Super Talent Technology VIDEGO28 User manual

Table of Contents
Major Functions……………………………………………………………………02
Description of Buttons/Interfaces……………………………………………………..03
Description of Display Screen………………………………………………………04
Basic Operation………………………………………………………………………07
Master Interface………………………………………………………………………09
Music Mode…………………………………………………………………………10
Video Playing………………………………………………………………………12
FM Radio……………………………………………………………………………14
Picture Browse………………………………………………………………………17
E-book………………………………………………………………………………19
Recording……………………………………………………………………………22
Resource Manager……………………………………………………………………23
Games………………………………………………………………………………...24
System Setup…………………………………………………………………………25
Video Conversion……………………………………………………………………34
Firmware Upgrade…………………………………………………………………36
Troubleshooting……………………………………………………………………38
1

2
Major Functions
·Brand new touch screen operating system, with enhanced display and convenient
operation
·320x240 dot matrix 260K-color (full color) high speed TFT display screen
·Supports MP3, WMA and WAV music formats
·Supports MPEG-4 (AVI) video format
·FM radio with 20 preset channels
·Supports picture browsing in JPEG, GIF and BMPformats
·Built-in microphone and extra long time recording
·Energy efficient setup, with automatic power off
·Multiple EQ and cycle options
·Supports multiple foreign languages
·Supports WIN98S/ME, WIN2000 and WINXP systems
·USB2.0 high-speed transmission
·Supports e-book reading
·Supports game functions
·Mobile hard disk functions
·Upgradable firmware

3

01：Play mode
02：Loop mode
03：Play/pause state
04：Powerdisplay
05：Current music/total music
06：EQ
07：Bit rate
08：Song name
09：Lyrics
10：Progress bar
11：ElapsedSongTime
12：Volume
13：Song Remaining Time
4

01：Power display
02：Manual search mode
03：Preset radio channel mode
04：Save radio channels
05：Delete radio channels
06：Automatic search mode
07：Radio frequency
08：Receiving area
09：Frequency progress bar
10：Receiving area frequency range
11：Volume
5

01：Power display
02：Recorded file name
03：Recording time
04：Recording progress bar
05：Recording quality
06：Remaining time for recording
6

Basic Operation
Power on
Push the power switch of the player towards for 3 seconds to power on.
Power off
While power is on, push the power switch of the player towards for 3 seconds to
power off.
Lock button on/off
In video, music and radio modes, you can set the lock button to ON to prevent
unintended button actions.
Button lock: Push the switch button of the player towards , and the buttons of the
player will be locked with no response.
Button lock: Push the switch button of the player to the original position to unlock and
restore button operation.
Volume Control
In music, FM radio and video, etc, modes you can adjust the volume using + or – buttons
at the lower part of the screen. Hold Button + or Button – to continuously increase or
reduce volume.
Switching the earphone/built-in speaker output
In the button menu, short press button to switch the sound output between the
earphone and built-in speaker.
Power reset
If the player shuts down while operating, you can turn off and restart the player by
pressing RESET button.
Connecting the computer and data file transmission
Start the computer and then connect the unit with the USB port of the computer using the
connection line. The USB cable connection is required for battery recharge and for data
transmission. This unit and the computer can be connected using the USB interface, and
can be used as a mobile disk. You can easily drag and drop your favorite music into the
player with no format conversion.
7

8
Battery
This unit uses a high capacity lithium battery. The duration of battery power depends on
volume and the amount of time the display is on. Use power saving modes [user define
power off time] or [display setup] to extend battery life.
Charging
To recharge the battery, connect the player with the computer USB port or the USB
charger. If the USB charger is used, the indicator of the charger during charging is red.
The battery is fully charged when the indicator of the charger turns green.
Using a MINI SD card
After this unit is connected with the computer, you will find two mobile disks. The first is
the built-in memory storage for this unit and the other is the MINI SD card. If no card is
inserted, the second disk cannot be opened. This unit supports MINI SD cards from
128MB to 4GB.
Inserting and Removing the MINI SD card
Inserting: Put the MINI SD card face up (side with words) (with the direction of the
display screen as the face), and gently press the card into the socket in the unit. Now you
can play the content in the MINI card.
Removing: Gently push the MINI SD card and it will eject slightly, then you can take it
out.
Caution: To prevent damage to music files on the card and in the unit, please ensure that
power is OFF when inserting or removing the MINI SD card!

Main Interface
MP4 provides an intuitive icon based touch screen operating system, which makes
navigation a breeze. In the main menu, click on the icons to access the different
functions.
After accessing the corresponding function mode, gently press the touch screen. You can
see a menu window.
Wait a short time or press at the upper part of the screen to close the menu window.
Press M button at the lower part of the screen or press at the bottom of the touch
screen to return directly to the main menu.
Long press M button at the lower part of the screen or in the control menu at the
upper part of the screen to return to the main menu.
Music mode
In the main menu, click on “Music” function icon on the touch screen to access the
“Music” function interface.
1. Description of playing interface
9

After accessing the “Music” function mode, gently touch the screen to see the “Menu
Window”.
Touch the “ ” at the upper part of the “screen menu”, and the “Menu Window” will
disappear.
Press “M” button at the upper part of the screen or “ ” button at the bottom of the
touch screen to return directly to the “Main Menu”.
Built-in speaker on/off control button
Use the music mode setup shortcut button to perform the music playing mode, the
loop mode and the EQ mode.
Return directly to the “Main Menu”.
Close the button menu display.
Short press the button to go back to the previous track or long press to fast rewind
the current music
Access the music list to select the music files
Play/pause the current music
Short press the button to advance to the next track or long press fast forward
2. Description of the music list interface
Directly touch the “name of music” on the screen to play the selected music.
10

