Swisstone BX 840 TWS User manual

Instructions BX 840 TWS
EN

2
OVERVIEW
Previous song
Next song
Light mode
Play
modes
Power on/off
Bluetooth LED indicator
Battery LED indicator
Pause/Play
Volume down/up
Charging port
Power output
TF card reader
AUX input
Reset key
WHAT’S IN THE BOX
• 1 x speaker
• 1 x AUX in cable (ø 3.5 mm)
• 1 x Type-C charging cable
• 1 x user manual

3
CHARGING
1. Before rst time use, fully charge the built-in battery.
2. Connect the Type-C USB Cable (included) between the USB
Type-C port on the speaker, and a USB port on a computer
or USB AC-Adapter.
Battery status LED indicator
Low battery (<20%) Blinking Red (sound prompts 3 times at
20%, 10%, and power off)
30% charged 1st white light ashes
30%-70% charged 2nd white light ashes
70%-99% charged 3rd white light ashes
3 solid white lights Fully charged
Note: When the battery charge <5%, the speaker will power off
automatically.
POWER ON
Power On Press power button ! until you hear a rising tone and
LED indicator light on.
Power Off Press power button ! until hear a descending tone
and LED indicator light off.
BLUETOOTH CONNECTION
Make sure that the speaker is within 10 meters from your mobile
device,
1. Press power button ! until you hear a rising tone and LED
indicator fast blinking blue.
2. Go to the Bluetooth settings on your mobile device, search and
select “BX 840 TWS” from the list.
3. Once paired, the Bluetooth LED indicator turns solid blue.
Note:
• When power on, the BX 840 TWS automatically reconnects to
the last mobile device it was connected to. (The BX 840 TWS
can memorize maximum of 8 paired devices).
• The BX 840 TWS will automatically shut down after 10 minutes
in pairing mode if no devices are paired for power saving.

4
BLUETOOTH DISCONNECTION
Press M mode button until the Bluetooth LED indicator is fast
blinking blue to disconnect the current connected device and go
into new Bluetooth-paring mode.
MUSIC CONTROL
Play/Pause Press 9
Volume up Rotate the volume control clockwise
Volume down Rotate the volume control counterclock-
wise
Next track Press 9|
Previous track Press |8
Switch Bluetooth
mode/AUX-In mode
Press M
POWER BANK FUNCTION
1. Lift the port cover.
2. Plug the USB cable to the USB Power Out port on speaker
and to the charging port on the mobile device. If the speaker
is powered on, it will automatically charge. If the speaker is
powered off, press the power on button ! to start the power
bank function.
Note: The power bank function is automatically turned off after
10 seconds in BX 840 TWS power off status if no device is
connected.
3. To check the battery charge level: Press the power on button !.
Battery status indicator, see “Charging” on page 3.
TRUE WIRELESS STEREO (TWS)
The TWS technology enables you to use two BX 840 TWS to pair
via Bluetooth to create a wireless dual-channel system to deliver
true stereo sound effect.

5
TWS connection operation
1. Place the two BX 840 TWS near each other (the distance should
not be over 10 meters).
2. Power on the two BX 840 TWS by pressing the power button !.
3. Double press the power button ! on one BX 840 TWS as
MASTER speaker (playback left channel ), the Bluetooth LED
indicator is fast blinking blue and green, the two BX 840 TWS
will pair other automatically (The other BX 840 TWS will be the
SLAVE speaker and playback right channel)
4. Once paired, the MASTER and SLAVE speaker Bluetooth LED
indicator turn solid blue.
Disconnect the TWS connection
Press M mode button on one of the BX 840 TWS until the
Bluetooth LED Indicator is fast blinking blue to disconnect the TWS
connection.
AUX-IN PORT
External audio source
1. Power on the BX 840 TWS.
2. Connect your external device to AUX-input port on speaker. using
the AUX Cable (ø 3.5 mm),
3. AUX-in mode will turn on automatically, the Bluetooth LED
indicator turns solid green
Note: In AUX-IN mode, skip songs does not work.

