Synology VisualStation VS960HD User manual

Synology VisualStation VS960HD
User’s Guide
Downloaded from ManualsNet.com search engine

Table of Contents
Chapter 1: Introduction
Chapter 2: Getting Started with Synology VisualStation
Setting up VisualStation 4
Getting to Know VisualStation 4
Chapter 3: Logging in Surveillance Station
Surveillance Station 5
Chapter 4: Working O󰀪ine
Timeline 6
Recording 8
Chapter 5: Options
Options 9
Chapter 6: Troubleshooting
2
Downloaded from ManualsNet.com search engine

Thank you for purchasing Synology VisualStation. Synology VisualStation allows you to manage and monitor IP
camera feeds without using a computer. You can log in to Surveillance Station directly through VisualStation for
complete control over your surveillance devices. After logging in to VisualStation, users will be redirected to a
web browser interface that is consistent with that of the Surveillance Station package. For more information on
Surveillance Station, please read the online resources below:
Online Resources
Click on the links to obtain Synology's online resources.
• Knowledge Base: www.synology.com/knowledgebase
• Forum: forum.synology.com
• Download Center: www.synology.com/support/download.php
• Technical Support: www.synology.com/support/support_form.php
Introduction 1
Chapter
3
Downloaded from ManualsNet.com search engine

Setting up VisualStation
This guide assumes that both your Synology VisualStation and Synology NAS/NVR product running with Surveillance
Station 8.0.2 (and above) have access to the Internet or local area network. If you have not yet completed hardware
and software setup, please refer to the Hardware Installation Guide that came with your Synology VisualStation before
proceeding.
Getting to Know VisualStation
This section explains the basics of navigating and operating Synology VisualStation.
Using a Mouse or Joystick
Once VisualStation is powered on and booted up, the VisualStation user interface appears on the HDMI1 or
HDMI2 display connected to it. In order to navigate and operate this user interface, you can plug a mouse or
joystick into one of the USB ports located on the back panel of VisualStation.
Navigating
At the top of the user interface, you should see a taskbar. Use this taskbar to navigate between pages. See the
graphic and explanation below:
Item Name Function
1. Main Menu Displays all available applications.
2. USB Eject the connected USB devices here.
3. Virtual Keyboard Launch the virtual keyboard here.
4. Options
This menu includes the following:
1. Information: View system information: model name, serial number, fan status.
2. Settings: Edit network, time, display, and login settings, and enable/disable
remote access support.
3. Firmware: Perform rmware upgrade.
4. Reboot: Restart VisualStation.
5. Shutdown: Power o󰀨 VisualStation.
Connecting to Surveillance Station
Synology VisualStation allows you to monitor IP camera feeds without a computer. Moreover, as a client of
Surveillance Station, it allows you to manage most conguration of Surveillance Station according to the
privileges you have. Users can sign in to Surveillance Station using an account belonging to the administrators
group of Synology DiskStation Manager (DSM) to obtain the full control of the system, or using an account
belonging to the Spectator group in Surveillance Station to operate with limited permissions.
After logging in to VisualStation, users will be redirected to a web browser interface that is consistent with that of
the Surveillance Station package. For more information, please read Online Help for Surveillance Station.
Working O󰀪ine from Surveillance Station
Synology VisualStation allows you to play back recordings without connecting to Surveillance Station or any
Internet access. By plugging a USB with recordings imported from Surveillance Station into your VisualStation,
you can play back the recordings with Recording or Timeline applications.
Getting Started with Synology
VisualStation
4
2
Chapter
Downloaded from ManualsNet.com search engine

This chapter introduces how to log in Surveillance Station through VisualStation and utilize full features of
Surveillance Station.
Surveillance Station
In the Surveillance Station application, you can sign in to any Surveillance Station account on a Synology
NAS/NVR product to operate the functions of Surveillance Station based on the privilege granted to the account.
Item Name Function
1. IP address or
QuickConnect ID
Enter the IP address and port number of the server with the Surveillance Station
package installed. Use a colon (:) to separate the IP address and port number
(e.g., 192.168.20.16:5000). You can choose to enter QuickConnect ID to avoid the
hassle of setting up port forwarding rules.
2. User account Enter the user name of an account with Surveillance Station privileges.
3. Password Enter the login password for the user account.
4. Login settings Open the Login settings page here. You can choose to enable HTTPS connection
in the Login settings page.
Logging in Surveillance Station 3
5
Chapter
Downloaded from ManualsNet.com search engine

