Superchips MAX MicroTuner 3715 Installation manual

Page 1 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Superchips Model 3715 MAX MicroTuner
2003 Dodge Ram V8 5.7L HEMI
98-03 Dodge Ram, Dakota, & Durango V8 5.9L, V8 5.2L & V6 3.9L
99-03 Dodge Ram, Dakota, Durango & Jeep Grand Cherokee
with V8 4.7L
Vehicle Programming Instructions
PLEASE READ THIS ENTIRE INSTRUCTION SHEET BEFORE YOU PROCEED
Thank you for choosing the Superchips Model 3715 MAX
MicroTuner, a state-of-the-art instrument that allows you to
install a Superchips performance program specifically tuned
for your Dodge or Jeep vehicle and your driving requirements.
You can select between a “Performance” or “Towing-
Performance” program when you are using premium fuel. You
can also select a program that provides optimum performance
when using 87 octane fuel.
This device enables the user to optionally raise or lower the
vehicle speed limiter, rpm limiter and make speedometer
correction to compensate for tire height changes. The Model
3715 MAX MicroTuner is intended for use on unmodified stock
engines.
Table of Contents
Product Information Page 1
Superchips Warranty & Return Policy Page 2
Towing/Gross Vehicle Weight Guidelines Page 3
Section A – Performance Programming Instructions Page 4
Section B – Return to Stock Instructions Page 10
Section C – Troubleshooting Page 13
Page 2 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Superchips Inc. Return Policy
If for any reason during the first 30 days after purchase you are dissatisfied with the quality of this
product you may return it for a full refund of the purchase price (up to MSRP) less the shipping
costs. You will be asked to provide a copy of a Proof of Purchase. Put the product back in its
original packaging and return the product to the place of purchase. Your refund will be made as
soon as possible and in the same manner as your payment was made.
If these goods must be returned for repair or replacement according to the terms of this Limited
Warranty, you must first contact Superchips Customer Service at the number shown below to
request a Return Authorization (RA) number. You will be asked to provide a copy of a Proof of
Purchase from an authorized dealer and the reason for return This RA number must be
prominently displayed on the outside of the shipping package. Put the goods back in their original
packaging and return the goods freight prepaid to Superchips at the address shown below. Goods
received without an RA number will be refused.
DO NOT ATTEMPT TO INSTALL THIS PRODUCT UNLESS YOU HAVE READ AND AGREE WITH
THE FOLLOWING:
Most Superchips Inc. products have the speed limiters increased. It is the buyer’s responsibility to
ensure that the vehicle is not driven faster than the speed rating of the tires on the vehicle in which
the Superchips Inc. product is installed and that the maximum speed rating of the engine is not
exceeded. In no case will Superchips Inc. be held liable if the Buyer exceeds these limits.
LIMITED WARRANTY
Superchips Inc., a Florida corporation, having its principle place of business at 1790 East Airport
Blvd., Sanford, FL 32773, warrants this Superchips Inc. product (“Product”) as follows:
1. Limited Warranty - Superchips Inc. warrants that the Product sold hereunder will be free
from defects in material and workmanship for the lifetime of the Product. If the Product does not
conform to this Limited Warranty, the original purchaser (Buyer) shall notify Superchips Inc. in
writing of the claimed defects and demonstrate to Superchips Inc.’s satisfaction that said defects
are covered by the Limited Warranty. If the defects are properly reported to Superchips Inc., and
the defects are of such type and nature as to be covered by this Limited Warranty, Superchips Inc.
shall at its own expense furnish a replacement Product or, at Superchips Inc.’s option, replacement
parts for the defective Product. Shipping and installation of the replacement Product or parts shall
be at the Buyer’s expense. This Limited Warranty applies only to the original purchaser and is not
transferable.
