Supermicro SuperServer SYS-110P-WR User manual

USER’S MANUAL
Revision 1.0b

SYS-110P-WR
SYS-110P-WTR

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGESARISING FROM THE USE OR INABILITYTO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A or Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in industrial environment for Class A device or in residential
environment for Class B device. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful interference with
radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in
which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.0b
Release Date: June 30, 2022
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2022 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!

3
Preface
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the server. Installation and maintenance should be
performed by experienced technicians only.

for updates on supported memory, processors and operating systems (http://www.supermicro.
com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: https://www.supermicro.com/wdl
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
[email protected]m
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Secure Data Deletion
A secure data deletion tool designed to fully erase all data from storage devices can be found
on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/
Lot9_Secure_Data_Deletion_Utility/
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage


4
SuperServer SYS-110P-WR/SYS-110P-WTR User's Manual
Contents
Chapter 1 Introduction
1.1 Overview...............................................................................................................................9
1.2 System Features ................................................................................................................10
Front View .........................................................................................................................10
Drive Carrier Indicators .....................................................................................................10
Control Panel.................................................................................................................11
Rear View..........................................................................................................................12
Top View............................................................................................................................13
Power Supply Option.....................................................................................................14
1.3 System Architecture ...........................................................................................................15
System Block Diagram......................................................................................................16
1.4 Motherboard Layout ...........................................................................................................17
Quick Reference Table......................................................................................................18
Chapter 2 Server Installation
2.1 Overview.............................................................................................................................20
2.2 Unpacking the System .......................................................................................................20
2.3 Preparing for Setup ............................................................................................................20
Choosing a Setup Location...............................................................................................20
Rack Precautions ..............................................................................................................21
Server Precautions............................................................................................................21
Rack Mounting Considerations .........................................................................................21
Ambient Operating Temperature....................................................................................21
 ............................................................................................................................22
Mechanical Loading.......................................................................................................22
Circuit Overloading ........................................................................................................22
Reliable Ground.............................................................................................................22
2.4 Installing the Rails ..............................................................................................................23
Identifying the Rails...........................................................................................................23
Installing the Outer Rails onto the Rack...........................................................................24
2.5 Installing the Chassis into a Rack......................................................................................25
Removing the Chassis from the Rack ..............................................................................26
Installing the Server into a Telco Rack .............................................................................27

5
Preface
Chapter 3 Maintenance and Component Installation
3.1 Removing Power ...............................................................................................................28
3.2 Accessing the System........................................................................................................29
3.3 Static-Sensitive Devices.....................................................................................................30
Precautions .......................................................................................................................30
3.4 Processor and Heatsink Installation...................................................................................31
The Processor Carrier Assembly ......................................................................................32
The Processor Heatsink Module (PHM) ...........................................................................34
Preparing the CPU Socket for Installation........................................................................35
Installing the PHM into the CPU Socket...........................................................................36
Removing the PHM from the CPU Socket .......................................................................39
Removing the Processor Carrier Assembly from the PHM ..............................................40
Removing the Processor from the Carrier Assembly........................................................41
3.5 Memory...............................................................................................................................42
Memory Support................................................................................................................42
General Guidelines for Optimizing Memory Performance ................................................43
DIMM Installation ..............................................................................................................44
DIMM Removal .................................................................................................................44
3.6 Motherboard Battery...........................................................................................................45
3.7 Storage Drives....................................................................................................................46
Installing Drives.................................................................................................................47
Checking the Temperature of an NVMe Drive..................................................................48
3.8 System Cooling ..................................................................................................................48
3.9 Cable Routing Diagram......................................................................................................49
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................50
4.2 Headers and Connectors ...................................................................................................52
Headers.............................................................................................................................52
4.3 Input/Output Ports ..............................................................................................................57
Rear I/O Ports................................................................................................................57
4.4 Jumpers..............................................................................................................................58
4.5 LED Indicators....................................................................................................................60

