Supero SUPER P6DBS User manual

®
SUPER P6DBS
SUPER P6DBE
SUPER P6DBU
SUPER P6SBU
SUPER P6SBS
SUPER P6SBA
USER’S AND BIOS
MANUAL
Revision 2.2
SUPER

The information in this User’s Manual has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be contained
in this document, makes no commitment to update or to keep current the information in this
manual, or to notify any person or organization of the updates. Please Note: For the
most up-to-date version of this manual, please see our web site at
www.supermicro.com.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in
this manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF THE REPAIRING, REPLACING, OR RECOVERING
SUCH HARDWARE, SOFTWARE, OR DATA.
Unless you request and receive written permission from SUPERMICRO COMPUTER, you may
not copy any part of this document.
Information in this document is subject to change without notice. Other products and
companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 1998 by SUPERMICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America.

Preface
About This Manual
This manual is written for system houses, PC technicians and
knowledgeable PC end users. It provides information for the installation and
use of SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA motherboard.
SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA supports Pentium II
400/350/333/300/266/233 MHz.
The Pentium II processor with the Dual Independent Bus Architecture is
housed in a new package technology called the Single Edge Contact (S.E.C.)
cartridge. This new cartridge package and its associated "Slot 1" infrastruc-
ture will provide the headroom for future high-performance processors.
Manual Organization
Chapter 1, Introduction, describes the features, specifications and perfor-
mance of the SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA system
board, provides detailed information about the chipset, and offers warranty
information.
Refer to Chapter 2, Installation, for instructions on how to install the Pentium
II processor, the retention mechanism, and the heat sink support. This chap-
ter provides you with the instructions for handling static-sensitive devices.
Read this chapter when you want to install DIM modules and to mount the
system board in the chassis. Also refer to this chapter to connect the floppy
and hard disk drives, IDE interfaces, parallel port, serial ports, as well as the
cables for the power supply, reset cable, Keylock/Power LED, speaker and
keyboard.
If you encounter any problem, please see Chapter 3, Troubleshooting, which
describes troubleshooting procedures for video, memory, and the setup con-
figuration stored in memory. For quick reference, a general FAQ [frequently
asked questions] is provided. Instructions are also included for technical
support procedure, for returning merchandise for service and for BIOS up-
grades using our BBS#.
See Chapter 4 for configuration data and BIOS features.
iii

SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA User’s Manual
Chapter 5 has information on running setup and includes default settings for
Standard Setup, Advanced Setup, Chipset function, Power Management, PCI/
PnP Setup and Peripheral Setup.
Appendix A offers information on BIOS error beep codes and messages.
Appendix B shows post diagnostic error messages.
iv
