Systems With Intelligence TCAM2000-PT Series User manual
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
1
Note: Please read this manual thoroughly before operating this unit and retain it for future reference.
TCAM2000
– Installation Guide
2020.03.05 Version 1.4
Quick Install Guide
support@SystemsWithIntelligence.com
www.SystemsWithIntelligence.com
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
2
Copyright
COPYRIGHT © 2020 Systems With Intelligence Inc. ALL RIGHTS RESERVED
Dissemination or reproduction of this document, or evaluation and communication of its
contents, is not authorized except where expressly permitted. Violations are liable for damages.
All rights reserved, particularly for the purposes of patent application or trademark registration.
This document contains proprietary information, which is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced or translated to another
language without the prior written consent of Systems With Intelligence Inc.
Disclaimer of Liability
We have checked the contents of this manual against the hardware and software described.
However, deviations from the description cannot be completely ruled out.
Systems With Intelligence shall not be liable for any errors or omissions contained herein or for
consequential damages in connection with the furnishing, performance, or use of this material.
The information given in this document is reviewed regularly and any necessary corrections will
be included in subsequent editions. We appreciate any suggested improvements. We reserve
the right to make technical improvements without notice.
Contacting Systems With Intelligence
6889 Rexwood Road, Unit #9, Mississauga, Ontario, L4V 1R2 Canada
Phone: +1-289-562-0126 Email: info@SystemsWithIntelligence.com
www.SystemsWithIntelligence.com
Technical Support
International: +1-289-562-0126 Fax: +1-289-562-0152
Email: support @SystemsWithIntelligence.com
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
3
Federal Communications Commission
Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference on his own
expense.
CAUTION
This product contains no user-serviceable parts. Attempted service by unauthorized personnel
shall render all warranties null and void. Changes or modifications not expressly approved by
Systems With Intelligence Inc. could void the user’s authority to operate the equipment.
Should this device require service please contact Systems With Intelligence.
Contacting Systems With Intelligence
6889 Rexwood Road, Unit #9, Mississauga, Ontario, L4V 1R2 Canada
Phone: +1-289-562-0126 Email: info@SystemsWithIntelligence.com
www.SystemsWithIntelligence.com
Technical Support
International: +1-289-562-0126 Fax: +1-289-562-0152
Email: support @SystemsWithIntelligence.com
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
4
Important Safety Instructions
Please read & save these instructions.
1. Keep these instructions.
2. Heed all warnings.
3. Follow all instructions.
4. Install in accordance with the manufacturer’s instructions.
5. Only use attachments/accessories specified by the manufacturer.
6. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
7. Installation should be done only by qualified personnel and conform to all local codes.
8. Use only installation methods and materials capable of supporting four times the
maximum specified load.
9. Use stainless steel hardware to fasten the mount to outdoor surfaces.
10. To prevent damage from water leakage when installing a mount outdoors on a roof or
wall, apply sealant around the bolt holes between the mount and mounting surface.
11. Only use replacement parts recommended by Systems With Intelligence.
12. Avoid aiming the camera directly to bright objects (e.g. sun) as this may damage the CCD
image sensor of the camera.