6
LED LIGHTS MODE
Click button to change the LED Lights modes.
1. Musical Pulse (pulse from bottom to top)
2. Half-circle rotation (rotate with the rhythm of the music)
3. Full-Cyclic rotation (rotation speed is automatically adjusted with
the music)
4. Flash rhythm (brightness ashes with the beats of the music)
5. Musical Pulse (from the middle to the upper and lower pulse) The
current trial production sample does not have this mode
6. Turn off the lights
SOUND MODE
Double click the play/pause 9 button to change the sound mode.
• The Bluetooth LED indicator slowly flash blue in outdoor mode,
• The Bluetooth LED indicator keep solid blue in indoor mode.
Note: This BX 840 TWS default mode is indoor.
TF CARD READER (MICRO SD CARD)
Just simply insert your TF card into the slot, the speaker will auto-
matically change to TF card reader mode and play the MP3 music
store in the card.
RESET THE SPEAKER
If the function buttons are not working, disconnect the charging
cable, place a small pin(< ø 3 mm) into the reset key and hold it for
2 seconds until the LED light turns off.
TROUBLESHOOTING
Cannot Power On
• Charge the BX 840 TWS and make sure it has enough battery.
Cannot connect to a device
Please check the following:
• The Bluetooth device supports A2DP profile.
• The BX 840 TWS is within 10m from the device.
• The BX 840 TWS is in pairing mode, the LED indicator blinking blue.

7
No Sound
• Make sure the music volume is at audible level on both your
device and BX 840 TWS.
• Make sure your device is successfully paired with the
BX 840 TWS, the LED indicator turns solid blue.
Poor sound quality
• Move the device closer to the BX 840 TWS or remove any
obstacle between the device and the BX 840 TWS.
TECHNICAL SPECIFICATIONS
Bluetooth Version 5.0
Bluetooth frequency band 2402-2480 MHz
Bluetooth maximum
radio-frequency power
< 10 dBm
Bluetooth proles
supported:
A2DPV1.2; AVRCPV1.4, GAVDPV1.2;
AVDTPV1.2; SPPV1.2; AVCTPV1.2
Wireless work distance: 10 m
Rated Power: 2 x 30 W
Driver Unit: ø 31 mm, 8Ω,15W x 2
ø 70 mm, 4Ω, 35W x 2
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: ≥80dB
Battery: Lithium-ion 7.2 V / 5000 mAh
(4 x 3.7 V / 2500 mAh)
DC input voltage/current: Type-C USB 5V/0.5A-2A
Playtime: 3-10 hours (varies by volume level and content)
Battery charge time: approx. 5-6 hours
Dimensions: 372 x 193 x 166 mm
Weight: 3.7 kg
Working temperature: Temperature: 0º C ~ 40º C
Humidity: 0% ~ 85% RH
Storage temperature: Temperature: -30º C ~ 60º C
Humidity: 0% ~ 90% RH

8
SAFETY INSTRUCTIONS
WARNING
The unit and the accessories can contain small parts. Keep all of the equipment
out of the reach of small children. The mains adapter is the disconnect device
between the product and mains power. The mains socket outlet must be close
to the equipment and easily accessible.
AREAS WITH EXPLOSION RISK
Always turn off the unit when you are in an area where there is a risk of
explosion. Follow all signs and instructions. There is a risk of explosion in
places that include areas where you are normally requested to turn off your car
engine. In these areas, sparks can cause explosion or re which can lead to
personal injury or even death.
Turn off the unit at lling stations, and any other place that has fuel pumps and
auto repair facilities.
Follow the restrictions that apply to the use of radio equipment near places
where fuel is stored and sold, chemical factories and places where blasting is
in progress. Areas with risk for explosion are often – but not always – clearly
marked. This also applies to below decks on ships; the transport or storage
of chemicals; vehicles that use liquid fuel (such as propane or butane); areas
where the air contains chemicals or particles, such as grain, dust or metal
powder.
LI-ION BATTERY
This product contains a Li-ion battery. There is a risk of re and burns if the
battery pack is handled improperly.
WARNING
Danger of explosion if battery is incorrectly replaced. To reduce risk of re or
burns, do not disassemble, crush, puncture, short external contacts, expose
to temperature above 60° C (140° F), or dispose of in re or water. Recycle or
dispose of used batteries according to the local regulations or reference guide
supplied with your product.
PROTECT YOUR HEARING
WARNING
Excessive exposure to loud sounds can cause hearing damage.
Exposure to loud sounds while driving may distract your attention and
cause an accident.
Do not hold the device near your ear when the loudspeaker is in use.

