Swegon GOLD RX/HC Series User manual

GB.RXHCF.191011
Reversible heat pump GOLD RX/HC
Installation and Maintenance Instructions
Sizes 011-080
The document was originally written in Swedish.
GOLD RX/HC

GB.RXHCF.191011
We reserve the right to alter specifications.
2 www.swegon.com
1. Safety Instructions ................................. 3
1.1 Safety isolating switch/Main switch ......................3
1.2 Risks ....................................................................3
1.3 Electrical equipment.............................................3
1.4 Authorisation.......................................................3
1.5 Decals..................................................................3
2. Overview ................................................ 4
2.1 General................................................................4
2.2 Basic function diagram.........................................5
2.2.1 Size 011-030 ........................................................... 5
2.2.2 Size 035 .................................................................. 6
2.2.1 Size 040-080 ........................................................... 7
3. Installation.............................................. 8
3.1 Unloading/site transport.......................................8
3.2 Arrangement .......................................................8
3.3 Basic installation principle.....................................8
3.3.1 Height adaptation/water trap installation ................. 8
3.3.2 Splitting/Installation of air handling unit sections...... 9
4. Power connection ................................ 10
5. Commissioning / Calibration ............... 12
5.1 General .............................................................12
5.2 Phase-sequence monitor ....................................12
5.3 Actions if incorrect phase-sequence....................12
6. Alarms................................................... 12
7 Maintenance.......................................... 13
7.1 Cleaning ............................................................13
7.2 Handling of refrigerant.......................................13
7.3 Leakage tracing interval/Obligation to report ......13
7.4 Service ...............................................................13
8. Trouble shooting and leakage tracing 14
8.1 Troubleshooting Schedule ..................................14
8.2 Leakage Tracing .................................................14
9. Dimensions ........................................... 15
10. General technical data ....................... 18
11. Wiring diagram .................................. 18
12. Declaration of Conformity................. 19
12.1 Sizes 011-020 ..................................................19
12.1 Sizes 025-080 ..................................................20

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 3
1. SAFETY INSTRUCTIONS
1.1 Safety isolating switch/Main switch
The connection hood for RX/HC 011-020 is placed on top
of the air handling unit to the right or left of the GOLD air
handling unit’s connection hood (above the rotating heat
exchanger), see illustration. The safety isolating switch is
located on the side of the connection hood for RX/HC size
011-020.
For size 025-080, the safety isolating switch is located on
the air handling unit’s inspection side to the right or left
of the GOLD air handling unit’s safety isolating switch (in
front of rotating heat exchanger), see illustration.
The safety switch should not be used to start or stop of
the reversible heat pump.
Ensure that the RX/HC is shut off by stopping the air han-
dling unit or by temporarily shutting off the RX/HC via the
hand-held micro terminal, see the GOLD operation and
maintenance instructions.
When this has been carried out, the current can be iso-
lated with the safety switch. The safety switch must be
switched off in order to make it possible to open the
inspection door.
Connection hood GOLDPossible locations of the
connection hood RX/HC
Safety isolating switch GOLD
Possible locations of the safety
isolating switch RX/HC
Important:
Always switch off the safety isolating switch before ser-
vicing the unit if not otherwise specified in the pertinent
instructions.
Warning
The inspection doors must not be opened when air han-
dling unit is operational. The doors can open and injure
personnel.
1.3 Electrical equipment
Housed on the inside of an inspection door to the right or
left of the rotating heat exchanger is electrical equipment
for RX/HC mounted in a separate electrical equipment
cubicle.
1.4 Authorisation
Only authorized electricians shall be permitted to install
electrical wiring in the unit.
Only an accredited refrigeration company shall be permit-
ted to modify or repair the refrigeration circuit.
Other service work in the unit should only be performed
by service personnel trained by Swegon.
1.5 Decals
The type number mark with type designation, serial num-
ber, refrigerant volume and more is affixed on the chiller’s
door.
1.2 Risks
Warning
Under no circumstances may the refrigerant circuit be
opened by unauthorised personnel, since it contains gas
under high pressure.
Warning
Before carrying out any work, make sure that the power
supply to the air handling unit has been switched off.
Risk areas for refrigerant
Risk area for refrigerant is in principal inside the entire
reversible heat pump. For handling when leakage, see
section 7.2.
The refrigerant used is R410A.