13. Do not drop the object or apply strong blows to it.
14. Keep away from locations subject to excessive vibration.
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
5
Table of Contents
1. Product Description..................................................................................................... 6
2. Camera Housing Dimensions...................................................................................... 8
PTZ (Pan/Tilt) Housing.................................................................................................... 8
PT Mounting Arm Dimensions ........................................................................................ 9
Junction Box Dimensions.............................................................................................. 10
Fixed Housing for Single Thermal Camera ................................................................... 11
Mounting Arm Dimensions............................................................................................ 11
3. Installation ................................................................................................................. 12
Installation Components ............................................................................................... 12
Fixed Mounting .............................................................................................................. 13
Wall Mount Arm (optional)............................................................................................. 13
Parapet Mount (optional) .............................................................................................. 14
Cables management...................................................................................................... 14
Connecting the base to the mounting arm or parapet mount...................................... 15
Fixing the base to the support....................................................................................... 16
4. Junction Box Wiring Schematic................................................................................ 18
Wiring for a single camera TCAM2000 without the PT Mount..................................... 18
Wiring for TCAM2000 with the PT Mount ..................................................................... 19
5. Wiring Considerations ............................................................................................... 20
6. Maintenance – General Recommendations............................................................. 20
7. CONFIGURATION....................................................................................................... 21
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
6
1. Product Description
Figure 1-1 TCAM2000
TCAM2000
Thermal Camera Monitoring Systems
•Remote monitoring of critical
substation components
•Provide early warning of impending
equipment failures
•Obtain temperature readouts of
overheating
•Spot nonfunctioning equipment with
low temperatures
•Instantly trigger audible and visual
alarms
•Automated email notification
•Substation hardened equipment
SPECIFICATIONS
IMAGING PERFORMANCE
Field of View,
Focal length
TL01/TS01= 25° x 19°, 13mm, 336 x 256 pixels
TL02/TS02= 45°x 35°, 7.5mm, 336 x 256 pixels
TL03/TS03= 35° x 27°, 9mm, 336 x 256 pixels
TL04/TS04= 17° x 13°, 19mm, 336 x 256 pixels
TL05/TS05= 13° x 10°, 25mm, 336 x 256 pixels
VL01/VS01= 25° x 20°, 25mm, 640 x 512 pixels
VL02/VS02= 45° x 37°, 13mm, 640 x 512 pixels
VL03/VS03= 32° x 26°, 19mm, 640 x 512 pixels
VL04/VS04= 18° x 14°, 35mm, 640 x 512 pixels
VL05/VS05= 12°x9.9°, 50mm, 640 x 512 pixels
Resolution
336 x 256 pixels
Detector
Type
Uncooled Vox Microbolometer
Pixel Pitch
17µm
Scene Range
(High Gain)
Scene Range
(Low Gain)
-25°C to 135°C
-40°C to 550°C
Time to
<4.0 secs
Video
Compression
H.264
Network
Interface
Pan/Tilt Housing: 10/100TX, RJ45
Fixed Housing: 100FX, LC or 10/100TX
Security
Password Protected
ELECTRICAL
TCAM2000-
PT
32W max. P&T static, heating
switched off, With IRCAM
155W max. P&T in motion, heating
switched on, With IRCAM
TCAM2000
Fixed
7.5W
max. No housing and using
fiber
38W max. Heater and fiber
THERMAL
Spectral band
7.5 to 13.5 µm
Sensitivity
0.1°C
Frame rate
TL/VL0x = 30Hz, TS/VS0x = 7.5Hz
ENVIRONMENTAL WITH PAN/TILT
HOUSING
Operating
Temperature
Range
-40°C to 85°C
Encapsulation
IP66 (IED 60529)
Wind
Resistance
Operational: up to 160 km/h
Stationary: up to 210 km/h
Resistance to
Salty Fog
EN50130-5, EN60068-2-52
Certification
IEC61850-3, IEEE1613, EN60950-1,
EN6095-22, EN61000-6-4, EN55022
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
7
Protocols
IPv4/v6, DHCP, HTTP, UDP,
RTP/RTSP, UPnP, NTP, ICMP
Software
Interface
Web Server
Class A, EN50130-4
*The specification for this product may change without prior
notice for product improvement.
SPECIFICATIONS: HOUSING
ELECTRICAL
Built in aluminum and ABS
Epoxypolyester powder pointing, RAL9002 color
To mount (OTT)
Transmission through toothed belt
Slip-ring
Electronic limit switches
Plug installation thanks to connector and easy replacement on-site
Zero backlash
MECHANICAL
Cable glands: 3xM16
Horizontal rotation: continuous
Vertical rotation: from +45° up to -20°
Horizontal speed (variable): from 0.002°/s up to 20°/s through
toothed belt
Tilt speed (variable): from 0.02° up to 20°/s
COMMUNICATIONS
Ethernet connection: IEEE 802.3 100Base-TX
PROTOCOLS
Pelco-D
ENVIRONMENT
Indoor/Outdoor
Operating temperature (with heater): -40°C/85°C (-40°F/+185°F)
Surge immunity: up to 2kV line to line, up to 4kV line to earth (Class
4)
CERTIFICATIONS
Electrical safety: EN60950-1
Photobiological safety of lamps and lamp systems (LED
illuminators): EN62471
Electromagnetic compatibility: EN55022
(Class A)
, FCC Part 15
(Class
A)
Immunity: EN50130-4
Outdoor installation: EN60950-22
IP protection degree: EN60529 (IP66)
Resistant to salty fog: EN50130-5, EN60068-52
EAC certification
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
8
ELECTRICAL
24VAC, 50/60Hz, 155W
*The specification for this product may change without prior notice for product
improvement.
