SWIT E-1040P User manual

Optical Fiber Camera System
User Manual
Ver: V1.0.0V01
Please read this User Manual
throughout before using.
Center Communication Unit E-1040P
Power upply Unit E-2010P
Camera Adaptor
E-4020A/

Preface
Congratulations on your purchase of this product. Please read this user manual carefully.
1 ． All internal technologies of this product are protected, including device, software and trademark.
Reproduction in whole or in part without written permission is prohibited.
2 ． All brands and trademarks of WIT Electronics Co., Ltd. are protected and other relative trademarks
in this user manual are the property of their respective owners.
3 ． Due to constant effort of product development, WIT reserves the right to make changes and
improvements to the product described in this manual without prior notice.
4 ． The warranty period of this product is 2 years, and does not cover the following:
(1) Physical damage to the products.
(2) Any damage caused by using third-party power adaptors.
(3) Any damage or breakdown caused by use, maintenance or storage not according to the user
manual.
(4) The product is disassembled by anyone other than an authorized service center.
(5) Any damage or breakdown not caused by the product design, workmanship, or manufacturing
quality, etc.
5 ． For any suggestions and requirements on this product, please contact us through phone, fax, Email,
etc.
SWIT Electronics Co., Lt .
Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone,
Nanjing 210038, P.R.China
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: http://www.swit.cc

1. System Connection
Note:
(1) Only CCU, Camera Adapter and Power upply Unit are included in this user manual.
(2) LEMO (3K.93C) or NEUTRIK (NO2-4FDW-A) cable socket is optional and NEUTRIK cable socket is
compatible with Pure fiber cable connection.

2. Center Communication Unit
Features
◆ 19” 1U includes 4 camera channels
◆ Allow cascading for more channels
◆ Offer Lemo or Neutrik input for option
◆ ONY/Panasonic Camera Remote input
◆ TALLY and return DI input
◆ Build-in Intercom control panel
◆ Headset and Microphone input
Front View
⑴ ⑵ ⑶ ⑷ ⑸ ⑹ ⑺ ⑻ ⑼ ⑽ ⑾
⑴ POWER: Power on/off
“ON”: Press to switch on the CCU and the power indicator goes on,
“OFF” : Press to switch off the CCU and the power indicator goes off.
⑵ MIC:3-pin Microphone input socket
⑶ INPUT: Audio switch, used for audio switch between headset and microphone.
Switch to CCU intercom au io input from: Camera intercom au io output via:
MIC Only 3-pin Microphone peaker and Headset earpiece
HEAD ET Only Headset Microphone Only Headset earpiece
⑷ HEAD ET: 5-pin headset input socket
⑸ tatus Indicator: Camera Adaptor signal status indicator.
When the Camera Adaptor connect with recognizable signal, the indicator goes on.
⑹ ET/VOLUME: Volume +/-
a) Revolve “ ET” to adjust the volume of the CCU peaker or the Headset.
b) Adjust the cascading CCU volume: When the “ANN” is switched on, press “ ET”, “ ET”
indicator light is blinking, then press “ANN” again, then “ANN” red indicator light is blink the
same frequency as the “ ET” indicator light. Revolve “ ET” to adjust the volume, press “ ET”
again to save the settings.
c) Adjust the Camera Adaptor input volume: Press the corresponding camera number key1-4, the
selected number key will turn red to activate the camera volume +/- function. Revolve “ ET” to
adjust the volume of the Camera Adaptor. You can adjust multiple cameras at the same time.
⑺ ANN: Broadcast communication mode button.
Press ANN to intercom with all camera channels
⑻ MIC OFF: CCU microphone mute button
Press “MIC OFF”, the indicator turns green, turn off the CCU microphone.
Press the button again, the indicator goes off, turn on the CCU microphone.
⑼ FN: Camera Adaptor MUTE button
Press “FN” and camera Number Key 1-4 at the same time to turn off the corresponding microphone
of the camera.

