SVS PB-2000 Pro User manual

1
Unbox It
Quick Start Guide
PB-2000 PRO
If you followed the PB-2000 PRO Subwoofer unboxing instructions properly
you will have the following items in front of you. Please confirm all pieces are
available before continuing.
Congratulations on choosing the SVS PB-2000 PRO, one of the most powerful and advanced
subwoofers in the world. We know you’re anxious to get it cranking so the following steps will
guide you through the quick and easy installation process.
We strongly recommend reading the PB-2000 PRO Owner’s Manual to get the best possible
performance out of your new subwoofer. You’ll find useful information about subwoofer
placement, connections, DSP functions and more. The full SVS PB-2000 PRO Owner’s Manual can
be found here: www.svsound.com/pb-2000pro-manual
[PB-2000 PRO Subwoofer] [Removable Grille]
[Detachable Power Cord]
4
The rear panel features an intuitive all-new user interface with controls for adjusting the subwoof-
er’s primary settings. The blue LED bar shows settings for Volume, Low Pass Frequency, and Phase.
Simply press the setting you want to change and then use the “+” and “-” buttons to adjust the
settings.
Please note, some DSP settings can only be accessed using the SVS app.
The SVS App is the easiest and most convenient
way to access all of the advanced control features
available on your PB-2000 PRO, from the comfort
of your favorite seat.
Get Control
5
Get Calibrated
 HOME / VOLUME
MOVIE
PRESET
LOW PASS FILTER
OPTIONS
-22
10050
20 40 200 0
6
4
2
0
-2
-4
-6
-8
-10
-12
PEQ1
ACTIVE
PEQ2
ACTIVE
PEQ3
DISABLED
BOOST: 0 dB
Q FACTOR: 1.2
FREQ: 200 Hz
PARAMETRIC EQ
Your SVS PB-2000 PRO Subwoofer can be controlled from the new SVS Mobile
App or via the rear panel for maximum flexibility when optimizing performance
based on your room layout, speakers, system set-up and more.
Download The App
On The Subwoofer
For iOS & Android Devices
ONOFF
R
3V-12V |AC/DC
100V-120V ~ 50-60Hz 800W
L
LINE LEVEL
INPUT OUTPUT
TRIGGER INPUT
SVS SOUNDPATH WIRELESS
AUDIO ADAPTER
STA -800D|2
LFE
AUTO / ON
UP (+)
LOW PASS FREQUENCY
PHASE
VOLUME
DOWN (-)
REG ISTER
REG ISTER
Register Your New SVS Product:
Thank you for choosing SVS! Registering your SVS product expedites any Sound Experts support requests, confirms your warranty registration and provides a proof of purchase. Plus, as a registered customer, you’ll be the first to get SVS news and updates.
Register your product now at: www.svsound.com/register
For connection to a Stereo Receiver or Preamplifier
without auto-set-up, adjust the PB-2000 PRO volume
to match the output of your main speakers, and
adjust the low pass filter to blend the bass between
the PB-2000 PRO and your speakers. If needed,
consult with our Sound Experts on the best phase
setting.
For additional guidance on recommended crossover or low pass filter settings specific to your system,
visit our Subwoofer Matching Tool at www.svsound.com/merlin, or just call, email or chat online with
our Sound Experts: [phone] | [email protected] | www.svsound.com
For connection to an AV Receiver, set the PB-2000 PRO volume to -10 in the app (on
the rear panel, all but the last two lights illuminated). Set the low pass filter to LFE
and the phase to 0 degrees, then run auto-set-up on the AV Receiver. Always re-run
set-up if you move the subwoofer to another location.
AUTO EQ - START
MIC INPUT
+
VOL
LOW
PASS
LOW PASS
PHASE
PHASE
0°
90° 180°
30Hz 40Hz 60Hz 90Hz 140Hz LFE
_

