OMEGA Scan’O’Vision MYRIA –PHOTO FINISH CAMERA
USER’S MANUAL
3503.502.02 l Version 1.0 l October 2017
MYRIA 10 & MYRIA 16

Caution and safety precautions
Never bypass a power cord ground lead by breaking off the ground pin, or by using inappropriate extension
cords or adapters.
Never plug a power cord into the AC power source until you have made sure that all installation, cabling and
power levels, are proper, and that the applicable procedures in this manual have been followed.
Protect the equipment against splashing, rain and excessive sun rays.
Never use the device if it is damaged or insecure.
Verify the selection of the power distribution.
Verify that the voltage quoted on the rating plate is the same as your voltage. Connect the appliance only to
power sockets with protective earth. The use of incorrect connection voids warranty.
This program may be modified at any time without prior notification.
Do not open the case; there is nothing that needs servicing inside it. Nevertheless, if the case must be
opened, you must call for some qualified personnel. The power supply cable must be disconnected before
opening the case.
During the transport of all Swiss Timing equipment delivered with a reusable carry case, the said case should
be used at all times. This is imperative to limit the damage, such as shocks or vibration that can be caused to
the units during transport.
The same cases should also be used when returning equipment to Swiss Timing for repair. Swiss Timing
reserves the right to refuse all guarantees if this condition is not fulfilled.
If the installation includes a horn, be sure to maintain a sufficient security distance from the public.
Documentation Updates
Swiss Timing LTD reserves the right to make improvements in the products described in this documentation at any
time without prior notice. Furthermore, Swiss Timing LTD reserves the right to revise this documentation in its content
at any time and without any obligation to notify any person or organization of such revision.
Disclaimer
The information provided in this documentation has been obtained from sources believed to be reliable, accurate and
current. However, Swiss Timing LTD makes no representation or warranty, express or implied, with respect, but not
limited to, the completeness, accuracy, correctness and actuality of the content of this documentation. Swiss Timing
LTD specifically disclaims any implied warranty of merchantability, quality and/or fitness for any particular purpose.
Swiss Timing LTD shall not be liable for errors contained in this documentation or for incidental or consequential
damages in connection with the supply, performance or use of this documentation.
Environment
This symbol indicates that this product should not be disposed with household waste. It has to be
returned to a local authorized collection system. By following this procedure you will contribute to the
protection of the environment and human health. The recycling of the materials will help to conserve
natural resources.
Copyright
© Swiss Timing LTD
All rights reserved.
This documentation may not, as a whole or in part, be copied, translated, reproduced, transmitted or reduced and/or
stored to any electronic medium or machine-readable form without the prior written consent of Swiss Timing LTD

OMEGA Scan'O'Vision MYRIA / OSV MYRIA
Swiss Timing LTD Phone [phone]
P.O. Box 138, Rue de l’Envers 1 [email protected]
CH-2606 Corgémont - Switzerland www.swisstiming.com
TABLE OF CONTENTS
1INTRODUCTION...................................................................................................................1
1.1 MYRIA parts.......................................................................................................................2
1.2 Definitions .........................................................................................................................2
2INSTALLATION.....................................................................................................................3
2.1 Installation of the camera .................................................................................................3
2.2 Wiring the installation.......................................................................................................4
2.3 Power ON / Power OFF .....................................................................................................5
2.4 Indicators...........................................................................................................................5
3SOFTWARE..........................................................................................................................6
3.1 Computer specification .....................................................................................................6
3.2 Software installation .........................................................................................................6
3.3 Network card configuration ..............................................................................................8
3.4 Software use......................................................................................................................9
3.4.1 Information about camera.................................................................................9
3.4.2 Test Window ......................................................................................................9
3.4.3 Synchronization Window .................................................................................10
3.4.4 Camera settings ...............................................................................................10
4TECHNICAL SPECIFICATIONS ..............................................................................................11
4.1 General specification.......................................................................................................11
4.2 Electric specification .......................................................................................................11
4.3 Certification.....................................................................................................................11
4.4 Connections.....................................................................................................................12
5PREVENTION AND MAINTENANCE ............................................................................13
5.1 Storage ............................................................................................................................13
5.2 Maintenance ...................................................................................................................13
6APPENDICE........................................................................................................................13
6.1 Index figures....................................................................................................................13
6.2 Version history ................................................................................................................13

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 1
1 INTRODUCTION
With its patented technology, the OMEGA Scan'O'Vision MYRIA camera lets you align the camera
very easily on any finish line using a video image.
This manual explains the general principles of the OMEGA Scan'O'Vision MYRIA camera (OSV
MYRIA), its installation, its working and its connections. It also contains information to install the
software and driver on your computer and specific software function for this camera. The
complete use of the software is described in the manual 3434.501.
A 10x (MYRIA 10) or 16x (MYRIA 16) optical zoom lens is integrated in the camera housing. It is
fully remote controlled (zoom, iris and focus). It allows setting the camera in almost any location
and having a perfect image framing.
OSV MYRIA camera is weather proof. Its temperature sensor will automatically control the internal
fan.