2. Other Limits - THE FOREGOING IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURCHASE. Superchips Inc. does not
warrant against damages or defects arising out of improper or abnormal use or handling of the
Product; against defects or damages arising from improper installation (where installation is by
persons other than Superchips Inc. employees), against defects in products or components not
manufactured by Superchips Inc., or against damages resulting from such non-Superchips Inc.
made products or components. Superchips Inc. passes on to the Buyer the warranty it receives (if
any) from the maker thereof of such non-Superchips Inc. made products or components. This
warranty also does not apply to Products upon which repairs have been affected or attempted by
persons other than employees of Superchips Inc. unless such repairs are authorized in writing by
Superchips Inc.
3. Exclusive Obligation - THIS LIMITED WARRANTY IS EXCLUSIVE. The sole and exclusive
obligation of Superchips Inc. shall be to repair or replace the defective Product in the manner and
for the period provided above. Superchips Inc shall not have any other obligation with respect to
the Product or any part thereof, whether based on contract, strict liability or otherwise. Under no
circumstances, whether based on the Limited Warranty or otherwise, shall Superchips Inc be liable
for incidental, special or consequential damages.
4. Other Statements - ORAL OR WRITTEN STATEMENTS BY SUPERCHIPS INC.’S
EMPLOYEES OR REPRESENTATIVES DO NOT CONSTITUTE WARRANTIES, shall not be
relied upon by the Buyer, and are not part of the contract for sale or this Limited Warranty.
5. Entire Obligation - The Limited Warranty states the entire obligation of Superchips Inc. with
respect to the Product. If any part of the Limited Warranty is determined to be void or illegal, the
remainder shall remain in full force and effect.
Superchips Inc. Customer Service [phone]

Page 3 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Your Vehicle’s STOCK Program
The MAX MicroTuner stores a copy of your vehicle’s original stock computer program. Your
vehicle’s computer must contain the manufacturer’s STOCK factory program. If you have
used a programmer from another aftermarket company you must use their product to return
your computer back to STOCK condition before proceeding. If you have an aftermarket
performance-enhancing electronic device installed, it must be removed prior to using the
Superchips MAX MicroTuner.
Your Vehicle and Service Centers
If you need to return your vehicle to a service center, restore the vehicle’s program to its
STOCK program as described below. The service center might reprogram your vehicle with
an updated STOCK program without your knowledge. If your vehicle has not been returned
to its STOCK program prior to service, the Superchips MAX MicroTuner will no longer be
able to program your vehicle. Such a failure is not covered by the Superchips Inc. warranty.
Vehicle Preparation
Before connecting the MAX MicroTuner to your vehicle, make sure that:
•All power-draining accessories are turned off. Radio, lights, cell phones, etc., all need to
be turned off as the MAX MicroTuner needs full battery voltage to program.
•Ensure your vehicle battery is fully charged and not connected to a battery charger.
•Do not leave the MAX MicroTuner connected and unattended for any length of time to
prevent unnecessary battery drain.
•Do not remove the programming cable during any programming sequence.
Caution
The “Performance” and “Towing Perf” Tuning Levels require that you use at least 91
octane fuel. Using a lower octane fuel while the “Performance” or “Towing Perf”
Tuning Level is selected may cause “pinging” that can be harmful to your vehicle.
About Maximum Trailer Weight
The original manufacturer of your vehicle has specified a Maximum Trailer Weight for your
vehicle. It may be found in your vehicle owner’s manual.
This Superchips product is designed to increase your engine power and performance. It
does not change the engine, suspension or drive train characteristics that limit the maximum
trailer weight your vehicle is designed to tow. Towing trailer weights above the maximum
trailer weight specified by the vehicle manufacturer may cause transmission or other
damage.
If you wish to tow greater than the maximum trailer weight for your vehicle, modifications to
your vehicle may need to be made. Consult your performance auto mechanic for the proper
vehicle modifications.
Damage caused by towing weights greater than the maximum trailer weight specified for
your vehicle shall not be the responsibility of Superchips Inc.
Important Note Regarding Storage of Your MAX MicroTuner
It is recommended that you not store your MAX MicroTuner in your vehicle if ambient
temperatures in your area fall below 32oF. Excessively low temperatures can cause
malfunction or damage to the MAX MicroTuner that is not covered by the Superchips Inc.
warranty.
