Symantec S500 User manual

Guide Revision: 4/28/2017
Symantec S500 Network
Interface Card Options
and Installation

2

Legal Notices
Copyright © 2017 Symantec Corp. All rights reserved. Symantec, the Symantec Logo, the Checkmark Logo, Blue Coat,
and the Blue Coat logo are trademarks or registered trademarks of Symantec Corp. or its affiliates in the U.S. and other
countries. Other names may be trademarks of their respective owners. This document is provided for informational pur-
poses only and is not intended as advertising. All warranties relating to the information in this document, either express or
implied, are disclaimed to the maximum extent allowed by law. The information in this document is subject to change
without notice.
THE DOCUMENTATION IS PROVIDED "AS IS" AND ALL EXPRESS OR IMPLIED CONDITIONS,
REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE
EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID. SYMANTEC CORPORATION SHALL
NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE
FURNISHING, PERFORMANCE, OR USE OF THIS DOCUMENTATION. THE INFORMATION CONTAINED IN
THIS DOCUMENTATION IS SUBJECT TO CHANGE WITHOUT NOTICE. SYMANTEC CORPORATION
PRODUCTS, TECHNICAL SERVICES, AND ANY OTHER TECHNICAL DATA REFERENCED IN THIS
DOCUMENT ARE SUBJECT TO U.S. EXPORT CONTROL AND SANCTIONS LAWS, REGULATIONS AND
REQUIREMENTS, AND MAY BE SUBJECT TO EXPORT OR IMPORT REGULATIONS IN OTHER COUNTRIES.
YOU AGREE TO COMPLY STRICTLY WITH THESE LAWS, REGULATIONS AND REQUIREMENTS, AND
ACKNOWLEDGE THAT YOU HAVE THE RESPONSIBILITY TO OBTAIN ANY LICENSES, PERMITS OR OTHER
APPROVALS THAT MAY BE REQUIRED IN ORDER TO EXPORT, RE-EXPORT, TRANSFER IN COUNTRY OR
IMPORT AFTER DELIVERY TO YOU.
Symantec Corporation
350 Ellis Street
Mountain View, CA 94043
www.symantec.com
3

Contents
Legal Notices 3
SafetyWarnings and Cautions 5
Power and Electrical Warnings 5
CAUTION 5
System Access Warnings 5
CAUTION 5
To avoid personal injury or property damage, the following safety instructions apply whenever accessing
the inside of the product: 5
CAUTION 6
CAUTION 6
Cooling and Airflow Warning 6
Electrostatic Discharge (ESD) Warning 6
CAUTION 6
Network Interface Card Options 7
Install an option card into Slot 1 or 2 18
Install an option card into Slot 3 or 4 20
Install an option card into Slot 5 or 6 24
Install an option card into Slot 7 27
Open the S500 Series Center Cover 29
Remove the S500 Series Rear Cover 30
Remove the S500 Series PCIe Expansion Module 31
Install the S500 Series PCIe Expansion Module 32
4

SafetyWarnings and Cautions
Caution: This product is designed to work with power systems having a grounded neutral. To reduce the
risk of electric shock, do not plug this product into any other type of power system. Contact a qualified elec-
trician if you are not sure what type of power is supplied to your building.
Power and Electrical Warnings
CAUTION
The power button, indicated by the stand-by power marking, DOES NOT completely turn off the system AC
power. 5V standby power is active whenever the system is plugged in. To remove power from system, you
must unplug the AC power cord from the wall outlet. If your system uses more than one AC power cord,
make sure all AC power cords are unplugged before you open the chassis, or add or remove any non hot-
plug components.
The power supply in this product contains no user-serviceable parts. Do not open the power supply. Haz-
ardous voltage,current, and energy levels are present inside the power supply. Return to manufacturer for
servicing. To avoid risk of electric shock, turn off the appliance and disconnect the power cord, tele-
communications systems, networks, and modems attached to the appliance before opening it.
The power cord set included with the appliance meets the requirements for use in the country of purchase.
Use the power cord that shipped with the appliance. If this appliance is to be used in another country, pur-
chase an AC power cord set that is approved for use in that country (18 AWG recommended).
The power cord must be rated for the product and for the voltage and current marked on the product's elec-
trical ratings label. The voltage and current rating of the cord should be greater than the voltage and current
rating marked on the product. In addition, the cross-sectional area of the wires must be a minimum of
1.00mmð or 18AWG or 18AWG, and the length of the cords must be between 1.8m (6 feet) and 3.6m (12
feet).
System Access Warnings
CAUTION
To avoid personal injury or property damage, the following safety instructions apply
whenever accessing the inside of the product:
nTurn off all peripheral devices connected to this product.
nTurn off the system by safety shutting down the appliance.
nDisconnect the AC power by unplugging all AC power cords from the system or wall outlet.
nDisconnect all cables and telecommunication lines that are connected to the system.
nRetain all screws or other fasteners when removing access cover(s). Upon completion of accessing
inside the product, refasten access cover with original screws or fasteners.
5