Page 2 3503.502.02 Version 1.0
1.1 MYRIA parts
1. Lens protective cap (lens is behind)
2. Air output (with internal filter)
3. Status LEDs
4. Air input (with internal filter)
5. I/O connector
6. Ethernet connector
7. Fixation plate
Figure 1 –MYRIA 10/16 front view
Figure 2 –MYRIA bottom view
1.2 Definitions
The camera is typically supplied with a support permitting the setting of its position according to 4
axes, here are the definitions used in this manual:
Translation
Horizontal displacement, perpendicular to the finish line.
Pan
Rotation in the horizontal plane.
Tilt
Rotation in the vertical plane, in the axis of the finish line.
Swivel
Rotation in the vertical plane, perpendicular to the finish line (to have the
sensor "vertical" in the plane of the finish line).

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 3
2 INSTALLATION
2.1 Installation of the camera
The photo finish camera must be installed exactly on a virtual extension of the finish
line and the sensor must be vertically perpendicular to this line.
The inclination of the camera is important for the ease of judgment. In general, a vertical
inclination of 8oto 10ois used for the rowing and the canoeing, and of 10oto 20o(in relation to the
middle of the finish line) for the cycling, the horse-racings and of greyhound. For athletics, an
angle of 25oto 30ois recommended in relation to the farthest lane in order to prevent the
competitors in the foreground masking another.
Centre the tripod on the extension of the finish line. If it is equipped with a spirit level,
align the bubble precisely in the middle of the reference mark. Then slowly tighten all
screws checking bubble does not move. For a better stability, spread the legs as far apart
as possible and do not raise the central extension tube:
On the tripod, first to fix the slide permitting the translation then the support permitting
the three way rotation. If required, move the tripod so that the translation movement can
be made perpendicularly (horizontally) to the finish line.
Fix the camera on the support (quick lock). Thereafter, to remove the camera, it is
sufficient to disassemble this quick lock (with security button). For more of details, please
refer to the manual for the support.

Page 4 3503.502.02 Version 1.0
The camera can also be fixed from top (for example to fix it under a roof); for that you should
invert the fixation plate with its screws between bottom and top:
2.2 Wiring the installation
Connect the delivered Start-Finish cable (3503.625) on the bottom of the camera on the I/O
connector. Connect the start device on the TUCHEL Start plug and the finish photocell on the
FINISH bananas. If you want to do manual recording of images, it is recommended to connect a
pushbutton (option 2872.003) on the FINISH bananas.
Connect the 10m network cable Ethernet Gigabit (9051.1315) between the Ethernet connector on
the camera and the PoE connector of the PoE injector (power supply). Connect the 2m network
cable Ethernet Gigabit (9051.1317) between the LAN connector of the PoE injector and the
computer.
Connect the power cord between the PoE injector and the mains; the camera will automatically
start up. To secure system availability during power disturbance, it is recommended to connect
the PoE connector on an Uninterruptible Power Supply (UPS).

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 5
2.3 Power ON / Power OFF
As soon the camera is powered by the Ethernet cable (PoE), the camera will boot; it takes about
40 seconds to be in operation. There is no ON/OFF switch.
When the power is removed (Ethernet cable unplugged or PoE injector switched off), the camera
will turn off, losing its time base (synchronisation).
2.4 Indicators
On the rear panel, different LEDs indicate the state of the camera:
LED
Name [color]
Description
Inclinometer left [yellow]
If blinking: see from rear, the left side of the camera is too
high. The faster the LED blinks, the closer the sensor is to
vertical.*
WiFi status [blue]
ON: WiFi enabled.
Ethernet status [green]
Flashing when Ethernet activity.
General status [green]
ON: µC powered, initialization in progress or freeze.
Fast blinking (~5Hz): µC working, time based not sync.
Slow blinking (~1Hz): µC working, time base sync.
PoE status [green]
ON: AT type 2 compliant PSE detected.
Inclinometer Right [yellow]
If blinking: see from rear, the right side of the camera is too
high. The faster the LED blinks, the closer the sensor is to
vertical.*
*: sensor is vertical when and are switched ON.