Page 4 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Section A – Performance Programming Instructions
1. Connecting the MAX MicroTuner to your vehicle
With the ignition switch in the OFF position, locate the diagnostic connector under the dash
near the steering wheel and connect the MAX MicroTuner cable to the diagnostic connector.
(See Figure 2)
When connected, the MAX MicroTuner will run a self-test,
displaying several start-up messages. Following the start up
messages, the MAX MicroTuner displays the following
message:
Begin with Ign.
OFF Press ‘>’
Insure the ignition switch is OFF, then press the ‘>’ key on
the keypad. The MAX MicroTuner displays the following
messages:
Please Wait…
then
Turn Ignition ON
Do NOT START ENG
Turn Ignition
ON Press ‘>’
Turn the ignition switch to the ON position and then press the ‘>’ key on the keypad.
2. Selecting Tune Vehicle / Diagnostics
The MAX MicroTuner will beep and display the message:
A= Tune Vehicle
B= Diagnostics
Press the ‘A’ key on the keypad to continue with the tuning process.
Press the ‘B’ key to read and/or clear any Diagnostic Trouble Codes from the vehicle. See
DTC Reader Instructions and DTC Interpretations in the separate manual provided for this
purpose with your product.
3. Vehicle Programming
Press the ‘A’ key on the keypad. The MAX MicroTuner will flash the message:
Initialization
Please Wait…
The MAX MicroTuner is establishing communications with and identifying the vehicle computer.
This may take a considerable amount of time, as the MAX MicroTuner has to insure it has
completely identify the vehicle and all of the components for correct operation.
4. Saving the STOCK program for the vehicle
The manufacturer’s STOCK program is first saved in the MAX MicroTuner in multiple files,
up to three total, to allow the vehicle to be reprogrammed to STOCK condition if necessary.
The STOCK program is saved only the first time the vehicle is programmed.
To save the complete stock program, the MAX MicroTuner may repeat the following
sequence up to three times depending on your vehicle’s configuration.
The MAX MicroTuner will beep and display the message
Turn Ignition
OFF Press ‘>’
Turn the ignition to the OFF position, then press the ‘>’ key on the keypad.
Fi
g
ure 2

Page 5 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
The MAX MicroTuner will flash the following message:
Please Wait…
After initialization is complete, the MAX MicroTuner will beep and display the message:
Turn Ignition ON
Do NOT START Eng
Or
Turn Ignition
On Press ‘>’
Turn the ignition to the ON position, DO NOT ATTEMPT TO START the vehicle. If
necessary, press the ‘>’ key on the keypad to continue.
The MAX MicroTuner will beep and start saving the stock program. This will take about one
to two minutes depending on the vehicle configuration. The MAX MicroTuner will blink the
following message where N is the file number it is saving:
Saving Stock
File N XX.X% (00.0 – 100.0%)
When 100% of the all the files has been saved, make sure to leave the ignition in the ON
position until instructed otherwise.
5. Installing the Superchips Performance Program
The MAX MicroTuner allows for three levels of performance tuning.
The “Performance” tuning level provides the most aggressive performance gains. Use of
premium fuel (91 octane or greater) is required to realize these gains. Towing up to half of
the manufacturer’s towing limit* is typically acceptable using this tuning level. If “pinging” or
a clattering from the engine is heard, change to the “Towing Perf” tuning level.
The “Towing Perf” tuning level provides enhanced engine and transmission tuning for heavy
towing up to the manufacturer’s towing limit*. Use of premium fuel (91 octane or greater) is
required.
The “87 OCTANE” tuning level provides optimized engine efficiency and enhanced
transmission tuning often resulting in increased fuel economy and performance. Towing up
to half of the manufacturer’s towing limit* is typically acceptable using this tuning level. If
while using the “87 OCTANE” tuning level “pinging” or a clattering from the engine is
heard, try a higher grade of fuel or return the vehicle to its “Stock” tuning level. The “87
OCTANE” tuning level may not be available for all vehicles.
Selecting the Tuning Level
The MAX MicroTuner will Display the following:
User Option
Instructions
Adjust = < or >
Save = YES
Press ‘>’
to Continue
*The manufacturer’s towing limit can be found in your vehicle owner’s manual and/or towing
supplement manuals.