This chapter introduces how to view footage exported from Surveillance Station o󰀪ine in Timeline and
Recording applications using a plugged in USB storage.
Timeline
In the Timeline application, you can play back recordings exported from Surveillance Station with a plugged in
USB storage when working o󰀪ine. Recordings can be ltered based on cameras or dates. In addition, footage
recorded at di󰀨erent times or with di󰀨erent cameras can be watched simultaneously, allowing you to easily
compare captured recordings.
Item Name Function
1. Recording Viewer Video footage recorded with IP cameras is displayed here. Please see “Recording
Viewer” below.
2. Timeline Search for recordings according to time captured. Please see “Timeline” below.
3. Calendar Select date for recordings. Please see “Calendar” below.
4. Playback Controller Controls recording playback, including play, pause, etc. Please see “Playback
Controller” below.
5. Sync Mode Enable the sync mode for all channels of Timeline. Please see “Sync Mode”
below.
6. Layout Panel Layout related such as edit layout, select layout, show camera information, etc.
Please see “Layout Panel” below.
7. Seek Panel Seek the specic time of timeline. Please see “Seek Panel” below.
Working O󰀪ine 4
6
Chapter
Downloaded from ManualsNet.com search engine

7 Chapter 4: Working O󰀪ine
Recording Viewer
Recordings from IP cameras can be displayed here. Please refer to the instructions below:
1 Click to select a camera feed.
2 Once a camera feed is selected, you can use controls located on the left to change viewing options. The
currently selected camera feed will be highlighted with a yellow frame.
3 Double-click a camera feed to enlarge the image of that feed. Double-click again to return back to the
original layout.
4 Hover the mouse over to the bottom left corner of the camera feed to nd Drag and Zoom, and Volume
buttons.
Item Name Function
1. Drag and Zoom Operate digital zoom in. After the feed is zoomed in, you can click the magnifying
glass icon at the upper left corner of the feed to end the zoom-in.
2. Volume Adjust the audio volume of the selected recording channel.
Timeline bar
The timeline bar displays the times when recordings were captured, allowing you to quickly search for recordings
captured at specic times. There are two columns, the left one representing all camera feeds, and the right one
representing the currently selected camera feed.
On the timeline, click a specic time to start playing the rst recording captured after that time.
For example, if you select Camera A and click 08:00:00, but no recordings were captured until 08:34:00, then
recordings will be played back starting from 08:34:00.
Calendar
Choose to play back recordings captured on specic dates. Any dates that have recordings are shown in blue.
Playback Controller
Control recording playback with these buttons, including play/pause, fast forward/slow motion, next/previous, and
next frame/previous frame.
Sync Mode
Click this button to enable/disable Sync Mode.
When Sync Mode is enabled, recordings captured at the same time are played back simultaneously. For
example, if you select 07:15:00, recordings captured by all selected cameras at 07:15:00 will be played back
simultaneously.
When Sync Mode is disabled, you can play back and compare recordings captured at di󰀨erent times by selected
cameras. For example, you can play back recordings captured by Camera A at 07:15:00, while playing back
recordings captured by Camera B at 03:45:00.
Downloaded from ManualsNet.com search engine

8 Chapter 4: Working O󰀪ine
Layout Panel
This panel provides some congurations of the layout of Recording Viewer.
Item Name Function
1. Management
Select the cameras for the layout. Recordings captured with the selected cameras
can be played back. Before playing back any recordings in Timeline application,
you must select at least one camera.
2. Current Layout Display the current layout on the Recording Viewer.
3. Information Show or hide the camera name and recording time.
4. Fixed aspect ratio View the recording feed with its original aspect ratio.
5. Full screen Display the recording feed in full screen.
Seek Panel
This panel allows you to search for recordings from a specic time. After entering a time and clicking the Go To
button, VisualStation will begin playing back recordings captured after the selected time.
For example, you enter 07:00:00 and click Go To, but no recordings were captured until 07:15:00. In this case,
recordings will start playing back from 07:15:00.
Recording
In the Recording application, you can view a list of footage exported from Surveillance Station with a plugged in
USB storage. Every recording le exported into the USB storage can be found here.
Recordings can be ltered based on source, camera, recording mode, or start time. You can dene which
recordings to play back by clicking the lter icon with server name on the upper-right corner and conguring lter
criteria.
Downloaded from ManualsNet.com search engine

This chapter introduces how to view system information and update rmware in Options.
Options
Options, including device information, settings, rmware install, reboot, and shutdown can be accessed by
clicking the option icon located on the taskbar as illustrated below.
Information
The information page displays device information related to your VisualStation, including model name, serial
number, thermal status, as well as the current device rmware version.
Thermal status is indicated as follows:
Item Light Status
Thermal Status
Green Normal
Red
VisualStation STATUS LED Indicator will show a static orange light
in the event of overheating.
Note: VisualStation will automatically shut down once its
temperature reaches 100°C (212°F).
Settings
View and edit network, time, display, and login settings, and enable/disable remote access support for
VisualStation on this page.
Options 5
9
Chapter
Downloaded from ManualsNet.com search engine

