Supero X9DRX+-F User manual

USER’S MANUAL
Revision 1.1
X9DRX+-F

Manual Revision 1.1
Release Date: October 30, 2013
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2013 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our Website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between the manufacturer and the customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of Santa Clara
shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Preface
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of the
X9DRX+-F motherboard.
About This Motherboard
The Super X9DRX+-F motherboard supports dual Intel E5-2600(v2) Series Proces-
sors (Socket R LGA 2011) that offer QPI (Intel QuickPath Interface) Technology
(V.1.1), providing point-to-point connection with a transfer speed of up to 8.0 TG/s.
With the C602 chipset built in, the X9DRX+-F motherboard supports Intel Rapid
Storage Technology, Digital Media Interface (DMI), PCI-E Gen. 3.0 and up to 1866
MHz DDR3 memory. This motherboard is ideal for HPC/Cluster/Database server
platforms. Please refer to our Website (http://www.supermicro.com) for CPU and
memory support updates.
Manual Organization
Chapter 1 describes the features, specications and performance of the mother-
board, and provides detailed information about the Intel C602 chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory, and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists Software Installation Instructions.
Preface
iii

iv
Conventions Used in the Manual
Pay special attention to the following symbols for proper system installation and to
prevent damage to the system or injury to yourself:
Warning: Important information given to ensure proper system installation or to prevent
damage to the components
Note: Additional information given to differentiate between various models
or provides information for correct system setup.
X9DRX+-F Motherboard User’s Manual

Preface
v
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 23511
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]

vi
Table of Contents
Preface
Chapter 1 Overview
1-1 Overview ......................................................................................................... 1-1
1-2 Processor and Chipset Overview...................................................................1-11
1-3 Special Features ........................................................................................... 1-12
1-4 PC Health Monitoring.................................................................................... 1-12
1-5 ACPI Features............................................................................................... 1-13
1-6 Power Supply ................................................................................................ 1-13
1-7 Serial Port Connection Support .................................................................... 1-14
1-8 Advanced Power Management..................................................................... 1-14
Intel®Intelligent Power Node Manager (NM) (Available when the NMView
utility is installed in the system) .................................................................... 1-14
Management Engine (ME) ............................................................................ 1-15
1-9 Overview of the Nuvoton WPCM450 Controller ........................................... 1-15
Other Features Supported by the WPCM BMC Controller........................... 1-15
Chapter 2 Installation
2-1 Standardized Warning Statements ................................................................. 2-1
Battery Handling.............................................................................................. 2-1
Product Disposal ............................................................................................. 2-3
2-2 Static-Sensitive Devices.................................................................................. 2-4
Precautions ..................................................................................................... 2-4
Unpacking ....................................................................................................... 2-4
2-3 Processor and Heatsink Installation................................................................ 2-5
Installing the LGA2011 Processor ................................................................. 2-5
Installing a Passive CPU Heatsink ................................................................. 2-9
Removing the Heatsink................................................................................. 2-10
2-4 Installing and Removing the Memory Modules..............................................2-11
Installing & Removing DIMMs........................................................................2-11
Removing Memory Modules ..........................................................................2-11
2-5 Motherboard Installation................................................................................ 2-16
Tools Needed ................................................................................................ 2-16
Location of Mounting Holes .......................................................................... 2-16
Installing the Motherboard ............................................................................ 2-17
2-6 Control Panel Connectors and I/O Ports ...................................................... 2-18
Back Panel Connectors and I/O Ports.......................................................... 2-18
Back Panel I/O Port Locations and Denitions ........................................... 2-18
Serial Ports............................................................................................... 2-19
X9DRX+-F Motherboard User’s Manual