GB.RXHCF.191011
We reserve the right to alter specifications.
4 www.swegon.com
Refrigerant
Type R410A refrigerant is used. The refrigerant circuits are
charged with refrigerant on delivery. At present, this re-
frigerant has no known influence on the ozone layer and
no known future restrictions are anticipated.
Refrigerant volume
See section 10. General technical data.
Installation check/Obligation to report/
Leakage tracing interval
Must be carried out according to the F-Gas Regulation
EU/517/2014 and associated local legislation.
Quality System to ISO 9001
and Environmental Management System to ISO
14001
Swegon AB works to a certified quality system that con-
forms to ISO 9001 standard and a certified Environmental
Management System that conforms to ISO 14001.
2. OVERVIEW
2.1 General
General
RX/HC is a complete reversible heat pump, fully inte-
grated in the GOLD air handling unit.
RX/HC consists of one section with sorption rotor and
one section on each side of this that contains heating/
cooling engineering components.
All components from a cooling and electrical standpoint
are pre-wired.
The casing is composed of cover panels and inspection
doors. The outer skin is made of galvanized sheet steel,
pre-painted in Swegon’s grey metallic colour (closest com-
parable: RAL, 9007). The inner skin is made of aluminium-
zinc plated sheet steel. Environmental Class C4. Panel
thickness of 52 mm with intervening insulation consisting
of mineral wool.
The evaporator and condenser consist of copper tubes
and profiled aluminium fins.
RX/HC is test run prior to delivery.
RX/HC is available in 6 physical sizes, designed for GOLD
air handling units in size 011-080.
RX/HC are designed and tested for ambient temperatures
from -40°C to +40°C. The heat pump function withstands
temperatures from -25°C to +35°C.
Compressors
The refrigerant circuit contains a variable speed controlled
compressor (all sizes) that regulates the output. Size 040-
080 also comprises an on/off compressor for increased
capacity.
Completely direct-acting system
The RX/HC has a completely direct-acting system. It has an
evaporation coil for direct-evaporating refrigerant on the
cold side and a condenser coil on the hot side.

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 5
03
NONC
SUCDIS
02
SPH High pressure switch
BPH High pressure sensor
BPL Low pressure sensor
BT5X Sensor, electronic expansion valve
01 Compressor
02 Condenser (exhaust air)
(Evaporator for heating operations)
03 Evaporator (supply air)
(Condenser for heating operations)
06 Electronic expansion valve
07 Shut-off valve
08 Connection, service
09 Drying filter
10 Sight glass
12 4-way valve
13 Non-return valve
14 Container, fluid
19 Safety valve
20 LP, service outlet in RX section
21 HP, service outlet in RX section
22 Fluid, service outlet in RX section
01
06 0710 09
19
SPH
08
08 08 08
12
1313
1313
BPH
14
BT5X
For a description of the control functionality, see the function guide
reversible heat pump RX/HC.
Exhaust air
coil
Supply
air coil
08 08
08 08
BPL
20 21
22
2.2 Basic function diagram
2.2.1 Size 011-030

GB.RXHCF.191011
We reserve the right to alter specifications.
6 www.swegon.com
2.2.2 Size 035
0203
NONC
SUC DIS
01
06 0710 09
19
SPH
08
08 08 08
12
1313
1313
BPH
14
BT5X
Exhaust
air coil
Supply
air coil 08 08
08
08
BPL
20 21
22
SPH High pressure switch
BPH High pressure sensor
BPL Low pressure sensor
BT5X Sensor, electronic expansion valve
01 Compressor
02 Condenser (exhaust air)
(Evaporator for heating operations)
03 Evaporator (supply air)
(Condenser for heating operations)
06 Electronic expansion valve
07 Shut-off valve
08 Connection, service
09 Drying filter
10 Sight glass
12 4-way valve
13 Non-return valve
14 Container, fluid
19 Safety valve
20 LP, service outlet in RX section
21 HP, service outlet in RX section
22 Fluid, service outlet in RX section
23 Solenoid valve
For a description of the control functionality, see the function guide reversible heat pump RX/HC.
07 23