10 Chapter 5: Options
Firmware
VisualStation rmware can be upgraded on this page. To upgrade rmware, please do the following:
1 Download the rmware from Download Center.
2 Copy the rmware le on to a USB drive.
3 Connect the USB drive to your VisualStation.
4 Go to Options (on top right corner).
5 Select Firmware.
6 Click Scan. The system would automatically detect the newest rmware le on the USB drive.
7 Click Upgrade to start.
When rmware upgrade is complete, VisualStation will automatically power o󰀨 and restart.
Reboot
This option restarts VisualStation.
Shutdown
This option shuts down VisualStation. If this button is unavailable, VisualStation can be shut down by pressing the
Power button located on the front panel of VisualStation
Downloaded from ManualsNet.com search engine

This chapter provides solutions to common issues you might encounter while using your Synology VisualStation.
Why is the frame rate of camera feeds low?
If the frame rate of camera feeds on the Live View page is lower than normal, please try the below suggestions.
• Check the bandwidth of your network equipment, such as routers or switches. You might need to upgrade your
equipment in order to increase network bandwidth and handle camera video feeds.
• Lower image resolution of your cameras. To edit the resolution of cameras, please do the following:
1 Sign in to Surveillance Station with a user account with Manager privileges.
2 Go to IP Camera.
3 Select a camera from the list.
4 Click Edit.
5 Go to Video tab in the Camera Settings page.
Why can’t I save snapshots or download recordings?
Snapshots, recordings, and system logs can be saved to a USB drive. In order to save any of these les, please
make sure a USB drive is connected to your VisualStation.
Troubleshooting 6
11
Chapter
Downloaded from ManualsNet.com search engine

SYNOLOGY, INC.
END USER LICENSE AGREEMENT
IMPORTANT–READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("EULA") IS A LEGAL AGREEMENT
BETWEEN YOU (EITHER AN INDIVIDUAL OR A LEGAL ENTITY) AND SYNOLOGY, INC. ("SYNOLOGY") FOR THE
SYNOLOGY SOFTWARE INSTALLED ONTO THE SYNOLOGY PRODUCT PUCHASED BY YOU (THE “PRODUCT”), OR
LEGALLY DOWNLOADED FROM WWW.SYNOLOGY.COM, OR ANY OTHER CHANNEL PROVIDED BY SYNOLOGY
( "SOFTWARE").
YOU AGREE TO BE BOUND BY THE TERMS OF THIS EULA BY USING THE PRODUCTS CONTAINING THE SOFTWARE,
INSTALLING THE SOFTWARE ONTO THE PRODUCTS OR DEVICE CONNECTED TO THE PRODUCTS. IF YOU DO NOT
AGREE TO THE TERMS OF THIS EULA, DO NOT USETHE PRODUCTS CONTAINING THE SOFTWARE OR DOWNLOAD
THE SOFTWARE FROM WWW.SYNOLOGY.COM, OR ANY OTHER CHANNEL PROVIDED BY SYNOLOGY. INSTEAD,
YOU MAY RETURN THE PRODUCT TO THE RESELLER WHERE YOU PURCHASED IT FOR A REFUND IN
ACCORDANCE WITH THE RESELLER'S APPLICABLE RETURN POLICY.
Section 1. Limited Software License. Subject to the
terms and conditions of this EULA, Synology grants you a
limited, non-exclusive, non-transferable, personal license to
install, run and use one copy of the Software loaded on the
Product or on your device connected to the Product solely
relating to your authorized use of the Product.
Section 2. Documentation. You may make and use a
reasonable number of copies of any documentation provided
with the Software; provided that such copies will only be
used for internal business purposes and are not to be
republished or redistributed (either in hard copy or electronic
form) to any third party.
Section 3. Backup. You may make a reasonable number
of copies of the Software for backup and archival purposes
only.
Section 4. Updates. Any software provided to you by
Synology or made available on the Synology website at
www.synology.com ("Website") or any other channel
provided by Synology that updates or supplements the
original Software is governed by this EULA unless separate
license terms are provided with such updates or
supplements, in which case, such separate terms will govern.
Section 5. License Limitations. The license set forth in
Sections 1, 2 and 3 applies only to the extent that you have
ordered and paid for the Product and states the entirety of
your rights with respect to the Software. Synology reserves
all rights not expressly granted to you in this EULA. Without
limiting the foregoing, you shall not authorize or permit any
third party to: (a) use the Software for any purpose other
than that in connection with the Product; (b) license,
