Sycard Technology PCCextend 145 User manual

PCCextend 145
HP Logic Analyzer Adapter
User’s Manual
Preliminary
M200014-00
July 1996
Sycard Technology
1180-F Miraloma Way
Sunnyvale, CA 94086
[phone]
[phone] FAX

PCCextend 145 User’s Manual Page 1
M200014-00 1994-96 Sycard Technology
1.0 Introduction1.0 Introduction
Sycard Technology's PCCextend 145 HP Logic Analyzer Adapter is an accessory product for the PCCextend 140
CardBus extender card. The PCCextend 145 is designed to interface with HP logic analyzers that use the 015650-
63203 termination adapter.
•For use with Sycard’s PCCextend 140 CardBus extender Card
•Supports all HP logic analyzers that use the HP 01650-63203 Termination Adapter
•Multi-layer construction to insure a low noise environment
•Connects to all CardBus signals
•Supports both timing and state analysis
•Unused logic analyzer inputs accessible via test points.
•Plug-in design allows for easy attachment and removal
2.0 Using the PCCextend 1452.0 Using the PCCextend 145
The PCCextend 145 is installed onto the two 34 pin headers located on the PCCextend 140 CardBus extender. The
adapter should be mounted in the orientation shown in figure 2.0-1. Once installed, the HP termination adapters (on
pods 1-4) can be installed on connectors JP1 through JP4.
JP3
JP4
JP5
JP6
JP2
JP1
A
B
C
DF
E
TowardsCard
Figure 2.0-1 The PCCextend 140Figure 2.0-1 The PCCextend 140

Page 2PCCextend 145 User’s Manual
1994-96 Sycard Technology M200014-00
The following tables list the mapping of signals to the HP Logic analyzer adapter:
AnalyzerAnalyzer
InputInput CardBusCardBus SignalSignal CardBusCardBus SignalSignal
PinPin
NoteNote
Pod 1-0 CCBE0# 7
Pod 1-1 CCBE1# 12
Pod 1-2 CCBE2# 21
Pod 1-3 CCBE3# 61
Pod 1-4 CREQ# 60
Pod 1-5 CGNT# 15
Pod 1-6 CFRAME# 54 Tie JP5-2 to JP5-3
Pod 1-7 CDEVSL# 50
Pod 1-8 CIRDY# 20 Tie JP6-2 to JP6-3
Pod 1-9 CTRDY# 53 Tie JP3-2 to JP3-3
Pod 1-10 CPAR 13
Pod 1-11 CSTOP# 49
Pod 1-12 CBLOCK# 48
Pod 1-13 CPERR# 14
Pod 1-14 CSERR# 59
Pod 1-15 CCLK 19 Tie JP4-2 to JP4-3
Pod 2-0 CAD0 2
Pod 2-1 CAD1 3
Pod 2-2 CAD2 37
Pod 2-3 CAD3 4
Pod 2-4 CAD4 38
Pod 2-5 CAD5 5
Pod 2-6 CAD6 39
Pod 2-7 CAD7 6
Pod 2-8 CAD8 41
Pod 2-9 CAD9 8
Pod 2-10 CAD10 42
Pod 2-11 CAD11 9
Pod 2-12 CAD12 10
Pod 2-13 CAD13 44
Pod 2-14 CAD14 11
Pod 2-15 CAD15 45
Table 2.1-1A Signal Connection Table - Part ATable 2.1-1A Signal Connection Table - Part A

PCCextend 145 User’s Manual Page 3
M200014-00 1994-96 Sycard Technology
AnalyzerAnalyzer
InputInput CardBusCardBus SignalSignal CardBusCardBus SignalSignal
PinPin
NoteNote
Pod 3-0 CAD16 46
Pod 3-1 CAD17 55
Pod 3-2 CAD18 22
Pod 3-3 CAD19 56
Pod 3-4 CAD20 23
Pod 3-5 CAD21 24
Pod 3-6 CAD22 25
Pod 3-7 CAD23 26
Pod 3-8 CAD24 27
Pod 3-9 CAD25 28
Pod 3-10 CAD26 29
Pod 3-11 CAD27 30
Pod 3-12 CAD28 64
Pod 3-13 CAD29 31
Pod 3-14 CAD30 65
Pod 3-15 CAD31 66
Pod 4-0 CCLKRN# 33
Pod 4-1 CINT# 16
Pod 4-2 CAUDIO 62
Pod 4-3 CRST# 58
Pod 4-4 RFU1 32
Pod 4-5 RFU2 40
Pod 4-6 RFU3 47
Pod 4-7 CSTSCHG 63
Pod 4-8 CVS1 43
Pod 4-9 CVS2 57
Pod 4-10 JP1-1 (A) -General Purpose Input
Pod 4-11 JP2-3 (F) -General Purpose Input
Pod 4-12 JP1-2 (C) -General Purpose Input
Pod 4-13 JP2-2 (D) -General Purpose Input
Pod 4-14 JP1-3 (E) -General Purpose Input
Pod 4-15 JP2-3 (F) -General Purpose Input
Table 2.1-1B Signal Connection Table - Part ATable 2.1-1B Signal Connection Table - Part A
The PCCextend 145 was designed to be used as state or timing analyzer. Jumpers JP3 through JP4 route selected
signals to either regular input channels or CLK inputs.

Page 4PCCextend 145 User’s Manual
1994-96 Sycard Technology M200014-00
JP3JP3 CTRDY# JumperCTRDY# Jumper
1 - 2 CTRDY# is CLK1 on POD 4
2 - 3 CTRDY# in D9 input on POD 1
JP4JP4 CCLK JumperCCLK Jumper
1 - 2 CCLK is CLK1 on POD 1
2 - 3 CCLK is D15 input on POD 1
JP5JP5 CFRAME# JumperCFRAME# Jumper
1 - 2 CFRAME# is CLK1 on POD 3
2 - 3 CFRAME# is D6 input on POD 1
JP6JP6 CIRDY# JumperCIRDY# Jumper
1 - 2 CIRDY# is CLK1 on POD 2
2 - 2 CIRDY# is D8 input on POD 1
Table 2.1-2 Timing/State Clock Select JumpersTable 2.1-2 Timing/State Clock Select Jumpers

PCCextend 145 User’s Manual Page 5
M200014-00 1994-96 Sycard Technology
AppendixAppendix
A. PCCextend 145 SchematicA. PCCextend 145 Schematic