Caution
The “Performance” and “Towing Perf” tuning levels require that you use at least 91 octane
premium fuel. Using a lower octane fuel while the “Performance” or “Towing Perf” tuning Level
is selected may cause “pinging” that can be harmful to your engine.
Page 6 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Pressing ‘<’ and ‘>’ on the keypad adjusts the Custom Option setting.
Pressing ‘YES’ on the keypad saves the Custom Option setting.
The MAX MicroTuner will Display the following:
Tuning Level:
xxxxxxxx (xxxxxxxx=Performance, Towing Perf or 87 Octane)
Pressing ‘<’ and ‘>’ on the keypad changes the fuel setting.
Pressing ‘YES’ on the keypad saves the tuning level setting.
Editing the Custom Options Settings
All options selected will be saved in memory in case additional adjustments are needed. The
MAX MicroTuner will beep and display the keys to use while editing the Custom Option
settings.
The MAX MicroTuner will beep and display the message:
Edit Custom
Opts? YES or NO
Press ‘YES’ to make changes to the Custom Option Settings.
Press ‘NO’ to bypass the Custom Options and go directly to Viewing the Option
Settings at Step 6 that follows.
Adjusting the RPM Limiter Option Setting
If available, the RPM Limiter option allows the user to set the vehicle RPM Limiter.
The MAX MicroTuner has two methods. The first allows the RPM Limiter to be set to:
•Superchips (a preset level that is optimized for your application)
•Stock
•Stock plus 250 RPM
•Stock plus 500 RPM
Pressing ‘<’ and ‘>’ on the keypad adjusts the Custom Option setting.
Pressing ‘YES’ on the keypad saves the RPM Limiter setting.
The second method asks if you want to raise the RPM Limiter. Pressing ‘YES’ will raise the
RPM limiter to the Superchips optimized setting. Pressing ‘NO’ will leave the limiter at the
stock setting.
Adjusting the Speed Limiter Option Setting
If available, the Speed Limiter option allows the user to set the vehicle Speed Limiter.
The MAX MicroTuner has two methods. The first allows the Speed Limiter to be set to:
•Superchips (a preset level that is optimized for your application)
•Stock
•120 MPH
•140 MPH
Pressing ‘<’ and ‘>’ on the keypad adjusts the Custom Option setting.
Pressing ‘YES’ on the keypad saves the Speed Limiter setting.
The second method asks if you want to raise the Speed Limiter. Pressing ‘YES’ will raise
the Speed limiter to the Superchips optimized setting. Pressing ‘NO’ will leave the limiter at
the stock setting.
Note
Keep the ignition ON while choosing options.

Page 7 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Editing the Tire Height Option Setting
If available, the Tire Height Option allows the user to correct the Speedometer/Odometer
when tires other than stock size are installed. The Tire Height Option allows the user to set
the Tire Height to STOCK or to 22.5 – 42.0 inches in 1/4-inch intervals. Tire height should
be measured from the top of the tire to the ground at its highest point.
The MAX MicroTuner will beep and display the message:
Adjust tire
height? YES/NO
Press ‘NO’ and the MAX MicroTuner will continue to the Viewing the Options Settings at
Step 6.
Press ‘YES’ and the MAX MicroTuner will beep and display Tire Height setting:
Pressing ‘<’ and ‘>’ on the keypad adjusts the Custom Option setting.
Pressing ‘YES’ on the keypad saves the Tire Height setting.
Stock Hght XX.XX (xx.xx is Stock Tire Height)
>Up <Down Yes
Press ‘<’ or ‘>’ to select the Tire Height setting. Once a tire height change has taken
place the MAX MicroTuner will display the message:
Tire Hght XX.XX (xx.xx is Tire Height)
>Up <Down Yes
Press ‘YES’ to save the Tire Height Option setting.
6. Viewing the Options Settings
The MAX MicroTuner will beep and display the message:
View Custom
Opt? YES or NO
Press ‘YES’ to view the present Custom Option Settings.
