that the right breaker size and wire gauge has
been used and that the unit has been connected to a ground in accordance with applicable codes.
Be sure to reattach the front cover of the unit with four screws.
STEP 5: Ensure that all the air has been purged from the water lines before turning on power to
the unit. Refer to STEP 3 in plumbing installation section. Restore power to the unit through the
dedicated circuit breaker in the main electrical panel.
It is crucial to follow the wire connection as shown and ensure all connections are made
correctly for proper operation of the unit. The unit will not operate correctly if you mix up the
wire sets, even though it turns on and otherwise appears to function.

11
Electrical Specications by Heater Input
Item # kW Max
Amps Required Breaker Req. Wire Size
AT-910-18TP 18 75 A 3 x 30A double Pole 3 x 8 AWG with ground
AT-910-24TP 24 100 A 3 x 40A double Pole 3 x 8 AWG with ground
AT-910-27TP 27 112.5 A 3 x 40A double Pole 3 x 8 AWG with ground
Power Rates
Item # 240V 220V 208V
AT-910-18TP 18,000 Watts 150,125 Watts 13,520 Watts
AT-910-24TP 24,000 Watts 20,166 Watts 18,026 Watts
AT-910-27TP 27,000 Watts 22,687 Watts 20,280 Watts
Your tankless water heater is now installed and ready to use! Follow the General Operating
Instructions to complete the setup.
Wiring Diagram for AT-910-18TP, AT-910-24TP, AT-910-27TP,
Terminal Block in Unit
Circuit Breakers
Unit Requires 10 AWG ground wire - one for each 240V circuit
L1L1L1 L2
8/2 AWG
8/2 AWG
8/2 AWG
L2L2
240V 240V 240V
L1 L2 L1 L2 L1 L2

12
9. Flow Rate
The chart below indicates maximum temperature rise for a given ow rate
INLET GROUND WATER TEMP
Item # kW 30°F 40°F 50°F 60°F 70°F
AT-910-18TP 18 4.1 GPM 3.06 GPM 3.52 2.04 GPM 1.75 GPM
AT-910-24TP 24 5.2 GPM 3.95 GPM 3.52 GPM 3.3 GPM 2.4 GPM
AT-910-27TP 27 5.4 GPM 4.15 GPM 3.65 GPM 3.4 GPM 2.7 GPM
Based on 105°F Output Water Temp
GPM = Gallon Per Minute
10. Operation Guide
Operating your new tankless water heater is like using any traditional water heating system. However,
it is essential that you carefully read all setup procedures and operating instructions to ensure the
maximum performance and energy savings from your new water heater. It is recommended that
all members of your household read these operating Instructions.
This electric water heater is designed to supply hot water. The unit’s internal heating elements are
capable of heating water quickly on-demand for as long as you need it. Unlike a conventional tank
storage water heater, this unit is a tankless water heater that does not store hot water. However,
once you begin using the system, you will understand it works like a conventional tank system.
Tankless system delivers hot water instantaneously on demand. Since a tankless system does not
waste energy continually when heating water, that is, idly sitting and losing heat in a storage tank,
it provides signicant energy savings than a conventional water heater.
With your new system, as soon as you turn on the hot water faucet, the demand for hot water is
detected by a ow sensor, and the high-power heating elements are activated. Sensors continually
monitor the water ow rate and measure the incoming and outgoing water temperature. Data is
transmitted to the system logic controls, which determine the exact amount of power required by
heating elements to heat the water to your desired temperature.
It is essential to keep in mind that all tankless water heaters are subject to a maximum ow rate. If
this ow rate is exceeded, the heater will not be capable of suciently heating water.
Also keep in mind that conventional tank heaters are set to high temperatures to prevent running
out of hot water quickly, and thus a large amount of cold water needs to be mixed in to reach a
comfortable level for washing and showering. Since this unit heats water on demand, it is designed
to heat to a lower temperature. This means you only need to mix in a small amount of cold water
or none at all.
Your hot water supply may also be aected by the incoming water temperature as the seasons
change. During winter, if incoming water temperature is very cold, you might not be able to run
multiple hot water outlets at the same time, as in the summer. However, you can run showers
back-to-back without having to wait for water to heat.