distribute, lease, rent, lend, transfer, assign or otherwise
dispose of the Software; (c) reverse engineer, decompile,
disassemble or attempt to discover the source code of or
any trade secrets related to the Software, except and only to
the extent that such conduct is expressly permitted by
applicable law notwithstanding this limitation; (d) adapt,
modify, alter, translate or create any derivative works of the
Software; (e) remove, alter or obscure any copyright notice
or other proprietary rights notice on the Software or Product;
or (f) circumvent or attempt to circumvent any methods
employed by Synology to control access to the components,
features or functions of the Product or Software. Subject to
the limitations specified in this Section 5, you are not
prohibited from providing any services hosted by Synology
Product to any third party for commercial purpose.
Section 6. Open Source. The Software may contain
components licensed to Synology under the GNU General
Public License ("GPL Components"), currently available at
http://www.gnu.org/licenses/gpl.html. The terms of the
GPL will control solely with respect to the GPL Components
to the extent that this EULA conflicts with the requirements
of the GPL with respect to your use of the GPL Components,
and, in such event, you agree to be bound by the GPL with
respect to your use of such components.
Section 7. Audit. Synology will have the right to audit your
compliance with the terms of this EULA. You agree to grant
Synology a right to access to your facilities, equipment,
books, records and documents and to otherwise reasonably
cooperate with Synology in order to facilitate any such audit
by Synology or its agent authorized by Synology.
Section 8. Ownership. The Software is a valuable
property of Synology and its licensors, protected by
copyright and other intellectual property laws and treaties.
Synology or its licensors own all rights, titles and interests in
and to the Software, including but not limited to copyright
and any other intellectual property rights.
Section 9. Limited Warranty. Synology provides a limited
warrant that the Software will substantially conform to
Synology's published specifications for the Software, if any,
or otherwise set forth on the Website, for a period required
by your local law. Synology will use commercially reasonable
efforts to, in Synology's sole discretion, either correct any
such nonconformity in the Software or replace any Software
that fails to comply with the foregoing warranty, provided that
you give Synology written notice of such noncompliance
within the warranty period. The foregoing warranty does not
apply to any noncompliance resulting from any: (w) use,
reproduction, distribution or disclosure not in accordance
with this EULA; (x) any customization, modification or other
alteration of the Software by anyone other than Synology; (y)
combination of the Software with any product, services or
other items provided by anyone other than Synology; or (z)
your failure to comply with this EULA.
Section 10. Support. During the period specified in the
Section 9, Synology will make available to you the support
services. Following the expiration of the applicable period,
support for Software may be available from Synology upon
written request.
Section 11. Disclaimer of Warranties. EXCEPT AS
EXPRESSLY SET FORTH ABOVE, THE SOFTWARE IS
PROVIDED "AS IS" AND WITH ALL FAULTS. SYNOLOGY
AND ITS SUPPLIERS HEREBY DISCLAIM ALL OTHER
WARRANTIES, EXPRESS, IMPLIED OR STATUTORY,
ARISING BY LAW OR OTHERWISE, INCLUDING BUT
NOT LIMITED TO ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR USE, TITLE AND NONINFRINGEMENT,
WITH REGARD TO THE SOFTWARE. WITHOUT LIMITING
THE FOREGOING, SYNOLOGY DOES NOT WARRANT
THAT THE SOFTWARE WILL BE FREE OF BUGS,
ERRORS, VIRUSES OR OTHER DEFECTS.
Section 12. Disclaimer of Certain Damages. IN NO
EVENT WILL SYNOLOGY OR ITS LICENSORS BE LIABLE
FOR ANY INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE,
CONSEQUENTIAL OR SIMILAR DAMAGES OR
LIABILITIES WHATSOEVER (INCLUDING, BUT NOT
LIMITED TO LOSS OF DATA, INFORMATION, REVENUE,
PROFIT OR BUSINESS) ARISING OUT OF OR RELATING
TO THE USE OF OR INABILITY TO USE THE SOFTWARE
OR OTHERWISE UNDER OR IN CONNECTION WITH
THIS EULA OR THE SOFTWARE, WHETHER BASED ON
CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT
Downloaded from ManualsNet.com search engine