nDo not access the inside of the power supply. There are no serviceable parts in the power supply.
Return to manufacturer for servicing.
nPower down the server and disconnect all power cords before adding or replacing any non hot-plug
component.
nWhen replacing a hot-plug power supply, unplug the power cord to the power supply being replaced
before removing the power supply from the server.
CAUTION
nIf the server has been running, any installed processor(s) and heat sink(s) may be hot. Unless you
are adding or removing a hot-plug component, allow the system to cool before opening the covers. To
avoid the possibility of coming into contact with hot component(s) during a hot-plug installation, be
careful when removing or installing the hot-plug component(s).
CAUTION
nTo avoid injury do not contact moving fan blades. If your system is supplied with a guard over the fan,
do not operate the system without the fan guard in place.
Cooling and Airflow Warning
Carefully route cables as directed to minimize airflow blockage and cooling problems.
For proper cooling and airflow, operate the system only with the chassis covers installed. Operating the sys-
tem without the covers in place can damage system parts. To install the covers:
1. Check first to make sure you have not left loose tools or parts inside the system.
2. Check that cables, add-in boards, and other components are properly installed.
3. Attach the covers to the chassis according to the product instructions.
Electrostatic Discharge (ESD) Warning
CAUTION
ESD can damage disk drives, boards, and other parts. We recommend that you perform all procedures at an
ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist strap
attached to chassis ground- any unpainted metal surface -- on your server when handling parts.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by their edges.
After removing a board from its protective wrapper or from the server, place the board component side up on
a grounded, static free surface. Use a conductive foam pad if available but not the board wrapper. Do not
slide board over any surface
6

Network Interface Card Options
The following lists the option cards that are available for the S500-based appliances. The low-profile option cards can be
installed into any of the PCIe slots, including the on-board PCIe slots and the PCIe expansion module slots. Full-height
cards, with a system maximum of 2, can only be installed in the PCIe expansion module, slots 3 and 4. Option cards are
shipped with a pre-installed bracket that might not be compatible with your appliance or desired slot usage. You must
replace the bracket with the necessary version before installing an option card.
Be sure to verify that your product supports the option card before installation.
S500 Series-based appliances equipped with a single CPU cannot use slots 5, 6, and 7.
Please select the option card that you wish to install:
Review the "SafetyWarnings and Cautions" on page5 before servicing your appliance.
Do not install any NIC (network interface cards) which are not explicitly supported by the appli-
ance. Installation and use of unauthorized NICs might damage the appliance and will invalidate
your warranty!
Network
Card
Supported Appli-
ances
Description Expansion Slot
Usage
Installation
NIC-S500-
2x10G-PT
ProxySG
PacketShaper
ASG
2-port 10GBASE-T
Pass-through (click for
details)
All expansion slots I'd like to install the option card
in:
lSlot 1 or 2
lSlot 7
lSlot 3 or 4 (PCIe
expansion module)
lSlot 5 or 6 (PCIe
expansion module)
NIC-S500-
4xGigE-PT-
Fiber
ProxySG
PacketShaper
ASG
4-port 1000BASE-SX
Pass-through, Fiber,
Small form Factor Plug-
gable (LC)
(click for details)
Only installable in
slots 3 or 4.
I'd like to install the option card
in:
lSlot 3 or 4 (PCIe
expansion module)
NIC-S500-
4xGigE-PT
ProxySG
PacketShaper
ASG
4-port 1000BASE-T Pass-
through
(click for details)
All expansion slots I'd like to install the option card
in:
lSlot 1 or 2
lSlot 7
lSlot 3 or 4 (PCIe
expansion module)
lSlot 5 or 6 (PCIe
expansion module)
7

