USER’S MANUAL
Revision 1.0
X9DRD-7JLN4F
X9DRD-7LN4F

Manual Revision 1.0
Release Date: May 16, 2012
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2012 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between the manufacturer and the customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of Santa Clara
shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Preface
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of the
X9DRD-7JLN4F/X9DRD-7LN4F motherboard.
About This Motherboard
The Super X9DRD-7JLN4F/X9DRD-7LN4F motherboard supports dual Intel E5-
2600 (Socket R) Series Processors that offer QPI (Intel QuickPath Interface)
Technology (V.1.1), providing point-to-point connection with a transfer speed of up
to 8.0 TG/s. With the C602J built in, the X9DRD-7JLN4F/-7LN4F motherboard sup-
ports Intel® Manageability Engine (ME), Rapid Storage Technology, Digital Media
Interface (DMI), PCI-E Gen. 3.0 and 1600 MHz DDR3 memory. This motherboard
is ideal for high-end server platforms. Please refer to our website (http://www.su-
permicro.com) for CPU and memory support updates.
Manual Organization
Chapter 1 describes the features, specications and performance of the mother-
board. It also provides detailed information about the Intel C602J chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory, and system setup stored in CMOS.
Chapter 4 includes an introduction to BIOS, and provides detailed information on
running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists Software Installation Instructions.
Preface
iii

iv
Conventions Used in the Manual
Pay special attention to the following symbols for proper system installation and to
prevent damage to the system or injury to yourself:
Danger/Caution: Instructions to be strictly followed to prevent catastrophic
system failure or to avoid bodily injury
Warning: Important information given to ensure proper system installation
or to prevent damage to the components
Note: Additional information given to differentiate between various models
or provides information for correct system setup.
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual

Preface
v
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacic
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Website: www.supermicro.com.tw
Email: [email protected] (Technical Support)
Tel: [phone] (Technical Support)

vi
Table of Contents
Preface
Chapter 1 Overview
1-1 Overview ......................................................................................................... 1-1
1-2 Processor and Chipset Overview...................................................................1-11
1-3 Special Features ........................................................................................... 1-12
1-4 PC Health Monitoring.................................................................................... 1-12
1-5 ACPI Features............................................................................................... 1-13
1-6 Power Supply ................................................................................................ 1-13
1-7 Super I/O....................................................................................................... 1-14
1-8 Advanced Power Management..................................................................... 1-14
Intel®Intelligent Power Node Manager (IPNM) ............................................ 1-14
Manageability Engine (ME)........................................................................... 1-15
1-9 Overview of the Nuvoton WPCM450 Controller ........................................... 1-15
Other Features Supported by the WPCM BMC Controller........................... 1-15
Chapter 2 Installation
2-1 Static-Sensitive Devices.................................................................................. 2-1
Precautions ..................................................................................................... 2-1
Unpacking ....................................................................................................... 2-1
2-2 Processor and Heatsink Installation................................................................ 2-2
Installing the LGA2011 Processor ................................................................. 2-2
Installing a Passive CPU Heatsink ................................................................. 2-6
Removing the Heatsink................................................................................... 2-7
2-3 Installing and Removing the Memory Modules............................................... 2-8
Installing & Removing DIMMs......................................................................... 2-8
Removing Memory Modules ........................................................................... 2-8
2-4 Motherboard Installation................................................................................ 2-12
Tools Needed ................................................................................................ 2-12
Location of Mounting Holes .......................................................................... 2-12
Installing the Motherboard ............................................................................ 2-13
2-5 Control Panel Connectors and I/O Ports ...................................................... 2-14
Back Panel Connectors and I/O Ports.......................................................... 2-14
Back Panel I/O Port Locations and Denitions ........................................... 2-14
Serial Ports............................................................................................... 2-15
Video Connection ..................................................................................... 2-15
Universal Serial Bus (USB)...................................................................... 2-16
Ethernet Ports .......................................................................................... 2-17
Unit Identier Switch/UID LED Indicators ................................................ 2-18
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual

