Macvision MA168 User manual

Customer Service Number: 1.800.938.9886
Website: www.macvision.com

Catalogue
Warning and Cautions
Product illustration andaccessories
Function introduction
Connect MP3 playerto PC
LED Mode
How to chargethe battery ofthe MP3 player
Installation procedure ofWIN98 driver
Battery life
Technicalparameters
2
3
4
5
6
6
6
7
5

Warning & Cautions
Do not usethe mp3 playerin hot, cold,dusty and humid environments.
Do not dropthe player,or expose todirect sunlight, other source of heat for a long
period of time.
Please charge themp3 player whenit has the following instance:
The Red andGreen LED blinkscontinuously.
The mp3 playerturns off automatically.
It does notwork when youpress any buttons.
Do not disconnectthe device suddenlywhen it is being formatted or during
uploading and downloading.Otherwise there maybe errors occurring in the software.
Do not attemptto service theunit.
When the Redand Green LEDblinks alternately during the "play" mode, it is a
indication of lowbattery and theplayer will be automatically power offafter another
five to tenminutes of play.
- 2 -

B. Accessories:
1. Product illustration and accessories:
A. Illustration:
EQ
-
V
O
L
+
On/Off
EQ
Volume-
(Previous song)
Volume+
(Next song)
Dual Jack of Dataand Charge
Driver CD
Sponge Cover
User's Manual
Dual wire ofdata and charge
- 3 -

2. Function introduction:
A. On/Off Button: Power On,Play, Pause and PowerOff
Power On: To turn onthe unit PHthe "On/Off button"for about 3seconds and the
Green LED willcome on, nowthe unit isin the "idle"mode. Then PSthe On/Off button
again to enter"play" mode. TheGreen LED will keep blinking continueously during
"Play" mode.
Pause: Press the"On/Off " buttonduring the "Play" mode, the player will enter
"Pause" mode. Bypress the buttonagain the playerwill revert backto "Play" mode.
Power Off: PHthe "On/Off "buttonto switch off.The unit willautomatically power off
after 30 seconds.
B. EQ Button:Effect adjustment
PS the "EQ"button during theplay mode toselect different musicmode, it will
change from oneto the next:Normal, Rock, POP, Classic, Soft,Jazz, Dbb.
Note: The EQfunction can only be judged from the sounds.
C. Volume+,Volume-: Select the songs and adjust the voice
PS the "Volume+, Volume-"in "play" modeto shift fromthe previous andnext song
PH the buttonto turn upor down thevolume when itis in "play"mode.
* Press ShortlyPS press the button 1 second
* Press andHold PH press the button 2 seconds
For example "On/Off button".
Definition of buttonfunction:
- 4 -

3. Connect MP3 Player to PC:
Connect the mp3player to thePC via theUSB cable, thered and greenLED is
constantly on. TheGreen LED will be constantly on and when the Red LED blinks it is
indicating transferring thedata.
Download and Deletefiles: Afterconnecting the MP3Player to PC,click "My
Computer" to find"Portable Disc" andthen drag orcopy the filesthat you wantto
download or uploadto the requiredfolder.
This MP3 Playercan also storemany other filesand be usedas a portablememory
device.
4. LED Mode:
Mode LED Mode
Red LED Green LED
Off Blinks 1 second pereach time
0.5 second blinksalternately (blinks 0.5seconds per each time)
Constantly onConstantly on
Constantly on
Off
Off
Playing Mode
Low battery Mode
Charging battery
(USB Mode)
Fully Charged
(USB Mode)
No File ForPlaying
Transferring Data Blinks according tothe speeds
of transferring
0.5 seconds blinks pereach time
and switch offafter 3 times
Constantly on
- 5 -

5. How to charge the battery of the MP3 Player:
a. When theMP3 Player isconnected to PC,the Red andGreen LED willbe constantly
on. When theGreen LED willbe off andred LED is blinks constantly the charge is
completed.
b. The MP3Player should be fully charged every time so as to extend the battery life
and the playingtime of theMP3 Player.
c. Transferof data canbe carried outduring charging ofthe MP3 Player.
6. Installation procedure of WIN98 driver:
If the operatingsystem of yourPC is orolder than WIN98,please install thedriver
using the followingprocedures:
Put the CD-ROMin the CDdriver and doubleclick to openthe CD-ROM. ChooseMP3
Driver/setup.
- 6 -
7. Battery life:
Please pull outthe power cableafter the batteryis fully chargedso as toextend
the battery lifeand playing time.

8. Technical parameters:
Music Format: MP1/MPMP2/MP3/WMA/WAV/ASF/WMV
Port Mode: USB 2.0 Protocol.(FS)
EQ Mode: POP,Classic, Soft, Jazz, Dbb, Rock, Normal
Playing time: Can continuously playmusic for about 350-400
minutes after fullycharged.
Battery Voltage: 3.7V Rechargeable Li-IonBattery.
Output Power: 55mw.
Headphone Output Power: 5 mw.
Frequency Response: 20Hz - 20Khz.
Battery Charge Time: About 3 Hours
Working Current: 35-40 mA
Capacity of thememory: 64M-1G(inside)
Info/noise ratio: 86dB
Dimensions: 43mm*12mm
Headphone Impedance: 16 *2
- 7 -