For most set-ups, a single RCA subwoofer interconnect cable running from the AV Receiver’s “SUB 1” output to the PB-2000 PRO’s
“LFE” line level input is all that’s required to connect the subwoofer into your system. If you run separate Preamplifier and Power
Amplifiers, follow the “Line Level Connection – Stereo Receiver or Preamplifier Left/Right Channels” connection guide below.
ONOFF
R
3V-12V|AC/DC
100V-120V ~ 50 -60Hz 80 0W
L
+
VOL
LOW
PASS
LOWPASS
PHASE
PHASE
0°
90° 180°
30Hz 40Hz 60Hz 90Hz 140Hz LFE
_
LINELEVEL
INPUT OUTPUT
TRIGGERINPUT
SVSSOUNDPATH WIRELESS
AUDIOADAPTER
STA-800D|2
LFE
CENTER
REAR FRONT
SUBWOOFER
(SUB1)
LINE LEVEL OUTPUTS
RL
INPUT OUTPUT
LFE
RECEIVER/PREAMP
2
Set It Up
3
Hook It Up
Need Help?
Line Level Connection – Single LFE Channel Line Level Connection – Stereo Receiver or Preamplifier Left/Right Channels
The location of your subwoofer in the listening environment can affect its performance. If possible, start with corner placement
on the same wall as the front speakers, or anywhere along the front stage in between or outside of your main speakers.
Our Sound Experts are standing by to help with subwoofer placement, installation,
calibration, AV receiver settings, room rattle and anything else you need advice about.
Just call, email or chat online with our Sound Experts:
[phone] | [email protected] | www.svsound.com
Corner Placement: offers huge impact and reduces the
potential to encounter bass nulls, or ‘dead spots’. If “boomi-
ness” occurs, you can try pulling it away from the wall and
using the DSP tuning controls to smooth performance.
Front Placement: In between or to the side of the front
channel speakers often results in the best blending with the
main speakers and center channel and minimizes localiza-
tion effects.
Side Wall Placement: Side wall placement is less frequently
used but can be an effective subwoofer location for
excellent accuracy and output.
Review your product now at: www.svsound.com/review
Review Your New SVS Product:
Your SVS product is built with the highest standards of engineering excellence to achieve stunning sound quality and dynamics. Honest feedback is important to us and others making decisions about audio products. Please share your ownership experience with the SVS community by writing a review today.
RE
VIEW
RE
VIEW
R
3V-12V |AC/DC
L
+
VOL
LOW
PASS
LOW PASS
PHASE
PHASE
0°
90° 180°
30Hz 40Hz 60Hz 90Hz 140Hz LFE
_
LINE LEVEL
INPUT OUTPUT
TRIGGER INPUT
LFE
LINE LEVEL OUTPUTS
REAR FRONT
R
L
RECEIVER/PREAMP

2000 PRO
SUBWOOFER
SAFETY INSTRUCTIONS
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instruc -
tions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampli fi ers) that produce heat.
• Do not defeat the safety purpose of any polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two prongs and a third
grounding point. The wide blade or the third prong are provided for yo ur safety. If the provided
plug does not fi t into your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories speci fi ed by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table speci fi ed by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus combina-
tion to avoid injury from tip-over.
•Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to quali fi ed service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• WARNING: To reduce the risk of fi re or electric shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids, such as vases, should not be placed on this
apparatus.
•This apparatus conforms to the use requirement in tropical and moderate climates, with a
maximum temperature of the environment not exeeding 45°C (113°F).
•If the subwoofer is to be used in a con fi ned space (e.g. built into furniture), the space must be
ventilated to allow su ffi cient air to circulate and cool the unit.
• To completely disconnect this equipment from the mains, disconnect the power supply cord plug
from the receptacle.
• The mains plug of the power supply cord shall remain readily operable.
The lightning fl ash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the products
enclosure that may be of sufficient magnitude to constitute risk of electric shock to
persons.
The exclamation point within a triangle is intended to alert the user to the presence of
importance operating and maintenance {servicing) instructions in the literature
companying the product.

2000 PRO
SUBWOOFER
FCC & IC COMPLIANCE
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi-
tions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment o
ff and on, the user is encouraged to try to correct the interference by one or more of
the follow- ing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit di ff erent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Any changes or modi fi cations to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
The device must not be colocated or operating in conjunction with any other antenna or transmitter.
“FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF
exposure guidelines, place the product at least 20cm from nearby persons.”
IC Statement
This device complies with RSS247 of Industry Canada. Cet appareil se conforme à RSS247 de
Canada d'Industrie. This device complies with Industry Canada licenseexempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device. appareils radio exempts de licence. Son fonctionnement est sujet aux deux
conditions suivantes: (1) le dispositif ne doit pas produire de brouillage prejudiciable, et (2) ce
dispositif doit accepter tout brouillage recu, y compris un brouillage susceptible de provoquer un
fonctionnement indesirable
