Syvio SA3300296 User manual

Cool Mist Humidifier
SA3300296 # INSTRUCTION MANUAL
Please read this manual carefully before use and keep it properly for future reference.

NAMES OF PARTS
Top cover
Mist outlet
Timer Button
Humidity Button
Mist Button
Power Button
Water tank
Atmosphere
light
Air outlet
Max Water
Level Line
Overflow hole
Ceramic Disc
Power Cord
Air inlet

FUNCTION CHARACTERISTICS
■ Power Button:
On the stand-by state:
1st Press: Turn on the medium mist with two mist icon indicators light
on, blue LED light on.
2nd Press: Turn off the humidifier.
Note: When waterless, the display will shows “E2” error code and the
waterless icon light will flash with buzzer warning 3 times (around
7S), and then will power off; If you press again, it will repeat the flash
and the warning again.
■ Mist Button:
On medium mist state:
1st Press: Turn on the high mist with three mist icon indicators light
on.
2nd Press: Turn on the low mist with one mist icon indicators light on.
3rd Press: Turn on the medium mist with two mist icon indicators light
on.
Cycle control.
■ Sleeping mode:
Long press the mist button for 3 seconds to enter the sleeping mode
with sleeping mode icon light on, the lighting of the water tank and
other icon of the display will turn off, mist volume will turns to low mist
mode; When waterless, unit will auto turn off without buzzer beeps.
Short press any button to exit the sleeping mode, will keep the mist
volume and light mode that setting before.

■ Power Button:
On the stand-by state:
1st Press: Turn on the medium mist with two mist icon indicators light
on, blue LED light on.
2nd Press: Turn off the humidifier.
Note: When waterless, the display will shows “E2” error code and the
waterless icon light will flash with buzzer warning 3 times (around
7S), and then will power off; If you press again, it will repeat the flash
and the warning again.
■ Mist Button:
On medium mist state:
1st Press: Turn on the high mist with three mist icon indicators light
on.
2nd Press: Turn on the low mist with one mist icon indicators light on.
3rd Press: Turn on the medium mist with two mist icon indicators light
on.
Cycle control.
■ Sleeping mode:
Long press the mist button for 3 seconds to enter the sleeping mode
with sleeping mode icon light on, the lighting of the water tank and
other icon of the display will turn off, mist volume will turns to low mist
mode; When waterless, unit will auto turn off without buzzer beeps.
Short press any button to exit the sleeping mode, will keep the mist
volume and light mode that setting before.
■ Timer Button:
On working state:
1st Press: Display will shows the current setting timer, if no timer
setting will shows “--”H.
2nd Press: Reset the timer, display shows “02” with timer icon “H”
light on, and the unit will power off after 2H
3rd Press: Display shows “04” with timer icon “H” light on, and the
unit will power off after 4H.
4th Press: Display shows “08” with timer icon “H” light on, and the
unit will power off after 8H.
5th Press: Display shows “--” with timer icon “H” light on, and no
timer setting.
Cycle control.
■ Humidity Button:
On working state:
1st Press: Display will shows the current setting humidity, if no
humidity setting will shows “--”%.
2nd Press: Setting the 40% humidity, display shows “40” with
humidity icon “%” light on.
3rd Press: Setting the 50% humidity, display shows “50” with
humidity icon “%” light on.
4th Press: Setting the 60% humidity, display shows “60” with
humidity icon “%” light on.
5th Press: Setting the 70% humidity, display shows “70” with
humidity icon “%” light on.

6th Press: Setting the 80% humidity, display shows “80” with
humidity icon “%” light on.
7th Press: No humidity setting, display shows “--” with humidity icon
“%” light on.
Cycle control.
Note:
1. After finishing the humidity setting, the display will show the
real-time humidity after finishing the setting.
2. When the real-time humidity lower than the setting humidity,
humidifier will work with the current setting mist mode; When the
real-timer humidity higher than the setting humidity, humidifier will
stop misting.