vii
Table of Contents
Front Control Panel....................................................................................... 2-19
Front Control Panel Pin Denitions............................................................... 2-20
NMI Button ............................................................................................... 2-20
Power LED .............................................................................................. 2-20
HDD LED.................................................................................................. 2-21
NIC1/NIC2 LED Indicators ....................................................................... 2-21
Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-22
Power Fail LED ........................................................................................ 2-22
Reset Button ........................................................................................... 2-23
Power Button ........................................................................................... 2-23
2-6 Connecting Cables........................................................................................ 2-24
Power Connectors ................................................................................... 2-24
Fan Headers............................................................................................. 2-25
Chassis Intrusion ..................................................................................... 2-25
Internal Speaker ....................................................................................... 2-26
Power LED/Speaker................................................................................. 2-26
TPM Header/Port 80 ................................................................................ 2-27
Overheat LED/Fan Fail ............................................................................ 2-27
Power SMB (I2C) Connector .................................................................... 2-28
IPMB......................................................................................................... 2-28
T-SGPIO 1/2 Headers .............................................................................. 2-29
DOM Power Connector ............................................................................ 2-29
Standby Power Header ............................................................................ 2-30
LAN3/LAN4 LED Indicators...................................................................... 2-30
2-7 Jumper Settings ............................................................................................ 2-31
Explanation of Jumpers ................................................................................ 2-31
GLAN Enable/Disable .............................................................................. 2-31
CMOS Clear ............................................................................................. 2-32
Watch Dog Enable/Disable ...................................................................... 2-32
VGA Enable.............................................................................................. 2-33
BMC Enable ............................................................................................ 2-33
I2C Bus to PCI-Exp. Slots ........................................................................ 2-34
2-8 Onboard LED Indicators ............................................................................... 2-35
GLAN LEDs.............................................................................................. 2-35
IPMI Dedicated LAN LEDs....................................................................... 2-35
Onboard Power LED ............................................................................... 2-36
BMC Heartbeat LED ................................................................................ 2-36
Unit Identication Switch/LED .................................................................. 2-37
2-9 SATA/SAS Connections ................................................................................ 2-38

viii
Serial ATA Ports........................................................................................ 2-38
SAS2 Ports .............................................................................................. 2-38
Chapter 3 Troubleshooting
3-1 Troubleshooting Procedures ........................................................................... 3-1
Before Power On ............................................................................................ 3-1
No Power ........................................................................................................ 3-1
No Video ......................................................................................................... 3-2
System Boot Failure ..................................................................................... 3-2
Losing the System’s Setup Conguration....................................................... 3-2
Memory Errors ............................................................................................... 3-3
When the System Becomes Unstable ............................................................ 3-3
3-2 Technical Support Procedures ........................................................................ 3-5
3-3 Battery Removal and Installation .................................................................... 3-6
Battery Removal.............................................................................................. 3-6
Proper Battery Disposal .................................................................................. 3-6
Battery Installation........................................................................................... 3-6
3-4 Frequently Asked Questions ........................................................................... 3-7
3-5 Returning Merchandise for Service................................................................. 3-8
Chapter 4 BIOS
4-1 Introduction...................................................................................................... 4-1
Starting BIOS Setup Utility.............................................................................. 4-1
How To Change the Conguration Data ......................................................... 4-2
Starting the Setup Utility ................................................................................. 4-2
4-2 Main Setup ...................................................................................................... 4-2
4-3 Advanced Setup Congurations...................................................................... 4-4
4-4 Event Logs .................................................................................................... 4-25
4-5 IPMI............................................................................................................... 4-27
4-6 Boot............................................................................................................... 4-29
4-7 Security .........................................................................................................4-30
4-8 Save & Exit ................................................................................................... 4-31
Appendix A BIOS Error Beep Codes
A-1 BIOS Error Beep Codes .................................................................................A-1
Appendix B Software Installation Instructions
B-1 Installing Software Programs ..........................................................................B-1
B-2 Conguring SuperDoctor III ............................................................................B-2
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual

Chapter 1: Overview
1-1
Chapter 1
Overview
1-1 Overview
Checklist
Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance.
Please check that the following items have all been included with your motherboard.
If anything listed here is damaged or missing, contact your retailer.
The following items are included in the retail box.
•One (1) Supermicro Mainboard
•Two (2) Serial ATA cables (CBL-0044Lx2)
•Two (2) I-Pass to 4 Serial ATA (50-cm) cables (CBL-097L-02)
•One (1) I/O Shield (MCP-260-00042-0N)
•One (1) User's/BIOS Manual (MNL#1318)

1-2
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual
Motherboard Image
Note: All graphics shown in this manual were based upon the latest PCB
Revision available at the time of publishing of the manual. The motherboard
you've received may or may not look exactly the same as the graphics
shown in this manual.