6
SuperServer SYS-110P-WR/SYS-110P-WTR/SYS-110P-WR/SYS-110P-WTR User's Manual
Chapter 5 Software
5.1 Microsoft Windows OS Installation.....................................................................................62
5.2 Driver Installation................................................................................................................64
5.3 SuperDoctor®5...................................................................................................................65
5.4 BMC....................................................................................................................................66
BMC ADMIN User Password ............................................................................................66
Chapter 6 Optional Components
6.1 Optional Parts List..............................................................................................................67
6.2 Power Supply Modules ......................................................................................................68
6.3 2.5" NVMe Drive Trays.......................................................................................................68
6.4 Storage Control Card and Cable(s) ...................................................................................68
6.5 CacheVault(s) .....................................................................................................................69
Installing the SuperCap Kit via Fan Tray..........................................................................69
Installing the SuperCap Kit via the PCIe Bracket.............................................................69
6.6 Intel Virtual RAID on CPU (VROC)....................................................................................70
Requirements and Restrictions.........................................................................................70
Supported SSDs and Operating Systems ........................................................................70
Additional Information .......................................................................................................71
Hardware Key ...................................................................................................................71
Enabling NVMe RAID........................................................................................................72
Status Indications..............................................................................................................73
Hot Swap Drives ...............................................................................................................74
Hot-unplug .....................................................................................................................74
Hot-plug .........................................................................................................................74
Chapter 7 Troubleshooting and Support
7.1 Information Resources .......................................................................................................75
Website .............................................................................................................................75
Direct Links for the SYS-110P-WR/SYS-110P-WTR System........................................75
Direct Links for General Support and Information .......................................................75
7.2 BMC Interface ....................................................................................................................76
7.3 Troubleshooting Procedures .............................................................................................77
Before Power On ..............................................................................................................77
No Power ..........................................................................................................................77
System Boot Failure .........................................................................................................77

7
Preface
Memory Errors ..................................................................................................................77
.........................................................................78
When the System Becomes Unstable ..............................................................................78
7.4 Crash Dump Using the BMC Dashboard...........................................................................80
7.5 CMOS Clear .......................................................................................................................81
7.6 Where to Get Replacement Components..........................................................................82
7.7 Reporting an Issue .............................................................................................................82
Technical Support Procedures ..........................................................................................82
Returning Merchandise for Service...................................................................................82
Vendor Support Filing System ..........................................................................................83
7.8 Feedback............................................................................................................................83
7.9 Contacting Supermicro.......................................................................................................84
Appendix A Standardized Warning Statements for AC Systems
Appendix B System Specications

8
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected] (Sales Inquiry)
[email protected] (Technical Support)
Website: www.supermicro.com.tw
SuperServer SYS-110P-WR/SYS-110P-WTR User's Manual

9
Chapter 1: Introduction
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the
SYS-110P-WR/SYS-110P-WTR. It is based on the X12SPW-F/TF motherboard and the
CSE-116AC10-R706WB chassis.
The following provides an overview of the specications and capabilities.
Chassis CSE-116AC10-R706WB
Motherboard X12SPW-F/TF
Processor Support 3rd Gen Intel® Xeon® Scalable processors
Memory Eight DIMM slots, up to 2TB ECC LRDIMM, DDR4-3200 MHz
Drive Support Ten 2.5" hot-swap SATA/SAS/NVMe hybrid drive bays
Expansion Slots One PCIe 4.0 x16 LP slot(s)
Two PCIe 4.0 x16 FHFL slot(s)
I/O Ports
Two LAN 10GbE ports
One dedicated BMC/KVM LAN port
One VGA port
One serial port
Two USB 3.2 Gen 1 ports
Two USB 2.0 ports
System Cooling Five (4cm x 4cm x 5.6cm) counter-rotating fan(s)
Passive Heatsink for 1U System
Power Redundant 750W Platinum level (94%)
Form Factor 1U rackmount
The following safety models associated with the SYS-110P-WR/SYS-110P-WTR have been
certied as compliant with UL or CSA: 116-R7X12 and 116-7

10
Chapter 1: Introduction
1.2 System Features
The following views of the system display the main features. Refer to Appendix B for additional
specications.
Front View
Figure 1-1. Front View
Drive Carrier Indicators
Each drive carrier has two LED indicators: an activity indicator and a status indicator. For RAID
congurations using a controller, the meaning of the status indicator is described in the table
below. For OS RAID or non-RAID congurations, some LED indications are not supported,
such as hot spare. For VROC congurations, refer to the VROC appendix in this manual.
Drive Carrier LED Indicators
Color Blinking Pattern Behavior for Device
Activity
LED
Blue Solid On Idle SAS/NVMe drive installed
Blue Blinking I/O activity
O󰀨 Idle SATA drive
Status
LED
Red Solid On Failure of drive with RSTe support
Red Blinking at 1 Hz Rebuild drive with RSTe support
Red Blinking with two blinks
and one stop at 1 Hz
Hot spare for drive with RSTe support
Red On for ve seconds,
then o󰀨
Power on for drive with RSTe support
Red Blinking at 4 Hz Identify drive with RSTe support
Control Panel
System Features: Front
Feature Description
Drive Bays
(Items 0 to 9) Ten 2.5" hot-swap drive bays
Control Panel See the next page for details.
USB Ports Two USB 3.2 Gen 1 ports
Drive Bays USB 3.2 Gen 1 Ports
Drive Bays
8
9
6
7
4
53
20
1
Service/Asset Tag
with BMC Password

