SV2000 SVX122AT User manual

7-EVENT/1 YEAR SMART PROGRAMMING
Program your VCR for unattended recording of
up to seven separate programs over a full 365-
day period
AUTOMATIC CHANNEL SETUP
The VCR tuner scans television
frequencies, automatically storing active
broadcast channels into memory
DIGITAL AUTO TRACKING SYSTEM
Automatically seeks the optimum
tracking position and optimum audio
signal for clearest picture and sound
181-CHANNEL FS TUNING The
digital quartz tuner receives up to 181
channels without the inconvenience
and expense of a cable company
decoder/converter
TIMER/PROGRAMMER BACKUP
SYSTEM Retains timer programming
information for up to one full minute
in the event of momentary power
interruptions
REMOTE CONTROL ON-SCREEN MENU
PROGRAMMING On-screen menus lead you
through normal, daily, or weekly programming by
remote control
VIDEOCASSETTE RECORDER
SVX122AT
SVX122AT
Multifunction
Infrared
Remote
Recorder
Recorder
Videocassette
Videocassette

15X FORWARD/REVERSE LATCHING SEARCH Search
in forward or reverse mode at 15 times normal playing
speed in SLP, and 5 times normal in SP.The Latching Search
feature provides continuous forward or reverse search with
a single touch of the control.A second touch stops the
search operation and returns the unit to the Play mode.
MULTIFUNCTION INFRARED REMOTE Controls all
operating features and functions of thisVCR with armchair
convenience–including all special features, random channel
access, and channel scan up/down, providing an LED virtual
“handshake” for confirmation.
• Power On
• Digital Auto Tracking
• Auto Play
• Auto Repeat
• Auto Rewind
• Auto Eject
• Auto Power Off
INTERNET ADDRESS: http://www.philipsmagnavox.com
special effects:
SV2000 Videocassette Recorder
SVX122AT
UPC: 037849848401
Product Dimensions: 14.2"W x 3.6"H x 9"D
Product Weight: 5.9 lbs.
Individual Package Dimensions: 16.7"W x 6.6"H x 12.2"D
Individual Package Weight: 8.1 lbs.
Master Pack: 1
Carton Contains: Videocassette Recorder, Multifunction
Infrared Remote Control, Operating Instructions,Warranty
Information
Printed in U.S.A.
©1997 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Visual Communications, Philips Consumer Electronics Co.
remote control:
additional features:
AUTOMATIC CHANNEL SETUP Activating this
feature allows theVCR tuner to scan through
television frequencies, automatically storing active
broadcast channels into memory.Then, only active
channels programmed into memory are tuned, using
the channel up/down buttons on either the remote
or front panel of theVCR.Automatic channel preset
can be repeated whenever desired, should new
channels become available. Channels can be manually
added or deleted.
181-CHANNEL FS TUNING The digital quartz
tuner is capable of receiving up to 181 channels,
including UHF,VHF, and 113 cable channels, without
the inconvenience and expense of a cable company
decoder/converter (on non-scrambled cable systems).
Channel tuning is by random access with the remote
control transmitter or scan tuning up and down by
remote or at the set.
LED FUNCTION INDICATORS Alerts the user
to the status of all important recording and
playback features with simple, easily recognized,
international symbols.
BILINGUAL (ENGLISH/SPANISH) ON-SCREEN
FUNCTION DISPLAY Indicates record/playback
functions, channel number, clock setting, date, counter,
programming, one-touch record and record standby,
keeping the user alerted to the status of all features
in a heads up, on-screen display.
convenience:
ON-SCREEN, REAL-TIME COUNTER Unlike the
0000 to 9999 tape counters found in standardVCRs,
this unit incorporates a linear, real-time counter which
shows elapsed recording and/or playback time in
hours, minutes, and seconds.
TIMER/PROGRAMMER BACKUP SYSTEM Retains
timer programming information for up to one full
minute in the event of momentary power interruptions.
REPEAT PLAY When the VCR recognizes no
recorded signal or reaches the end of a tape with the
Repeat Play control activated, it will automatically
rewind to the beginning and enter the Play mode
again. Repeat Play can be discontinued by touching the
button a second time or by changing operation mode.
QUICK START MECHANISM Quickly and
effortlessly switches the tape mechanism from Stop to
Play in only one second, instead of the approximately
5 1/4 seconds of older models.
AUDIO/VIDEO INPUT/OUTPUT JACKS Connect
yourVCR to the direct audio and video inputs of a
television receiver or monitor equipped with input
jacks, for better picture and sound quality during tape
playback. Jacks also allow a second VCR to be
connected for editing and/or duplicating personally
recorded, non-copyrighted videotapes.
programming &
record/playback
features:
ONE-TOUCH RECORD Record up to eight
hours or to the end of the tape with the touch
of a single button. Each touch of the OTR button
adds 30 minutes of additional recording time.
7-EVENT/1 YEAR SMART PROGRAMMING
Program your VCR for unattended recording of
up to seven separate programs over a full
365-day period. No manual setting, adjusting, or
programming of the calendar function is required.
REMOTE CONTROL ON-SCREEN MENU
PROGRAMMING Program by remote control
for unattended recording, with programming
instructions on-screen for visual verification.
On-screen menus lead you through normal,
daily, or weekly programming by program
number, channel to be recorded, start and stop
times, speed, and date of recording by day,
month, and year. Pushing the CLEAR button
allows you to go back and reprogram over
mistakes, and pushing the MENU button at the
end of programming verifies that instructions
are locked into memory.
DIGITAL AUTO TRACKING SYSTEM When
tape playback begins, this feature automatically
seeks the optimum tracking position in the
tracking range, and the optimum audio signal
tracking position for clearest picture and sound
from videotapes. Controls are provided on the
remote transmitter to give you manual control
should tracking adjustments be necessary.
