Super Handy GUO110 User manual
Operator's Manual
REV 1.0
Stump Grinder
WARNING:
Carefully review and understand all INSTRUCTIONS prior to operating this device. Failure to follow
the safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe place and accessible so that they can be reviewed as required. Keep these
instructions to assist in future servicing needs.
The stump grinder is designed solely for outdoor operations and is capable of eliminating tree
stumps and protruding root systems down to near ground level. By horizontally swaying the
wheel across the stump's top and front, you can incrementally remove it. Before you start using
the grinder, thoroughly read and understand the entire manual. Neglecting to operate or
maintain the machine correctly could lead to severe injuries or even fatalities for both the
operator and onlookers. Every machine carries inherent risks, and this stump grinder has its
own specific dangers that you must be conscious of. If you own or operate this machine, it's
your responsibility to be aware of these risks and how to mitigate them. Pay extra attention to
these specific hazards in the manual.
Specifically, pay close attention to these key points:
●Know the positions of subterranean services such as power cables before starting.
●Only allow trained individuals to handle the equipment; keep untrained adults and children
away.
●Wear appropriate eye gear and protective clothing to shield yourself from projectiles like
stones and fragments.
●Ensure the grinder's blades are intact, well-sharpened, and firmly secured.
●Do not operate the grinder if disengaging the safety bar fails to shut off the engine.
●Maintain a safe distance of no less than 75 feet between the grinding operation and
onlookers or children.
●Put protective barriers around cars, windows, and other valuables within a 75-foot radius to
guard against flying particles.
●Be prepared for any sudden recoil from the machine when it first contacts the stump.
●Remain vigilant about the potential for carbon monoxide exposure.
●Exercise caution during fueling to avert fire or explosion risks.
●Do not attempt to make adjustments, clear jams, or clean the equipment when the engine is
active.
●Avoid contact with the engine and exhaust to prevent burn injuries.
●Refrain from using the machine in conditions where slipping is likely, including wet or icy
surfaces.
SAFETY SYMBOLS
Please study the following symbols and learn their meanings. Proper interpretation of these
symbols will help you to operate the product in a safe and responsible manner.
1EN
Read these instructions
carefully. No smoking,sparks,or flames.
Wear eye protection.
Wear hearing protection.
Do not touch parts that are hot from
operation. Serious burns may result.
Wear protective gloves. Keep your feets clear from all
rotating parts.
Wear safety footwear. Be aware, objects may be thrown
whilein use.
Do not remove or tamper with the
protection and safety devices.
Keep children and bystanders off
and away.
TECHNICAL SPECIFICATIONS
MAIN COMPONENTS
EN 2
SKU#
Engine Displacement
Start Type
Transmission
Wheel
Cutter Disc Size
Rotation Speed
Grinding Depth
GUO110
274CC
Recoil
belt drive
10"
13.5"
3600 RPM
12"
Fig. 1
Handle bar x 1pc
5
Equipment main body x 1pc
4
Handle connecting rod x 1pc
1
Axle x 1pc
8
Wheel x 2pcs
11
M6*60 bolt x 2pcs
6
M8 nut x 6pcs
3
Flat washer x 3pcs
9
M6 nut x 2pcs
7
Split pin x 3pcs
10
M8*45 bolt x 6pcs
2
ASSEMBLY
1. Handle Bar (Fig. 2)
(1) Remove the two mounting bolts (2)
from the handle connecting rod (1).
After lifting the front end of the
equipment, the handle connection
can be removed.
(2) Place the handle connecting rod (1)
onto the main body of the equipment
(4). Use 4 M8x45 bolts (2) and 4
M8 nuts (3) for installation (insert
the nuts from the bottom of the
equipment main body). (Fig. 3)
(3) Insert the handle bar (5) into the
handle connecting rod (1) and
secure using 4 M8x45 bolts (2)
and 4 M8 nuts (3). (Fig. 4)
EN3
2
B
1
5
1
2
3
Fig. 2
Fig. 3
Fig. 4
4
1
2
3
(4) Using 2 M6x60 bolts (6) and 2 M6 nuts (7), install the clutch handle (C) onto the handle bar
(5) as shown in the illustration. (Fig. 5)
2. Wheel
(1) Insert the wheel axle (8) completely
through the equipment's left-side
mounting hole (H) as shown in
the illustration. Secure it on the
right side using 1 cotter pin (9)
and 1 flat washer (10).
(Fig. 6 & Fig. 7)
EN 4
Fig. 5
Fig. 7
Fig. 6
6 C 5 7
10 9
8
H
(2) Attach the 2 wheels (11) to both ends
of the wheel axle (8). Secure them
using 2 cotter pins (10) and 2 flat
washers (9).
Note: After installation, ensure the
wheel inflation valve (V) is on the
outer side of the wheel; do not
install the wheels in reverse.
(Fig. 8)
OPERATION
CAUTION: Add engine crankcase oil.
A new engine is shipped without oil.
You must add the correct amount of
oil to engine crankcase or engine
will be damaged beyond repair.