vii
Table of Contents
Video Connection ..................................................................................... 2-19
Universal Serial Bus (USB)...................................................................... 2-20
Ethernet Ports .......................................................................................... 2-21
Unit Identier Switch ................................................................................ 2-22
Front Control Panel....................................................................................... 2-23
Front Control Panel Pin Denitions............................................................... 2-24
NMI Button ............................................................................................... 2-24
Power LED .............................................................................................. 2-24
HDD LED.................................................................................................. 2-25
NIC1/NIC2 LED Indicators ....................................................................... 2-25
Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-26
Power Fail LED ........................................................................................ 2-26
Reset Button ........................................................................................... 2-27
Power Button ........................................................................................... 2-27
2-7 Connecting Cables........................................................................................ 2-28
Power Connectors ................................................................................... 2-28
Fan Headers............................................................................................. 2-29
Chassis Intrusion ..................................................................................... 2-29
Internal Speaker ....................................................................................... 2-30
Power LED/Speaker................................................................................. 2-30
TPM Header/Port 80 Header ................................................................... 2-31
Overheat LED/Fan Fail ............................................................................ 2-31
Power SMB (I2C) Connector .................................................................... 2-32
System Management Bus Header ........................................................... 2-32
3-SGPIO 1/2/3 Headers ........................................................................... 2-33
SATA Device Power Connector................................................................ 2-33
Standby Power ......................................................................................... 2-34
2-8 Jumper Settings ............................................................................................ 2-35
Explanation of Jumpers ................................................................................ 2-35
GLAN Enable/Disable .............................................................................. 2-35
CMOS Clear ............................................................................................. 2-36
Watch Dog Enable/Disable ...................................................................... 2-36
VGA Enable.............................................................................................. 2-37
BMC Enable ............................................................................................ 2-37
Management Engine (ME) Recovery ...................................................... 2-38
Manufacture Mode Select ........................................................................ 2-38
2-9 Onboard LED Indicators ............................................................................... 2-40
GLAN LEDs.............................................................................................. 2-40
IPMI Dedicated LAN LEDs....................................................................... 2-40

viii
Onboard Power LED ............................................................................... 2-41
BMC Heartbeat LED ................................................................................ 2-41
Unit Identication LED.............................................................................. 2-42
2-9 Serial ATA Connections................................................................................. 2-43
Serial ATA Ports........................................................................................ 2-43
Chapter 3 Troubleshooting
3-1 Troubleshooting Procedures ........................................................................... 3-1
3-2 Technical Support Procedures ........................................................................ 3-5
3-3 Battery Removal and Installation .................................................................... 3-6
3-4 Frequently Asked Questions ........................................................................... 3-7
3-5 Returning Merchandise for Service................................................................. 3-8
Chapter 4 BIOS
4-1 Introduction...................................................................................................... 4-1
4-2 Main Setup ...................................................................................................... 4-2
4-3 Advanced Setup Congurations...................................................................... 4-4
4-4 Event Logs .................................................................................................... 4-25
4-5 IPMI...............................................................................................................4-27
4-6 Boot............................................................................................................... 4-29
4-7 Security .........................................................................................................4-30
4-8 Save & Exit ................................................................................................... 4-31
Appendix A BIOS Error Beep Codes
A-1 BIOS Error Beep Codes .................................................................................A-1
Appendix B Software Installation Instructions
B-1 Installing Software Programs ..........................................................................B-1
B-2 Conguring SuperDoctor® III..........................................................................B-2
X9DRX+-F Motherboard User’s Manual

Chapter 1: Overview
1-1
Chapter 1
Overview
1-1 Overview
Checklist
Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance.
Please check that the following items have all been included with your motherboard.
If anything listed here is damaged or missing, contact your retailer.
The following items are included in the retail box.
•One (1) Supermicro Mainboard
•Six (6) Serial ATA cables (CBL-0044L)
•One (1) Quick Reference Guide (MNL-1323-QRG)
Note: For your system to work properly, please follow the links below to
download all necessary drivers/utilities and the user's manual for your
motherboard.
SMCI product manuals: http://www.supermicro.com/support/manuals/
Product Drivers and utilities: ftp://ftp.supermicro.com/
If you have any questions, please contact our support team at support@supermicro.
com.

1-2
X9DRX+-F Motherboard User’s Manual
Motherboard Image
Note: All graphics shown in this manual were based upon the latest PCB
Revision available at the time of publishing of the manual. The motherboard
you've received may or may not look exactly the same as the graphics
shown in this manual.