2. Camera Housing Dimensions
PTZ (Pan/Tilt) Housing
Figure 2-1 TCAM2000 Housing Overall Dimensions
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
10
Junction Box Dimensions
Figure 2-4 TCAM2000 Junction Box Dimensions without PT Mount
Figure 2-5 TCAM2000 Junction Box Dimensions with PT Mount
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
11
Fixed Housing for Single Thermal Camera
Figure 2-6 Fixed housing for single thermal camera
Mounting Arm Dimensions
Figure 2-7 Mounting Arm Dimensions
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
13
Fixed Mounting
Fasten the plate between the bottom of the housing and bracket using the screws
supplied.
Figure 3-2 TCAM2000 Fixed Installation
Wall Mount Arm (optional)
The bracket is drilled is drilled to make it easy the connection cables through it
Figure 3-3 Distance between mounting holes on Wall mount arm in millimeters
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
14
Parapet Mount (optional)
The column support allows the internal passage of the connection cables.
Figure 3-4 Distance between holes on Parapet mount in millimeters
Cables management
The connection cables should not be accessible from the outside. It is
necessary to fasten the cables securely to the pole in order to prevent
excessive weight pulling them out accidentally.
You must use cables suited to the type of installation
Insert the cables into the support so that they protrude by about 50cm.
Figure 3-5 Illustration of how cables passes through mounts
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
15
Connecting the base to the mounting arm or parapet mount
Do not make any changes or install connections that are not included in
this handbook. Failure to follow the connection instruction that are given
in the handbook may create serious safety hazards for people and for the
installation.
Do not change the wiring in the product as it is supplied to you. Failure to
follow this instruction may create serious safety hazards for people and
for the installation and will also invalidate warranty.
Keep a connection diagram for future reference.
If using the washer kit, the spray support should be installed before
positioning the pan & tilt and the wiring
Figure 3-6 Assembling camera housing and mounts
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
16
Fixing the base to the support
Use the screws and the washers supplied with the base.
Figure 3-7 Connecting the housing base to the Wall Mount arm
Figure 3-8 Connecting Parapet Mount to the camera housing
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
17
Align the 3 notches on the base with those on the support as shown in the following
figure.
Figure 3-9 Lining up notches on housing base to Wall Mount arm
Apply a thread-locker on the holes of the screws (Loctite 243).
Pay attention to the fixing. Tightening torque: 4Nm.
TCAM2000 Installation Guide v1.4
–
2020.03.05
© Copyright 2020 Systems With Intelligence. All rights reserved.
www.SystemsWithIntelligence.com
support SystemsWithIntelligence.com
20
5. Wiring Considerations
Power Cables
The TCAM2000 PT series only accepts 24VAC. In most cases Systems with
Intelligence will supply a junction box which converts the voltage level from
120VAC/240VAC to 24VAC. The gauge of the power cables should be chosen carefully
as long cable lengths could induce significant voltage drops due to the wire
resistance. Table 5-1 shows the resistance of some popular wire gauges for the CCTV
power cable.
Table 5-1 Wire Gauge vs. Resistance
AWG
Resistance per Km
18
20.95 Ohms
16
13.17 Ohms
14
8.29 Ohms
12
5.21 Ohms
When a junction box, as shown in section 4, is used other voltages may be supplied to
the junction box and they are then converted to 24VAC. The voltage levels supported
by the junction box will vary based on model.
6. Maintenance – General Recommendations
The TCAM2000 does not require a special maintenance, however regularly scheduled
maintenance prolongs the operational life and appearance of the camera. Part of this
maintenance should also include verifying that all mounting hardware is secure. When
needed clean the viewing window with a mild, nonabrasive detergent in water and a
soft cloth
This manual suits for next models
2
Table of contents