⑽ Number Key 1-4: Channel select button
Press the button, the indicator turns yellow, the communication between CCU and Camera Adaptor
is established. upport multiple camera channels simultaneous operation.
⑾ peaker
Rear View
⑴ ⑶ ⑷ ⑹ ⑼ ⑿ ⒂
⑵ ⑸ ⑺ ⑻ ⑽ ⑾ ⒀ ⒁ ⒃ ⒄ ⒅
⑴ VOICE LINK: 4-pin audio cascading socket, connect when cascading another CCU.
⑵ TALLY IN: witcher TALLY signal input socket (DB9).
Through CCU and fiber cable, TALLY signal transmit to each Camera Adaptor which has build-in
TALLY signal display and output to each monitor’s TALLY display. Pin descriptions are:
Pin 1 2 3 4 5 6 7 8 9
Description Green Red Green Red Green Red Green Red GND
Channel CH4 CH3 CH2 CH1
⑶ RETURN SDI IN: witcher return DI input socket. (BNC)
Through CCU and fiber cable, witcher returned DI video signal transmits to substation and returns
to camera mounted monitor.
⑷ RETURN SDI LOOP: (3) RETURN DI IN loop output socket, for CCU cascading
⑸ ⑻ ⑾ ⒁ OPT FIBER: fiber cable socket, LEMO (3K.93C) or NEUTRIK (NO2-4FDW-A) optional.
NEUTRIK （ NO2-4FDW-A ） socket is compatible with Pure fiber socket.
⑹ ⑼ ⑿ ⒂ SDI OUT: CH1~CH4 DI output, every optical channel converts 2 DI output
The camera video signal will be compiled to the optical signal by Camera Adaptor to CCU through
fiber cable, then CCU will parse the optical signal to DI signal and output to switcher and monitors.
⑺ ⑽ ⒀ ⒃ RCU: 10-pin RCU socket.
Through CCU, fiber cable and Camera Adaptor, RCU output signal will be transmitted to camera to
adjust camera shooting parameters. This socket is compatible with Panasonic 10-pin RCU and
support ony RCU with the provided 10-pin to 8-pin conversion cable.
⒄ DC 12V 4A: Power input socket, only for providing power to CCU.
⒅ DC 48V 9A: Power input socket, to connect with power station E-2010 to provide power to CCU, and
through fiber cable to supply power to cameras.
Supporte SDI vi eo formats:
DI
MPTE-425M 1080P (60 / 59.94 / 50)
MPTE-274M 1080i (60 / 59.94 / 50)
1080p (30 / 29.97 / 25 / 24 / 23.98)
MPTE-RP211 1080psf (30 / 29.97 / 25 / 24 / 23.98)
MPTE-296M 720p (60 / 59.94 / 50)
MPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)

3. Camera Optical Fiber A aptor
Features
◆ Convert Camera DI and control signal to Optical and interconnect with CCU
◆ Lemo / Neutrik connection optional
◆ Camera DI input and loop output
◆ witcher Return DI output
◆ Return DI on/off control
◆ TALLY display and output to monitor
◆ Headset input, Volume +/- adjustment
◆ ony / Panasonic camera remote input
◆ V-mount or Gold mount camera installation
⑴ STATUS A/B: tatus indictor
tatus A tatus B Description
on on Bi-directional intercom is setup with CCU
off on CCU has turned off his Microphone
on off CCU has turned off my channel’s voice
⑵ CHANNEL/VOL: Channel or Volume value display.
The LED displays the volume value when adjust, and other time it displays the channel number.
⑶ VOL+: Camera adaptor headset volume up.
⑷ VOL-: Camera adaptor headset volume down.