11
Chapter 1: Introduction
Control Panel Features
Feature Description
UID Button
Depressing the Unit Identier button illuminates an LED on both the front and rear of the
chassis for easy system location in a rack conguration. The LED will remain on until the
button is pushed a second time. Another UID button on the rear of the chassis serves the
same function.
Information LED Alerts operator to several states, as noted in the table below.
NIC1 LED Indicates network activity on GLAN1 when ashing.
NIC2 LED Indicates network activity on GLAN2 when ashing.
HDD LED Indicates activity on the storage drives when ashing.
Power LED Indicates power is being supplied to the system power supply units. This LED is illuminated
when the system is operating normally.
Power button The main power switch applies or removes primary power from the power supply to the server
but maintains standby power.
Information LED
Color, Status Description
Red, continuously An overheat condition has occurred.
Red, blinking at 1Hz Fan failure, check for an inoperative fan.
Red, blinking at 0.25Hz Power failure, check for a non-operational power supply.
Blue, solid UID has been activated locally to locate the server in a rack environment.
Blue, blinking UID has been activated using BMC to locate the server in a rack environment.
Power
Power LED
Information LED
HDD LEDNIC2 LED
Control Panel
Figure 1-2. Control Panel
UID Button
NIC1 LED

12
Chapter 1: Introduction
Rear View
Figure 1-3. System: Rear View
Expansion Slot Locations
Item Description
1PCIe 4.0 x16 slot: full-height, full-length
2PCIe 4.0 x16 slot: full-height, full-length
3PCIe 4.0 x16 slot: low prole
System Features: Rear
Feature Description
Power Supplies Two redundant power supply modules: PWS1 on the right, PWS2 on the left.
COM Serial port
Dedicated BMC LAN Accepts an RJ45 type cable and has two LED indicators
USB Two USB 3.2 Gen 1 ports and two USB 2.0 ports
LAN LAN port; when speed indicator is green, connection is 100 Mb/s
VGA Video port
Unit Identier Switch/
UID LED Indicator UID switch and LED (see Control Panel description)
1
PWS2
Dedicated BMC LAN
USB Ports
LAN2
VGA Port
LAN1
3
UID Switch/LED
2
COM1
PWS1

13
Chapter 1: Introduction
Top View
Figure 1-4. System: Top View
System Features: Top
Feature Description
USB 3.2 Gen 1 ports Type A USB ports
Power Supply Dual redundant modules; see option below
DIMM slots Dual in-line memory module (DIMMs) slots
Processor Single Intel Xeon Scalable Processor
System fans 4-cm counter-rotating fans used to provide cooling for the system
USB 3.2 Gen 1 Ports
DIMM Slots
System Fans
Single Processor
Power Supply Modules

14
Chapter 1: Introduction
Power Supply Option
DC Power Supply Module Option
Watts Part Number 80Plus Level
650 PWS-654-1R N/A

15
Chapter 1: Introduction
1.3 System Architecture
This section covers the locations of the system electrical components, a cable routing diagram,
and block diagrams of the motherboard and the overall system.
Figure 1-5. Main Component Locations
Storage Backplane
BPN-SAS3-LB16A-N10
Power Supplies
3rd Generation Intel Xeon
Scalable Processor
PCIe Exapnsion Slots
Fans
DIMM Slots