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 7
2.2.1 Size 040-080
SPH High pressure switch
BPH High pressure sensor
BPL Low pressure sensor
BT5X Sensor, electronic expansion valve
01 Compressor
02 Condenser (exhaust air)
(Evaporator for heating operations)
03 Evaporator (supply air)
(Condenser for heating operations)
06 Electronic expansion valve
07 Shut-off valve
08 Connection, service
09 Drying filter
10 Sight glass
12 4-way valve
13 Non-return valve
14 Container, fluid
19 Safety valve
20 LP, service outlet in RX section
21 HP, service outlet in RX section
22 Fluid, service outlet in RX section
23 Solenoid valve
For a description of the control functionality, see the function guide reversible heat pump RX/HC.
0203
NONC
SUC DIS
ØL
01
06 07
10 09 19
SPH
08
08 08 08
12
1313
1313
BPH
14
BT5X
Exhaust
air coil
Supply
air coil 08 08
08
08
BPL
20 21
22
01
10
07 23

GB.RXHCF.191011
We reserve the right to alter specifications.
8 www.swegon.com
GOLD RX/HC 011-080
Right-hand version
Left-hand version
Outdoor air Supply air Extract air Exhaust air
GOLD RX/HC supply air fan, right, lower level GOLD RX/HC supply air fan, right, upper level
GOLD RX/HC supply air fan, left, upper level
GOLD RX/HC supply air fan, left, lower level
3.3.1 Height adaptation/water trap installation
The drainage pipes to the evaporator/condenser must
each be fitted with a water trap (accessory). The air
handling unit must be raised by at least 50 mm to provide
space for the water trap on the lower level. Adjustable
support feet (accessory) can be appropriately fitted to the
base beams for this purpose.
3. INSTALLATION
3.1 Unloading/site transport
See the Installation Instructions for the GOLD air handling
unit.
3.2 Arrangement
See the Installation Instructions for the GOLD air handling
unit.
3.3 Basic installation principle
1)
2)
3)
1) Connection hood, only size 011-020.
2) Electric air heater for defrosting (accessory).
3) Air recirculation section RX/HC (accessory).
1) 1)
2)
3)
1)
1)
2)
3)
1) 1)
2)
3)
1)

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 9
3.3.2 Splitting/Installation of air handling unit sections Connector pipes must be insulated to the extent required.
This can occur during or after installation of connector
pipes.
The connector pipes are delivered in appropriate lengths
and do not need to be cut.
NOTE! In order to facilitate access, work to solder the con-
nector pipes is to be started in the outer section with coil.
Solder the connector pipes on the refrigerant pipes in the
outer section with coil.
The outer section (with coil) is slid into the centre section,
at the same time as the connector pipe is guided through
the centre section via the rubber seals in the pipe lead-
throughs. Be careful not to damage the pipes!
Screw the outer section (with coil) to the centre section.
The outer section with compressor is slid into the centre
section.
Screw the outer section (with compressor) to the centre
section.
Solder the connector pipes to the refrigerant pipes in the
outer section (with compressor).
Connect hoses marked HP, LP and LIQUID to each service
outlet in the centre section (behind the inspection cover).
Leakage test, vacuum the refrigerant circuit and open the
taps (x4) to fill the whole circuit with refrigerant.
Install fan/filter parts to RX/HC and connect electrical quick
connectors, see the separate installation instruction for
GOLD.
RX/HC with full refrigerant circuit
For separation/installation to other air handling unit sec-
tions, see the separate installation instructions for each
GOLD.
RX/HC with split refrigerant circuit
The outer section in RX/HC housing the compressor is pre-
filled with refrigerant, the other outer section is prefilled
with nitrogen.
RX/HC is divided into three sections, see the separate
installation instructions for each GOLD.
All brazing must be carried out with a shield gas.
All the cover panels at the rear of the air handling unit
(torx screws) are to be removed to gain access for contin-
ued work.
NOTE! The sections must not be transported when
the cover plates are removed.
NOTE!
The work below may only be performed by certified
refrigeration technicians.
There are lead-throughs in the lower edge of the centre
section for a supply air fan on the lower level. There are
pipe lead-throughs in the upper edge of the upper level
for a supply air fan. See the basic circuit diagram.
There are four refrigerant pipes (of which two to the sub-
cooling circuit) in each outer section. The refrigerant pipes
are closed at the ends. Braze loose ends on all refrigerant
pipes.
There are connector pipes supplied in some of the outer
sections.
Refrigerant pipes and connector pipes are numbered 1-4.
Refrigerant pipe 1 should be paired with connector pipe 1
etc.
Outer section Centre section Outer section
The illustration shows RX/HC as seen from the back in an air handling
unit with the supply air fan on the lower level. The refrigerant pipes are
placed on the top edge of the upper level with the supply air fan on the
upper level, see dashed lines.
-/+
Refrigerant pipes
(4 pcs.)
Pipe lead-throughs (4 pcs.)
Refrigerant pipes
(4 pcs.)
Pipe lead-throughs (4 pcs.)
Connector pipes
(4 pcs.)
Upper level
Lower level
Basic circuit diagram
-/+
Centre section
Outer section
with compressor
Outer section
with coil Centre section
Upper level
Lower level
-/+