⑸ RETURN: When work with WIT -1071F(EFP) monitor, press RETURN to switch on/off the return
DI window on the monitor.
⑹ Hea set socket: 5-pin XLR socket, for intercom with the CCU.
⑺ Fiber Cable socket: Transmit power, video, intercom, control signal and Tally. LEMO (3K.93C) or
NEUTRIK (NO2-4FDW-A) is optional, of which NEUTRIK (NO2-4FDW-A) can be directly input with
pure optical fiber cables.
⑻ ⒃ Battery Plate: V-mount or Gold mount battery plate optional.
Fix the camera adaptor on camera battery mount position, and attached with V-mount or Gold mount
battery, so that the battery can power the camera adaptor and camera simultaneously.
⑼ TALLY: TALLY light display.
⑽ SDI IN: DI input socket, connected with camera DI to output signal.
⑾ SDI LOOP: DI loop output socket ， loop signal output from input ⑽ DI IN, for on-camera monitor.
⑿ RETURN OUT: witcher returned DI output socket. Output the RETURN IN input signal of CCU.
⒀ CAM REMOTE*: 10-pin camera remote input.
Directly connect to Panasonic camera “REMOTE” socket. By the provided 10-pin to 8-pin conversion
cable, you can connect to ONY camera “REMOTE” socket. The camera remote control signal will be
transmit to CCU by Optical Fiber cable.
⒁ TALLY: TALLY and DC power output socket. (7-pin)
Work together with WIT -1071F(EFP) monitor and provided 7-pin to DB9 cable, the Camera
Adaptor can output TALLY signal and DC power to -1071F(EFP) monitor.
⒂ RETURN BUTTON: External Return DI on/off button connection (4-pin)
When work with WIT -1071F(EFP) monitor, you can switch on/off the return DI window on the
monitor by pressing the provided external Return DI on/off button .
* Remote Control Protocol Setting:
The Camera Adaptor supports ONY, Panasonic and JVC camera remote protocol.
For the V-mount plate installed Camera adaptor, the default Remote protocol is ONY’s;
For the Gold mount plate installed Camera adaptor, the default Remote protocol is Panasonic’s;
To change the remote Protocol, please press the button by the following sequence:
VOL ＋
＋＋
＋ , VOL ＋
＋＋
＋ , VOL －
－－
－ , VOL －
－－
－ , VOL ＋
＋＋
＋ , VOL －
－－
－ , VOL ＋
＋＋
＋ , VOL －
－－
－
to enter setting, and then press VOL ＋
＋＋
＋ to switch between "P"-Panasonic, "S"- ony and “J”-JVC,
and press VOL －
－－
－ to save and quit.

4. Power Supply Unit
Features
◆ 19” 1U standard rack mount
◆ AC 100-240V or DC 120-370V input
◆ Main and Back Up power input
◆ DC 48V 9A power output to CCU
◆ Build-in multiple power protection
⑴
⑵ ⑶ ⑷
⑴ Power on/off :
“ON”, Press to switch on and the power indicator goes on ；
“OFF”: Press to switch off and the power indicator goes off.
⑵ DC output: 48V/9A, to connect with CCU, and power CCU and distribute power to cameras
⑶ AC input (Main): AC 100-240V.
⑷ AC input (Backup): AC 100-240V.
Power Distribution Max Loa
When CCU is getting power from 48V E-2010P Power upply Unit, it can distribute DC power to Camera
Adaptors via Lemo or Neutrik fiber cable; the power load is inversely proportional to the length of the
fiber cable. The power load and distance reference is as below:
CCU Power Input Transmission channel Transmission Distance Max Load
48V from E-2010P
CH1/CH2/CH3/CH4
(Independently)
100 meters 90W
200 meters 80W
300 meters 55W
If the distance is too far to supply enough power, please take spare battery to power the Camera
Adaptor.
Protection Mo e
Overloa Protection witched to limited current mode, and will recover to normal
automatically when load dropped down.
Over Voltage Protection topped power output, and will recover to normal when restart
E-2010P.
Over Temperature Protection topped power output, and will recover to normal automatically
when temperature is dropped down.

