SWIFTCOLOR SCL-4000P Installation Procedure
PRINTED IN JAPAN PUB No. 4Y8-8063-020

2
2
How to Read This Guide
When Using the Included Parts
When the parts supplied with this product are required to be used in the installation
procedure, the following symbol indicating that the parts are supplied with the product is
shown in the illustration.
Packaged Item
About the Symbols Used in Illustrations
In this guide, operations performed frequently are represented by the following symbols:
Connector
Disconnect
Screw
Tighten Remove Connect Secure Free
Harness
Push
Insert Plug in Turn on
Sound CheckCheck Visual Check
Claw
Remove
Checking instruction
Check Before Installation
Installation requirements are listed below.
Checking the Power Supply
Power Cord of Printer must be connectable to the outlet (100V to 240V AC -15% to +10%)
exclusively.
Checking the Installation Environment
1. The installation environment must be as described below. Avoid installing Printer near the
faucet, water heater, humidier, or refrigerator.
• Operating temperature range: 5 to 35 degrees Celsius
• Operating humidity range: 10%RH to 90%RH
2. Avoid placing Printer in place exposed to high temperature and humidity, extremely low
temperature, severe temperature changes, and direct sunlight. Especially, avoid placing
Printer near re, out of doors, in distribution warehouse, or in refrigerator.
3. Avoid installing Printer in an area subject to dust.
4. The room must be well-ventilated properly.
5. None of Printer feet should oat. The machine must be held level constantly.
6. When placing Printer on desk, table or the like, it must be sturdy and stable enough to
support weight of Printer.

3
3
Checking the Installation Space
1. The minimum space required for installation is shown below.
691mm
548mm
100mm or more 500mm or more
500mm or more
500mm or more
F-1-1
Installation Precautions
When installing Printer, observe the following precautions:
1) Imaging faults can result due to dew condensation that occurs when the machine is moved
from a cold place to a warm place. Leave the unpacked machine as it is for at least two
hours before installing it.
(Dew condensation: When a metallic object is brought from a low-temperature place to a
high-temperature place, water vapor around it is cooled abruptly and consequently water
drops stick to the surface of the metallic object.)
2) Printer weighs about 24kg. At least two persons are required to install it. In addition, be
sure to keep the machine leveled when lifting it.
F-1-2

4
4
Checking the Included Parts
[1] 1 x Printhead Unit [2] 4 x Ink Tank / for starter
(1 Ink Tank for each color)
[3] 1 x Scraper
[4] 1 x Power Cord (for 120V series) [5] 1 x Power Cord (for 230V series) [6] Spare Paper
CAUTION:
Several types of Power Cords come with Printer. Use appropriate Power Cord for the power supply used at the installation site.
NOTE:
Included Spare Paper can be used for a print image checking.
Check that none of the following is missing:
• Start Guide
T-1-1

5
5
Unpacking Procedure
NOTE:
Printer is secured using xing tape and cushioning materials to protect it against
the vibrations and shocks applied during transportation. By following the procedure
described below, remove all pieces of xing tape and cushioning materials before
installing Printer. Keep the removed cushioning materials for future transportation for
relocation or repair of Printer.
1) Remove 4 grips from the packing carton, and then remove the outer casing.
F-1-3
2) Remove Accessory Box , and then remove Upper Pads.
3) Strip the plastic bag from top to bottom.
F-1-4
F-1-5

6
6
4) Holding the handles at the bottom of Printer, lift Printer to take it out from the package
base.
A
B
A
B
CAUTION:
• Printer weighs about 24 kg. At least two persons are required to lift it up.
• Do not hold the front side of Printer.
F-1-6
F-1-7
5) Place Printer on a horizontal table, and then remove all pieces of xing tape and
cushioning materials visible on the exterior of Printer.
6) Open Roll Cover.
7) Remove all pieces of the tape securing Roll Holder.
8) Push down Upper Unit Open Lever, and then open Upper Unit.
F-1-8
F-1-9

7
7
9) Remove xing tapes and cushioning materials from inside of Printer.
NOTE:
Keep the removed cushioning materials, because they may be used for future
transportation for relocation or repair of Printer.
CAUTION:
• After ink loading, remove the paper on Transport Unit.
• The paper receives the ink drop from Printhead. A shock of closing Upper Unit
may make ink drop.
F-1-10

8
8
Installation Procedure
Mounting Printhead Unit
1) Remove 2 screws to remove Maintenance Cover from Upper Unit.
x2
2) Close Upper Unit.
F-1-11
F-1-12
3) Remove the xing tape, remove Print Module Cover, and then open Lower Printhead
Release Lever.
x4
F-1-13
F-1-14

9
9
4) Remove Blade Cleaner.
5) Take out included Printhead from the package.
F-1-15
F-1-16
6) Remove the cover and cushioning materials.
7) Remove the 4 caps.
F-1-17
F-1-18