Chapter 1: Overview
1-3
Note 1: For the latest CPU/Memory updates, please refer to our Website
at http://www.supermicro.com/products/motherboard/ for details.
Note 2: Changing BMC log-in information is recommended during initial
system power-on. The default username is ADMIN and password is
ADMIN. For BMC best practices, please refer to: http://www.supermicro.
com/products/nfo/les/IPMI/Best_Practices_BMC_Security.pdf
Motherboard Layout
S-SATA0
S-SATA1
S-SATA2
S-SATA3
I-SATA0
FAN/PCH
SP1
JSD1
JPI2C1
JPW4
JITP2
BIOS
LED3
FAN8/CPU2
FAN7/CPU1
FAN6
FAN5
FAN1
FANA
FAN4
FAN3
FANB
JVRM_I2C2
JVRM_I2C1
JPG1 JPL1JPB1 JWD1
JPW1
J4
JPW3 JPW2
3-SPGPIO3
3-SPGPIO1
3-SPGPIO2
JIPMI1
JF1
JI2C1
JI2C2
JL1
JOH1
JD1
JSTBY1
JTPM1
JBAT1
(IN X8)
KB/MOUSE
USB2/3
IPMI_LAN
TPM/PORT80
CPU2 Slot 7 PCI-E 3.0 x 8
CPU2 Slot 5 PCI-E 3.0 x 8
CPU1 Slot 3 PCI-E 3.0 x 8
CPU1 Slot 1 PCI-E 3.0 x 8
USB8/9
USB6/7
P2-DIMMG1
P2-DIMMH2
P2-DIMMH1
P2-DIMMG2
P2-DIMME2
P2-DIMME1
P2-DIMMF2
P2-DIMMF1
P1-DIMMD1
P1-DIMMC2
P1-DIMMC1
P1-DIMMD2
P1-DIMMA1
P1-DIMMA2
P1-DIMMB1
CPU1 Slot 2 PCI-E 3.0 x 8
CPU1 Slot 4 PCI-E 3.0 x 8
CPU2 Slot 6 PCI-E 3.0 x 8
CPU1 Slot 8 PCI-E 3.0 x 8
CPU2 Slot 9 PCI-E 3.0 x 8
CPU2 Slot 10 PCI-E 3.0 x 8
CPU2 Slot 11 PCI-E 2.0 x 4
P1-DIMMB2
COM2
UID VGA
LAN2 LAN1
COM1
I-SATA2
I-SATA4
I-SATA1
I-SATA3
I-SATA5
JPT1
USB4 USB5
JITP1
LED1
BMC CTRL
LAN
CTRL
FAN2
LED2
JBT1
X9DRX+-F
Rev. 1.02
PCH
USB0/1
CPLD
BMC Firmware
Clock Chip
JPME1
JPME2
CPU1
CPU2

1-4
X9DRX+-F Motherboard User’s Manual
Notes:
•See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front
panel connections.
•" " indicates the location of "Pin 1".
•Jumpers/LED Indicators not indicated are for testing only. Components that are
not documented in this manual are reserved for internal use only.
•Use only the correct type of onboard CMOS battery as specied by the manufac-
turer. Do not install the onboard battery upside down to avoid possible explosion.
X9DRX+-F Quick Reference
S-SATA0
S-SATA1
S-SATA2
S-SATA3
I-SATA0
FAN/PCH
SP1
JSD1
JPI2C1
JPW4
JITP2
BIOS
LED3
FAN8/CPU2
FAN7/CPU1
FAN6
FAN5
FAN1
FANA
FAN4
FAN3
FANB
JVRM_I2C2
JVRM_I2C1
JPG1 JPL1JPB1 JWD1
JPW1
J4
JPW3 JPW2
3-SPGPIO3
3-SPGPIO1
3-SPGPIO2
JIPMI1
JF1
JI2C1
JI2C2
JL1
JOH1
JD1
JSTBY1
JTPM1
JBAT1
(IN X8)
KB/MOUSE
USB2/3
IPMI_LAN
TPM/PORT80
CPU2 Slot 7 PCI-E 3.0 x 8
CPU2 Slot 5 PCI-E 3.0 x 8
CPU1 Slot 3 PCI-E 3.0 x 8
CPU1 Slot 1 PCI-E 3.0 x 8
USB8/9
USB6/7
P2-DIMMG1
P2-DIMMH2
P2-DIMMH1
P2-DIMMG2
P2-DIMME2
P2-DIMME1
P2-DIMMF2
P2-DIMMF1
P1-DIMMD1
P1-DIMMC2
P1-DIMMC1
P1-DIMMD2
P1-DIMMA1
P1-DIMMA2
P1-DIMMB1
CPU1 Slot 2 PCI-E 3.0 x 8
CPU1 Slot 4 PCI-E 3.0 x 8
CPU2 Slot 6 PCI-E 3.0 x 8
CPU1 Slot 8 PCI-E 3.0 x 8
CPU2 Slot 9 PCI-E 3.0 x 8
CPU2 Slot 10 PCI-E 3.0 x 8
CPU2 Slot 11 PCI-E 2.0 x 4
P1-DIMMB2
COM2
UID VGA
LAN2 LAN1
COM1
I-SATA2
I-SATA4
I-SATA1
I-SATA3
I-SATA5
JPT1
USB4 USB5
JITP1
LED1
BMC CTRL
LAN
CTRL
FAN2
LED2
JBT1
X9DRX+-F
Rev. 1.02
PCH
USB0/1
CPLD
BMC Firmware
Clock Chip
JPME1
JPME2
CPU1
CPU2