13
Water Quality: The quality of water must be taken into consideration when installing and
maintaining the water heater. Water conditions that do not comply with the recommended levels
can damage the water heater. Atmor reserves the right to deny any warranty claim for damage
resulting from water conditions that deviate from the levels specied in the table below.
To prevent damage to the heat exchanger and heating elements, the water must be treated, and
the heater must be ushed regularly when this unit is installed in a location known to have hard
water that causes scale build-up. Atmor recommends the installation of a water treatment device
or water softener to maintain optimal performance of the water heater in hard water areas.
Recommended Water Quality levels
pH Total
Dissolved
Solid (TDS)
Free
CO2 Total Hardness Aluminum Chloride Copper Iron Manganese Zinc
6.5
-
8.5
Up to
500
mg/L
Up to
500
mg/L
Up to
200
mg/L
Up to
0.2
mg/L
Up to
250
mg/L
Up to
1.0
mg/L
Up to
0.3
mg/L
Up to
0.05
mg/L
Up
to 5
mg/L
11. Care and Maintenance
To ensure maximum performance of your water heater and to reduce the risk of a water leak, the
following maintenance is recommended:
• The water heater has minimal maintenance requirements. Periodically inspect and test the
heater for signs of damage or failure. Any damage, cracks, leakage or weakness should be
addressed and xed immediately. Do not over tighten any of the connections. Over tightening
the connection points could cause severe internal damage to the unit.
• Remember that water heated at higher temperatures produces scale buildup much faster
than at lower temperatures. Plumbing connections on the water heater should be inspected
at least once a year for any signs of damage or failure. If the water supply has a high level
of mineralization (hard water), the water heater should be inspected and descaled more
frequently. Installing a manual shut-o on the inlet and outlet of the water heater will allow
access for ushing the unit with a descaling solution.
• Clean the lter on the water inlet pipe once every six months. Wash lightly to remove any
debris..
When any form of maintenance is carried out on the water heater or the home’s plumbing system
that may introduce air into the plumbing, it is crucial to power o the water heater and purge the
air from all pipes before allowing the unit to power up.
FAILURE TO DO SO COULD RESULT IN PERMANENT DAMAGE TO THE HEATING ELEMENT
AND VOID YOUR WARRANTY.

14
When air is introduced into the plumbing system, follow the steps below to ensure the unit can
safely resume operation.
1. Shut o all power to the unit at the circuit breaker on the main electrical panel.
2. Perform the maintenance or servicing tasks.
3. Open one or more hot water faucets and allow water to run through the unit for several
minutes to purge any air from the heater and water lines
This step must be performed before turning on power to the heater. Failure to complete
this step may cause permanent damage to the heating elements.
4. Reconnect power to the unit at the circuit breaker on the main electrical panel.
5. With water running through the unit, check the temperature and adjust by turning the knob.
The recommended temperature setting is 118°F (48°C).
12. User Interface/Controls
Power
• Turn the knob to the right (clockwise) to activate the heater.
The display will light up.
• Turn the knob all the way to the left (counterclockwise) to turn
o the heater.
Setting the Output Water Temperature
• To set the temperature, turn on a hot water faucet and allow
water to run through the heater. Turn the knob clockwise to
activate the heater and display the outlet temperature.
• To raise the temperature setting, turn the knob clockwise. To lower the temperature, turn the
know counterclockwise.
• The temperature can be set to a level from 90°F to 122°F (30°C to 50°C).
• A comfortable temperature for bathing and showering is between 98°F and 105°F (37°C to
41°C).
• The recommended temperature setting is 118°F (48°C), which will deliver hot water for all
household needs at a maximum water ow rate.
CAUTION: A higher temperature setting is not recommended, as it can cause severe
scalding injuries to children and elderly persons. Higher temperatures also produce more
scale buildup in water heating devices.
115
º
F
Lower
temperature Raise temperature

15
Starting the system for the rst time
1. With the water running through the unit, turn the temperature knob clockwise to activate the
heater.
2. Turn the knob to adjust the temperature.The recommended temperature setting is 118°F
(48°C).
Freezing Temperatures
If the ambient temperature falls below 32°F (0°C), protect the heater from potential damage. Power
o the unit using the dedicated circuit breaker on the main electrical panel. Open a faucet slightly
to cause water to ow continuously through the device at a very low rate, without heating. Restore
power to the unit when temperature condition is normal.
If the water inside the heater freezes, it can cause damage that is not covered by warranty. If
you suspect water has frozen within the unit, do not turn it on until you are sure the frozen water
has melted, and there are no leaks in the unit. It is recommended to contact a qualied electrician
or the manufacturer for service in this situation.
A. Temperature setting knob
B. Digital temperature display
C. Hot water outlet
(to be connected to the main hot water pipe)
D. Cold water inlet
(to be connected to the main cold water pipe)
118
º
F
BA
CD