16
Chapter 1: Introduction
Figure 1-6. System Block Diagram
System Block Diagram
The block diagram below shows the connections and relationships between the subsystems
and major components of the overall system.
SPI
LAN3 (To CMM)
RGRMII
Debug Card
PCI-E X1 G2
USB 2.0
#14 USB2.0
PCH
621A
6.0 Gb/S
RTL8211FS-VS-CG
ESPI
Temperature Sensor
W83773G *2 (RT1/RT2)
TPM HEADER BIOS
SPI
AST2600
BMC
#4
BMC Boot Flash
DDR4
7+1 PHASE
300W
DDR4
VR13HC
DMI3
DDR4
#1DMI3
PVCCIN_CPU1 12V_STBY
CPU1
PECI:30
SOCKET ID:0
#2
DMI X4
PCI-E GEN3 X8
SATA0-1
CPU1-A1
DDR4
CPU1-B1
DDR4
CPU1-C1
2666/2933/3200
DDR4
CPU1-D1
#0
SPI
LBG-1G X1 UPLINK NO QAT (15W)
LAN 10G
X550-AT2
M.2
PCI-E X4
PCI-E X16 G4
2666/2933/3200 2666/2933/3200 2666/2933/3200
PCI-E GEN4 X16
PCI-E GEN3 X8
CPLD
(PFR)
SPI
SPI NAND
FLASH
1G-1UPC1F-1UPC CPU1-H1
DDR4 DDR4 DDR4 DDR4
2666/2933/3200 2666/2933/3200 2666/2933/3200
2666/2933/3200
CPU1-E1
PCI-E X16
WIOR
#3A
PCI-E GEN4 X8 PCI-E GEN4 X8
PCI-E TWO X4 G4
WIOL
PCI-E X32
PCI-E TWO X4 G4
6.0 Gb/S
#1
#0
sSATA
SATA-DOM
Mini SAS HD
SATA #0~7
SSATA0
PCI-E X4 G3
#0~3
PCI-E X4 G3 (SATA X1)
#8~11
USB 2.0
USB
USB 3.0
USB
Front USB2.0 x 2
USB 2.0
USB
Rear USB2.0 x 2
Front USB3.2 Gen 1 x 2
USB
USB
Type A USB3.0
Rear USB3.0 x 2
0~15
PCI-E X16 G4
PCI-E X16 G4
#3B
SlimSAS
NVME X2
NVME X2
SlimSAS
I210(LAN1)
PCI-E X1
I210(LAN2)
PCI-E X1
#0
(LANE REVERSE)
#5
SSATA #0~1
(PCIE #6,7)
USB2.0(1,3)
USB2.0(6,12)
USB3.0(3, 4)
USB3.0(6)
USB3.0(1, 2)

17
Chapter 1: Introduction
Figure 1-7. Motherboard Layout
1.4 Motherboard Layout
Below is a layout of the X12SPW-F/TF motherboard with jumper, connector and LED locations
shown. See the table on the following page for descriptions. For detailed descriptions, pinout
information and jumper settings, refer to Chapter 4 or the Motherboard Manual.
BIOS
LICENSE
1
BAR CODE
IPMI CODE
MAC CODE
SAN MAC
DESIGNED IN USA
X12SPW-TF/F
REV: 2.00
JNCSI1
S-SGPIO1
JBT1
JPWR2
JSD2
JSD1
S-SATA1
S-SATA0
JSTBY1
JRK1
JPWR3 JPWR1
JF1
JVRM2
JVRM1
JPFR3
JPFR2
JPFR1
JL1
JD1
JPRG1
JWD1
JP4
FAN6
FAN7
FAN4
FAN3
FAN5
FAN1
BT1
NVME0/1
NVME2/3
MH16
MH15
JPI2C1
JIPMB1
JNVI2C
JI2C_EXP1
MH4
MH6
MH1
MH9
MH5
MH3
MH2
JPME1
JPL2
JMP2
JMP1
JPL1
JPL3
SXB2: PCI-E 4.0 X16
SXB1A SXB1B: PCI-E 4.0 X16 + X16
SXB1C
COM2
I-SATA4~7
M.2-H
COM1
DIMMG1 DIMMH1 DIMME1 DIMMF1
DIMMA1 DIMMB1 DIMMD1 DIMMC1
CPU
USB6/7(3.0)
USB4/5 (3.0)
USB2/3
LAN2 LAN1
CMOS CLEAR
I-SATA0~3
TPM/PORT80
UID-SW
UID-LED
VGA
USB0/1
BMC_LAN
USB8(3.0)
LE3
LEDBMC
LE4
FAN2
DIMMC1
DIMMD1
DIMMA1
DIMMB1
DIMMF1
DIMME1
DIMMH1
DIMMG1
COM2
JPWR2
JL1
FAN7
SXB1A
VGA LAN2 LAN1
USB4/5 (3.2)
BMC_LAN COM1
JVRM1
JVRM2
FAN1
CPU
UID-LED
UID-SW USB0/1
JNCSI1
M.2-H
JSD1
JSD2
S-SATA0
S-SATA1
USB2/3
TPM/PORT80
JRK1
USB6/7(3.0)
USB8(3.0)
JF1
JSTBY1
JPI2C1
JPWR3
JPWR1
SXB2
SXB1B
LEDBMC
JIPMB1
JPME1
I-SATA0~3
SXB1C
S-SGPIO1
JNVI2C
JI2C_EXP1
NVME2/3
FAN6 FAN5 FAN4 FAN3 FAN2
NVME0/1
I-SATA4~7
JPL1
JPL3
JPL2
BT1
JBT1