Chapter 1: Overview
1-5
X9DRX+-F Jumpers
Jumper Description Default Setting
JBT1 Clear CMOS See Chapter 2
JI2C1/JI2C2 SMB to PCI-E Slots Off (Disabled)
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME1 Management Engine (ME) Recovery
Mode Enable
Pins 1-2 (Normal)
JPME2 Management Engine (ME) Manufacture
Mode Select
Pins 1-2 (Normal)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
X9DRX+-F Connectors
Connectors Description
BT1 Onboard Battery (See Chpt. 3 for Used Battery
Disposal)
COM1/COM2 Backplane COM Port1/Front Accessible COM2
Header
FAN1~8, FANA, FANB CPU/System (4-Pin) Fan Headers (FAN7/FAN8:
CPU 1/2 Fans)
FAN PCH 3-Pin PCH Fan Header
I-SATA 0/1,
S-SATA 0~3
Intel SB SATA 3.0 I-SATA#0/1, S-SATA 2.0 #0~3
I-SATA 2~5 Intel PCH SATA 2.0 Connectors 2~5 (Color: Black)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMI1 4-pin External BMC I2C Header (for an IPMI
Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JPI2C1 Power Supply SMBbus I2C Header
JPW1 ATX 24-Pin Power Connector (See Warning on
Pg. 1-6.)
JPW2/3 12V 8-Pin Power Connectors (See Warning on Pg.
1-6.)
JPW4 12V 4-Pin Power Connector (See Warning on Pg.
1-6.)
JSTBY1 3V Standby Power Header

1-6
X9DRX+-F Motherboard User’s Manual
Warning: To avoid damaging your motherboard and components, please use a
power supply that supports a 24-pin, two 8-pin and one 4-pin power connectors. Be
sure to connect the 24-pin and the 8-pin power connectors to your power supply
for adequate power delivery to your system. The 4-pin power connector is optional;
however, Supermicro recommends that this connector also be plugged in for optimal
power delivery.
JTPM1 TPM (Trusted Platform Module)/Port 80 Header
JSD1 SATA Device Power Connector
Keyboard/Mouse PS2 Keyboard/Mouse
LAN1/LAN2 G-bit Ethernet Ports 1/2
(IPMI) LAN IPMI_Dedicated LAN
SP1 Onboard Buzzer (Internal Speaker)
(CPU1) Slots1~4, Slot8 PCI-Express 3.0 x8 Slots
(CPU2) Slots5~7, Slots 9~10 PCI-Express 3.0 x8 Slots
(CPU2) Slot11 PCI-Express 2.0 x4 in x8 Slot
3-SGPIO 1/2/3 Serial_Link General Purpose I/O Headers
BP USB 0/1, 2/3 Back Panel USB 0/1, 2/3
USB 4, 5 Front Panel Type A USB Connections
USB 6/7, USB 8/9 Front Panel Accessible USB Connections
UID UID (Unit Identication) Switch
VGA Backpanel VGA Port
X9DRX+-F LED Indicators
LED Description State Status
LED1 BMC Heartbeat LED Green: Blinking BMC Normal
LED2 Onboard PWR LED Green: On Main Power On
LED3 UID Switch LED Blue: On (Windows)
Blue: Blinking (Linux) Unit Identied