Network
Card
Supported Appli-
ances
Description Expansion Slot
Usage
Installation
NIC-S500-
2x10G
ProxySG
Malware Analysis
ASG
2-port 10GBASE-T Non-
bypass
(click for details)
All expansion slots I'd like to install the option card
in:
lSlot 1 or 2
lSlot 7
lSlot 3 or 4 (PCIe
expansion module)
lSlot 5 or 6 (PCIe
expansion module)
NIC-S500-
2x10G-PT-
SR-Fbr
ProxySG
PacketShaper
ASG
2-port 10GBASE-SR
Pass-Through,10 Gigabit
(SFP+)
(click for details)
All expansion slots I'd like to install the option card
in:
lSlot 1 or 2
lSlot 7
lSlot 3 or 4 (PCIe
expansion module)
lSlot 5 or 6 (PCIe
expansion module)
NIC-S500-
2x10G-PT-
LR-Fbr
ProxySG
PacketShaper
ASG
2-port 10GBASE-LR
Pass-Through, 10 Gigabit
(SFP+)
(click for details)
All expansion slots I'd like to install the option card
in:
lSlot 1 or 2
lSlot 7
lSlot 3 or 4 (PCIe
expansion module)
lSlot 5 or 6 (PCIe
expansion module)
NIC-S500-
4xGigE-LX-
Fiber)
ProxySG
PacketShaper
ASG
4-port 1000BASE-LX
Single Mode, Pass-
through, Fiber, LC Con-
nector
Only installable in
slots 3 or 4.
I'd like to install the option card
in:
lSlot 3 or 4 (PCIe
expansion module)
8

The 10 Gigabit Ethernet bypass NIC cards [NIC-S500-2x10G_PT / NIC-S400-2x10G_PT] are PCIe x8 network
adapters containing two copper 10 Gigabit interfaces.
Key Features Technical Specifications
WDT Interval (Software Programmable):
l3,276,800 mSec (3,276.8 Sec):
Maximum
l100 mSec (0.1 Sec) : Minimum
lWDT Interval = (2^wdt_interval_
parameter)*(0.1) sec.
lwdt_interval_parameter: {Valid
Range: 0-15}
IEEE Standard / Network topology:
lCopper 10Gigabit Ethernet,
10GBASE-T, IEEE 802.3an
lGigabit Ethernet, 1000Base-T
l100 Mb Ethernet : 100BASE- TX
Data Transfer Rate: 20 Gb/s, 2000Mb/s
and 200 Mb/s in full duplex mode per port.
Cables and Operating distance:
l100Base-Tx Category 5 maximum
50m*
l1000Base-T Category 5E maximum
50m*
l10GBase-T Category 6A maximum
50m**
*Theoretical Distance – Defined as half a distance as
stated by the IEEE 802.3-2005 standard
**Theoretical Distance – Defined as half a distance as
stated by the IEEE 802.3an standard
Interface Standard: PCI-Express Base Specification Revision 2.1
(5GT/s)
Board Size: 167.65mm X 68.91mm (6.60”X 2.713”)
PCI Express Card Type: X8 Lane
PCI Express Voltage: +12V ± 8%
PCI Connector: Gold Finger - X8 Lane
Controller: Intel x540
Holder: Metal Bracket
I/O: RJ45
Weight: 170gr (5.997oz)
Power Consumption:
l18 W, 1.5 A at 12V: Typical all ports operate at 10Gb/s, (Normal
Mode).
l10.44 W, 0.87 A at 12V: Typical all ports operate at 1Gb/s, (Normal
Mode).
l7.56 W, 0.63 A at 12V: Typical all ports operate at 100Mb/s,
(Normal Mode).
l8.88 W, 0.74 A at 12V: Typical Bypass Mode.
l8.88 W, 0.74 A at 12V: Typical Disconnect** Mode.
l8.16 W, 0.68 A at 12V: Typical No link at all ports
LEDs: (2) LED per port
lUpper (Left) LED: Link /ACT:
lTurns on link , blinks on activity (green)
lLower (Right) LED: Speed / Bypass / Disconnect*
lLink of 1Gb/s: Turns on link (yellow)
lLink of 10Gb/s: Turns on link (green)
lBypass: Blink (Green) on Bypass
lDisconnect* : Blink (Yellow)
lLEDs location: LEDs are located in the RJ45 connector port.
lConnector: (2) Shielded RJ-45
9

