SHIVAKI
LED TV SERVICE MANUAL
CUSTOMERS Model Name: SZTV-40LED6TC
Version NO.. : 1.0
The release of this document is under controlled by the company. Any extra
copy of this document must be written permission by the product manager.
TABLE OF CONTENTS

2
RECORDS OF REVISION …………………………………………………………………………..…..03
CHAPTER 01: WARNING……………………………………………………………………………04
CHAPTER 02: SAFETY PRECAUTIONS…………………………………………………………..05
CHAPTER 03: PRODUCT ROUGH SPEC……………………\\…………………………………..06
CHAPTER 04: EEXPLODING BLOCK………………..………………………………….…………07
CHAPTER 05: MAIN COMPONENT DIAGRAM………………………………………….……..08~11
CHAPTER 06: CONNECTION INTERFACE…………………………………………...………….10
CHAPTER 07: EASY TROUBLE SHOOTING…………………………………………………13~19
CHAPTER 08: TOOUBLE SHOOTING FLOW CHART………………………………………20~27
CHAPTER 09: MAIN BOARD SCHEMATICS…………………………………………………28~38
CHAPTER 10: POWER BOARD SCHEMATICS………………………………………………….….39
CHAPTER11: FIRMWARE UPDATE SOP…………………………………………………………40~42
RECORDS OF REVISION

3
Re vision N o. Re vision Date Pa ge Re ason De sc ription
1.0 De c.15.2 0 10 All Initial Release
CHAPTER 1: WARNING

4
This service information is designed for experienced repair technicians only and is
notdesigned for user by the general public.It does not contain warnings or cautions to
advise non-technical individuals of potential dangers in attempting to service a
product.Products powered by electricity should be serviced or repaired only by
experienced professional technicians.Any attempt to service or repair the product or
products dealt within this service information by anyone else could result in serious
injury or death.
CHAPTER 2: SAFETY PRECAUTIONS
2-1. CAUTION:

5
No modification of any circuit should be attempted. Service worker should only be performed after going
through to familiar with all of the following safety checks and servicing guidelines.
2-2. SAFETY CHECK
Care should be taken while servicing this TV display. Because of the high voltage is used in the inverter
circuit. These voltages are exposed in such areas as the associated transformer circuits.
2-3. POWER SUPPLY REQUIREMENTS
The internal power converter with the attached AC power cord is necessary for the TV monitor. Any attempt to
replace another power converter could result in serious of problems on the display.
2-4. LEAKAGE CURRENT HOT CHECK
2-4-1 Plug the AC cord directly into the AC outlet. Do not use an isolation transformer during this check.
2-4-2 Connect a 1500 ohm, 10 watt resistor, paralleled by a 0.15uF capacitor between each metallic part and a
good earth ground.
2-4-3 Use an AC voltmeter with 1000 ohm / volt or more sensitivity and measure the AC voltage across the
combination 1500 ohm resistor and 0.15uF capacitor.
2-4-4 Move the resistor connection to each exposed metallic part and measure the voltage.
2-4-5 Reverse the polarity of the AC plug in the AC outlet and repeat the above measurement.
2-4-6 Voltage measured must not exceed 1.5 volt RMS, from any exposed metallic part to the ground.
A leakage current tester may be used in the above hot check, in which case any circuit measured
must not exceed 1 milliamp. In the case of a measurement exceeding the 1 milliamp value, the rework is
required to eliminate the chance of a shock hazard.
CHAPTER 3: PRODUCT ROUGH SPEC
To Metal Parts
V
AC VOLTMETER
1500 10W
0.15u
.
Earth Ground

6
Product Rough Specification
General
Information
TV ID YICHANG CA1
Pnael Model CN39B21A
Main Board Model MSD309.B81C
Power model AY079D-4HF11
Power Consumption(Stand-by Mode) <0.5W
Power Consumption(TOY) 80W
Power Input Voltage 110-240V~
Power Rated Input Freq 50/60Hz
ATV
Video System PAL ;SECAM
Sound System BG;DK,I,L/L' ;NICAM/A2
Max Storage Channel 100CH
Teletext 1000Page
DTV
Modulation COFDM 2K/8K; OPSK; 16QAM; 64QAM
Video System MPEG-2 MP@ML
Sound System MPEG-1 LAYER1,2
Basic Functions EPG; Subtitle; Teletext
Max Storage Channel 400CH
Teletext 1000Page
Other
Parameter
COMB Filter 3D
Deinterlace 3D
Audio power output 2 X 10W@8ohm THD+N<10%@1KHz
Audio Frequency Response 100Hz~15KHz
OSD Language Eng;Fre;Ger;;Spa;Rus,Tur,pol
Panel Resolution Up to 1920*1080
Terminals
AV Input 1
S-Video Input NO
SCART Input 1
CI (Common Interface) 1
Component(Y Pb Pr or Y Cb Cr) 1
VGA D-15 Input 1
PC Audio L/R Input 1
HDMI Input 3
Head phone out 1
AV out NO
SPDIF YES
DVD & Driver board NO
EMC EN 55022 Class B Yes
Safety EN 60950 (Europe) Yes
Environmental
Conditions
ESDspec. 4/8KV(Reference)
Operation Temperature 0~40'C(Operating), -20~60'C(Storage)
Relative Humidity 10~85%(Operating) 5~95%(Storage)
CHAPTER 4: EXPOLDING BLOCK

7

8
CHAPTER 5: MAIN BOARD CONNECTION
5-1: Main Board TOP View
5-2: Main Board Botton View

9
5-3: Main Board Connection

10