Chapter 1: Overview
1-7
Motherboard Features
CPU • Dual Intel®E5-2600(v2) Series Processors (Socket
R LGA 2011); each processor supports four full-width
Intel QuickPath Interconnect (QPI) links (with support
of up to 25.6 GT/s per QPI link and with Data Transfer
Rate of up to 8.0 GT/s per direction).
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory • Integrated memory controller supports up to 1 TB
of Load Reduced (LRDIMM), 512 GB of Registered
(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/
Non-ECC DDR3 800/1066/1333/1600/1866 MHz
240-pin 4-channel memory modules in 16 DIMM slots.
Note 1: 1866 MHz memory speed is dependent
on Intel E5-2600v2 CPUs.
Note 2: For an updated memory support list,
please refer to the Tested Memory List on the
motherboard specication webpage.
• Virtualization: VT-x, VT-d, and VT-c
Chipset • Intel® C602 Chipset (PCH-A)
Expansion • Ten (10) PCI Express 3.0 x8 slots (CPU1 Slot1~Slot4,
Slot8, and CPU2 Slot5~Slot7, Slot9~Slot10),
• One (1) PCI Express 2.0 x4 in x8 slot (CPU2 Slot 11)
Slots
Graphics • Nutovon BMC Video Controller (Matrox G200eW)
Network • One Intel I350 Gigabit (10/100/1000 Mb/s) Ethernet
Dual-Channel Controller for LAN 1/LAN 2 ports.
• Nutovon WP450R Base-board Controller (BMC) sup-
ports IPMI_LAN 2.0
I/O Devices SATA Connections
• SATA Ports Two (2) SATA 3.0 (I-SATA 0/1),
Eight (8) SATA 2.0 Ports (I-
SATA2~5, S-SATA0~3)
• RAID (Win-
dows)
RAID 0, 1, 5, 10
• RAID (Linux-
Latest Kernel)
RAID 0, 1, 5, 10

1-8
X9DRX+-F Motherboard User’s Manual
IPMI 2.0
• IPMI 2.0 supported by the Nutovon WPCM450R BMC
Serial (COM) Port
• Two (2) Fast UART 16550 Connection: 9-pin RS-232
port
Super I/O
• Winbond Super I/O 83527
Peripheral
Devices
USB Devices
• Four (4) USB ports on the rear I/O panel (USB 0/1,
USB 2/3),
• Four (4) USB connections for front access (USB 6/7,
USB 8/9),
• Two (2) Type A USB connections for Type A USB
devices (USB 4, USB 5)
BIOS • 16 MB SPI AMI BIOS®SM Flash BIOS
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.5
Power • ACPI/ACPM Power Management
Cong. • Main switch override mechanism
• Keyboard Wake-up from Soft-Off
• Power-on mode for AC power recovery
PC Health CPU Monitoring
Monitoring • Onboard voltage monitors for 1.8V, +3.3V, 3.3VSB,
+5V Standby, Memory Voltage, Chipset Voltage, and
Battery Voltage.
• CPU 5 Phase switching voltage regulator
• CPU/System overheat LED and control
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) support
Fan Control
• Fan status monitoring with rmware fan speed control
(via IPMI)
• Low noise fan speed control
System
Management
• PECI (Platform Environment Conguration Interface)
2.0 support
• System resource alert via SuperDoctor® III
• SuperDoctor® III, Watch Dog, NMI

Chapter 1: Overview
1-9
• Chassis Intrusion Header and Detection
Dimensions • 15.20" (L) x 13.20" (W) (386.08 mm x 335.28 mm)
Note 1: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
Note 2: Changing BMC log-in information is recommended during initial
system power-on. The default username is ADMIN and password is
ADMIN. For BMC best practices, please refer to: http://www.supermicro.
com/products/nfo/les/IPMI/Best_Practices_BMC_Security.pdf