Page 6 3503.502.02 Version 1.0
3 SOFTWARE
3.1 Computer specification
OSV MYRIA camera works with a computer (laptop or desktop) with the following minimum
specifications:
For acquisition computer
(with camera connection)
For judging computer
(without camera connection)
Operating system
Windows 7 or 10
Windows 7 or 10
Screen resolution
1920x1080 pixels
1920x1080 pixels
Hard disk
SSD, minimum 100GB
any
Network for camera connection
1Gb/s
MTU 9kB (jumbo frame packet
size)
Network for computers
connection
2nd network adapter (different
from camera).
1Gb/s recommended.
For example USB3-Ethernet
adapter DeLock 62121
1Gb/s recommended
Various
USB port for software
installation
USB port for software
installation
3.2 Software installation
1. Install the software available on the delivered support. Installer will also install PLEORA eBUS
SDK 64-bit (driver for camera Ethernet connection). During installation, do not remove the
check box for “Install GigE Vision Driver”. Computer reboot can be requested.
2. For a computer used without camera (judgment, diffusion), installation is finished. For
computer with camera or Bridge connected, continue with next points.

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 7
3.Run “eBUS Driver Installation Tool” from the list of All Programs: “Pleora Technologies Inc”
“eBUS SDK”.
4. Click on the “Advenced…” button of “GiGE VISION” part.
5. In the scroll list, select the network adapter where the camera is connected. Ensure that
check boxes “eBUS Universal Pro for Ethernet” and “Jumbo Packet” are checked.
6. Close the windows.

Page 8 3503.502.02 Version 1.0
7. To run the software, use the shortcut on the desktop (created by the installer) or run
C:\OSV8\OSV7.exe.
3.3 Network card configuration
In addition to above driver setting, you should specify the TCP/IP address:
Press the windows button "Start", "Settings" then "Control panel".
Double click on "Network Connections".
Right click on the line corresponding to the network card on which MYRIA camera is
connected and choose "Properties".
Highlight "Internet Protocol (TCP/IP)" then to click on the "Properties" button.
Click on "Use the following IP address:" and enter data, as in the picture below:
Note: IP address is 192.168.2.100 for OSV MYRIA connection and 192.168.0.100 for OSV-STAR connection.
Click on the "OK" button of this window, and then on the "OK" button of the previous
“Connection Properties” window.
It is also recommended to fix the transmission speed to 1Gb/s between the computer and the
camera (this setting is not available for all network interface):
Press the windows button "Start", "Settings" then "Control panel".
Double click on "System ".
Click on the "Hardware" tab and then on the "Device Manager" button.
Right click on the network adapter where the camera is connected and select "Properties".

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 9
Select the "Advanced" tab; select "Link Speed/Duplex Mode" in the list and change the
value from "Auto Negotiation" to "1000Mbps/Full Duplex". Note: the previous text in
magenta may change depending of the network adapter.
Close all the opened windows by clicking on the corresponding "OK" button.
3.4 Software use
You can read OSV-STAR and OSV MYRIA images with any OSV7 software configuration.
The complete use of the software is described in the manual 3434.501 (available in the
\Documentation sub-directory. Following are some change related to MYRIA camera.
3.4.1 Information about cameraWith "Help", "About Hardware" menu, you can get a lot of
information about the camera; for example its inclination or the temperature inside the camera
(hottest point).
3.4.2 Test Window
With OSV MYRIA camera, when ready is set, it is automatically reset if a start pulse is received
(with OSV-STAR camera, Ready is independent of Start impulse).

Page 10 3503.502.02 Version 1.0
3.4.3 Synchronization Window
The logo representing the synchronization status has a different signification.
OSV-STAR
OSV MYRIA
Sync not done or sync done
automatically with PC time
Sync not done or Manual sync done or sync
done automatically with PC time
Sync done (manual or with start
pulse)
Sync done with start pulse
3.4.4 Camera settings
White balance
To do the automatic white balance:
In Camera settings active the matrix view (
should be displayed).
Enable the horizontal references ( should be
displayed).
With the left mouse button, draw a rectangle
in the live image where white should be.
Click on the Auto-Adjust button.
Zoom in matrix
To change the location of one of the three zoom
square:
In Camera settings active the matrix view (
should be displayed).
Disable the horizontal references ( should be
displayed).
Click on one of the three zoom (at the right of
the matrix view) to select it.
Click in the matrix view to assign the center
location of the vertical position (horizontal
position is automatically fixed).
Choice of timing line in matrix
The vertical line (timing line) can be move by using < and > buttons. The | button will replace it in
the center. When the horizontal references are enabled ( is displayed), you can also do SHIFT-
right-click in the matrix image to place the timing line.
Active Link
Active Link+ is not available with MYRIA software. Instead you should:
Open the race or do Fast Open on both instances.
If the race is not "seen", wait until the start occurs - that should solve the problem.
When race is "seen" on both instances, press "Active link" button on main instance.