Power
Voltage
Mist Volume
Working Time
Capacity
25W
110V~
200±40 ml/h
24H(low mist),12H(high mist)
2.8L
Timer 2H/4H/8H
Size 195×182×263mm
■ Waterless protection function: When lacking water, the display
will shows “E2” and the waterless icon light will flash with buzzer
warning 3 times (around 7S), and then will power off; If you press
again, it will repeat the flash and the warning again.
■ Touch button sound: Each press will comes with one buzzer
beep.
■ Stand-by stage: The buzzer beeps when power on.
■ Humidity display: Humidity display: Displays the humidity and
the humidity icon. (When the humidity ≥85%RH, the display shows
H%RH; When the humidity ≤30%RH, the display shows L%RH), if
any poor contact of the humidity detector, the display will shows“E3”
error code.
■ Intelligent constant humidity mode: Automatically adjust the
mist spray state according to the humidity setting value.
■ Sleeping Mode: Turn off the lighting of the water tank, all the icon
of the display will turn off, mist volume will turns to low mist mode;
When waterless, unit will auto turn off without buzzer beeps.

INSTRUCTIONS FOR USE
Place unit on a flat, water-resistant surface as moisture may cause
damage to carpet, finished floors, furniture, or walls.
1. Remove the Top Cover from the Water Tank.
2. Fill the Water Tank with tap water up to the Max Water Level
Line. Do not overfill. Add approximately 10 drops of essential oil
per 1 liter of water into the Water Tank.
3. Replace Top Cover onto the Water Tank.
4. Plug the Power Cord into an electrical wall outlet. It will take a
few minutes for the essential oil to blend with the water before
fragrance begins diffusing.

Place unit on a flat, water-resistant surface as moisture may cause
damage to carpet, finished floors, furniture, or walls.
1. Remove the Top Cover from the Water Tank.
2. Fill the Water Tank with tap water up to the Max Water Level
Line. Do not overfill. Add approximately 10 drops of essential oil
per 1 liter of water into the Water Tank.
3. Replace Top Cover onto the Water Tank.
4. Plug the Power Cord into an electrical wall outlet. It will take a
few minutes for the essential oil to blend with the water before
fragrance begins diffusing.
2.
4.
1. 3.
5.
Timer Button
Humidity Button
Mist Button
Power Button

CARE & MAINTENANCE
Do not add hot water, only suitable for cold water
Please use the original power cord
Always unplug the power cord from electrical outlet before filling.
Essential oil should not come in contact with the exterior surface
of unit.
Do not submerge unit into water to avoid risk of exterior surface
of unit.
Do not submerge unit into water to avoid risk of electric shock.
Do not put fingers, hands, or any object into the unit while
operating.
Do not attempt to adjust or repair the unit.
Do not touch the water while unit is operating.
Do not fill water through the Mist Outlet or the Air Outlet.
Do not place the unit near heat sources or direct sunlight.
Use two hands when moving your humidifier
Please follow the instruction manual to operate the unit.
Easy to Clean:
Pour the water out of the tank,be careful do not pour water out
from the air outlet side.
The ceramic disc should not come in contact with any hard or
sharp objects. To remove possible buildup, rinse with a white
vinegar and water solution.
Dry thoroughly with a soft cloth. Do not use strong cleaning
agents.
Note: Recommend to clean the humidifier once a week

TROUBLE SHOOTING
Problem
Will not turn on or
turn off?
Will not put out
mist?
Possible Factors Solution
Not enough water in the
tank
Please add enough water to the tank,
not exceeding the 2.8L MAX water line.
The power cord connects
not properly
Please disconnect the cord, check the cables
and reconnect carefully.
Not enough water or too
much in the tank
Please add enough water to the tank, not
exceeding the 2.8L MAX water line.
The "Mist Outlet" has dirt
Just clean the "mist outlet" put it in a cool
place and wait for it to dry naturally, then it
can be used normally.
The "Air Intake" port
under the base has dirt Clean the "air intake" with a dry brush
Get Help Fast
"Thanks for purchasing the SYVIO product!
If there is any problem, please contact us for a replacement or refund.
Also, register your order id for an EXTRA 12-months warranty!
Support Email: [e-mail]"