LIABILITY OR OTHER THEORY EVEN IF SYNOLOGY HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Section 13. Limitation of Liability. SYNOLOGY'S AND
ITS SUPPLIERS' LIABILITY ARISING OUT OF OR
RELATING TO THE USE OF OR INABILITY TO USE THE
SOFTWARE OR OTHERWISE UNDER OR IN
CONNECTION WITH THIS EULA OR THE SOFTWARE IS
LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU
FOR THE PRODUCT REGARDLESS OF THE AMOUNT OF
DAMAGES YOU MAY INCUR AND WHETHER BASED ON
CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT
LIABILITY OR OTHER THEORY. The foregoing disclaimer
of warranties, disclaimer of certain damages and limitation of
liability will apply to the maximum extent permitted by
applicable law. The laws of some states/jurisdictions do not
allow the exclusion of implied warranties or the exclusion or
limitation of certain damages. To the extent that those laws
apply to this EULA, the exclusions and limitations set forth
above may not apply to you.
Section 14. Export Restrictions. You acknowledge that
the Software is subject to U.S. export restrictions. You agree
to comply with all applicable laws and regulations that apply
to the Software, including without limitation the U.S. Export
Administration Regulations.
Section 15. Termination. Without prejudice to any other
rights, Synology may terminate this EULA if you do not abide
by the terms and conditions contained herein. In such event,
you must cease use of the Software and destroy all copies of
the Software and all of its component parts.
Section 16. Assignment. You may not transfer or assign
your rights under this EULA to any third party, except for that
pre-installed in the Products. Any such transfer or
assignment in violation of the foregoing restriction will be
void.
Section 17. Applicable Law. Unless expressly prohibited
by local law, this EULA is governed by and construed in
accordance with the laws of the Republic of China (R.O.C. or
Taiwan) without regard to any conflict of law principles to the
contrary.
Section 18. Dispute Resolution. Any dispute, controversy
or claim arising out of or relating to this EULA will be
resolved exclusively and finally by arbitration conducted by
three neutral arbitrators in accordance with the procedures
of the R.O.C. Arbitration Law and related enforcement rules.
In such cases, the arbitration will be limited solely to the
dispute between you and Synology. The arbitration, or any
portion of it, will not be consolidated with any other
arbitration and will not be conducted on a class-wide or class
action basis. The arbitration shall take place in Taipei,
Taiwan, R.O.C., and the arbitration proceedings shall be
conducted in English or, if both parties so agree, in Mandarin
Chinese. The arbitration award shall be final and binding on
the parties and may be enforced in any court having
jurisdiction. You understand that, in the absence of this
provision, you would have had a right to litigate any such
dispute, controversy or claim in a court, including the right to
litigate claims on a class-wide or class-action basis, and you
expressly and knowingly waives those rights and agrees to
resolve any disputes through binding arbitration in
accordance with the provisions of this Section 18. Nothing in
this Section shall be deemed to prohibit or restrict Synology
from seeking injunctive relief or seeking such other rights
and remedies as it may have at law or equity for any actual
or threatened breach of any provision of this EULA relating
to Synology's intellectual property rights.
Section 19. Attorneys' Fees. In any arbitration, mediation,
or other legal action or proceeding to enforce rights or
remedies under this EULA, the prevailing party will be
entitled to recover, in addition to any other relief to which it
may be entitled, costs and reasonable attorneys' fees.
Section 20. Severability. If any provision of this EULA is
held by a court of competent jurisdiction to be invalid, illegal,
or unenforceable, the remainder of this EULA will remain in
full force and effect.
Section 21. Entire Agreement. This EULA sets forth the
entire agreement of Synology and you with respect to the
Software and the subject matter hereof and supersedes all
prior and contemporaneous understandings and agreements
whether written or oral. No amendment, modification or
waiver of any of the provisions of this EULA will be valid
unless set forth in a written instrument signed by the party to
be bound thereby.
Downloaded from ManualsNet.com search engine