18
Chapter 1: Introduction
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPL1 LAN1 Enable/Disable (I210, -F only) Pins 1-2 (Enabled)
JPL2 LAN2 Enable/Disable (I210, -F only) Pins 1-2 (Enabled)
JPL3 LAN1/2 Enable/Disable (X550, -TF only) Pins 1-2 (Enabled)
JPME1 ME Manufacturing Mode Pins 1-2 (Normal)
LED Description Status
LE3 Power LED Solid Green: Power On
LE4 M.2 HDD LED Blinking Green: Device Working
LEDBMC BMC Heartbeat LED Blinking Green: BMC Normal
UID-LED Unit Identier (UID) LED Solid Blue: Unit Identied
Connector Description
BT1 Onboard CMOS Battery
COM1, COM2 COM Port, COM Header
FAN1 ~ FAN7 CPU/System Fan Headers
BMC_LAN Dedicated BMC LAN Port
I-SATA0 ~ I-SATA7 Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
JF1 Front Control Panel Header
JI2C_EXP1 4-pin BMC External I2C Header (for internal testing only)
JIPMB1 4-pin BMC External I2C Header
JL1 Chassis Intrusion Header
JNCSI1 NC-SI Header for BMC Support
JNVI2C NVMe I2C Header
JPI2C1 Power System Management Bus (SMB) I2C Header
JPWR1 8-pin Power Connector
JPWR2 4-pin Power Connector
JPWR3 24-pin ATX Power Connector
JRK1 Intel RAID Key Header
JSD1, JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JVRM1, JVRM2 SMBus Clock/DATA header connected to CPU/Mem VRMs
LAN1, LAN2 LAN (RJ45) Ports
M.2-H M.2 PCIe 3.0 x4 Slot (Supports M-Key 2280 and 22110)
NVME0/1, NVME2/3 PCIe 4.0 x8 Slimline SAS Connector
SXB1A, SXB1B, SXB1C Supermicro Proprietary WIO Left Add-on Card Slots

19
Chapter 1: Introduction
Connector Description
SXB2 Supermicro Proprietary WIO Right Add-on Card Slot
S-SATA0, S-SATA1 SATA 3.0 Ports with SATA DOM Power
S-SGPIO1 Serial Link General Purpose I/O Connection Header
TPM Trusted Platform Module/Port 80 Connector
UID-SW Unit Identier (UID) Switch
USB0/1 Back Panel Universal Serial Bus (USB) 2.0 Ports
USB2/3 Front Accessible USB 2.0 Headers
USB4/5 (3.2 Gen 1) Back Panel USB 3.2 Gen 1 Ports
USB6/7 (3.2 Gen 1) Front Accessible USB 3.2 Gen 1 Header
USB8 (3.2 Gen 1) USB 3.2 Gen 1 Type-A Header
VGA VGA Port

20
Chapter 2: Server Installation
Chapter 2
Server Installation
2.1 Overview
This chapter provides advice and instructions for mounting your system in a server rack.
If your system is not already fully integrated with processors, system memory etc., refer to
Chapter 3 for details on installing those specic components.
Caution: Electrostatic Discharge (ESD) can damage electronic components. To prevent such
damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle
all PCBs by their edges and keep them in anti-static bags when not in use.
2.2 Unpacking the System
Inspect the box in which the system was shipped, and note if it was damaged. If any equipment
appears damaged, le a claim with the carrier.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic elds are generated. It will also require a grounded AC power outlet nearby.
Be sure to read the precautions and considerations noted in Appendix A.
2.3 Preparing for Setup
The box in which the system was shipped should include the rackmount hardware needed to
install it into the rack. Please read this section in its entirety before you begin the installation.
Choosing a Setup Location
• The system should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic elds are generated.
• Leave enough clearance in front of the rack so that you can open the front door completely
(~25 inches) and approximately 30 inches of clearance in the back of the rack to allow
su󰀩cient space for airow and access when servicing.
• This product should be installed only in a Restricted Access Location (dedicated equipment
rooms, service closets, etc.).