5. Specifications
⑴ The Center Communication Unit (CCU)
Mo el E-1040P
Working Voltage Main power Backup power
30 ～ 48V 7~17V
Max. Power Consumption 13.0W
Working
Environment
Working Temperature
0°C ～ +40°C
Working Humidity 10%
～ 90%RH
torage Temperature -20°C
～ +55°C
torage Humidity 10%
～ 90%RH
Dimension 483×297×45mm
Net Weight 2.992Kg
⑵ Camera Optical Fiber Adaptor
Mo el E-4020A E-4020S
Working Voltage 48V DC fiber cable / 11-15V battery
Output Voltage / Current
(to power the camera) 15V / 6A
Max. Power Consumption 4.0W
Working
Environment
Working Temperature
0°C ～ +40°C
Working Humidity 10%
～ 90%RH
torage Temperature -20°C
～ +55°C
torage Humidity 10%
～ 90%RH
Battery Plate Gold mount V-mount
Dimension 157×65×212mm 157×63×212mm
Net Weight 1.068Kg
⑶ Power upply Unit
Mo el E-2010P
Input Voltage AC 85-264V or DC 120-370V
Output Voltage / Current 48V / 9A
Working
Environment
Working Temperature
-40°C ～ +70°C
Working Humidity 20
～ 90%RH, non-condensing
torage Temperature -40°C
～ +85°C
torage Humidity 10
～ 90%RH
Dimension 483×292×45mm
Net Weight 2.534Kg

6. Trouble-Shooting
Problems Trouble shooting
CCU Intercom channel buttons
could not light up
1. Check if CCU is powered up and the power indicator goes on
2. Check if it is in Volume etup mode, when SET indicator is blinking
3. FN button will never light up, that is normal.
4. Check if the camera channel is properly connected to Camera Adaptor
CCU elected the camera
channel, but can’t hear voice from
the cameraman.
1. Increase the volume of CCU speaker or headset.
2. Increase the volume of Camera channel microphone.
3. Check optical fiber connection
Camera side can’t hear the
CCU’s voice.
1. Increase the volume of CCU Microphone.
2. Check optical fiber connection
Camera side can’t hear the CC
U’s voice when CCU using 3-pi
n Microphone input.
1. Check if “INPUT” switcher of CCU has been switched to MIC.
The Camera Adaptor could not
output Return DI video
1. Check the switcher return DI input at CCU side
2. Check the connection of the Camera Adaptor Return DI output
3. Check the return DI format; see the supported formats at
“6. Specifications- Supporte SDI vi eo formats”

7. Packing List
The 4-ch Package includes the following items in package:
CCU Description Quantity
Main Device E-1040P 4-channel CCU
(LEMO/NEUTRIK optional) 1
Accessories
Headset 1
Gooseneck microphone 1
10-pin to 8-pin( ONY) RCU cable (1.5m) or
10-pin to 10-pin (Panasonic) RCU cable (1.5m) 4
Intercom cascading cable 1
AC-DC adaptor + AC cable 1
Camera A aptor Description Quantity
Main Device
E-4020 Camera Adaptor
(Gold mount or V-mount optional,
LEMO/NEUTRIK optional)
4
Accessories
BNC cable (30cm) 12
10-pin to 8-pin( ONY) remote cable (30cm) or
10-pin to 10-pin (Panasonic) remote cable (30cm) 4
7-pin to DB9 power +TALLY cable (60cm) 4
4-pin external return DI on/off button (1m) 4
Headset 4
Power Supply Unit Description Quantity
Main Device E-2010P Power upply Unit 1
Accessories AC cable 1
DC cable (connected to the CCU) 1
Return SDI Monitor Description Quantity
Main Device -1071F(EFP) 7” Local/Return DI Pic-in-Pic monitor 4
Accessories un hood 4
Cold shoe / crew ball head 4
Carrying Case Description Quantity
Main Device 19” 6U fiber case 1

Product Registration Link