GB.RXHCF.191011
We reserve the right to alter specifications.
10 www.swegon.com
Possible locations of the
connection hood RX/HC
4. POWER CONNECTION
The cross-sectional dimension of the power supply cable
should take into consideration the ambient temperature
and way the cable is run.
Cables must be routed safely. Make sure that the cables
do not touch components, since surfaces could be hot or
vibrate.
The connection of RX/HC is shown here. For the connec-
tion of the GOLD air handling unit, see the installation
instruction GOLD.
Size 011-020
Dismantle the connection hood to RX/HC.
Connect the incoming power supply to the safety switch,
see the illustration.
5-core system, 400 V ±10%. Also see section 10 Technical
data.
Dismantle the connec-
tion hood to RX/HC
Connect the incoming power
supply to the safety switch
Important:
Installation must be carried out by a authorised electri-
cian.

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 11
Size 025-080
Open the inspection door in front of the electrical equip-
ment cubicle.
Open the cover on the electrical equipment cubicle.
The incoming power supply is routed through the cable
entry on the upper cover panel by the electrical equip-
ment cubicle on the upper level and on to the safety
switch block in the electric equipment cubicle.
At electrical equipment cubicle on the lower level,
dismantle the cover panel above the electrical equipment
cubicle. The incoming power supply is routed through the
cable entry on the upper cover panel, down to the cable
entries on the rear of the electrical equipment cubicle and
on to the safety switch block in the electric equipment
cubicle.
The cable entries on the back of the electrical equipment
cubicle are accessible by opening the inspection door on
the closest air handling unit section.
Possible locations of the safety
isolating switch RX/HC
Safety switch block.
Factory-fitted
cables
The power
supply is con-
nected here
/HC
/HC
/HC
/HC
Connect the incoming power supply to the safety switch
block. The wiring terminal for incoming earth is situated
right next to the safety switch.
5-core system, 400 V ±10%. Also see section 10 Technical
data.
Inspection door in front of the
electrical equipment cubicle.
Electrical equipment cubicle on the upper level Electrical equipment cubicle on the lower level
Cable entries
Safety isolating switch
Cable entries
Safety isolating switch
Cover panel (dismantled)
Inspection door in
front of the electrical
equipment cubicle.

