SystemBase eCAN User manual
1
Revision History
Revision Date
Document
Ver.
Pages
Revised
Revised/Added/Removed
Details of Revision
2021.07.02
1.0
All
-
New
eCAN
User Manual
2
Contents
1. CAN ................................................................................................................................... 3
2. COMPONENTS ................................................................................................................. 5
3. PRODUCT ......................................................................................................................... 6
4. FEATURES........................................................... 오류! 책갈피가 정의되어 있지 않습니다.
5. HOW TO USE.................................................................................................................... 9
6. HOW TO SETUP ............................................................................................................. 10
7. SETTING EXAMPLES .................................................................................................... 21
---------------------------------------------------------------------------------------------------------------
1. SPECIFICATION ............................................................................................................. 23
2. DIMENSION .................................................................................................................... 25
3. CAN PORT PIN SPECIFICATION .................................................................................. 26
4. SETTING MENU.............................................................................................................. 27
5. ECAN FRAME STRUCTURE ......................................................................................... 30
6. ECANVIEW ..................................................................................................................... 35
7. CERTIFICATION ............................................................................................................. 40
8. COPYRIGHT ................................................................................................................... 40
eCAN
User Manual
3
Please be sure to read this manual before using and use the product safely and accurately.
• Pictures and photos in the manual may be different from the physical, and the document is subject to change
without notice to improve performance. For the last information, please visit our website (www.sysbas.com).
• To view frequently asked questions and answers, please visit our website and find Support –Technical Support –
FAQ section.
• Documents can be downloaded from the product page or Download section.
• Sellers or users should be aware of the fact that this device is intended for industrial use(Class A), not for
residential use.
• This device has a potential for radio interference during use and may receive harmful interference from other
devices.
• Warranty policy is included in the product packaging.
• This product is domestic (Korea) and cannot be used overseas with different power/frequency.
eCAN
User Manual
4
1. CAN
CAN was developed to cause this problem by German company Bosch in 1986. It used bus communication method
rather than 1:1 communication method which UART based serial communication has, and various technologies
were incorporated to prevent communication conflicts.
1) Message Directional
ID is assigned to CAN according to the priority of the message and used to communicated. This causes each node
to self-judge the message delivered to each node and ignore the message which is except it needs.
2) Enhanced Error Mechanism
Several mechanisms have applied to CAN to improve communication reliability. If communication state detection,
error check and management were carried out in conventional SW method, CAN can detect and handle errors
occurring during communication due to the error detection mechanism built in HW in real time.
3) Multi-Master
CAN communication is conducted based on priority of each note and message without a network administrator which
manages the network. If arbitrary node A message is assigned with the highest priority ID, the rest of the nodes
communicate according to the priority of each ID after the A message is sent.
eCAN
User Manual
5
2. Components
Components
Ordering Information
eCAN, 5V DC Adaptor, LAN Cable,
Warranty/Download Guide
eCAN
eCAN
User Manual
6
3. Product
Connector
DC Adaptor, LAN Port
CAN Port(Male)
LED
LED
State
Operation
1
RDY(Ready)
Blink
Blinks when power is applied and boots normally
2
DATA(Data)
Blink
LED blinks when sending/receiving data
3
LNK(Link)
On/Off/
Blink
Lights when Ethernet socket is connected
Blinks when Bus off
eCAN
User Manual
7
Button
Press RST button less than 3 seconds: Reset equipment
Press RST button more than 3 seconds: Factory initialize equipment
(Please refer to the APPENDIX for initialization values)
Switch
ON
1234
Switch Number
Status
Operation
1
Switch1, 4
-
Not used
2
Switch2, 3
* Must be used at the same time
ON
Enable termination resistance of 120Ω
OFF
Disable termination resistance of 120Ω
eCAN
User Manual
8
4. Features
eCAN performs the following functions, as a converter converting signals coming from the CAN BUS into network
signals over the LAN port, or delivers signals to the CAN BUS via network signals.
1) Converts CAN communication to socket communication
Converts CAN communication which requires a direct connection to the cable facility, to socket communication
which the network communication is able.
2) CAN VBUS Power Supply Feature
In addition to the 5V Power supply through DC adapter, eCAN can be also powered by pin no.9 of the CAN port.
3) VCP(Virtual Com Port) Function
ComRedirector, a virtual COM Port(VCP) among the utilities provided, enables using LAN port of the eCAN
connected to the same network as if it were a serial port mounted on a PC. It also supports Sever/Client mode to
connect serial socket.
4) Web Page Setup Feature
Users can change, save, reboot the eCAN through its own Web Page provided.
eCAN
User Manual
9
5. How to Use
Connection between CAN equipment(CAN Bus) and PC
eCAN performs ComRedirector, TCP Server/Client and UPD connection over the network. Users can check CAN
data on PC over the network, or generate CAN data and forward it to CAN Bus.