The MAX MicroTuner will beep and display the message:
Press Any Key
to Continue...
Press any key on the MAX MicroTuner keypad. The Custom Options current settings
will be presented in order. Press any key to view the next Custom Option setting.
Press ‘NO’ to continue without viewing the Custom Option Settings.
7. Accepting the Options Settings
The MAX MicroTuner will beep and display the message:
Accept Selected
Opts? YES or NO
Press ‘NO’ to start over and return to the Installing the Superchips Performance
Program at Step 5.
Press ‘YES’ to accept the options and continue even if no changes have been made.
Page 8 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
The MAX MicroTuner will beep and display the message for each file it needs to build, where
N is the file it needs to build, for up to three files:
Building File N
Please Wait…
8. Programming Section
Leave the ignition ON until instructed otherwise. The MAX MicroTuner will display the
following message:
Install Tuning
YES or NO
Press ‘YES’ to continue with the programming process.
Press ‘NO’ to STOP the programming attempt and not apply any changes to your
vehicle. The MAX MicroTuner will then continue to End of Programming & Exit
Sequence at Step 9 to insure correct vehicle operation.
If ‘YES’ is pressed, the MAX MicroTuner will repeat the following sequences for up to three
files, depending upon your vehicle configuration, where N is the number of the file being
programmed.
The MAX MicroTuner will display the message:
Program Engine
File N XX.X% (00.0 – 100.0%)
Please Wait…
When 100% of the first file has been programmed, the MAX MicroTuner will beep and
display the message:
Turn Ignition
OFF Press ‘>’
Turn the ignition to the OFF position, then press the ‘>’ key. The MAX MicroTuner will flash
the following message:
Please Wait…
The MAX MicroTuner will then beep and display the message:
Turn Ignition ON
Do NOT START Eng
Or
Turn Ignition
On Press ‘>’
Turn the ignition to the ON position, DO NOT ATTEMPT TO START the vehicle. If
necessary, press the ‘>’ key on the keypad to continue.
When 100% of the all the files have been programmed the MAX MicroTuner will continue to
the End of programming & Exit Sequence.
IMPORTANT NOTE
Do not interrupt the MAX MicroTuner programming cycle or disconnect it from your vehicle
until the programming cycle is complete. The entire programming cycle can take several
minutes.

Page 9 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
9. End of Programming & Exit Sequence
The MAX MicroTuner will beep and display the message:
Turn Ignition
OFF Press ‘>’
Turn the ignition to the OFF position, then press the ‘>’ key. The MAX MicroTuner will beep
and flash the following message:
Please Wait…
Then
Turn Ignition
On Press ‘>’
Turn the ignition to the ON position, DO NOT ATTEMPT TO START the vehicle, then press
the ‘>’ key on the keypad to continue. Then flash
Please Wait…
If a Tire Height change needs to be installed, The MAX MicroTuner will blink the following
message:
Adjusting Speedo
Please Wait…
Once the speedometer programming is complete, the MAX MicroTuner will display:
Adjusting Speedo
Complete!
Please Wait…
When the programming sequence is completed the MAX MicroTuner beeps and will display:
Vehicle now has
Tuning installed
Turn the
Ignition OFF
Remove the MAX
MicroTuner
Turn the ignition to the OFF position and unplug the MAX MicroTuner from the vehicle. It is
now safe to operate your vehicle in a normal operation.
Page 10 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Section B – Return to Stock Instructions
Return to Stock Sequence
The Return to Stock Sequence is used to reprogram a vehicle previously tuned with the
Superchips MAX MicroTuner with its original stock tuning.
Follow the steps described in Connecting the Superchips MAX MicroTuner to Your Vehicle
at Step 1 above. Following the typical start up messages, if the MAX MicroTuner has been
previously used to program a vehicle, the MAX MicroTuner will beep and display:
MICROTUNER is
VIN Locked
(Note: Other messages displayed here indicate why the MAX MicroTuner is locked.)
This indicates the MAX MicroTuner has been previously used to program a vehicle. It
cannot be used program another vehicle other than the original vehicle. The DTC reader
function will still operate on any vehicle following the separate DTC Reader Instructions and
DTC Interpretations manual.