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 11
4 TECHNICAL SPECIFICATIONS
4.1 General specification
Acquisition speed
500 to 2’000 lines per seconds or
500 to 10’000 lines per seconds1
Resolution
2048 pixels (at any speed)
Nbr. of color per pixel
>16 millions
Time base precision
±0.1ppm (oven-controlled)
Transmission
Ethernet 1Gb/s (PoE PD), 9kB jumbo frame
IEEE 802.3at (25W)
IEEE 1588 (Precision Time Protocol)
Max. distance between camera and computer2
100m (Cat5e Ethernet cable)
Temperature
Working: 0oC to +50oC
Storage: -20oC to +70oC
Protection
IP55
Camera dimension
415 x 270 x 143mm (LxWxH)
Camera weight
MYRIA 10: 3.6kg MYRIA 16: 4.5kg
Lens (included in camera housing)
Zoom ratio
Vertical field angle
Max. aperture
Minimum object distance
Remote control
MYRIA 10
10x
6.5oto 58.8o
F1.4
1.2m
Zoom, Aperture, Focus
MYRIA 16
16x
4.2oto 61.3o
F1.8
1.0m
Zoom, Aperture, Focus
4.2 Electric specification
Condition
Min
Typ
Max
Unit
Power supply
PoE injector side (up to 100m cable)
48
56
V
Power supply
On camera input
42
56
V
Power consumption
10m cable
14
15
W
Power consumption
100m cable
19
21
W
4.3 Certification
According to IEC 61326-1:2014 Class A equipment:
IEC 61000-4-2:2009 Electrostatic discharge
IEC 61000-4-3:2008 Electromagnetic fields
IEC 61000-4-4:2004 Electrical fast transients (Burst)
IEC 61000-4-5:2005 Surge
IEC 61000-4-6:2008 Conducted disturbances
IEC 61000-4-8:1993 / A1:2001 Power frequency magnetic field
IEC 61000-4-11:2004 Voltage dips and interruptions
CISPR 16-2-3:2010 Radiated electromagnetic field
CISPR 16-2-1:2008+A1:2010 Conducted disturbance mains
1
Depends of purchased option
2
Between 100 and 200m, an amplifier can be inserted; for longer distance, an optical fibre should be used. Please
contact Swiss Timing for information about available interface.

Page 12 3503.502.02 Version 1.0
RoHS 2 compliant
2011/65/EU Restriction of Hazardous Substances
METAS (Swiss Federal Institute of Metrology)
Δt / t = (-5.8 ± 4.0) 10-8 ~5ms / 24 hours
4.4 Connections
Ethernet
Standard RJ45 Ethernet connector Cat 5e. Support also cable plug housing Neutrik NE8MC-B IP54
connector. Ethernet 1Gb/s, 9kB jumbo frame, Powered Device (PoE PD).
Pin nbr
Signal
1
TxRx A+ and VDC1+
2
TxRx A- and VDC1+
3
TxRx B+ and VDC1-
4
TxRx C+ and VDC2+
5
TxRx C- and VDC2+
6
TxRx B- and VDC1-
7
TxRx D+ and VDC2-
8
TxRx D+ and VDC2-
I/O
Matching cable connector: Binder serie 723 (09-0129-70-12)
Pin nbr
Signal
View
A
Not connected
B
Ready + (1)
C
Finish + (2)
D
Finish - (2)
E
Start + (2)
F
Start -(2)
G
Rx [RS232 input] (3)
H
GND
J
5VDC output [max 100mA]
K
PPS input
L
Ready - (1)
M
Tx [RS232 output] (3)
Notes:
(1) Output to control an armed LED indicator on the starting device.
(2) Timing pulse input.
(3) Rx & Tx can be used for GPS connection or for Remote Positioning Support connection.

OMEGA Scan'O'Vision MYRIA
Version 1.0 3503.502.02 Page 13
5 PREVENTION AND MAINTENANCE
5.1 Storage
Ideally, the Scan'O'Vision MYRIA camera should be stored in its transporting case in a place which
is not too humid and where the temperature is around 20°C.
5.2 Maintenance
Never touch the glass in the front of the camera with your fingers. After use, please always replace
the protection cap.
It is recommended to clean the glass in the front of the camera regularly with a photographic link
free cloth.
6 APPENDICE
6.1 Index figures
Figure 1 –MYRIA front view ................................................................................................................2
Figure 2 –MYRIA bottom view ............................................................................................................2
6.2 Version history
Version
Date
Modifications since last version
1.0
02.10.2017
Initial version

Swiss Timing LTD Phone [phone]
P.O. Box 138, Rue de l’Envers 1 [email protected]
CH-2606 Corgémont - Switzerland www.swisstiming.com