Connection between CAN equipment(CAN Bus)
To enable communication between different CAN Buses, set two eCANs to Server and Client(Target: Server) each
and connect to the network.
* Please refer to 6. How to Setup for more information on setting up each connection.
eCAN
User Manual
10
6. How to Setup
First, check if the input voltage supplied to eCAN is consistent with 5V 1A and supply the voltage correctly. If power
is supplied normally, the eCAN starts booting with power on.
There are LEDs such as RDY to check the operation status. Please refer to the manual Ch3. Product – LED menu
in for more information.
To view or setup your eCAN environment, you should use eCANConfig utility, or use the WebPage to connect to the
IP Address, the network address on which the eCAN is operating.
Setting through Web Page
(1) Preparation for Connection(when connecting PC-eCAN without AP)
To connect eCAN and PC directly, you need to set the network address of the PC environment. Please follow the order of
setup as bellow.
1. Go to Control Panel\Network and Internet\Network Connection and open the Ethernet icon.
2. Click “Properties”.
eCAN
User Manual
11
3. Click Internet protocol version(TCP/IPv4) and then click Properties.
eCAN
User Manual
12
4. Click “Use IP Address(S)” and enter IP address.
5. Enter the IP address and subnet mask address and click “OK”.
eCAN
User Manual
13
(2) Web Connection
Open a web browser and enter the IP address of the eCAN. Then the authentication window appears on the first connection.
Default ID is “ecan”, password is “99999999(eight nines)”. After login, the web settings page appears.
eCAN Initial IP Address: 192.168.0.223
User name: ecan
Password: 99999999
eCAN
User Manual
14
Precautions for Accessing the Web
The setting using the web is not supported in the network environment below 10Mbps.
PC 10Mbps eCAN
Therefore, if you change the settings using the web, you should connect the integrated device to
the 100Mbps network environment or PC as below. If it is difficult to configure the environment
below, you can use the eCANConfig utility to set up your device.
Please refer to (1) Preparation for Connection when connecting directly with PC.
PC 100Mbps eCAN
PC eCAN
eCAN
User Manual
15
(3) Network Setting
The network Setting pages appears on the initial screen of the Web Settings page, that shows network information for the
equipment. The screen on the page is as follows.
You can set your network environment and management in the Network Setting. After changing the settings, you must press
the [Submit] button to save the changed value and restart it through the Reboot menu to apply it to the actual equipment
operation. If you exit without saving the changes, the changed value will be lost.
If you have not saved the changed value with the [Submit] button, you can return to the before value with the [Cancel] button.
*Please refer to APPENDIX 4. Settings for detailed information on Network Setting.
eCAN
User Manual
16
(4) CAN Setting
You can set the operating environment for CAN port in CAN Settings. After changing the settings, you must press the [Submit]
button to save the changed value and restart it through the Reboot menu to apply it to the actual equipment operation. If you
exit without saving the changes, the changed value will be lost.
If you have not saved the changed value with the [Submit] button, you can return to the before value with the [Cancel] button.
*Please refer to APPENDIX 4. Settings for detailed information on Network Setting.
eCAN
User Manual
17
(5) Filter Setting
You can set the SW Filter for the eCAN.
SW Filter is a feature that blocks a single ID unlike ID and MASK, and can set up to 32 SW Filter.
If you specify the ID and properties to filter, only those IDs will not be received.
Set the SW Filter value for CAN ports in Filter Setting. You can set the ID and Properties to filter by electing the
filter number in the combo box at the bottom of the setting page. After changing After changing the settings, you
must press the [Submit] button to save the changed value and restart it through the Reboot menu to apply it to the
actual equipment operation. If you exit without saving the changes, the changed value will be lost.
eCAN
User Manual
18
(6) Change ID/PW
To access the web settings page, an ID and Password are required. ID and password can be changed by the user on the
screen below. Please be aware that this setting will be applied simultaneously with saving without rebooting. If you forget your
ID and password, you can reset it to the default ID and password by pressing the RST button for more than 3 seconds.
(7) Reboot
The device will be restarted.
If you have changed the setting and save it via [Submit], you must press the [Reboot] button to restart the eCAN to reflect the
set values normally.
eCAN
User Manual
19
Setting through eCANConfig(PC Utility)
(1) Search
Search and displays eCAN equipment that exists on the local area network.
However, if eCAN is in the socket connected state, it will not be searched.
(2) Search IP
If you cannot find it by searching or if it is not a local network, you can search directly by IP address. When you click
[Search IP] button, the Search by IP window appears where you can enter the IP address directly to search for.
(3) Configure
You can change and save settings for the selected device.
1: You can set Network, Operation Mode, CAN Setting, Filter Setting.
2: Click Export button to save the information currently set in the eCAN to your PC.
3: Click Apply button to save and apply the changed setup information to the device.