Note: If the MAX MicroTuner displays “Recovery” after the above message, the MAX
MicroTuner is in recovery mode. See Section C – Troubleshooting.
The MAX MicroTuner then displays the following message
Begin with Ign.
OFF Press ‘>’
Insure the ignition switch is OFF, then press the ‘>’ key on the keypad.
The MAX MicroTuner displays the following messages:
Please Wait…
then
Turn Ignition ON
Do NOT START Eng
Turn the ignition switch to the ON position. The MAX MicroTuner will beep and display the
message:
A= Tune Vehicle
B= Diagnostics
Press the ‘A’ key on the keypad to continue with the tuning process.
Press the ‘B’ key to read and/or clear any Diagnostic Trouble Codes. (See DTC
Reader Instructions and DTC Interpretations in the separate manual provided for
this purpose with your product.)
Initialization
Please Wait…
The MAX MicroTuner is establishing communications with and identifying the vehicle
computer. This may take a considerable amount of time, as the MAX MicroTuner has to
insure it has completely identify the vehicle and all of the components for correct operation.
After establishing communications, the MAX MicroTuner may repeat the following
sequence up to three times depending on your vehicle’s configuration.
The MAX MicroTuner will display the following message:
Turn Ignition
OFF Press ‘>’
Turn the ignition to the OFF position, then press the ‘>’ key.

Page 11 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
The MAX MicroTuner flash the following message:
Please Wait…
The MAX MicroTuner will then beep and display the message:
Turn Ignition ON
Do NOT START Eng
Or
Turn Ignition
On Press ‘>’
Turn the ignition to the ON position, DO NOT ATTEMPT TO START the vehicle. If
necessary, press the ‘>’ key to continue.
The MAX MicroTuner flashes the following message:
Please Wait…
Leave the ignition ON until instructed otherwise. The MAX MicroTuner will then display the
following message:
RETURN to STOCK?
YES or NO
If ‘NO’ is pressed, the MAX MicroTuner will return to Installing the Superchips
Performance Program at Step 5 above.
If ‘YES’ is pressed, the MAX MicroTuner will repeat the following sequences for up
to three files, depending upon your vehicle configuration, where N is the number of
the file being programmed.
The MAX MicroTuner will display the message:
Program Engine
File N XX.X% (00.0 – 100.0%)
Please Wait…
When 100% of the first file has been programmed, the MAX MicroTuner will beep and
display the message:
Turn Ignition
OFF Press ‘>’
Turn the ignition to the OFF position, then press the ‘>’ key. The MAX MicroTuner will flash
the following message:
Please Wait…
The MAX MicroTuner will then beep and display the message:
Turn Ignition ON
Do NOT START Eng
Or
Turn Ignition
On Press ‘>’
Turn the ignition to the ON position, DO NOT ATTEMPT TO START the vehicle. If
necessary, press the ‘>’ key to continue.
When 100% of the all the files have been programmed, the MAX MicroTuner will beep and
display the message:
Turn Ignition
OFF Press ‘>’
Page 12 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Turn the ignition to the OFF position, then press the ‘>’ key. The MAX MicroTuner will beep
and display the following message:
Please Wait…
Then
Turn Ignition ON
Do NOT START Eng
Then flash
Please Wait…
If a Tire Height change was installed, The MAX MicroTuner will blink the following
message:
Adjusting Speedo
Please Wait…
Once the speedometer programming is complete, the MAX MicroTuner will display:
Adjusting Speedo
Complete!
Please Wait…
When the programming sequence is completed the MAX MicroTuner beeps and will display:
Vehicle is at
Stock setting
Turn the
Ignition OFF
Remove the MAX
MicroTuner
Turn the ignition to the OFF position and unplug the MAX MicroTuner from the vehicle. It is
now safe to operate your vehicle in a normal operation.