The quad port Gigabit Ethernet bypass NIC cards [NIC-S500-4xGigE-PT-Fiber / NIC-S400-4xGigE-PT-Fiber]
are PCIe x4 network adapters containing four fiber Gigabit interfaces, based on a single chip, non-bridged GBE
controller.
Key Features Technical Specifications
Fiber Gigabit Ethernet 1000Base-SX::
lIndependently Fiber Gigabit Ethernet channel/s
support Gigabit Ethernet 1000Base-SX.
lSmall Form Factor (SFF) LC Connectors.
WDT Interval (Software Programmable):
l3,276,800 mSec (3,276.8 Sec): Maximum
l100 mSec (0.1 Sec) : Minimum
lWDT Interval = (2^wdt_interval_parameter)*(0.1)
sec.
lwdt_interval_parameter: {Valid Range: 0-15}
IEEE Standard / Network topology: Fiber Gigabit Ethernet,
1000Base-SX (850nM)
Full duplex / Simplex: Support both Simplex & Full duplex
operation in all operating speeds
Auto negotiation: Auto-negotiation between Full duplex and
simplex operations and between 10Mb/s 100Mb/s speeds
and duplex 1000Mb/s.
Data Transfer Rate: 2000Mbit/s in full duplex mode per port
Cables and Operating distance: Multimode fiber - 137m
maximum at 62.5 um *
*Theoretical Distance – Defined as half a distance as stated by the IEEE
802.3 standard
Interface Standard: PCI-Express Base Specification
Revision 2.1 (5GT/s)
Board Size: 167.65mm X 111.15mm (6.60”X 4.376”)
PCI Express Card Type: X4 Lane
PCI Express Voltage: +3.3V +-9%, +12V +- 8%
PCI Connector: Gold Finger - X4 Lane
Controller: Intel i350AM4
Holder: Metal Bracket
I/O: LC
Weight: 330g (11.641oz)
Power Consumption:
l0.40A, 4.8W at 12V: Typical all ports operate at
1000Mb/s.
l0.40A, 4.8W at 12V: Typical No link at all ports.
l0.38A, 4.56W at 12V: Bypass Mode.
l0.38A, 4.56W at 12V: Disconnect Mode.
LEDs: (1) LED per port
lLink/ACT:
lBlinks on activity (green).
lTurns on link (green).
lBi-color LED per Bypass pair:
lBYPASS: Turns on Green on Bypass
lDisconnect : Turns on Yellow on
Disconnect
lNormal: Off
lLEDs location: LEDs are located on the PCB,
visible via holes in the metal bracket holder
lConnector: (4) LC
10

The quad port Gigabit Ethernet bypass NIC cards [NIC-S500-4xGigE-PT / NIC-S400-4xGigE-PT] are PCIe x4
network adapters containing four copper Gigabit interfaces, based on a single chip, non-bridged GBE controller.
Key Features Technical Specifications
Copper Gigabit Ethernet 1000Base-T:
lIndependently copper Gigabit
Ethernet channels support four
Gigabit Ethernet (1000Base-T), Fast
Ethernet (100Base-Tx) and Ethernet
(10Base-T).
lTriple speed 1000Mbps (1000Base-
T), 100 Mbps (100Base-Tx) and 10
Mbps (100Base-T) operation.
lNway auto negotiation automatic
sensing and switching between
1Gbps full duplex and 100 / 10 Mbps
operations Simplex or Full Duplex.
lRJ-45 female connectors.
WDT Interval (Software Programmable):
l3,276,800 mSec (3,276.8 Sec):
Maximum
l100 mSec (0.1 Sec) : Minimum
lWDT Interval = (2^wdt_interval_
parameter)*(0.1) sec.
lwdt_interval_parameter: {Valid
Range: 0-15}
IEEE Standard / Network topology:
lGigabit Ethernet, 1000Base-T
lFast Ethernet, 100Base-TX
lEthernet, 10Base-T
Interface Standard: PCI-Express Base Specification Revision 2.1
(5GT/s)
Board Size: 167.65mm X 68.91mm (6.60”X 2.713”)
PCI Express Card Type: X8 Lane
PCI Express Voltage: +12V ± 8%
PCI Connector: Gold Finger - X8 Lane
Controller: Intel i350AM4
Holder: Metal Bracket
I/O: RJ45
LEDs: (2) LED per port
lLink / Act Led:
lTurn on any Link speed , Blinks on Activity (green)
lSpeed/Bypass/Disconnect (Bi-color) Led:
l1000Mb/s: Turns on Yellow
l100Mb/s: Turns on Green.
l10Mb/s: Turns off
lDisconnect: Blink Yellow
lBypass: Blink Green
lLEDs location: LEDs are integrated on RJ-45 connector
lConnector: (4) Shielded RJ-45
11