Chapter 1: Overview
1-3
Motherboard Layout
Note: For the latest CPU/Memory updates, please refer to our website at
http://www.supermicro.com/products/motherboard/ for details.
JPME1
JI2C1
VGA1
I-SATA1
I-SATA0
I-SATA5
I-SATA4
I-SATA3
I-SATA2
JIPMB1
JPME2
JPL1
JBR1
JWD1
JPG1
JPB1
JVRM_I2C1
JVRM_I2C2
JVR1
FAN5
FAN6
FAN8 FAN7
FAN1
FAN2
FAN3
FAN4
JF2
T-SGPIO1
T-SGPIO2
JUSB6
JSD1
JBT1
JBAT1
JTPM1
JF1
JPI2C1
JOH1
JI2C2
JL1
JSTBY1
JUIDB
J4
JD1
LED3
LEDM1
LED2
LAN2/4 LAN1/3
CPU1
CPU2
CPU2
CPU1
CPU2
CPU1
PWR I2C
UID
P2-DIMME1 P2-DIMMF2 P2-DIMMF1
P2-DIMMG2
P2-DIMMG1
P2-DIMMH2 P2-DIMMH1
P1-DIMMA2
P1-DIMMA1
P1-DIMMB2
P1-DIMMB1
P1-DIMMC1 P1-DIMMC2
P1-DIMMD1
P1-DIMMD2
USB4/5USB8/9
SLOT1 PCI-E 3.0 X8
SLOT2 PCI-E 3.0 X8
SLOT3 PCI-E 3.0 X8
SLOT4 PCI-E 3.0 X8
SLOT5 PCI-E 3.0 X8
USB6
TPM/PORT80
BUZZER
CMOS CLEAR
SLOT6 PCI-E 3.0 X8
COM2
USB2/3
COM1
USB0/1
SP1
CPU2
IPMI_LAN
CPU2
CPU2
Battery
BIOS
JPW1
JPW2
24-Pin Main PWR
8-Pin PWR
JPW4
P2-DIMME2
JPW3
8-Pin PWR
4-Pin PWR
L-SAS4~7 L-SAS0~3
LSI SAS CTRL
Intel
PCH
JPS1
LAN
CTRL
BMC
CPU1
X9DRD-7(J)LN4F
Rev. 1.01

1-4
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual
Notes:
•See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front panel
connections. " " indicates the location of "Pin 1".
•Jumpers/LED Indicators not indicated are for testing only. Also, components that
are not documented in this manual are reserved for internal use only.
•Use only the correct type of onboard CMOS battery as specied by the
manufacturer. Do not install the onboard battery upside down to avoid possible
explosion.
X9DRD-7JLN4F/-7LN4F Quick Reference
JP2 Manufacture (ME) Mode Pins 1-2 (Normal)
JPME1 ME Recovery Pins 1-2 (Normal)
JVRMI2C1/
JVRMI2C2
CPU1/CPU2 VRM SMbus Enable Pins 1-2 (Normal)
JPME1
JI2C1
VGA1
I-SATA1
I-SATA0
I-SATA5
I-SATA4
I-SATA3
I-SATA2
JIPMB1
JPME2
JPL1
JBR1
JWD1
JPG1
JPB1
JVRM_I2C1
JVRM_I2C2
JVR1
FAN5
FAN6
FAN8 FAN7
FAN1
FAN2
FAN3
FAN4
JF2
T-SGPIO1
T-SGPIO2
JUSB6
JSD1
JBT1
JBAT1
JTPM1
JF1
JPI2C1
JOH1
JI2C2
JL1
JSTBY1
JUIDB
J4
JD1
LED3
LEDM1
LED2
LAN2/4 LAN1/3
CPU1
CPU2
CPU2
CPU1
CPU2
CPU1
PWR I2C
UID
P2-DIMME1 P2-DIMMF2 P2-DIMMF1
P2-DIMMG2
P2-DIMMG1
P2-DIMMH2 P2-DIMMH1
P1-DIMMA2
P1-DIMMA1
P1-DIMMB2
P1-DIMMB1
P1-DIMMC1 P1-DIMMC2
P1-DIMMD1
P1-DIMMD2
USB4/5USB8/9
SLOT1 PCI-E 3.0 X8
SLOT2 PCI-E 3.0 X8
SLOT3 PCI-E 3.0 X8
SLOT4 PCI-E 3.0 X8
SLOT5 PCI-E 3.0 X8
USB6
TPM/PORT80
BUZZER
CMOS CLEAR
SLOT6 PCI-E 3.0 X8
COM2
USB2/3
COM1
USB0/1
SP1
CPU2
IPMI_LAN
CPU2
CPU2
Battery
BIOS
JPW1
JPW2
24-Pin Main PWR
8-Pin PWR
JPW4
P2-DIMME2
JPW3
8-Pin PWR
4-Pin PWR
L-SAS4~7 L-SAS0~3
LSI SAS CTRL
Intel
PCH
JPS1
LAN
CTRL
BMC
CPU1
X9DRD-7(J)LN4F
Rev. 1.01