SYNOLOGY, INC.
LIMITED PRODUCT WARRANTY
THIS LIMITED WARRANTY ("WARRANTY") APPLIES TO THE PRODUCTS (AS DEFINED BELOW) OF SYNOLOGY, INC.
AND ITS AFFILIATES, INCLUDING SYNOLOGY AMERICA CORP, (COLLECTIVELY, "SYNOLOGY"). YOU ACCEPT AND
AGREE TO BE BOUND BY THE TERMS OF THIS WARRANTY BY OPENING THE PACKAGE CONTAINING AND/OR
USING THE PRODUCT. IF YOU DO NOT AGREE TO THE TERMS OF THIS WARRANTY, DO NOT USE THE PRODUCT.
INSTEAD, YOU MAY RETURN THE PRODUCT TO THE RESELLER WHERE YOU PURCHASED IT FOR A REFUND IN
ACCORDANCE WITH THE RESELLER'S APPLICABLE RETURN POLICY.
Section 1. Definitions. (a) “New Product”, including: (1)
"Category I Product" means Synology product models
RS810+, RS810RP+, RX410, all FS-series models, all
DS/RS NAS models with the XS+/XS suffix (except
RS3413xs+) in or after 13-series, all DX/RX/RXD expansion
units with 12 or more drive bays in or after 13-series, 10GbE
NIC, DDR4-2133 and DDR3-1600 memory modules. (2)
"Category II Product" means Synology product models
RS3413xs+, RS3412xs, RS3412RPxs, RS3411xs,
RS3411RPxs, RS2211+, RS2211RP+, RS411, RS409RP+,
RS409+, RS409, RS408-RP, RS408, RS407, DS3612xs,
DS3611xs, DS2411+, DS1511+, DS1010+, DS509+, DS508,
EDS14, RX1211, RX1211RP, RX4, DX1211, DX510, DX5,
NVR216, VS360HD, VS240HD, and all other memory
modules not included in Category I. (3) "Category III
Product" means Synology product models that apply with the
following requirements: all DS NAS models without the
XS+/XS suffix and with 5 and more drive bays in or after 12-
series, all RS NAS models without the XS+/XS suffix in or
after 12-series, and all DX/RX expansion units with 4 or 5
drive bays in or after 12-series. (4) "Category IV Product"
means all other Synology product models purchased by
Customer after March 1, 2008. (5) "Category V Product"
means all other Synology product models purchased by
Customer before February 29, 2008. (b) "Refurbished
Product" means all Synology products which have been
refurbished and sold directly by Synology through Online
Store, not including those sold by an authorized Synology
distributor or reseller. (c) "Customer" means the original
person or entity purchasing the Product from Synology or an
authorized Synology distributor or reseller. (d) "Online Store"
means an online shop operated by Synology or Synology’s
affiliate. (e) "Product" means a New Product or a
Refurbished Product and any hardware incorporated into the
Product by Synology and any accompanying documentation.
(f) "Software" means the Synology proprietary software that
accompanies the Product when purchased by Customer, is
downloaded by Customer at the Web Site, or is pre-installed
on the Product by Synology, and includes any firmware,
associated media, images, animations, video, audio, text
and applets incorporated into the software or Product and
any updates or upgrades to such software. (g) "Warranty
Period" means the period commencing on the date the
Product is purchased by Customer and ending (1) five years
after such date for Category I Products; (2) three years after
such date for Category II & lll Products; or (3) two years after
such date for Category IV Products; or (4) one year after
such date for Category V Products; or (5) 90 days after such
date for Refurbished Products, except for those sold as "as
is" or with "no warranty" on Online Store. (h) "Web Site"
means the Synology web site located at
www.synology.com.
Section 2. Limited Warranty and Remedies
2.1 Limited Warranty. Subject to Section 2.6, Synology
warrants to Customer that each Product (a) will be free of
material defects in workmanship and (b) under normal use
will perform substantially in accordance with Synology's
published specifications for the Product during the Warranty
Period. Synology warrants the Software as set forth in the
accompanying end user license agreement provided with the
Product, if any. Synology provides no warranty to
Refurbished Product sold as “as is” or with “no warranty” on
Online Store.
2.2 Exclusive Remedy. If Customer gives notice of
noncompliance with any of the warranties set forth in
Section 2.1 within the applicable Warranty Period in the
manner set forth below, then, upon verification of the
noncompliance by Synology, Synology will, at Synology's
option: (a) use commercially reasonable efforts to repair the
Product, or (b) replace the noncomplying Product or part
thereof upon return of the complete Product in accordance
with Section 2.3 The foregoing sets forth Synology's entire
liability and Customer's sole and exclusive remedy for any
breach of warranty under Section 2.1 or any other defect or
deficiency in the Product. Customer will reasonably assist
Synology to diagnose and validate any nonconformity with
the Product. The warranty set forth in Section 2.1 does not
include: (1) any warranty relating to the Software;
(2) physical installation or removal of the Product from
Customer's site; (3) visits to Customer's site; (4) labor
necessary to effect repairs or replace defective parts other
than during Synology's or its contracted service providers'
normal local business hours, exclusive of weekends and
service providers’ holidays; (5) any work with any third party
equipment or software; (6) any warranty of the hard disk if
installed by Customer or any other third party; or (7) any
warranty of compatibility with the hard disk.
2.3 Return. Any Product returned by Customer under
Section 2.2 must be assigned a Return Merchandise
Authorization ("RMA") number by Synology before shipment
and must be returned in accordance with Synology's then
current RMA procedures. Customer may contact any
authorized Synology distributor or reseller or Synology
Support to obtain assistance in obtaining an RMA, and must
provide proof of purchase and product serial number when
asking for such assistance. For warranty claims, Customer
must return the complete Product to Synology in accordance
with this Section 2.3 to be eligible for coverage under this
Warranty. Any Product returned without an RMA number, or
any Product that has been disassembled (except under the
direction of Synology) will be refused and returned to
Customer at Customer's expense. Any Product that has
been assigned a RMA number must be returned in the same
condition as it was received from Synology to the address
designated by Synology, freight pre-paid, in packaging
sufficient to protect the contents thereof and with the RMA
number prominently displayed on the outside of the box.
Customer is responsible for insurance and risk of loss with
respect to returned items until they are properly received by
Synology. A Product issued a RMA number must be
returned within fifteen (15) days after issuance of the
applicable RMA number.
2.4 Replacement by Synology. If Synology elects to
replace any Product under this Warranty set forth in Section
2.1, then Synology will ship a replacement Product at
Synology's expense via the shipping method selected by
Synology after receipt of the nonconforming Product
returned in accordance with Section 2.3 and validation by
Synology that the Product does not conform to the warranty.
In some countries, Synology may at its own discretion apply
the Synology Replacement Service to certain Products,
through which Synology will ship a replacement Product to
Customer before its receipt of the nonconforming Product
returned by Customer (“Synology Replacement Service”).
2.5 Support. During the Warranty Period, Synology will
make available to Customer the support services. Following
Downloaded from ManualsNet.com search engine