16
13. Troubleshooting
Before calling for service, check the troubleshooting list of common issues.
If you are unable to resolve a problem, contact your locally authorized distributor.
PROBLEM
ISSUE
POSSIBLE CAUSE SOLUTION
No hot
water and
display do
NOT light up
Power outage or
faulty wiring.
Check the power supply. Check the circuit breakers.
Make sure the breakers at main electrical panel are ON.
You may have a faulty breaker or unit may be wired
incorrectly.
Make sure the shuto valve on the unit’s incoming water
supply line is fully open.
The ow rate needed
to activate the heating
element (0.5 gpm) has
not been reached.
Increase the ow rate from the water supply source.
Clean the lter screen on the unit’s water inlet.
No hot
water and
display
DOES light
up
Reset the unit Refer to manual (Page 18) for diagram of reset points.
Make sure to shut all power on your breaker panel
before attempting to reset unit. All resets must be
pressed.
Potential internal part
failure
Please call us for further technical assistance.
Water is
heated,
but not hot
enough.
The water ow rate
exceeds the heating
capacity of the heater.
Reduce the water ow rate at the faucet or slightly close
the shuto valve on the unit’s incoming water supply line
to reduce the water ow rate.
Voltage less than 240
Volts
The heating elements on your water heater are designed
for 240 volts. When used with a lower voltage, they
produce less heating power. You may need to upgrade
to a larger input heater.
Crossed Wires. If it’s a new installation, double check the wiring to
conrm that it is correct.
Temperature setting is
too low.
Increase the temperature setting on the unit.
Water pressure is less
than 0.5 bar (7 psi).
Make sure the shuto valve is fully open, and the water
supply line is not blocked.
Mixing too much cold
water
You do not need to mix as much cold water with your
tankless water heater compared to when you use a
conventional water heater. You may also have an anti-
scald feature on your faucet that is mixing cold water.
These types of faucets can usually be adjusted to reduce
the amount of cold water mixed.
Thermal loss due to
long pipe run.
As the hot water from the heater runs through the hot
water delivery system to your faucet, some heat will be
lost especially if it has long distance to travel or the pipes
are cold. This is normal. You can compensate for this by
increasing the setting on your water heater if you need/
want hotter water.

17
Water is
heated,
but not hot
enough.
Voltage less than 240
Volts
The computer chips in your tankless water heater are
programmed with the expectation that your incoming line
voltage is 240 volts. If you have less than 240 volts [i.e.
208V or 220V], it may aect the reading on your water
heater’s digital display and cause it to read slightly higher
than the actual output temperature. To compensate
for this, increase the setting on your water heater if you
need or want hotter water.
Water is too
hot.
The water ow rate
through the heater is
too slow.
Increase the ow rate at the water outlet.
Temperature setting is
too high
Switch to a lower temperature setting.
Water Temperature at
faucet is too hot.
Check for too little ow, or if the set point temperature is
too high. This could possibly indicate a possible internal
part failure. Call us for technical assistance.
Heater
shuts o
during use.
Power outage or
faulty wiring.
Check the power supply. Check the circuit breakers.
If the problem persists, please call us for further technical
assistance.
Water stops
owing.
Possible Blockage in
water pipes or hoses.
Make sure the main water line valve is fully open, and
there are no obstructions in the water supply line.
Water
temperature
varies from
hot to cold
during use.
Water pressure has
dropped below a
minimum level.
Increase the ow rate from the water supply source.

18
14. Reset Unit
As with all electrical appliances, it is crucial to rst shut o all power to the unit directly at the fuse
or breaker box before attempting to reset this water heater.
WARNING: SERIOUS BODILY INJURY OR DEATH COULD OCCUR IF YOU IGNORE THIS
WARNING.
Locate the three reset button locations as shown below and press all buttons. If you hear a “click,”
the unit has reset. If you nd that the unit needs to be reset quite often, please call our customer
service for further assistance. Proceed to turn on your breakers and power on the unit.

19
LIMITED WARRANTY
For service, repair or any questions regarding your water heater, call the appropriate 800 number
listed within this section. Please DO NOT return the product to the place of purchase. Also, DO
NOT mail the product back to the manufacturer, nor bring it to a service center without proper
instructions and permission from one of our representatives.
The terms of this warranty are solely subject to the original owner and are at no time transferable. A
transfer of ownership will result in immediate termination of this warranty. This warranty is valid only
if the product is purchased from an authorized reseller that has an established direct relationship
with the manufacturer.
The manufacturer warrants to the original owner that our instant water heaters will be free from
defect in workmanship and material for TWO YEARS from the date of purchase, and free from
leakage for SEVEN YEARS from the date of purchase. Should any part(s) prove to be defective
during this period, the manufacturer will only be responsible for a replacement water heater or
replacement of the defective part(s). The manufacturer is not responsible for labor charges or any
incidental or consequential expenses. If a replacement water heater or part is not available, the
manufacturer’s liability is limited to the cost of the water heater or $1,000.00, whichever is less.
The manufacturer is not an insurer, and the original owner should purchase insurance to cover
damage to property or belongings. The original owner agrees to waive their right to jury trial or to
participate in a class action. Also, the original owner agrees to waive subordination to the extent a
loss is covered by insurance, so that their insurance company cannot proceed with action against
the manufacturer for recovery of any claims. Furthermore, all requests must be arbitrated in the
state of New Jersey.
Should the owner wish to return the water heater for repair, the owner must rst secure written
authorization from the manufacturer. The owner shall be required to show proof of purchase date
and to pay all transportation costs to return the defective part(s) or water heater for repair or
replacement. Warranty is void if: (i) water heater has been installed or used improperly; (ii) design
has been altered in any way; (iii) water heater has been installed and/or serviced by someone other
than a licensed electrician; (iv) or if the water heater has been installed or used in contradiction to
installation instructions, applicable laws and/or ordinances.
Phone: [phone]
Email: [email protected]
Web: www.atmorusa.com
Imported by:
PARAGON GROUP USA LLC
Englewood, NJ 07631
USA

Notes:
P.N. 196183J
