Swisstone TIMEDOT User manual
EN
TIMEDOT
Instructions
2
Thank you for purchasing swisstone TIMEDOT for the Amazon Echo Dot (2. Gen.).
It combines with the Echo Dot (2. Gen.) to make the perfect smart alarm clock,
adding an LED clock face, stylish fabric grill and improved speakers so you can wake
up easily.
Use Alexa to set alarms, listen to music, read the morning headlines and more.
1. Overview
1. Brightness/Set:
Press to change brightness.
Press and hold for two seconds to set
the clock .
2. Upwards clock adjustment for hours/
minutes
3. Downwards clock adjustment for
hours/minutes
4. USB Charging Port
5. Power adaptor input socket
6. Micro USB-connector for
Echo Dot (2. Gen.)
7. 3.5mm stereo jack connector for
Echo Dot (2. Gen.)
6
7
4
3
2
1
5
3
2. Insert your Echo Dot (2. Gen.) (not supplied)
Make sure that the sockets on your Echo Dot (2. Gen.) are lined up with the cable
entry points on your speaker. Also make sure to not damage the cables when you
insert the Echo Dot (2. Gen.).
4
3. Connect both cables
These cables will connect your Echo Dot (2. Gen.) with the power and to the built-in
speakers.
5
4. Power up
Connect the supplied power adaptor to the input socket (DC 5V) on the rear of the
unit.
5. USB Charging
Use the USB 5V 1A port for charging smartphones and other portable devices.
6
6. Set the clock
1. Press and hold the ‘set’ buon for 2 seconds. The clock LEDs will ash.
2. Adjust the hour using the up/down buons
{
/
}
.
3. Press the ‘set’ buon . The minute LEDs will ash.
4. Adjust the hour using the up/down buons
{
/
}
.
5. Press the ‘set’ buon. The clock LEDs will stop ashing.
7. Adjust the LED brightness
Press the 'brightness' buon to cycle through the clocks brightness modes.
8. Set up or stop Timer & Alarm
To adjust the volume for alarm clock and mer, go to
Devices
(boom right) in the
Alexa app.
Select your Echo Dot (Echo and Alexa)
Sound
Alarm, mer and nocaons
(slider). To learn how to select a new sound for an alarm clock, go to
Customs sounds
Alarm
.
Use voice control to set mulple mers and alarms. You can also set repeated alarms.
“Wake me up at 6 in the morning.”
“Set the alarm clock to 7:30 clock.”
“Set the mer to 10 minutes.”
“When is my alarm clock set?”
“Set the alarm clock for [me / day].”
“What alarm clocks are set for
tomorrow?”
“Which mers are set?”
“Stop” (when the alarm or mer sounds)
“Napping” (when the alarm sounds)
“End the mer for 10 minutes.” (If you
have set several mers)
7
9. Alexa - More things to try
Music:
“Alexa, play some Prime Music. Alexa,
shue my mellow playlist. Alexa, play my
Classic Jazz staon”
“Alexa, what song is this?”
“Alexa, buy this song”
Shows, Podcasts & Radio
“Alexa, play the program In Our Time”
“Alexa, play BBC 1 radio”
Shop Amazon
“Alexa, order bin bags”
“Alexa, buy more kitchen towels”
Quesons & Answers
“Alexa, what Italian restaurants are near
me”
“Alexa, tell me a joke’’
“Alexa, Wikipedia Winston Churchill”
News, Weather & Trac
“Alexa, what is the latest news?”
“Alexa, what’s the weather forecast?”
Smart Home
“Control supported smart home devices
like swisstone SH 310 lights. To get
started, go to the Alexa App’’
“Alexa, dim lights to 50%”
“Alexa, turn on the fan”
Use These Anyme
“Alexa, stop’’
“Alexa, volume ve. (1-10)”
8
10. Other information
WARNING
The unit and the accessories can contain small parts. Keep all of the equipment out of the reach of small children. The mains adapter is the
disconnect device between the product and mains power. The mains socket outlet must be close to the equipment and easily accessible.
Protect your hearing
WARNING
Excessive exposure to loud sounds can cause hearing damage. Exposure to loud sounds while driving may distract your aenon and cause
an accident. Do not hold the device near your ear when the loudspeaker is in use.
Care and maintenance
Your unit is a technically advanced product and should be treated with the greatest care. Negligence may void the warranty.
• Protect the unit from moisture. Rain/snowfall, moisture and all types of liquid can contain substances that corrode the electronic circuits. If the
unit gets wet, you should remove the power and allow the unit to dry completely before you replace it.
• Do not use or keep the unit in dusty, dirty environments. The unit’s moving parts and electronic components can be damaged.
• Do not keep the unit in warm places. High temperatures can reduce the lifespan for electronic equipment, damage baeries and distort or
melt certain plascs.
• Do not keep the unit in cold places. When the unit warms up to normal temperature, condensaon can form on the inside which can damage
the electronic circuits.
• Do not drop the unit. Do not knock or shake it either. If it is treated roughly the circuits and precision mechanics can be broken.
• Do not use strong chemicals to clean the unit.
The advice above applies to the unit and other accessories. If the unit is not working as it should, please contact the place of purchase
for service. Don’t forget the receipt or a copy of the invoice.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collecon systems)
This marking on the product, accessories or manual indicates that the product and its electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other household waste. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government oce, for details of
where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the
terms and condions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial
wastes for disposal. This product is RoHS compliant.
Declaration of Conformity
We hereby declare that the radio equipment type swisstone TIMEDOT is in compliance with Direcves:
2014/53/EU and 2011/65/EC (RoHS).
A copy of the Declaraon of Conformity is available at www.swisstone.de.
9
Warranty
In case you need support during setup or usage of your product you will nd the relevant contact details on the following website:
www.swisstone.de.
If you detect a defect resulng from manufacturing and/or material faults within 24 months from purchase, please contact your dealer.
The warranty does not apply for improper treatment or failure to comply with informaon contained in this user guide, for interference
on device executed by dealer or user (e. g. installaons, soware downloads,…) and for total loss. Furthermore it does not apply to
ingress of liquids, use of force, non-maintenance, improper operaon or other circumstances caused by the user. It also does not apply
to failure caused by a thunderstorm or any other voltage uctuaons. The manufacturer reserves the right in this case to charge the
customer for replacement or repair. For wear parts such as baeries or casing a restricted warranty period of 6 months is valid. Manuals
and possibly supplied soware are excluded from this warranty. Further or other claims arising from the manufacturer’s warranty are
excluded. Thus, there is no liability claim for business interrupon, loss of prots, loss of data, addionally installed soware by user or
other informaon. The receipt with purchase date forms the warranty proof.
Technical Specifications
Power input (micro USB port): 5V 3A
Power output (USB port): 5V 1A
Speaker Power: 6 Wa RMS
Dimensions Lenght: 17.8 cm
Width: 11 cm
Height: 6.8 cm
Weight 530 g
10
11
Changes and errors excepted.