Page 13 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Section C – TROUBLESHOOTING
A. No Response
Solution: If the MAX MicroTuner does not power up when plugged into the diagnostic port,
please check the fuse that powers the diagnostic port. This may be the
radio/cluster/underhood lamp fuse located in the fuse box found under the hood. It should
be a 20 amp fuse and possibly labeled # 51.
If a blown fuse cannot be found, check the pin connectors in the vehicle diagnostic
connector into which you are plugging the MAX MicroTuner cable. Make sure that none of
the pins in the connector have been pushed out of the connector body.
If the fuses are all good and the pins are in place, plug the MAX MicroTuner into another
Dodge or Jeep truck. If the MAX MicroTuner powers up, your truck has something wrong
with either the wiring harness or there is still a blown fuse somewhere else in the vehicle.
If the MAX MicroTuner fails to power up on a second Dodge or Jeep truck, call Superchips
Customer Service at 407 585-7000 to ask for a Return Authorization to send the MAX
MicroTuner in for inspection.
B. MAX MicroTuner Requires an Update
If the MAX MicroTuner does not have the information necessary to tune your vehicle, the
following messages will be displayed:
Tuner Requires
an Update...
Call Superchips!
Use Code #E-XX (XX=a two digit number)
Record this File
Name: XXXXXXXXXX
Solution: Write down both the Code number (#E-XX) and the File Name XXXXXXXXXX
and give these to the customer service representative when you call Superchips Customer
Service.
C. Vehicle Requires a Factory (Dealer) Update
If the MAX MicroTuner has found your vehicle box code and it is problematic to tune, the
following messages will be displayed:
Vehicle Requires
a Factory Update
Call Superchips!
Use Code #E-XX (XX=a two digit number)
Record this File
Name: XXXXXXXXXX
Solution: Superchips has found that some stock applications have numerous problems that
have been fixed with an updated stock program available from a dealer for your vehicle.
Such an update of the stock program in your vehicle is required before the MAX Micro
tuner may be used on your vehicle.
You may call Superchips Customer Service for confirmation that a dealer updated file is
available and instructions about how to have the stock files for your vehicle updated. Write
down both the Code number (#E-XX) and the File Name XXXXXXXXXX and give this to
the Superchips customer service representative.
D. Unsupported application
If your particular vehicle or engine type is not currently supported by the MAX MicroTuner
Firmware, the following error messages will be displayed:
Page 14 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
This application
is unsupported
currently! Call
us if incorrect.
Call Superchips!
Use Code #E-36
Solution: Check year, model and engine to verify the MAX MicroTuner being used is correct
for the application. If not, return it to the dealer from which it was purchased for the correct
MAX MicroTuner. If the vehicle is correct for the MAX MicroTuner being used, call
Superchips Customer Service at 407 585-7000 for a Return Authorization number to send
the MAX MicroTuner in for inspection.
E. Non-Stock File Application
If the MAX MicroTuner has checked your file and cannot match it to a stock file the
following messages will be displayed:
Vehicle File is
Not Stock...
Call Superchips!
Use Code #E-43
Solution: This may be because another programmer has been previously used to
reprogram the vehicle. The vehicle computer must be reprogrammed with a valid stock
program before trying to use the Superchips MAX MicroTuner. You may call Superchips
Customer Service for instructions about how to have the stock files for your vehicle
updated. Write down both the Code number (#E-XX) and the File Name XXXXXXXXXX
and give this to the Superchips customer service representative.
F. Locked Vin Number
If the MAX MicroTuner has used on a vehicle, it is “locked” to that vehicle. If an attempt is
made to use on a different vehicle the following messages will be displayed:
Locked VIN
is mismatched!
Not the Original
Vehicle/Program
Call Superchips!
Use Code #E-37
Solution: Return the original vehicle back to stock before using the MAX MicroTuner on a
different vehicle.
G. Not original Program ID
If the MAX MicroTuner is “VIN locked” to a vehicle and that vehicle has been updated at the
dealership to a different Box Code (identification number) without first using the MAX
MicroTuner to Return the Vehicle to Stock, the following messages will be displayed:
Not the Original
Program ID
Not the Original
Vehicle/Program
Call Superchips!