Built-in speaker on/off control button
Return directly to the main menu
Close the button menu display
File browse up
Delete the selected music
Return to the folder up one level
File browse down
3. Lyric display
The player supports “*LRC” lyric files (The user can download via “www.lrc.com”
website, or acquire lyric files via “LRC”) to perform synchronous playing of lyrics and
music. Names of lyric and music files must be identical.
Lyrics will automatically be displayed when a lyric file with LRC extension is present in
the same folder as a currently playing song file with exactly the same name.
Movies playing
In the main menu, click on the “Movies” icon to access the “Movie” function.
In the “Movie” mode, gently press the touch screen to see the menu window.
11

Touch the “ ” at the upper part of the “screen menu”, and the “Menu Window” will
disappear.
Press “M” button at the upper part of the screen or “ ” button at the bottom of the
touch screen to return directly to the “Main Menu”.
1. Description of movie file list
Directly click on the name of video file on the screen to start playing the selected video.
Built-in speaker on/off control button
Return directly to the main menu
Close the button menu display
File browse up
Delete the selected music file
Return to the folder up one level
File browse down
Description of movies playing
12

Close button menu display
Return directly to the main menu
Built-in speaker on/off control button
Short press this button to access the previous video and long press for fast rewind
of the current video
Access the video list and select the video files
Play/pause the current video
Short press the button to access the next video and long press to fast forward the
current video
FM radio
In the main menu, click on the “Radio” icon on the screen to access the FM radio
function.
In the “Radio” mode, gently touch the screen to see the menu window.
Touch the “ ” at the upper part of the “screen menu”, to close the “Menu Window”.
Press “M” button at the upper part of the screen or “ ” button at the bottom of the
touch screen to return directly to the “Main Menu”.
13

Built-in speaker on/off control button
FM record shortcut button
Return directly to the main menu
Close the button menu display
Change radio channels to the low frequency direction
Use the “Switch” button in the FM mode to switch between “Manual Search,
Preset, Delete, Save, Automatic Search”, etc
Change radio channels to the high frequency direction
1. Searching radio channels
Short press “ ” button in the FM mode. Select “Manual” option and short press
“ / ” button to search radio channels up and down. You can use silencing for this
operation.
2. Saving radio channels
Short press the “ ” button in the FM state. Select “Save” option. Short press “ ”
button to save the current radio channels. After selecting the radio channel selection
positions CH1 and CH2, short press again the “YES” button for saving the same.
14

3. Fully automatic search and memory of radio channels
Short press “ ” button to select the “Auto” option. Press “ ” to perform fully
automatic search of radio channels and saving. After the search is over, it will switch to
the first radio channel for the frequency modulation. In the process of radio frequency
search, press “ /” button to stop automatic search.
4. Deleting radio channels
Short press “ ” button to select “Delete” option. Short press “ ” button to pop up
the radio channel preset list. Select the preset radio channel position CH1 or CH2 to be
deleted, and then short press “ ” button for “YES” and deletion.
5. FM recording
In the radio state, press “ ” button to access the FM recording interface.
15

Built-in speaker on/off control button
Return directly to the main menu
Close the button menu display
Long press the button to save the recorded files and stop recording
Short press the button to start/pause recording
Picture browse
In the main menu, press the “Picture” icon to access the “Picture” mode.
In the “Picture” mode, gently press the touch screen to see the “menu window”.
Touch the “ ” at the upper part of the “screen menu”, to close the “Menu Window”.
Press “M” button near the top of the screen or “ ” button at the bottom of the touch
screen to return directly to the “Main Menu”.
1. Description of the picture file list interface
Directly click on the “picture file name” on the screen to display the selected pictures.
16

Built-in speaker on/off control button
Return directly to the main menu
Close the button menu display
File browse up
Delete the selected pictures
Return to the folder up one level
File browse down
2. Picture browse
17

Close the button menu display;
Return directly to the main menu;
Built-in speaker on/off control button;
Access the previous picture;
Access the picture list to select from the picture files;
Automatic picture browse playing/pausing switch button;
Access the next picture.
E-book
In the main menu, touch the “E-book” function icon to access the “E-book” function
interface.
After accessing the “E-book” function mode, gently touch the screen to see the menu
window.
Touch the “ ” at the upper part of the “screen menu”, and the “Menu Window” will
disappear.
Press “M” button at the upper part of the screen or “ ” button at the bottom of the
touch screen to return directly to the “Main Menu”.
18

1. E-book file list
Directly touch the “E-book file name” on the screen to display the selected e-book.
Built-in speaker on/off control button
Return directly to the main menu
Close the button menu display
File browse up
Delete the selected e-book
Return to the folder up one level
File browse down
2. E-book browse
19

Built-in speaker on/off controller
Automatic e-book browse setup button to set automatic browse switching time
Press this button to return directly to the main menu
Close the button menu display
E-book text page down
Return to the e-book text file interface
E-book bookmark
E-book text page up
Prompt: Push the power switch to the “ ” direction for one second to start/pause the
automatic browse function of the e-book.
3. E-book bookmark setup
In the e-book browse mode, short press “ ” button to open the e-book setup menu.
Press the e-book setup menu and then press “ /” button to select the bookmarks to
be saved/exported. After selecting “Save/Export Bookmark”, press “ ” button to
confirm saving/exporting bookmarks, and then press “ ” to cancel saving/exporting the
bookmark.
20
