User manual
About CONDUCTOR
CONDUCTOR is a regulation system for controlling the
room temperature and air quality. You can create a com-
fortable indoor climate by keying heating, cooling and
airflow settings in the room unit. When you leave the
room, the system automatically regulates the climate until
you enter a new temperature or airflow setting.
In the automatic mode, the CONDUCTOR will regulate
heating and cooling dependent on the circumstances in
the room: is anyone in the room, is a window open, is
the room air humid?
This instruction describes how you as day-to-day user of
the CONDUCTOR, office worker or hotel guest, using the
room unit can manually regulate the heat, coolness and
air quality in the room.
The parts of the room unit



Figure 1. The room unit.
1Display
Shows the current status of the climate system and
information about the room temperature and airflow.
It also shows the settings you enter with the key set.
2Keyset
You use it for changing room temperature and air
volume settings.
3 Temperature sensor
Placed inside the enclosure.
N.B.! In that the measurement of the temperature is in-
fluenced by the surroundings, the measurement of the
room temperature, dependent on where the room unit
is located, is not necessarily representative of the actual
heating or cooling requirements of the room.
To use the CONDUCTOR
The following section describes how you use the room
unit to adjust the room temperature and airflow.
The key set
You use the key set to raise and lower desired room tem-
perature and increase and decrease desired airflow.



Figure 2. The key set.
1 The keys for adjusting the temperature
▲UP To increase the temperature.
▼DOWN To decrease the temperature.
2 Keys for adjusting the airflow
◄LEFT To decrease the airflow.
►RIGHT To increase the airflow.
3Accept key for temperature and airflow
OK CONFIRM Confirm the setting.

4
CONDUCTOR
Swegon reserves the right to alter specifications 20090310 www.swegon.com
The Main image
The main image shows the current status of the climate
system and the temperature and airflow settings.
1
2
3
45
6
Figure 3. The Main image.
1 Current temperature
The field shows present temperature setting. Specified
in ˚C.
2 Heating/cooling
The field shows whether the climate system is set to
heating or cooling.
Heating
Cooling
3 Battery level/window status
The field shows the battery level. If a window is open
in the room this will be visible on the screen.
Good battery status.
Medium good battery status.
Change battery! See Service and sup-
port.
Open window.
4Currentairflow
The indicator shows the present airflow setting.
Low airflow
Normal airflow
High airflow
5Operatingmode
The field shows current operating mode of the climate
system.
N.B.! The field is empty in manual mode.
AUTO Automatic
ECON Economy
STOP Stop
EMERG Emergency
6 Presence status
Someone is in the room.

5
CONDUCTOR
Swegon reserves the right to alter specifications 20090310 www.swegon.com
User manual
To set the desired room temperature
You set the desired room temperature in the main image
by pressing any of the following keys: ▲UP or ▼DOWN.
The first press of the key ( ▲UP or ▼DOWN) will take
you to the temperature setting menu, without affecting
the temperature setting. You can now set your desired
room temperature.
Figure 4. The temperature setting image.
As in the main image, the desired room temperature can
be read in ˚C in the centre of the display.
To increase the temperature
Press ▲UP until the desired room temperature can be
read in the display.
Then press OK CONFIRM to confirm your setting. You
then return to the main image.
To decrease the temperature
Press ▼DOWN until desired room temperature can be
read in the display. Then press OK CONFIRM to confirm
your setting and return to the main image.
To set the desired airflow
You set the desired airflow in the main menu, by pressing
any of the keys ►RIGHT or ◄LEFT.
The first press of the key (►RIGHT or ◄LEFT) will take
you to the airflow adjusting image, without affecting the
airflow setting.
Figure 5. The airflow adjusting image.
The airflow rate can be read on the triangular indicator
in the centre of the image. Depending on the comfort
needs, one of three different levels can be selected: low,
normal or high.
Low airflow
Normal airflow
High airflow
To increase the airflow.
Press ►RIGHT until the desired airflow can be read in the
display.
Then press OK CONFIRM to confirm your setting. You
then return to the main image.
To decrease the airflow
Press ◄LEFT until desired airflow can be read in the
display.
Then press OK CONFIRM to confirm your setting and
return to the main image.
Service and support
If the room unit does not operate in a satisfactory
manner, please contact the person(s) responsible for
maintaining the premises (caretaker or receptionist).

6
CONDUCTOR
Swegon reserves the right to alter specifications 20090310 www.swegon.com

7
CONDUCTOR
Swegon reserves the right to alter specifications 20090310 www.swegon.com
User manual
To increase and decrease the room temperature
1 2 3 4
To increase or decrease the airflow
1 2 3 4
QUICK GUIDE
Press the ▲or ▼
key.
Press the ▲key to
increase the tem-
perature.
Press the ▼key to
decrease the tem-
perature.
Press one time for
each degree if you
wish to change the
temperature.
Press the OK key
to confirm your
setting.
You have now
finished setting
the room tempera-
ture.
You have now fin-
ished setting the
airflow.
Press the OK key
to confirm your
setting.
Press the ►key to
increase the air-
flow.
Press the ◄key to
decrease the air-
flow.
Press one time for
each step if you desire
to change the airflow.
Press the ►or ◄
key.