Before starting the engine you must
make sure you have completed the
following:
1. Clearing Area of People and Objects
2. Marking Underground Utilities
3. Wearing Personal Protection
4. Checking/Adding Oil
5. Filling Stump Grinder Gasoline Tank
6. Inspecting Fuel System for Leaks
7. Checking Controls
Notice: make sure the handle clutch
controller is in the released position.
(Fig. 9)
1. Start the engine. (Fig. 10)
When starting the engine, you must
squeeze the operator presence handle.
During operation, you need to continue
squeezing the operator presence
handle. Once you release operator
presence handle the engine will stop
working.
Notice: The operator presence
handle is not a throttle lever, the
throttle control needs to be
adjusted on the engine.
Note: For more information on
engine operations, please refer
EN5
10
9
811 V
Fig. 8
Fig. 9
Fig. 10
Operator
Presence
Handle
2. Pull the clutch tight
After starting the engine, pull the
handle clutch controller tightly to
make the cutter disc rotate.
Now you can start working.
(Fig. 11)
WARNING: When the equipment
is operating, do not stand directly
in front of the cutter disc to avoid
injury from flying wood chips.
(Fig. 12)
EN 6
Fig. 11
Fig. 12
MAINTENANCE AND STORAGE
WANRING: Read and follow these safety rules whenever you will be servicing the
grinder:
• Turn off grinder. Always turn off grinder and make sure the engine is cool before
working on the engine or grinder.
• Repair. Major service, including the installation or replacement of parts, should be
performed only by a qualified electrical service technician.
• Replacement parts. If a part needs replacement, only use factory approved repair parts.
Replacement parts that do not meet specifications may result in a safety hazard or
poor operation of the grinder and will void the warranty.
EN7
Perform engine maintenance
Cutter teeth replacement
Belt tension replacement
Perform engine maintenance as specified in the engine
owner's manual. Follow your engine manual for further
information.
Remove the installation bolts (M8x35) and
nuts (M8) for the blade to replace it. Please
note: When installing a new blade, make
sure to fully insert the new blade into the
groove of the blade disc before tightening
it with the installation bolts and nuts. Pay
attention to differentiate between the left
and right blades.
1. Remove the four fixing bolts (M6x12) from the belt
cover, and then remove the belt cover.
MAINTENANCE
M6x12 Bolt
M6x12 Bolt
EN 8
Belt tension replacement
Lubricate
2. Adjust the handle clutch controller to a release
state; you can then begin to replace the belt.
(Note: You can loosen three belt fasteners,
which will make replacing the belt easier.)
Cutter shaft bearings should be greased. The cutter
shaft bearing is greased by pumping grease into
zerks located on the housing of the bearing.
The wheels should be greased by repacking the
bearings inside the wheel hub with grease.
MAINTENANCE
Release state
Belt
Fasteners
STORAGE
When you are finished using the grinder and it has cooled, you must:
●Cool engine before storage.
●Clean the grinder.
●Inspect for worn or damaged parts.
●Choose covered storage location.
●Prevent accidental starting.
●Plan on exercising the engine at least monthly unless the grinder is prepared for
long-term storage.
TROUBLE SHOOTING
Note: Follow your engine manual for further engine troubleshooting.
WARRANTY
The product comes with a 1-year warranty for residential use. For commercial use, the
warranty period is limited to 90 days. Warranty period starts from the product purchase date.
Warranty covers material quality and workmanship only. Warranty does not cover product for
issues caused by improper usage or any operation not in accordance with the specifications of
this manual. Any modification or tampering with the product in any way voids the warranty.
EN9
Problem Possible Solution
Engine won’t start
Unit vibrates
Belt coming off.
Belt engages late or slips.
Belt not staying tight after
adjustment
The cutting wheel does
not rotate.
1. Make sure you squeeze the Operator presence handle.
2. Check Engine oil level
3. Check Gas level
4. Follow your engine manual for further trouble shooting.
1. Check your cutters for missing or loose teeth
2. Check your cutter wheel pillar rear mounting bolts
1. Pulleys not aligned.
2. Belt tension is insufficient. Adjust belt tension.
1. Reduce cutting depth.
1. Check for damage on the axle and pulley. Make sure
that the setscrews are properly tightened.
2. Replace damaged parts.
1. Belt tension is insufficient. Adjust belt tension.
2. Clutch is worn - replace shoes and springs,
and/or clutch bearings.
EXPLODED AND PARTS LIST
EN 10
No.
1
2
3
4
5
6
7
8
9
10
11
No.
12
13
14
15
16
17
18
19
20
21
22
Description
Equipment main body
Handle connecting rod
Bolt M8x45
Nut M8
Bolt M6x60
Handle clutch controller
Nut M6
Handle assembly
Cotter pin
Ф20 flat washer
Wheel
Description
Wheel axle
Bolt M12x40
Ф12 standard elastic washer
Ф 12flat washer
Bolt M8x35
Middle blade
Right blade
Left blade
Cutter disc assembly
Nut M12
Vertical bearing seat
Qty.
1
1
6
18
2
1
2
1
3
3
2
Qty.
1
4
4
4
12
6
3
3
1
4
2
Great Circle USA
Support Line: 1-866-493-0524
www.superhandyus.com
Size: 145x210mm REV 09/07/23 3020516157克双铜
