System Sensor MP120KL User manual

1 I56-0006-002
10/02/2018
PRODUCT SPECIFICATIONS
Standard Operating Temperature: –40°F to 151°F (–40°C to 66°C)
Humidity Range: 10 to 93% non-condensing (indoor products)
Nominal Voltage: Regulated 120 VAC
Operating Voltage Range: 96-132 VAC
Current Draw From AC Line: 150 mA max.
MP120KL may be used with any standard L-Series indoor Horn, Strobe, or Horn Strobe, at all horn and strobe settings.
NOTICE: This manual shall be left with the owner/user of this equipment.
GENERAL DESCRIPTION
The MP120KL mounting plate is designed to allow the use of 120 VAC to
power L-Series indoor horn, strobes, horn strobes, chimes, and chime strobes.
The MP120KL consists of a mounting plate that has been fitted with a power
supply that converts 120 VAC to nominal 24V FWR.
The MP120KL must be installed using a 120 VAC power source. This unit
can only be used for non-synchronous applications; it will NOT work with
System Sensor Sync•Circuit Modules.
WIRING
This module has pig-tail wires and is intended to be wired without rigid con-
nections inside a standard electrical box.
INSTALLATION AND MAINTENANCE INSTRUCTIONS
3825 Ohio Avenue, St. Charles, Illinois 60174
800/736-7672, FAX: [phone]
www.systemsensor.com
I56-0006-002
MP120KL
120 VAC Adapter Mounting Plate
MOUNTING (WALL)
1. Attach the mounting plate. (See Figure 2.) The mounting plate is compat-
ible only with 4 × 4 electrical boxes.
2. Connect field wiring. (For indoor models only)
3. If the product is not to be installed at this point, use the protective dust
cover to prevent contamination of the mounting plate terminals.
4. To attach product to mounting plate:
a. Remove the protective dust cover.
b. Hook the tabs on the top of the product housing into the grooves on
mounting plate.
c. Pivot the product into position to engage the terminals on the mount-
ing plate. Make sure that the tabs on the back of the product housing
fully engage with the mounting plate.
d. Hold product in place with one hand, and secure product by tighten-
ing the single mounting screw in the front of the product housing.
FIGURE 1. NON-SYNCHRONIZED DEVICES; ANY COMBINATION OF MODELS POWERED BY A 2-WIRE CIRCUIT
Horn Strobe Only
Two Wire System
An
y Mix of Models
Wired for Tandem
Operation
120
VAC
Power
Horn Strobe
A0356-01
FIGURE 2. WALL-MOUNTING (INDOOR ONLY)
4x4x21/8" BACKBOX 120V WIRES 120V MOUNTING PLATE
(Shipped mounted to MP120KL Module)
L-SERIES WALL-MOUNT
NOTIFICATION APPLIANCE
A0526-01

2 I56-0006-002
©2018 System Sensor. 10/02/2018
System Sensor®is a registered trademark of Honeywell International, Inc.
MOUNTING (CEILING)
Indoor L-Series ceiling appliances use a round mounting plate that is not sup-
plied with the MP120KL. The mounting plate that ships with the notification
appliance will need to be attached to the MP120KL module
1. Remove the mounting plate which comes attached to the MP120KL
module. Disconnect the red and black wire and remove the 4 mounting
screws that attach the mounting plate to the MP120KL module.
2. Attach the round mounting plate that ships with the notification appli-
ance to the MP120KL module. Attach with the four screws from Step 1
and attach the red and black wires to the terminal screws.
3. Attach the mounting plate. (See Figure 3.) The mounting plate is compat-
ible only with 4 × 4 electrical boxes.
4. Connect field wiring to the mounting plate per the notification appliance
user manual.
FIGURE 3. CEILING-MOUNTING (INDOOR ONLY)
L-SERIES CEILING-MOUNT
NOTIFICATION APPLIANCE
4x4x21/8" BACKBOX 120V MOUNTING PLATE
(Ships with Notification Appliance)
120V WIRES
MP120KL MODULE
(Mounting plate removed)
A0573-00
5. If the product is not to be installed at this point, use the protective dust
cover to prevent contamination of the mounting plate terminals.
6. To attach product to mounting plate:
a. Remove the protective dust cover.
b. Hook the tabs on the top of the product housing into the grooves on
mounting plate.
c. Pivot the product into position to engage the terminals on the mount-
ing plate. Make sure that the tabs on the back of the product housing
fully engage with the mounting plate.
d. Hold product in place with one hand, and secure product by tighten-
ing the single mounting screw in the front of the product housing.
Ceiling Models only: To remove product from the mounting plate, loosen the
captive mounting screw and press the locking button.
FCC STATEMENT
System Sensor Strobes and Horn/Strobes have been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
For the latest Warranty information, please go to:
http://www.systemsensor.com/en-us/Documents/E56-4000.pdf
For Limitations of Fire Alarm Systems, please go to:
http://www.systemsensor.com/en-us/Documents/I56-1558.pdf
Speakers only: For the latest Important Assembly Information, please go to:
http://www.systemsensor.com/en-us/Documents/I56-6556.pdf