Key Features Technical Specifications
Full duplex / Simplex: Support both
Simplex & Full duplex operation in all
operating speeds
Auto negotiation: Auto-negotiation
between Full duplex and simplex operations
and between 10Mb/s 100Mb/s speeds and
duplex 1000Mb/s.
Data Transfer Rate:
l1000 Mb/s, 100 Mb/s and 10 Mb/sec
in simplex mode per port.
l2000Mb/s 200 and 20 Mb/s in full
duplex mode per port.
Cables and Operating distance:
l10Base-T Category 3, 4, or 5
maximum 50m *
l100Base-Tx Category 5 maximum
50m *
l1000Base-T Category 5E maximum
50m *
*Theoretical Distance – Defined as half a distance as
stated by the IEEE 802.3 standard
12

The 10 Gigabit Ethernet PCIe non-bypass NIC cards [NIC-S500-2x10G / NIC-S400-2x10G] contain two copper
10 Gigabit interfaces.
Key Features Technical Specifications
IEEE Standard / Network topology:
lCopper 10Gigabit Ethernet,
10GBASE-T, IEEE 802.3an
lGigabit Ethernet, 1000Base-T
l100 Mb Ethernet : 100BASE- TX
Data Transfer Rate: 20 Gb/s, 2000Mb/s
and 200 Mb/s in full duplex mode per port.
Cables and Operating distance:
l100Base-Tx Category 5 maximum
100m
l1000Base-T Category 5E maximum
100m
l10GBase-T Category 6A maximum
100m
Interface Standard: PCI-Express Base Specification Revision 2.1
(5GT/s)
Board Size: 251.4mm X 68.91mm (6.0”X 2.713”)
PCI Express Card Type: X8 Lane
PCI Express Voltage: +12V ± 8%
PCI Connector: Gold Finger - X8 Lane
Controller: Intel x540
Holder: Metal Bracket
I/O: RJ45
Weight: 130g
Power Consumption:
l14.28 W, 1.19 A at 12V: Typical all ports operate at 10Gb/s,
(Normal Mode).
l7.92 W, 0.66 A at 12V: Typical all ports operate at 1Gb/s, (Normal
Mode).
l5.04 W, 0.42 A at 12V: Typical all ports operate at 100Mb/s,
(Normal Mode).
l7.26 W, 0.605 A at 12V: Typical No link at all ports
LEDs: (2) LED per port
lSpeed LED:
lLink of 1Gb/s: Turns on link (yellow)
lLink of 10Gb/s: Turns on link (green)
lLink /ACT LED:
lTurns on link, blinks on activity (green)
lLEDs location: LEDs are located in the RJ45 connector port.
lConnector: (2) Shielded RJ-45
13

The dual port fiber 10 Gigabit Ethernet bypass NIC cards [NIC-S500-2x10G_PT_SR_fbr / NIC-S400-2x10G_
PT_SR_fbr] are PCIe x8 network adapters containing two fiber (SR) 10 Gigabit interfaces.
Key Features Technical Specifications
10 Gigabit Fiber Ethernet port supports
10GBASE-SR (850nM LAN PHY) 10Gigabit
850nM Small form Factor Pluggable (SFP+)
WDT Interval (Software Programmable):
l3,276,800 mSec (3,276.8 Sec): Maximum
l100 mSec (0.1 Sec) : Minimum
lWDT Interval = (2^wdt_interval_
parameter)*(0.1) sec.
lwdt_interval_parameter: {Valid Range:
0-15}
IEEE Standard / Network topology: Fiber 10 Gig-
abit Ethernet, 10GBase-SR (850nM)
Data Transfer Rate: 10.3125GBd
Cables and Operating distance:
lMultimode fiber:
l62.5um, 160MHz/Km 26m
l62.5um, (OM1)200MHz/Km 33m
l50um, 400MHz/Km 66m
l50um, (OM2)500 MHz/Km 82m
l50um, (OM3)2000MHz/Km 300m
Interface Standard: PCI-Express Base Specification Revision 2.0
(5GT/s)
Board Size: 167.65mm X 68.91mm (6.60”X 2.713”)
PCI Express Card Type: X8 Lane
PCI Express Voltage: +12V ± 8%
PCI Connector: Gold Finger - X8 Lane
Controller: Intel 82599ES
Holder: Metal Bracket
I/O: SR
Weight: 200g (7.055Oz)
Power Consumption:
l6.6 W, 0.55 A at 12V: Typical all ports operate at 10Gb/s,
(Normal Mode).
l6.12 W, 0.51 A at 12V: Typical Bypass Mode.
l6.36 W, 0.53 A at 12V: Typical No link at all ports
14