the expiration of the applicable Warranty Period, support for
Products may be available from Synology upon written
request.
2.6 Exclusions. The foregoing warranties and warranty
obligations do not apply to any Product that (a) has been
installed or used in a manner not specified or described in
the Product specifications; (b) has been repaired, modified
or altered by anyone other than Synology or its agent or
designee; (c) has been in any way misused, abused, or
damaged; (d) has been used with items not provided by
Synology other than the hardware or software for which the
Product is designed; or (e) otherwise fails to conform to the
Product specifications and such failure is attributable to
causes not within or under Synology's control. Further, the
foregoing warranties will be void if (1) Customer
disassembles the Product except as authorized by Synology;
(2) Customer fails to implement any correction, modification,
enhancement, improvement or other update made available
to Customer by Synology; or (3) Customer implements,
installs or uses any correction, modification, enhancement,
improvement or other update made available by any third
party. The warranty set forth in Section 2.1 will terminate
upon Customer's sale or transfer of the Product to a third
party.
2.7 Disclaimer of Warranties. THE WARRANTIES,
OBLIGATIONS, AND LIABILITIES OF SYNOLOGY AND
THE REMEDIES OF CUSTOMER SET FORTH IN THIS
WARRANTY ARE EXCLUSIVE AND IN SUBSTITUTION
FOR, AND CUSTOMER HEREBY WAIVES, RELEASES
AND DISCLAIMS, ALL OTHER WARRANTIES,
OBLIGATIONS AND LIABILITIES OF SYNOLOGY AND ALL
OTHER RIGHTS, CLAIMS AND REMEDIES OF
CUSTOMER AGAINST SYNOLOGY, EXPRESS OR
IMPLIED, ARISING BY LAW OR OTHERWISE, WITH
RESPECT TO THE PRODUCT, ACCOMPANYING
DOCUMENTATION OR SOFTWARE AND ANY OTHER
GOODS OR SERVICES DELIVERED UNDER THIS
WARRANTY, INCLUDING, BUT NOT LIMITED TO ANY:
(A) IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE OR USE;
(B) IMPLIED WARRANTY ARISING FROM COURSE OF
PERFORMANCE, COURSE OF DEALING, OR USAGE OF
TRADE; (C) CLAIM OF INFRINGEMENT OR
MISAPPROPRIATION; OR (D) CLAIM IN TORT
(WHETHER BASED ON NEGLIGENCE, STRICT LIABILITY,
PRODUCT LIABILITY OR OTHER THEORY). SYNOLOGY
MAKES NO GUARANTEE AND SPECIFICALLY
DISCLAIMS ANY WARRANTY THAT THE DATA OR
INFORMATION STORED ON ANY SYNOLOGY PRODUCT
WILL BE SECURE AND WITHOUT RISK OF DATA LOSS.
SYNOLOGY RECOMMENDS THAT CUSTOMER TAKES
APPROPRIATE MEASURES TO BACK UP THE DATA
STORED ON THE PRODUCT. SOME
STATES/JURISDICTIONS DO NOT ALLOW LIMITATIONS
ON IMPLIED WARRANTIES, SO THE ABOVE LIMITATION
MAY NOT APPLY TO CUSTOMER.
Section 3. Limitations of Liability
3.1 Force Majeure. Synology will not be liable for, or be
considered to be in breach of or default under this Warranty
on account of, any delay or failure to perform as required by
this Warranty as a result of any cause or condition beyond
its reasonable control (including, without limitation, any act or
failure to act by Customer).
3.2 Disclaimer of Certain Damages. IN NO EVENT
WILL SYNOLOGY OR ITS SUPPLIERS BE LIABLE FOR
THE COST OF COVER OR FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, PUNITIVE, CONSEQUENTIAL OR
SIMILAR DAMAGES OR LIABILITIES WHATSOEVER
(INCLUDING, BUT NOT LIMITED TO LOSS OF DATA,
INFORMATION, REVENUE, PROFIT OR BUSINESS)
ARISING OUT OF OR RELATING TO THE USE OR
INABILITY TO USE THE PRODUCT, ANY
ACCOMPANYING DOCUMENTATION OR SOFTWARE
AND ANY OTHER GOODS OR SERVICES PROVIDED
UNDER THIS WARRANTY, WHETHER BASED ON
CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT
LIABILITY OR OTHER THEORY EVEN IF SYNOLOGY HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
3.3 Limitation of Liability. SYNOLOGY'S AND ITS
SUPPLIERS' LIABILITY ARISING OUT OF OR RELATING
TO THE USE OR INABILITY TO USE THE PRODUCT, ANY
ACCOMPANYING DOCUMENTATION OR SOFTWARE
AND ANY OTHER GOODS OR SERVICES PROVIDED
UNDER THIS WARRANTY IS LIMITED TO THE AMOUNT
ACTUALLY PAID BY CUSTOMER FOR THE PRODUCT
REGARDLESS OF THE AMOUNT OF DAMAGES
CUSTOMER MAY INCUR AND WHETHER BASED ON
CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT
LIABILITY OR OTHER THEORY. The foregoing disclaimer
of certain damages and limitation of liability will apply to the
maximum extent permitted by applicable law. The laws of
some states/jurisdictions do not allow exclusion or limitation
of certain damages. To the extent that those laws apply to
the Product, the exclusions and limitations set forth above
may not apply to Customer.
Section 4. Miscellaneous
4.1 Proprietary Rights. The Product and any
accompanying Software and documentation provided with
the Product include proprietary and intellectual property
rights of Synology and its third party suppliers and licensors.
Synology retains and reserves all right, title, and interest in
the intellectual property rights of the Product, and no title to
or ownership of any intellectual property rights in or to the
Product, any accompanying Software or documentation and
any other goods provided under this Warranty is transferred
to Customer under this Warranty. Customer will (a) comply
with the terms and conditions of the Synology end user
license agreement accompanying any Software furnished by
Synology or an authorized Synology distributor or reseller;
and (b) not attempt to reverse engineer any Product or
component thereof or accompanying Software or otherwise
misappropriate, circumvent or violate any of Synology's
intellectual property rights.
4.2 Assignment. Customer will not assign any of its
rights under this Warranty directly, by operation of law or
otherwise, without the prior written consent of Synology.
4.3 No Additional Terms. Except as expressly
permitted by this Warranty, neither party will be bound by,
and each party specifically objects to, any term, condition or
other provision that conflicts with the provisions of this
Warranty that is made by the other party in any purchase
order, receipt, acceptance, confirmation, correspondence or
otherwise, unless each party specifically agrees to such
provision in writing. Further, if this Warranty conflicts with
any terms or conditions of any other agreement entered into
by the parties with respect to the Product, this Warranty will
prevail unless the other agreement specifically references
the sections of this Warranty that it supersedes.
4.4 Applicable Law. Unless expressly prohibited by
local law, this Warranty is governed by the laws of the State
of Washington, U.S.A. without regard to any conflict of law
principles to the contrary. The 1980 U.N. Convention on
Contracts for the International Sale of Goods or any
successor thereto does not apply.
4.5 Dispute Resolution. Any dispute, controversy or
claim arising out of or relating to this Warranty, the Product
or services provided by Synology with respect to the Product
or the relationship between Customers residing within the
United States and Synology will be resolved exclusively and
finally by arbitration under the current commercial rules of
the American Arbitration Association, except as otherwise
provided below. The arbitration will be conducted before a
Downloaded from ManualsNet.com search engine