Chapter 1: Overview
1-5
X9DRD-7JLN4F/-7LN4F Jumpers
Jumper Description Default Setting
JBT1 Clear CMOS See Chapter 3
JI2C1/JI2C2 SMB to PCI-E Slots Off (Disabled)
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPS1 SAS Enabled Pins 1-2 (Enabled)
JVRMI2C1/2 CPU1/2 VRM I2C Bus Pins 2-3 (Manufac-
ture Default)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
X9DRD-7JLN4F/-7LN4F Connectors
Connectors Description
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
FAN1~8 CPU/System Fan Headers
JBAT1 Onboard Battery (See Chpt. 3 for Used Battery Disposal)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JF2 LAN3 (NIC3)/LAN4 (NIC4) LED Indicators
JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JPI2C1 Power Supply SMBbus I2C Header
JPW1 24-Pin ATX Main Power Connector (Warning on Pg. 1-6.)
JPW2/3 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JPW4 12V 4-Pin Power Connectors (See Warning on Pg. 1-6.)
JSD1 SATA DOM (Device on Module) Power Connector
JSTBY1 +5V Standby Power Header
JTPM1 TPM (Trusted Platform Module)/Port 80
JUID UID (Unit Identication) Switch
LAN1/3, LAN2/4 Gigabit Ethernet Ports 1/2, 3/4
(IPMI) LAN IPMI_Dedicated LAN
(I)SATA1~6 Intel SATA Connectors 1~6 from the Intel PCH
(L)SAS0~3, 4~7 Serial_Link SCSI Attached 2.0 Connectors 0~3, 4~7 from
the LSI SAS 2308 Controller
JP2 Manufacture (ME) Mode Pins 1-2 (Normal)
JPME1 ME Recovery Pins 1-2 (Normal)
JVRMI2C1/
JVRMI2C2
CPU1/CPU2 VRM SMbus Enable Pins 1-2 (Normal)
Note: PCI-E slots support Low-Prole MD2 form factor for devices/add-on
cards that are shorter than 167.64mm or 6.59" (in) in length only.

1-6
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual
Warning!
To prevent damage to the power supply or the motherboard, please use a
power supply that contains a 24-pin, a 4-pin, and two 8-pin power connec-
tors. Be sure to connect the power supply to the 24-pin power connector
(JPW1), the 4-pin connector (JPW4), and the two 8-pin power connectors
(JPW2/3) on the motherboard. Failure in doing so will void the manufac-
turer warranty on your power supply and motherboard.
SP1 Onboard Buzzer (Internal Speaker)
(CPU1)Slots1/2/6,
(CPU2)Slot3/4/5
PCI-Express 3.0 x8 Slots (See Note Below)
(T-)SGPIO 1/2 Serial ATA (SATA) General Purpose I/O Header
(BP) USB 0/1, 2/3 Back Panel USB 0/1, 2/3
(FP) USB 4/5, USB 8/9 Front Panel Accessible USB Connections (4/5, 8/9)
(FP) USB 6 Type A USB Embedded Drive Connector
VGA Backpanel VGA Port
X9DRD-7JLN4F/-7LN4F LED Indicators
LED Description State Status
LED2 Standby PWR LED Green: On Standby PWR On
LED3 Rear UID LED Blue: On Unit Identied
LEDM1 BMC Heartbeat LED Green: Blinking BMC Normal