1-10
X9DRX+-F Motherboard User’s Manual
System Block Diagram
Note: This is a general block diagram and may not exactly represent the
features on your motherboard. See the Motherboard Features pages for
the actual specications of each motherboard.
DDR3 DIMM
PROCESSOR
Socket 2
CPU REAR
E5-2600(v2)
PE3
SLOT 5
SLOT 6
SLOT 7
SLOT 9
SLOT10
SLOT 1
SLOT 2
SLOT 3
SLOT 4
SLOT 8
P0 P1
PE2 PE1 DMI
PCIE 3.0x8 *5
PCIE 2.0x8 Slot 11
P00_P11
Lane Reversal
#2
#1
DDR3 DIMM
#2
#1
F
E
DDR3 DIMM
#2
#1
DDR3 DIMM
#2
#1
H
G
DDR3 DIMM
PROCESSOR
SSB
Socket 1
CPU FRONT
PE3
P1 P0
PE2 PE1 DMI
DMI
PCI
Windbond
VGA
VGA CONN
DDR2 RAM
TPM Header
BMC
PHYSuperI/OHW Monitor
NCT7904D
W83527
IPMI LAN
RJ45
RTL8201F
USB [10,11] LPC
S-SATA0 S-SATA1 S-SATA2 S-SATA3
JLAN1
RJ45
JLAN2
RJ45
Dual GbE
I350AM2 PEG [0..3]SATA [0..5]
USB [0..9]
SPI
BIOS
SATA
SATA Gen3 6GB/s
3GB/s
SATA Gen2
Gen2
3GB/s
SPI Flash
#2
#1
DDR3 DIMM
#2
#1
D
C
DDR3 DIMM
QPI QPI
#2
#1
DDR3 DIMM
#2
#1
B
A
PCIE 3.0x8
S-SATA3 S-SATA4
S-SATA5 S-SATA2 S-SATA1 S-SATA0
REAR
HDR 2X5
ports 0,1 port 4 port 5
REAR TYPE A TYPE A
2,3
6,7 8,9
HDR 2X5
SATA Gen2 [0..3]
E5-2600(v2)
(x4)
Intel C602
DMI: LANE
Reversal
PCIE 3.0x8
PCIE 2.0x4 *1
x8 *5
x4 *1
PET [1..7]

Chapter 1: Overview
1-11
1-2 Processor and Chipset Overview
Built upon the functionality and the capability of Intel E5-2600(v2) Series Proces-
sors (Socket R LGA 2011) and the C602 chipset, the X9DRX+-F motherboard
provides the performance and feature sets required for dual_processor-based
HPC/Cluster/Database servers.
With support of Intel QuickPath interconnect (QPI) Technology, the X9DRX+-F
offers point-to-point serial interconnect interface with a transfer speed of up to
8.0 GT/s, providing superb system performance.
The C602 chipset provides extensive IO support, including the following functions
and capabilities:
•PCI-Express Rev. 2.0 support
•PCI-Express Gen. 3 uplink supported by some SKUs
•ACPI Power Management Logic Support Rev. 3.0b or Rev. 4.0
•USB host interface backplane and front access support
•Intel Rapid Storage Technology supported
•Intel Virtualization Technology for Directed I/O (Intel VT-d) supported
•Intel Trusted Execution Technology supported
•Serial Peripheral Interface (SPI) supported
•Digital Media Interface (DMI) supported
•Advanced Host Controller Interface (AHCI) supported
Note: For Intel E5-2600(v2) processor support, BIOS version 3.0 or
above is required.

1-12
X9DRX+-F Motherboard User’s Manual
1-3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will
respond when AC power is lost and then restored to the system. You can choose for
the system to remain powered off (in which case you must press the power switch
to turn it back on), or for it to automatically return to the power-on state. See the
Advanced BIOS Setup section for this setting. The default setting is Last State.
1-4 PC Health Monitoring
This section describes the features of PC health monitoring of the motherboard.
This motherboard has an onboard System_Hardware_Monitor chip that supports
PC health monitoring. An onboard voltage monitor will scan the following onboard
voltages continuously:1.8V, +3.3V, 3.3VSB, +5V Standby, Memory Voltage, Chipset
Voltage, and Battery Voltage. Once a voltage becomes unstable, a warning is given,
or an error message is sent to the screen. The user can adjust the voltage thresholds
to dene the sensitivity of the voltage monitor.
Environmental Temperature Control
A thermal control sensor monitors the CPU temperature in real time and will turn
on the thermal control fan whenever the CPU temperature exceeds a user-dened
threshold. The overheat circuitry runs independently from the CPU. Once it detects
that the CPU temperature is too high, it will automatically turn on the thermal fan
control to prevent the CPU from overheating. The onboard chassis thermal circuitry
can monitor the overall system temperature and alert the user when the chassis
temperature is too high.
Note: To avoid possible system overheating, please be sure to provide
adequate airow to your system.
System Resource Alert
This feature is available when used with SuperDoctor® III in the Windows OS
environment or used with SuperDoctor II in Linux. SuperDoctor is used to notify
the user of certain system events. For example, you can congure SuperDoctor
to provide you with warnings when the system temperature, CPU temperatures,
voltages, and fan speeds go beyond a predened range.