GB.RXHCF.191011
We reserve the right to alter specifications.
12 www.swegon.com
5. COMMISSIONING / CALIBRATION
5.1 General
Commissioning is performed according to the ordinary
commissioning for GOLD RX, see the separate Operation
and Maintenance Instructions.
Calibration of defrosting parameters is performed at the
factory before delivery.
Recalibration may be necessary in the following instances:
Replacement of the GOLD air handling unit’s control card
IQlogic.
The exhaust air coil is modified or deformed.
The exhaust air coil has a surface coating that is consid-
ered small enough not to be rectified.
Other suspicions of erroneous calibration.
It is important during calibration that the coil is dry
and the airflow is unaffected.
5.2 Phase-sequence monitor
GOLD RX/HC size 040 - 080 is equipped with a phase
sequence monitor for compressors.
The phase sequence monitor is installed in the electrical
equipment cubicle for RX/HC, see section 4 for the loca-
tion of the electrical equipment cubicle.
Alarm no. 70:12 is initiated if an incorrect phase sequence
is detected.
1
PSC
DPA51 3-Phase monitoring relay
1
2
The phase sequence is correct when LED 1 is lit.
The voltage is connected when LED 2 is lit.
6. ALARMS
For a description of the alarms, see the GOLD Manual for
Alarms and Information Messages.
5.3 Actions if incorrect phase-sequence
Warning
May only be performed by a qualified electrician or
trained service personnel.
• Stop GOLD RX/HC on the handheld terminal.
• Set the safety switch to position OFF on RX/HC.
• Isolate the power supply to RX/HC.
Important:
Check that the incoming power supply to RX/HC is off
by measuring.
• Switch two phases on the incoming power supply
cable in order to obtain the correct phase sequence
(direction of rotation).
• Connect the power supply to RX/HC.
• Set the safety switch on RX/HC to ON.
• Start GOLD RX/HC, see section 5.1.

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 13
7 MAINTENANCE
7.1 Cleaning
If needed, clean the inside cleaning of the unit by vacuum
cleaning and wiping surfaces with a damp cloth.
Inspections should be performed twice a year.
7.2 Handling of refrigerant
The refrigerant used is R410A.
The refrigerant circuit is completely charged when the unit
is delivered.
Warning
Under no circumstances may the refrigerant circuit be
opened by unauthorised personnel, since it contains
gas under high pressure. Only an accredited refrigera-
tion company shall be permitted to modify or repair the
refrigeration circuit.
RX/HC is equipped with a safety valve to prevent exces-
sively high pressure in the system caused by e.g. a fire.
Important:
Contact Swegon Service in the event of leakage of
refrigerant.
Warning
If refrigerant is exposed to fire or in some other way
becomes superheated in the atmosphere, poisonous
gases can form.
7.3 Leakage tracing interval/
Obligation to report
Must be carried out according to the F-Gas Regulation
EU/517/2014 and associated local legislation.
7.4 Service
Only service personnel trained by Swegon should be per-
mitted to modify the chiller.
Important:
Filling of refrigerant must be performed in accordance
with the recommendations of the refrigerant manufac-
turer.
Avoid direct skin contact with refrigerant and lubricant.
Use tightly sitting protective glasses, protective gloves
and covering work clothes.
Arrange ventilation/point extraction.
In the event of eye contact
rinse the eyes using an eye-wash shower (or with luke-
warm water) for 20 minutes. seek a doctor.
In the event of contact with skin
carefully wash with soap and lukewarm water.
In the event of frostbite
seek a doctor.

GB.RXHCF.191011
We reserve the right to alter specifications.
14 www.swegon.com
8. TROUBLE SHOOTING AND LEAK-
AGE TRACING
8.1 Troubleshooting Schedule
Symptoms Possible cause Action
Compressor is not operating The voltage has been isolated.
Incorrect phase sequence.
The compressor safety circuit has been broken.
Defective compressor.
Check the operating/safety switch. Check the condi-
tion of the fuses.
Check and change the phase sequence.
Check, reset if needed.
Replace the compressor.
Too low capacity Leakage, inadequate refrigerant.
The voltage has been isolated.
No air flow or too low air flow across the evaporator.
Thermostat/Control equipment incorrectly set or defec-
tive.
Leak test, fill with refrigerant if necessary.
Check the operating/safety switch. Check the condi-
tion of the fuses.
Check the air flow.
Adjust the setting or replace faulty components.
The compressor switches off
because the low pressure sensor
has measured an excessively low
value.
Inadequate refrigerant.
No air flow or too low air flow across the evaporator.
The expansion valve is defective.
The low pressure switch is defective.
The cooling system is leaking. Tighten the leak and
charge with refrigerant.
Check the airflow.
Check, replace.
Check, replace.
The compressor switches off
because the high pressure sensor
has measured an excessively high
value.
No air flow or too low air flow across the condenser.
Excessively high exhaust air temperature.
The high pressure sensor is defective.
Check the air flow.
Check the exhaust air temperature.
Check, replace.
Significant freezing on the
evaporator.
The expansion valve is defective or incorrectly set.
No air flow or too low air flow across the evaporator.
Check. Replace or adjust setting.
Check the air flow.
8.2 Leakage Tracing
Leakage tracing should be carried out at least once per
year as a precaution. The leakage tracing inspection must
be documented.
If the system is leaking, this will become apparent firstly
by impaired performance, or if the leakage is substantial,
when the system does not operate at all.
If you suspect that the cooling system is leaking refriger-
ant, check the level of refrigerant in the sight glass located
on the heating circuit’s electrical equipment cubicle.
If you see continuous and a substantial amount of bub-
bling in the sight glass and the reversible heat pump
operates at appreciably lower capacity than normal, the
system is probably leaking. One or several bubbles appear-
ing when the chiller is started up, operation at reduced
capacity or normal operation need not necessarily indicate
a refrigerant deficiency.
If it is bubbling in the sight glass and the chiller operates at
appreciably lower capacity, call for qualified service help.
NOTE! Maintenance work in the refrigerant system is per-
mitted to be carried out only by an accredited inspectorate
(a company with requisite authorisation).