Chapter 1: Overview
1-7
Motherboard Features
CPU • Dual Intel®E5-2600 Series (Socket R-LGA 2011) pro-
cessors; each processor supports two full-width Intel
QuickPath Interconnect (QPI) links (with support of up
to 25.6 GT/s per QPI link and with Data Transfer Rate
of up to 8.0 GT/s per direction)
Memory • Integrated memory controller supports 240-pin Reg-
istered (RDIMM)/Load Reduced (LRDIMM) ECC
or Unbuffered (UDIMM) ECC/Non- ECC DDR3
800/1066/1333/1600 MHz memory modules of up to
512 GB in 16 DIMM modules
Note: For the latest CPU/memory updates, please
refer to our website at http://www.supermicro.com/
products/motherboard.
DIMM sizes
• RDIMM 1GB, 2GB, 4GB, 8GB,16GB and 32GB
@ 1.35V/1.5V
• Virtualization: VT-x, VT-d, and VT-c
Chipset • Intel® C602J Chipset
Expansion • Six (6) PCI Express 3.0 x8 slots (CPU1 Slot1/Slot2/Slot6
and CPU2 Slot3/Slot4/Slot5),
Slots
Graphics • Nuvoton BMC Video Controller (Matrox G200eW)
Network • One Intel I350 Gigabit (10/100/1000 Mb/s) Ethernet
Quad Port Controller for LAN 1/2, 3/4 ports.
• Nuvoton WPCM450 Base-board Controller (BMC) sup-
ports IPMI_LAN 2.0
I/O De-
vices
Serial_Link Connections
• SATA Ports Two (2) SATA 3.0 Ports (I-SATA0/1)
Four (4) SATA 2.0 Ports (I-SATA2~5)
• SAS Con-
nectors
Eight SAS 2.0 Connections (SAS
0~3, 4~7) from LSI 2308 SAS Con-
troller.
• RAID SATA RAID 0, 1, 5, 10 (Windows,
Linux),
SAS RAID 0, 1, 10 (X9DRD-7LN4F
Only)

1-8
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual
Integrated IPMI 2.0
• IPMI 2.0 supported by the WPCM450 BMC
Serial (COM) Port
• Two (2) Fast UART 16550 Connection: 9-pin RS-232
port
Super I/O
• Nuvoton 83527HG
Peripheral
Devices
USB Devices
• Four (4) USB ports on the rear I/O panel (USB 0/1,
USB 2/3),
• Four (4) USB connections for front access (USB 4/5,
USB 8/9),
• One (1) Type A USB connection for front access (USB 6)
BIOS • 128 Mb SPI AMI BIOS®SM Flash BIOS
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0/4.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.7.1
Power • ACPI/APM Power Management
Cong. • Main switch override mechanism
• Power-on mode for AC power recovery
• Intel®Intelligent Power Node Manager (NM) (Available
when the NMView utility is installed in the system)
• Manageability Engine (ME)
PC Health CPU Monitoring
Monitoring • Onboard voltage monitors for CPU Cores, +3.3V,
3.3VSB, +5V, +12V, -12V, VBT, and Memory Voltages
• CPU 6-Phase switching voltage regulator
• CPU/System overheat LED and control
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) support
Fan Control
• Fan status monitoring with rmware fan speed control
via IPMI
• Low noise fan speed control
System
Manage-
ment
• PECI (Platform Environment Conguration Interface)
2.0 support

Chapter 1: Overview
1-9
• UID (Unit Identication)/Remote UID
• System resource alert via SuperDoctor III
• SuperoDoctor III, Watch Dog, NMI
• Chassis Intrusion Header and Detection
Dimen-
sions
• 13.00" (L) x 12.00" (W) (330.20 mm x 340.80 mm)
Note: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.