Key Features Technical Specifications
Optical Output Power:
lNormal Mode (Bypass Off):
lTypical: -3.1dBm (TX –Switch
Normal – Fiber – LC/LC)
lMinimum: -7.3 dBm
LEDs: (2) LED per port
lLink: Turns on Blue on 10G link.
lACT: Blinks on activity (green).
lBi-color LED per Bypass pair:
lBYPASS: Turns on Green on Bypass
lDisconnect : Turns on Yellow on Disconnect
lNormal: Off
lLEDs location: LEDs are located on the PCB, visible via
holes in the metal bracket holder
lConnector: (2) SR
Optical Receive Sensitivity:
lNormal Mode (Bypass Off)
lTypical: -15.37 dBm
lMaximum: -11 dBm
Insertion Loss:
lBypass Mode:
lInsertion loss (Optical Power
attenuation between TX to RX) (LC-
fiber- switch- LC)
lTypical: 0.39 dB (From RX to TX)
lMaximum 1.6 dB
15

The dual port fiber 10 Gigabit Ethernet bypass NIC cards [NIC-S500-2x10G_PT_LR_fbr / NIC-S400-2x10G_
PT_LR_fbr] are PCIe x8 network adapters containing two fiber (LR) 10 Gigabit interfaces.
Key Features Technical Specifications
10 Gigabit Fiber Ethernet port supports
10GBASE-LR (1310nM LAN PHY)
WDT Interval (Software Programmable):
l3,276,800 mSec (3,276.8 Sec):
Maximum
l100 mSec (0.1 Sec) : Minimum
lWDT Interval = (2^wdt_interval_
parameter)*(0.1) sec.
lwdt_interval_parameter: {Valid
Range: 0-15}
IEEE Standard / Network topology: Fiber
10Gigabit Ethernet, 10GBASE-LR (1310nM
LAN PHY)
Data Transfer Rate: 10.3125GBd
Cables and Operating distance: Single-
Mode: 10000m at 9um
Interface Standard: PCI-Express Base Specification Revision 2.0
(5GT/s)
Board Size: 167.65mm X 68.91mm (6.60”X 2.713”)
PCI Express Card Type: X8 Lane
PCI Express Voltage: +12V ± 8%
PCI Connector: Gold Finger - X8 Lane
Controller: Intel 82599ES
Holder: Metal Bracket
I/O: LC
Weight: 200g (7.055oz)
Power Consumption:
l6.6 W, 0.55 A at 12V: Typical all ports operate at 10Gb/s, (Normal
Mode).
l6.12 W, 0.51 A at 12V: Typical Bypass Mode.
l6.36 W, 0.53 A at 12V: Typical No link at all ports
Optical Output Power:
lNormal Mode (Bypass Off):
lMinimum: -5.2 dBm
Optical Receive Sensitivity:
lNormal Mode (Bypass Off)
lMaximum: -12.6 dBm
Insertion Loss:
lBypass Mode: Insertion loss (Optical
Power attenuation between TX to
RX) (LC- fiber- switch- LC)
lMaximum 0.5 dB
LEDs: (2) LED per port
lLink: Turns on Blue on 10G link.
lACT: Blinks on activity (green).
lBi-color LED per Bypass pair:
lBYPASS: Turns on Green on Bypass
lDisconnect : Turns on Yellow on Disconnect
lNormal: Off
lLEDs location: LEDs are located on the PCB, visible via holes in
the metal bracket holder
lConnector: (2) LC
16

