SwannOne ZEN-01 User manual

QUICK LOOK
Change
mode
Change
mode
Increase temperature
Decrease temperature
BASIC OPERATION
Center touch to wake.
Display shows current ambient
temperature.
Center touch again.
Display shows current set point
temperature.
Touch left or right to select
operating modes. Center touch
to confirm your selection.
Touch up or down to change the
set point temperature. Center
touch to confirm your selection.
ICON GUIDE
Network
Connected
Active
Status
Cooling Mode
Schedule Mode
Eco mode
Auto Mode
Second stage
heating or cooling
Emergency heating
Demand response
event in progress
Fan On
Continuous
Preferences Mode
ErrorBattery Low
Warning
Heating Mode
Filter Change
Required
Confirm
USER PREFERENCES
Access the user preferences by removing the unit from the wall and
center touch to activate options.
Some modes may not be enabled by your heating/cooling system.
Units
Fahrenheit
Celsius
Brightness Language
English
Français
Español
Touch right or left to scroll through the preferences. Touch up or down
to modify a preference. Center touch to confirm.
Info
View software
version and
configuration
setting.
DR
Quick Start Guide

Extra Low Voltage only. Do not
connect to mains voltages.
Do not interconnect the outputs
of class two circuits
WARNING
INSIDE THE BOX
Wall mountMain display
Adapter plate
Wire labels
2 x screws
2 x wall plugs
4 x AA Batteries
RH
RC
O/B
AUX
C
RH
RC
O/B
AUX
C
Y1
Y2
G
W1
W2
Y1
Y2
G
W1
W2
GETTING STARTED
The ZEN thermostat™can only be connected to low voltage systems.
Ensure that you complete the following steps before you begin installation.
1. Turn o main breaker 3. Check2. Remove cover from old unit
Is your system labeled
120V-240V? Do you see thick
wires with wire-nuts? If you do
your system is NOT compatible
with the ZEN thermostat™.
If you’re unsure, please contact
your home automation provider
or HVAC installer.
4. Begin installation
If you are certain that your
system is low voltage, begin
the installation process by
following the online guide:
zen.swannone.com/install
You will need an
internet web browser to
complete installation.
It takes approximately 45
minutes to get your ZEN
thermostat™ready to use.
Caring for your ZEN thermostat™
Clean with a damp cloth only. Avoid using chemical cleaning agents.
Rebooting or Resetting to Factory Defaults
If you are experiencing issues, reboot your display by removing and reinserting the batteries.
This will retain your configuration settings. To restore to factory settings, press the Config button
on the back of the main display 20 times, the display will beep five times to confirm the reset.
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the condition
that this device does not cause harmful interference. This device complies with Part 15
of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The transmitter must not be co-located or operated in conjunction with any other antenna
or transmitter.
This equipment complies with the FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a minimum
distance of 20 cm between the radiator and any part of your body.
NOTE: THE GUARANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS
NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH
MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
Industry Canada Notice
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Have a question? Visit
zen.swannone.com/faq
?
Be sure to peel o the protective film from the main display before using it.
zen.swannone.com
Your SwannOne product is backed by a full 12 month
guarantee from the date of purchase. In the unlikely
event of anything going wrong, you can have
confidence that your purchase is protected. Refer to
swannone.com for terms and conditions.
Designed in Australia by Planet Innovation
Powered by MMB Networks RapidConnect
Built in Malaysia
Model: ZEN-01, Electrical Rating: 24VAC, 2A
FCC ID: 2ADJL-ZEN01, IC ID: 12476A-ZEN01
QSGZEN170316E
