Synway SHT-16B-CT/PCI User manual

Synway ATP Series
SHT-16B-CT/PCI
SHT-16B-CT/PCI/MP3
Analog Tap Passive Board
Synway Information Engineering Co., Ltd
www.synway.net

Synway Information Engineering Co., Ltd
Functions
zHigh-impedance connection ensures no interruption of data transmission on the
monitored line
zA variety of ways to start/stop recording
zSupports simultaneous recording on 16 channels, each with a different format
zCaller ID detection, DTMF and FSK support
zDTMF digits detection
zProgrammable tone analyzer detects all kinds of tones
zActivity/silence detection
zAGC support in recording/playback operation
zCall progress monitoring
zAutomatic line voltage detection
zAutomatically checks board to see if recording modules are correctly inserted
Characteristic Features
zPCI 2.1 Bus Support
Includes PCI 2.1 bus with burst data transmission rate up to 133 MB/s; PNP (plug and
play) feature eliminates the need for jumper leads
zModule Configurable
8 on-board dual channel modules can be freely arranged in pairs or groups for various
complex combination applications, such as call center and recording functions available
on a single board.
zOn-board SIMM Slots
Fit recording modules to board. Contacts on both sides of the SIMM slots greatly
improve connection and ease installation.
zRJ45 Jack
A single board has four 8-pin RJ45 jacks, each of which can be converted into four 2-pin
RJ11 jacks via a proper 4-way hub, making connection easy and malfunctions rare.
SHT-16B-CT/PCI, SHT-16B-CT/PCI/MP3 Analog Tap Passive Board Product Introduction Page 1

Synway Information Engineering Co., Ltd
z2 to 16 Port Hi-Z Monitoring of Analog Lines
Flexible positioning of the access point on the communication line between Central Office
Terminal (COT) and PBX, COT and telephones, PBX and telephones, etc. allows
monitoring of any analog tone signal such as tone signals from radio station. This function
is widely used in small-to-large capacity call recording systems, call centers and
microphone recording systems.
zProgrammable Tone Detector
Detects single or dual tones at any frequency, offering facility for use with a variety of
switches and enterprise phone systems
zHigh-impedance Recording
The recording impedance is up to 10KΩAC/2MΩDC, ruling out interruption on
transmission of monitored signals.
zVarious CODECs Support
Offers a large selection of voice CODECs, including hardware-based A-Law (G.711),
μ-Law, IMA-ADPCM, software-based 16-bit linear PCM, MP3 and VOX
zSupports WAV File
The recorded speech files can be edited and played by audio tools such as Cooledit.
zAudio Output Interface
The first channel on the board equipped with an analog tone amplifier circuit and an
output interface, can directly connect to the headset or sound box, and monitor a
specified channel in real time via a simple function call.
zTDM Capability
Includes H.100 bus, facilitating smooth connectivity to third-party boards with H.100 bus
for the transfer of acquired voice signals to other devices
zUnique Hardware Serial Number
Each board has a unique hardware serial number written in the firmware to distinguish
itself from other boards and prevent piracy. The number is available via an easy function
call with applications.
zAuthorized Code Identification Circuit
The on-board authorized code identification circuit is designed for software safety. Users
can apply to our company for the authorized code.
zSynway’s Unified SynCTI Driver Development Platform
Synway owns the intellectual property rights for the unified high-intelligence SynCTI
SHT-16B-CT/PCI, SHT-16B-CT/PCI/MP3 Analog Tap Passive Board Product Introduction Page 2

Synway Information Engineering Co., Ltd
driver development platform. Each system supports up to 2048 channels. Functions such
as the detection and analysis of rings, tones and Caller IDs, are available via simple
function calls on the driver platform, without having to understand complex call
procedures.
SHT-16B-CT/PCI, SHT-16B-CT/PCI/MP3 Analog Tap Passive Board Product Introduction Page 3

Synway Information Engineering Co., Ltd
Operation Principle
Typical Application
SHT-16B-CT/PCI, SHT-16B-CT/PCI/MP3 Analog Tap Passive Board Product Introduction Page 4

Synway Information Engineering Co., Ltd
Technical Specifications
Dimensions
310 × 115mm2 （ excluding fixed slider ）
Weight
≈400g （ including 8 dual channel modules ）
Environment
Operating temperature: 0℃ — 55℃
Storage temperature: -20℃ — 85℃
Humidity: 8%
— 90% non-condensing
Storage humidity: 8%
— 90%
non-condensing
Input/output Interface
Headset jack: One φ3.5 stereo jack
Telephone line jack: Four 8-pin RJ45 jacks
Audio Specifications
CODEC: CCITT A/µ-Law 64kbps,
IMAADPCM 32kbps
Output power: ≥50mW
Distortion:
≤ 2%
Frequency response: 300-3400Hz(
± 3dB)
Signal-to-noise ratio: ≥ 38dB
Echo suppression:
≥ 40dB
Maximum System Capacity
Up to 10 boards concurrently per system; up
to 16 channels per board
Power Requirements
+5V DC: 600mA
-12V DC: 80mA
+12V DC: 300mA
Maximum power consumption:
≤ 12W
(PC power supply only)
Impedance
Input impedance: ≥1MΩ/500V DC;
≥10kΩ/1000V AC
Insulation resistance for PC isolation from
telephone line
： ≥2MΩ/500V DC
Audio Encoding & Decoding
16Bit PCM 128kbps
8Bit PCM 64kbps
A-Law 64kbps
µ-Law 64kbps
VOX 32kbps
ADPCM 32kbps
GSM 13.6kbps
MP3 8kbps
Sampling Rate
8kHz
Safety and Certifications
Lightning Resistance: Level 4
Safety: FCC ； CE ； CCC
SHT-16B-CT/PCI, SHT-16B-CT/PCI/MP3 Analog Tap Passive Board Product Introduction Page 5

Synway Information Engineering Co., Ltd
Purchasing Guide
The Synway SHT-16B-CT/PCI board provides a complete range of features to meet all
requirements.
¾Model Description
Model PC
Bus
Voice
Channel
Voltage
Detection
Audio
Jack
Tone
Detection DTMF
Detection
On-board
Exchange
Bus
CT
Bus
SHT-16B-CT/PCI PCI 16 √√√√√H.100
Technical/sales Support
Headquarters
Synway Information Engineering Co., Ltd
http://www.synway.net/
9F, Synway D&R Center, No.3756, Nanhuan Road, Binjiang District, Hangzhou,
P.R.China, 310053
Tel: [phone]
Fax: [phone]
Technical Support
Tel: [phone]
Mobile: [phone]
Email: [email protected]
Email: [e-mail]
MSN: [email protected]
Sales Department
Tel: [phone]
Tel: [phone]
Fax: [phone]
SHT-16B-CT/PCI, SHT-16B-CT/PCI/MP3 Analog Tap Passive Board Product Introduction Page 6

Synway Information Engineering Co., Ltd
Email: [e-mail]