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 15
9. DIMENSIONS
RX/HC 011/012
45 45
J
K
76
52
45 45
J
K76
380 18
52
16
E
/HC
ø ø
350 350
==
Size A B C D E F G H J K L Ø Weight, kg
011 647 1199 324 565 1695 324 647 1295 953 551 2989 500 737-835
012 647 1199 324 565 1695 324 647 1295 953 551 2989 500 765-868
The illustration shows RX/HC integrated in a GOLD standard air handling unit set-up.
The installation length for RX/HC corresponds to the E-measurement.
Placement of the air handling unit sections, duct connections, connection hood, drain pipe, etc. may vary depending on the selected variant.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
The AHU can also be supplied with full face end connection panel (accessory).
RX/HC 014/020
EF
52
F
52
11
M
M
76
45 45J
380 18
C
/HC
Size A B C D E F G H I J K L M Weight, kg
014 757,5 1400 1695 565 205 400 1000 1551 375 115 4 200 3210 188 934-1062
020 757,5 1400 1695 565 205 400 1000 1551 375 115 4 200 3210 188 9 6 4 -1112
The illustration shows RX/HC integrated in a GOLD standard air handling unit set-up.
The installation length for RX/HC corresponds to the C-measurement.
Placement of the air handling unit sections, duct connections, connection hood, drain pipe, etc. may vary depending on the selected variant.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
The AHU can also be supplied with full face end connection panel (accessory).

GB.RXHCF.191011
We reserve the right to alter specifications.
16 www.swegon.com
RX/HC 025/030
M
35
M
45 45J
C
52
E
52
/HC
Size A B C D E F G H I J K L M Weight, kg
025 848 1600 1695 565 200 500 1200 1811 405 1354 200 3391 203 1238 -1426
030 848 1600 1695 565 200 500 1200 1811 405 1354 200 3391 203 1300-1460
The illustration shows RX/HC integrated in a GOLD standard air handling unit set-up.
The installation length for RX/HC corresponds to the C-measurement.
Placement of the air handling unit sections, duct connections, connection hood, drain pipe, etc. may vary depending on the selected variant.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
The AHU can also be supplied with full face end connection panel (accessory).
M
M
45 45J
/HC
40
C
52 52
Size A B C D E F G H I J K L M Weight, kg
035 1038.5 1990 1695 565 245 600 1400 2159 479 1744 295 3772 240 1664-1894
040 1038.5 1990 1695 565 245 600 1400 2159 479 1744 295 3772 240 1740 -1988
RX/HC 035/040
The illustration shows RX/HC integrated in a GOLD standard air handling unit set-up.
The installation length for RX/HC corresponds to the C-measurement.
Placement of the air handling unit sections, duct connections, connection hood, drain
pipe, etc. may vary depending on the selected variant.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
The AHU can also be supplied with full face end connection panel (accessory).