9
WHEN YOU FLY
It is prohibited to use the unit in ight. Turn off the unit before you board a
plane. Using wireless Bluetooth units inside a plane can pose risks to air safety
and interfere with telecommunications. It may also be illegal.
CLEAN THE UNIT
• Clean the surface with a soft, dry cloth.
• Do not use any sprays near the unit. Do not use any solvents, chemicals, or
cleaning solutions containing alcohol, ammonia or abrasives.
• Do not allow liquids to spill into any openings.
CARE AND MAINTENANCE
Your unit is a technically advanced product and should be treated with the
greatest care. Negligence may void the warranty.
• Protect the unit from moisture. Rain, snow, humidity, and all types of liquids
can contain substances that corrode the electronic circuits. If the unit gets
wet, you should immediately power off the unit.
• Do not use or keep the unit in dusty, dirty environments. The unit’s moving
parts and electronic components can be damaged.
• Do not keep the unit in warm places. High temperatures can reduce the
lifespan for electronic equipment, damage batteries and distort or melt certain
plastics.
• Do not keep the unit in cold places. When the unit warms up to normal
temperature, condensation can form on the inside which can damage the
electronic circuits.
• Do not try to open the unit in any other way than that which is indicated here.
• Do not drop the unit. Do not knock or shake it either. If it is treated roughly the
circuits and precision mechanics can be broken.
• Do not use strong chemicals to clean the unit.
The advice above applies to the unit, battery, mains adapter and other
accessories. If the phone is not working as it should, please contact the place
of purchase for service. Don’t forget the receipt or a copy of the invoice.
DECLARATION OF CONFORMITY
Hereby, Doro declares that the radio equipment type swisstone BX 840 TWS
is in compliance with Directives: Directives: 2014/53/EU and 2011/65/EU
including delegated Directive (EU) 2015/863 amending Annex II.
The full text of the EU declaration of conformity is available at the following
internet address:
www.swisstone.de

WARRANTY
In case you need support during setup or usage of your device you will nd the
relevant contact details on the following website: www.swisstone.de.
If you detect a defect resulting from manufacturing and/or material faults within
24 months from purchase, please contact your dealer. The warranty does not
apply for improper treatment or failure to comply with information contained
in this user guide, for interference on device executed by dealer or user (e. g.
installations, software downloads,…) and for total loss. Furthermore it does not
apply to ingress of liquids, use of force, non-maintenance, improper operation
or other circumstances caused by the user. It also does not apply to failure
caused by a thunderstorm or any other voltage uctuations. The manufacturer
reserves the right in this case to charge the customer for replacement or repair.
For wear parts such as batteries, keyboard or casing a restricted warranty
period of 6 months is valid. Manuals and possibly supplied software are
excluded from this warranty. Further or other claims arising from the manu-
facturer’s warranty are excluded. Thus, there is no liability claim for business
interruption, loss of prots, loss of data, additionally installed software by user
or other information. The receipt with purchase date forms the warranty proof.
Bluetooth® and the Bluetooth® logo are registered trademarks of Bluetooth
SIG, Inc.
© IVS GmbH 2020 • All rights reserved
English
QSG_Swisstone_BX_840_TWS_en_v10