The quad port Gigabit Ethernet bypass NIC cards [NIC-S400-4xGigE-LX-Fiber / NIC-S200-4xGigE-LX-Fiber]
are PCIe x4 network adapters containing four fiber Gigabit interfaces, based on a single chip, non-bridged GBE
controller.
Key Features Technical Specifications
Fiber Gigabit Ethernet 1000Base-SX::
lIndependently Fiber Gigabit Ethernet channel/s
support Gigabit Ethernet 1000Base-SX.
lSmall Form Factor (SFF) LC Connectors.
WDT Interval (Software Programmable):
l3,276,800 mSec (3,276.8 Sec): Maximum
l100 mSec (0.1 Sec) : Minimum
lWDT Interval = (2^wdt_interval_parameter)*(0.1)
sec.
lwdt_interval_parameter: {Valid Range: 0-15}
IEEE Standard / Network topology: Fiber Gigabit Ethernet,
1000Base-SX (850nM)
Full duplex / Simplex: Support both Simplex & Full duplex
operation in all operating speeds
Auto negotiation: Auto-negotiation between Full duplex and
simplex operations and between 10Mb/s 100Mb/s speeds
and duplex 1000Mb/s.
Data Transfer Rate: 2000Mbit/s in full duplex mode per port
Cables and Operating distance: Multimode fiber - 137m
maximum at 62.5 um *
*Theoretical Distance – Defined as half a distance as stated by the IEEE
802.3 standard
Interface Standard: PCI-Express Base Specification
Revision 2.1 (5GT/s)
Board Size: 167.65mm X 111.15mm (6.60”X 4.376”)
PCI Express Card Type: X4 Lane
PCI Express Voltage: +3.3V +-9%, +12V +- 8%
PCI Connector: Gold Finger - X4 Lane
Controller: Intel i350AM4
Holder: Metal Bracket
I/O: LC
Weight: 330g (11.641oz)
Power Consumption:
l0.40A, 4.8W at 12V: Typical all ports operate at
1000Mb/s.
l0.40A, 4.8W at 12V: Typical No link at all ports.
l0.38A, 4.56W at 12V: Bypass Mode.
l0.38A, 4.56W at 12V: Disconnect Mode.
LEDs: (1) LED per port
lLink/ACT:
lBlinks on activity (green).
lTurns on link (green).
lBi-color LED per Bypass pair:
lBYPASS: Turns on Green on Bypass
lDisconnect : Turns on Yellow on
Disconnect
lNormal: Off
lLEDs location: LEDs are located on the PCB,
visible via holes in the metal bracket holder
lConnector: (4) LC
17

Install an option card into Slot 1 or 2
The S500 Series expansion slots 1 and 2 supports low-profile cards which can be accessed without the removal of the
PCIe expansion module.
ALWAYS observe proper electrostatic discharge (ESD) conventions. Attach an ESD protective
wrist strap to your wrist and to the chassis. Ensure that the appliance is on an ESD-safe work sur-
face or ground the unit appropriately. Symantec does not assume responsibility or liability for dam-
age resulting from ESD.
1. Unplug the appliance power cords.
2. Open the appliance center cover.
3. Remove the appliance rear cover panel.
4. Unlock the PCIe support latch.
5. Remove the PCIe slot cover by lifting straight up from the appliance.
6. Insert the option card by holding the edges of the card and gently inserting into the slot. It might be necessary to
lightly rock the option card into position. Verify that the PCIe card has been fully seated and is aligned with the
chassis.
18

7. Lock the securing latch. Verify that it is fully closed and that the option card is secured.
8. Reinstall the appliance’s center and rear panels.
9. Reconnect the network cabling as necessary for your deployment.
10. Reconnect the power cords.
11. Verify that you have correctly installed the option card.
19

Install an option card into Slot 3 or 4
The S500 Series is equipped with a PCIe expansion module that houses four PCIe cards - two full-height and two low-pro-
file cards. Slots 3 and 4 are the only available slots which can accept a full-length card.
ALWAYS observe proper electrostatic discharge (ESD) conventions. Attach an ESD protective
wrist strap to your wrist and to the chassis. Ensure that the appliance is on an ESD-safe work sur-
face or ground the unit appropriately. Symantec does not assume responsibility or liability for dam-
age resulting from ESD.
1. Unplug the appliance power cords.
2. Open the appliance center cover.
3. Remove the appliance rear cover panel.
4. Remove the PCIe expansion module and flip over the to access the slots.
5. Unlock the blue PCIe support latches.
6. Remove the expansion slot cover by pressing the release button and then pulling out the cover from the side. Set
the expansion slot cover aside in a safe location for future use
20
