Supermicro Super X6DHR-TG Installation and operating instructions

Attention!!
Important Notice!!
(Read the information listed below before using this product.)
Jumpers J4F4/J4F5 (PLLSEL Select): These jumpers allow the user to select PLLSEL (Memory Speed). Make sure
that the jumper settings are set correctly according to your memory speed before you power on the system.
(*Warning!! If these jumpers are not set correctly according to your memory speed, video display failure may
occur!!!)
DDR
*333 MHz
266MHz
J4F4 J4F5
Closed Closed
Open Open
PLLSEL Select
Jumper Settings
(J4F4/J4F5)
(*Default:Closed-333MHz)
(*Note: the default setting is “Closed” for both jumpers to
enable DDR Memory at 333MHz. However, if your memory
speed is 266MHz, please make sure to set both jumpers
to “Open”.)
Add-X6DHR-TG-11/10/04
KB
DIMM 4B
Mouse
USB
0/1
COM1
DIMM 4A
DIMM 3B
DIMM 3A
DIMM 2B
DIMM 2A
DIMM 1B
DIMM 1A
GLAN1
GLAN2
VGA
Battery
JPG1
JPL1
RAGE-
XL
GLAN
CTRL
PXH
PCI-X 133 MHz
PCI-X 100 MHz
E7520
(North Bridge)
ICH5R
(South
Bridge)
ZCR RAID
IPMI 2.0
IDE #1
IDE #2
Floppy
WOL
COM2
Fan3
USB2/3
JBT1
FP CTRL
FAN2
FAN1
20-Pin ATX PW
PW SMB
JL1
JWD
CPU1
CPU2
JOH1 JD1
J4F4
J4F5
PWR
Fail
SPKR
Bank1
Bank2
Bank3
Bank4
PCI-Ex8
PCI-Ex8
SATA
S I/O
Graphic
Memory
SMB IPMB COM2
BIOS
WOR
JS10
JPS1
SATAII
JWF2
JP18 JWF1
JP17
SATA0 SATA1
Fan5
Fan4
JP10
JP11
12V
8 Pin
PWR
12V
4 Pin
PWR
JS9
Marvell SATA#0-3
J3J4
J4F4/J4F5
Addendum to X6DHR-TG Motherboard User’s Manual