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 17
M
M
40
C
52 52
78 782162
123 835 835
45
402
JJ
/HC
Size A B C D E F G H I J K L M Weight, kg
050 1038.5 2318 1815 565 145 800 1600 2288 344 625 359 3892 172 2138-2414
060 1038.5 2318 1815 565 145 800 1600 2288 344 625 359 3892 172 2322-2580
The illustration shows RX/HC integrated in a GOLD standard air handling unit set-up.
The installation length for RX/HC corresponds to the C-measurement.
Placement of the air handling unit sections, connection hood, drain pipe, etc. may vary
depending on the selected variant.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
The AHU can also be supplied with full face end connection panel (accessory).
RX/HC 050/060
40
M
M
C
52 52
JJ
76
121 1150 1200
45
762485
/HC
Size A B C D E F G H I J K L M Weight, kg
070 1273,5 2637 1815 565 162 1000 1800 2640 320 625 418,5 4362 160 3322-3592
080 1273,5 2637 1815 565 162 1000 1800 2640 320 625 418,5 4362 160 3426-3732
RX/HC 070/080
The illustration shows RX/HC integrated in a GOLD standard air handling unit set-up.
The installation length for RX/HC corresponds to the C-measurement.
Placement of the air handling unit sections, connection hood, drain pipe, etc. may vary
depending on the selected variant.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
The AHU can also be supplied with full face end connection panel (accessory).

GB.RXHCF.191011
We reserve the right to alter specifications.
18 www.swegon.com
Sizing
For correct sizing, we refer to our ProUnit air handling unit
selection program AHU Design.
10. GENERAL TECHNICAL DATA
11. WIRING DIAGRAM
For the wiring diagram, see the separate document.
1) For an outdoor temperature of 26°C, 50% RH, extract air temperature of 22°C, supply air temperature 16°C.
Cooling capacity: rotating heat exchange / coil HC.
2) For an outdoor temperature of -20°C, 95% RH, extract air temperature of 22°C, supply air temperature 20°C.
Heating capacity: rotating heat exchange / coil HC.
Size
Airflow at SFPv
1.8 (m3/s)
Min. airflow
(m3/s)
Cooling capac-
ity (kW)1)
Heating capac-
ity (kW)2)
Refrigerant
(kg) Power supply EER1) COP2)
011 0.89 0.45 14.8 / 8.2 44.0 / 4.1 6 3 x 400 V ±10%, +N +PE 16A 4.7 3.5
012 0.97 0.50 15.9 / 8.9 47.4 / 4.8 8 3 x 400 V ±10%, +N +PE 25A 4.6 3.5
014 1.48 0.75 24.2 / 13.6 72.0 / 7.9 8 3 x 400 V ±10%, +N +PE 25A 5.3 3.6
020 1.53 0.75 25.0 / 14.1 74.1 / 8.4 10 3 x 400 V ±10%, +N +PE 25A 4.4 3.4
025 2.07 0.95 33.7 / 19.1 100.1 / 11.5 10 3 x 400 V ±10%, +N +PE 25A 4.4 3.4
030 2.10 0.95 34.1 / 19.4 101.4 / 11.8 13 3 x 400 V ±10%, +N +PE 32A 4.9 3.4
035 3.12 1.50 51.2 / 28.5 152.0 / 16.4 18 3 x 400 V ±10%, +N +PE 50A 4.5 3.2
040 3.30 1.58 53.8 / 30.3 159.7 / 18.3 20 3 x 400 V ±10%, +N +PE 50A 4.9 3.3
050 4.22 2.05 68.8 / 38.9 204.4 / 23.2 17.5 3 x 400 V ±10%, +N +PE 63A 4.3 3.1
060 4.25 2.08 69.3 / 39.2 205.7 / 23.5 20 3 x 400 V ±10%, +N +PE 63A 3.9 3.0
070 5.51 2.87 90.5 / 50.5 268.8 / 28.7 25 3 x 400 V ±10%, +N +PE 63A 4.0 2.9
080 5.52 2.92 90.6 / 50.6 269.2 / 28.8 30 3 x 400 V ±10%, +N +PE 80A 4.0 2.9