10
10
8) Peel the release paper from bundled Scraper.
CAUTION:
Do not touch the area indicated in the following gure.
F-1-19
CAUTION:
Handle scraper as following gure.
F-1-20
F-1-21
9) Take Printhead Unit out of the case.
CAUTION:
• Ink comes out from nozzles of Printhead kept out of the case. Install Printhead
immediately after attaching scraper.
• Do not touch the circuit boards and Printhead face. An ink injection problem can
occur.
F-1-23
F-1-22

11
11
10) Attach Scraper to Printhead.
CAUTION:
Do not touch the area indicated in the following gure.
F-1-24
CAUTION:
Handle scraper as following gure.
F-1-25
F-1-26
11) Put Printhead Unit on the rail guide, and then insert it into Printer until it stops.
NOTE:
Skewering Shaft must be on Printhead Guide Rails.
CAUTION:
If Printhead Unit is insufciently inserted, Lower Printhead Release Lever cannot be
closed.
To conrm Printhead Unit is in the correct position, see if the end of Printhead Unit grip
and the edge of the inner metal plate are in the same plane as shown in the gure.
F-1-28
F-1-27

12
12
12) Mount Blade Cleaner.
F-1-29
13) Close Lower Printhead Release Lever and Upper Printhead Release Lever.
F-1-30
F-1-31

13
13
14) Check that numbers [1] , [2], and [3] indicated on Print Module are visible.
NOTE:
If any one of numbers [1] , [2], and [3] is invisible, Printhead Release Lever ( [1] ,[2] )has
not been closed or Blade Cleaner ( [3] ) has not been mounted. Follow the steps 12) and
13) again.
15) Conrm that Upper Printhead Release Lever is rmly closed as shown in the gure.
CAUTION:
Improper closing of Upper Printhead Release Lever may cause Printer failure.
F-1-32
F-1-33
16) Attach Print Module Cover to Print Module.
x2
x2
CAUTION:
• Set Print Module Cover surely.
• Conrm that claws are in the rectangular apertures.
F-1-34
F-1-35

14
14
17) Push down Upper Unit Open Lever, and then open Upper Unit.
18) Mount Maintenance Cover on Upper Unit.
• 2 screws
x2
19) Close Upper Unit, and then close Roll Cover.
F-1-36
F-1-37
Loading Ink Tanks
1) Open Ink Tank Door.
2) Open Ink Tank Lever for each color while pushing it downward.
F-1-38
F-1-39

15
15
3) Take out included Ink Tanks from the packages, and then remove the cushioning materials.
4) Shake Ink Tank 2-3 times slowly with the ink supply port facing upward as shown in the
gure.
NOTE:
Ink needs to be shaken before installing Ink Tank in Printer because the components
of the pigment ink are likely to settle.
F-1-40
F-1-41
5) Slowly insert Ink Tank as far as it will go.
CAUTION:
Ink Tank cannot be loaded properly if it is inserted in a wrong Ink Tank Slot.
6) Close Ink Tank Lever.
F-1-42
F-1-43

16
16
7) Set the rest of Ink Tanks and close Ink Tank Door.
F-1-44
Installing Cutter Unit
In the case installing Cutter Unit, follow the installation procedure of Cutter Unit.

17
17
Initial Ink Loading
NOTE:
• Initial ink loading takes about 25 minutes.
• Ink loading time might be changed due to the design change.
CAUTION:
• Do not turn the power off or open covers and doors such as Roll Cover during ink
loading.
• Should Power Key be switched OFF or covers be opened during ink loading, its
operation will be terminated and has to be started from the beginning. In such a
case, turn on the power to start ink loading again.
• Restarting the ink loading results in more ink consumption.
PAUSE FEED
BACK
FEED
STATUS
ERROR
BK C M Y
MC
F-1-45
1) Several types of Power Cords come with Printer. Use appropriate Power Cord for the
power supply used at the installation site.
2) Connect Power Cord to the outlet.
3) Turn the power on. STATUS Lamp changes from lit to ashing and initial ink loading starts
automatically. When ink loading is complete, STATUS Lamp changes from ashing to lit
and a buzzer sounds. Be sure to move to the next step after STATUS Lamp is lit.
PAUSE FEED
BACK
FEED
STATUS
ERROR
BK C M Y
MC
F-1-46
F-1-47

18
18
Operation Check
After completion of installation, print any image, that is usually used, following the procedure
below and check that the printing result is free from faint print and/or color deviation.
1. Install software in Computer and load printing paper that is usually used in Printer.
2. Print any image, that is usually used and check the printing result.
In case the printing result contains faint print and/or color deviation, clean Printhead and/or
adjust Printhead position.