1-10
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual
System Block Diagram
Note: This is a general block diagram and may not exactly represent the
features on your motherboard. See the Motherboard Features pages for
the actual specications of each motherboard.
X9DRD-7JLN4F/-7LN4F Block Diagram
J23 SLOT#3 PCIE 3.0 x8 J24 SLOT#4 PCIE 3.0 x8 J25 SLOT#5 PCIE 3.0 x8
P0 P1
PE2
(AB)PE2 (CD)
PE1
(AB) DMI
DDR3 DIMM
CPU REAR
PROCESSOR
SANDYBRIDGE
PROCESSOR
SANDYBRIDGE
F
ESocket 01
#2
#1
DDR3 DIMM
#2
#1
PE3
J22 SLOT#2
PCIE 3.0 x8
PCIE 3.0 x8
PCIE 3.0 x8
PCIE 3.0 x4
SAS LSI
LAN1 LAN2
RJ45 RJ45
LAN3 LAN4
VGA CONN
IPMI LAN
PHY
RTL8201F
RJ45 RJ45
SAS2308
Powerville
I350-AM4
Quad GLAN
J26 SLOT#6
L-SAS0~3
L-SAS4~7
J21 SLOT#1
PCIE 3.0 x8
DDR3 DIMM
H
G
#2
#1
DDR3 DIMM
#2
#1
P1 P0
PE2
(AB)PE2 (CD) (AB)(CD)
PE1
(AB) PE3 DMI
PCH C602J
BIOS
SATA
SPI SATA Gen3
6Gbps
SATA Gen3
6Gbps
SATA
SATA [0..1]
SCU0
USB
LPCPCI 32
SPI FLASH
DDR3 DIMM
CPU FRONT
D
CSocket 00
#2
#1
#2
#1
PE3
DDR3 DIMM
B
A
#2
#1
DDR3 DIMM
QPI QPI
#2
#1
I-SATA0 I-SATA1
S-SATA0 S-SATA1 S-SATA2 S-SATA3
REAR
HDR 2X5
0,1
TYPE-A
REAR
2,3
4,5 6 8,9
HDR 2X5
TPM HDR Port 80
HERMON
WPCM450]
NCT7904D
HW Monitor
DDR3
DDR3 DIMM

Chapter 1: Overview
1-11
1-2 Processor and Chipset Overview
Built upon the functionality and the capability of Intel E5-2600 Series (Socket
R) processors and the C602J chipset, the X9DRD-7JLN4F/-7LN4F motherboard
provides the performance and feature sets required for dual processor-based
HPC/Cluster/Database servers.
With support of Intel QuickPath interconnect (QPI) Technology, the X9DRD-
7JLN4F/-7LN4F offers point-to-point serial interconnect interface with a transfer
speed of up to 8.0 GT/s, providing superb system performance.
The C602J chipset provides extensive IO support, including the following func-
tions and capabilities:
•ACPI Power Management Logic Support, Rev. 4.0
•USB host interface with support of up to 9 connections
•Intel Rapid Storage Technology supported
•Intel Virtualization Technology for Directed I/O (Intel VT-d) supported
•Intel Trusted Execution Technology supported
•Serial Peripheral Interface (SPI) Supported
•Digital Media Interface (DMI) supported
•Advanced Host Controller Interface (AHCI) supported

1-12
X9DRD-7JLN4F/X9DRD-7LN4F Motherboard User’s Manual
1-3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will
respond when AC power is lost and then restored to the system. You can choose for
the system to remain powered off (in which case you must press the power switch
to turn it back on), or for it to automatically return to the power-on state. See the
Advanced BIOS Setup section for this setting. The default setting is Last State.
1-4 PC Health Monitoring
This section describes the features of PC health monitoring of the motherboard.
This motherboard has an onboard System_Hardware_Monitor chip that supports
PC health monitoring. An onboard voltage monitor will scan voltages and power
usage continuously. Once a voltage becomes unstable, a warning is given, or an
error message is sent to the screen. The user can adjust the voltage thresholds to
dene the sensitivity of the voltage monitor.
Fan Status Monitor with Firmware Control
The PC health monitoring chip can check the RPM status of a cooling fan. The
onboard CPU and chassis fans are controlled by rmware Thermal Management
via IPMI 2.0.
Environmental Temperature Control
A thermal control sensor monitors the CPU temperature in real time and will turn
on the thermal control fan whenever the CPU temperature exceeds a user-dened
threshold. The thermal management runs independently from the CPU. Once it
detects that the CPU temperature is too high, it will automatically turn on the ther-
mal fan control to prevent the CPU from overheating. The onboard chassis thermal
circuitry can monitor the overall system temperature and alert the user when the
chassis temperature is too high.
Note: To avoid possible system overheating, please be sure to provide
adequate airow to your system.
System Resource Alert
This feature is available when used with SuperDoctor III in the Windows OS
environment or used with SuperDoctor II in Linux. SuperDoctor is used to notify
the user of certain system events. For example, you can congure SuperDoctor