GB.RXHCF.191011
We reserve the right to alter specifications. www.swegon.com 19
12. DECLARATION OF CONFORMITY
12.1 Sizes 011-020
EC DECLARATION OF CONFORMITY
FOR THE MACHINERY
Original
Directive 2006/42/EC, Annex II 1A
The document was originally written in Swedish, other languages are translated copies.
Manufacturer (and whenever applicable its authorized representative):
Company:
Address:
Declares that:
Type of machine:
Machine No.:
Swegon Operations AB
Box 300, SE
-53523 Kvänum, Sweden
Air handling unit
GOLD 011/012, 014/020 F RX/HC and accessories
for each respective size that fall within the scope of these directives
Conform with the Machinery Directive 2006/42/EC, (LVD included).
Also conform to the following directives:
2009/125/EG, Ecodesign (Commission regulation (EU) No. 327/2011)
2009/125/EG, Ecodesign (Commission regulation (EU) No. 1253/2014)
2014/53/EU RED (Radio equipment directive), (EMC included)
The following harmonised standards have been applied:
EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk mitigation
EN 60204-1:2006 Safety of machinery - Electrical equipment of machines - Part 1: Generic standards
EN ISO 13857:2008 Safety of machinery - Safety distances to prevent hazard zones from being reached by arms
and legs. EN 61000-6-2:2005 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
EN 61000-6-3:2007+A1 Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission from
equipment in homes, offices, shops and similar environments
EN 60730-1 Automatic electrical control and control unit for household use - Part 1: Generic standards
EN 378-2:2016 Refrigerating systems and heat pumps. Safety and environmental requirements – Part 2: Design,
construction, testing, marking and documentation
The following other standards and specifications have been applied:
EN 1886:2007 Ventilation for buildings - Air handling units - Mechanical performance
EN 13053:2006+A1:2011 Ventilation for buildings - Air handling units - Rating and performance for units, unit
sections and components
Person qualified to compile the technical documentation:
Name: Dan Örtengren
Address: Box 300, SE-53523 Kvänum, Sweden
Signature:
Place/Date: Kvänum / 08/01/2018 Kvänum / 08/01/2018
Name:
Clarification of: William Lawrance Niklas Tjäder
signature
Position: Product Manager, Kvänum Plant Manager, Kvänum

GB.RXHCF.191011
We reserve the right to alter specifications.
20 www.swegon.com
12.1 Sizes 025-080
EC DECLARATION OF CONFORMITY
FOR THE MACHINERY
Original
Directive 2006/42/EC, Annex II 1A
The document was originally written in Swedish, other languages are translated copies.
Manufacturer (and whenever applicable its authorized representative):
Company:
Address:
Declares that:
Type of machine:
Machine No.:
Swegon Operations AB
Box 300, SE
-53523 Kvänum, Sweden
Air handling unit
GOLD 025/030, 035/040
, 050/060, 070/080 F RX/HC and accessories for each respective
size that fall within the scope of these directives
Conform with the Machinery Directive 2006/42/EC, (LVD included).
Also conform to the following directives:
2009/125/EG, Ecodesign (Commission regulation (EU) No. 327/2011)
2009/125/EG, Ecodesign (Commission regulation (EU) No. 1253/2014)
2014/53/EU RED (Radio equipment directive), (EMC included)
2014/68/EU, PED
The following harmonised standards have been applied:
EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk mitigation
EN 60204-1:2006 Safety of machinery - Electrical equipment of machines - Part 1: Generic standards
EN ISO 13857:2008 Safety of machinery - Safety distances to prevent hazard zones from being reached by arms
and legs. EN 61000-6-2:2005 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
EN 61000-6-3:2007+A1 Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission from
equipment in homes, offices, shops and similar environments
EN 60730-1 Automatic electrical control and control unit for household use - Part 1: Generic standards
EN 378-2:2016 Refrigerating systems and heat pumps. Safety and environmental requirements – Part 2: Design,
construction, testing, marking and documentation
The following other standards and specifications have been applied:
EN 1886:2007 Ventilation for buildings - Air handling units - Mechanical performance
EN 13053:2006+A1:2011 Ventilation for buildings - Air handling units - Rating and performance for units, unit
sections and components
Person qualified to compile the technical documentation:
Name: Dan Örtengren
Address: Box 300, SE-53523 Kvänum, Sweden
Signature:
Place/Date: Kvänum / 28/03/2018 Kvänum / 28/03/2018
Name:
Clarification of: William Lawrance Niklas Tjäder
signature
Position: Product Manager, Kvänum Plant Manager, Kvänum