single arbitrator, and will be limited solely to the dispute
between Customer and Synology. The arbitration, or any
portion of it, will not be consolidated with any other
arbitration and will not be conducted on a class-wide or class
action basis. The arbitration shall be held in King County,
Washington, U.S.A. by submission of documents, by
telephone, online or in person as determined by the
arbitrator at the request of the parties. The prevailing party in
any arbitration or legal action occurring within the United
States or otherwise shall receive all costs and reasonable
attorneys’ fees, including any arbitration fee paid by the
prevailing party. Any decision rendered in such arbitration
proceedings will be final and binding on the parties, and
judgment may be entered thereon in any court of competent
jurisdiction. Customer understands that, in the absence of
this provision, Customer would have had a right to litigate
any such dispute, controversy or claim in a court, including
the right to litigate claims on a class-wide or class-action
basis, and Customer expressly and knowingly waives those
rights and agrees to resolve any disputes through binding
arbitration in accordance with the provisions of this
Section 4.5. For Customers not residing within the United
States, any dispute, controversy or claim described in this
section shall be finally resolved by arbitration conducted by
three neutral arbitrators in accordance with the procedures
of the R.O.C. Arbitration Law and related enforcement rules.
The arbitration shall take place in Taipei, Taiwan, R.O.C.,
and the arbitration proceedings shall be conducted in
English or, if both parties so agree, in Mandarin Chinese.
The arbitration award shall be final and binding on the
parties and may be enforced in any court having jurisdiction.
Nothing in this Section shall be deemed to prohibit or restrict
Synology from seeking injunctive relief or seeking such other
rights and remedies as it may have at law or equity for any
actual or threatened breach of any provision of this Warranty
relating to Synology's intellectual property rights.
4.6 Attorneys' Fees. In any arbitration, mediation, or
other legal action or proceeding to enforce rights or
remedies under this Warranty, the prevailing party will be
entitled to recover, in addition to any other relief to which it
may be entitled, costs and reasonable attorneys' fees.
4.7 Export Restrictions. You acknowledge that the
Product may be subject to U.S. export restrictions. You will
comply with all applicable laws and regulations that apply to
the Product, including without limitation the U.S. Export
Administration Regulations.
4.8 Severability. If any provision of this Warranty is held
by a court of competent jurisdiction to be invalid, illegal, or
unenforceable, the remainder of this Warranty will remain in
full force and effect.
4.9 Entire Agreement. This Warranty constitutes the entire
agreement, and supersedes any and all prior agreements,
between Synology and Customer related to the subject matter
hereof. No amendment, modification or waiver of any of the
provisions of this Warranty will be valid unless set forth in a
written instrument signed by the party to be bound thereby.
Downloaded from ManualsNet.com search engine