Use Code #E-38

Page 15 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Solution: You must return the vehicle back to stock before going to a dealership. In such a
case, the MAX MicroTuner will need to be returned to Superchips to be unlocked. Call
Superchips Customer Service at 407 585-7000 for a Return Authorization number before
shipping.
H: Checksum Error
If the MicroTuner is “VIN locked” to a vehicle and that vehicle has been updated at the
dealership to the same Box Code (identification number) without first using the MAX
MicroTuner to Return the Vehicle to Stock, the following messages will be displayed:
Not the Original
Program Checksum
Not the Original
Vehicle/Program
Call Superchips!
Use Code #E-39
Solution: Users must return the vehicle back to stock before going to a dealership. In such
a case, the MAX MicroTuner will need to be returned to Superchips to be unlocked. Call
Superchips Customer Service at 407 585-7000 for a Return Authorization number before
shipping.
I. Upload Error
If the MAX MicroTuner cannot detect the ignition is in the on position the following
messages will be displayed:
Problem with
uploading!
Please retry
Call Superchips!
Use Code #E-XX (XX=a two digit number)
Solution: Make sure Ignition is ON. Retry again. If it still fails, then contact Superchips. The
MAX MicroTuner will need to be returned to Superchips to be unlocked. . Write down the
Code number (#E-XX) and give this to the Superchips customer service representative.
Call Superchips Customer Service at 407 585-7000 for a Return Authorization number
before shipping.
J. Ignition ON Error
If the MAX MicroTuner cannot detect that the ignition is in the ON position, the following
messages will be displayed:
Cannot Detect
Ignition On
Please retry
Call Superchips!
Use Code #E-31
Solution: Make sure Ignition key is turned completely forward in the ON position. Check to
see if pins are pushed out of the diagnostic connector.
Page 16 of 16 Form 0135J 11/23/2004 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
K. Communications Error
If the MAX MicroTuner looses communications the following messages will be displayed:
Communications
Error!!!
Please retry
Call Superchips!
Use Code #E-XX
Solution: Make sure Ignition is ON. Retry again. If it still fails, then contact Superchips. The
MAX MicroTuner will need to be returned to Superchip. . Write down the Code number
(#E-XX) and give this to the Superchips customer service representative. Call Superchips
Customer Service at 407 585-7000 for a Return Authorization number before shipping.
L. The MAX MicroTuner did not program same number of files as saved
This is normal. The MAX MicroTuner communicates with all the necessary modules on the
vehicle to gain the information need to correctly operate. It may be necessary to save
additional files that are not programmed for correct tuning.
M. My friend’s truck has the same engine but programs or reads at different speeds.
Each vehicle configuration has been optimized to the fastest and safest method of
operation. Your friend’s truck may have different types of vehicle computers in his truck
which may require more or less time to do certain operations.
N. Why do similar vehicle types have different numbers of files?
Even similar vehicles can have different configurations and quantities of computers. The
MAX MicroTuner communicates with all the necessary computer modules on the vehicle to
gain the information needed to operate correctly.
O. My friend’s truck has the same engine but is tuned differently, why?
Each vehicle configuration has been optimized for the best tuning. Your friend’s truck may
have different types of vehicle computers, thus requiring different tuning. If you believe this
is incorrect please call Superchips Customer Service at 407 585-7000.
Recovery Procedure
In the event of an error during a programming sequence, the MAX MicroTuner will attempt
to recover the vehicle to the original stock program. It is necessary to follow the screen
prompts, possibly requiring multiple “Ignition OFF” and “Ignition ON” sequences, to
correctly return the vehicle to stock settings.
Error Notification
In the event recovery is successful and you are able to start your vehicle, you may now
attempt to use the MAX MicroTuner to program your vehicle again. Follow the on-
screen prompts. If recovery is unsuccessful, or for any reason the MAX MicroTuner fails
to complete its programming cycle, an error message will be displayed on the unit.
Please make note of the message displayed and contact Superchips Customer Service.
If you need assistance please contact your local dealer or call Superchips Customer
Service at [phone], M-F 8:00 AM till 5:00 PM. EST.
