T.MIX pm184x User manual

PM SERIAL
PROFESSIONAL
MIXERS

11
PM184X
Mic input
Frequency response
Distortion(THD&N)
Gain renge
Max input
Line input
Frequency response
Distortion(THD&N)
Channel fader range
Max input
EQ
Low
Mid
High
Lo cut filter
Stereo input channels
Line input
Frequency respones
Distortion(THD&N)
Channel fader range
Max input
EQ
Low
Lo mid
Hi mid
High
Main mix
Max output
Aux send max, output
Control room output
Noise
Graphik equalizer
Frequencies
Max boost/out
Power conaumption 1200W
Output power
Power supply AC 220V-240V, 100V-120V(option)/50-60Hz
Mono input channels
Electronically balanced,discrete
input configuration
10Hz to 60KHz 3dB
0.007% at +4Bu, 1KHz,
bandwidth 80KHz
+10dB to +60dB
+12dBu
Electronically balanced
10HZ to 60KHz 3dBv
0.007% at +4Bu, 1KHz,
bandwidth 80KHz
+10dBu to -60dBu
+22dBu
80dB to 15dB
100Hz to 8KHz 15dB
12KHz 15dB
-3dB at 75Hz 18dB/Okt
Electronically balanced
10Hz to 60KHz 3dB
0.007% at +4dBu, 1KHz,
bandwidth 80KHz
+10dBu to -60dBu
+22dBu
80Hz 15dB
500Hz 15dB
3KHz 15dB
12KHz 15dB
Main mix
+28dBu balanced on XLR,
+22dBu unbalanced on JACK
+22dBu unbalanced
+22dBu unbalanced
-112dB
(all channels open,at unity gain)
60Hz,160Hz,410Hz,1.1KHz,
2.3KHz,6.2KHz,15.6KHz
10dB
2x400W/ 4
TECHNICAL SPECIFICATION
10

3
PM SERIES PROFESSIONAL MIXING CONSOLE
(24) ALT3-4 OUTPUT PFL
(25) PFL/SOLO
When you push the SOLO/PFL button, the SOLO/PFL control led will light up.
(26) OUTPUT LEVEL DISPLAYAND WORKING INDICATOR
You can choose the master channel and monitor the output level from the chosen bus channel.
(27) HEAD PHONE JACK
You can monitor the working condition by phone. You can also monitor the master sound and a certain channel.
(28) +48V PHANTOM POWER
(29) POWER INDICATOR
(30)(31) UP AND DOW BUTTONS
You can choose the desired preset
(32) ENTER BUTTON
It activates the secleted preset.
8
PM SERIES PROFESSIONAL MIXING CONSOLE

56
(5)HIGH FREQUENCY EQUALIZATION CONTROL
Provides 15dB of fixed frequency equalization that shelves at 12KHz.
(6) MIDRANGE GAIN CONTROL
It has up to 15dB of cut and boost, with a centre detent for off.
(7) MIDRANGE CONTROL
It is semi-parametric with peaking response, Q fixed at 1 octave, sweepable from 100 Hz to 8 KHz.
(8).LO FREQUENCY EQUALIZATION CONTROL
Provides 15dB of fixed frequency equalizationthat shelves 80Hz.
9) AUX CHANNEL
It provide pfl reverb or be connected with other related equipments.
(10) AUX SIGNAL SWITCH
Adjusting the switch, you can know where the signals are from?
(11) DIGITAL EFFECTS PROCESSOR
It is integrated effects processor which offers 32 different standard effects like reverb, chorus, delay, pitch shifter and various
combination effects.
(12).PAN CONTROL
The pan control sends continuously variable amounts of the post fader signal to either the
Left & Right main busses. In the center position,equal amounts of signal are sent to the and right
busses. As the control is roated in either direction,more signal is sent to the buss indicated in the
direcction of the rotation while less signal issent to the other buss, if the control is turned all the way to one side, the signal is only.
(13) PRE-FADER LEVEL(PFL)
Pressing channel mode switch once disengages the stereo solo bus, and replaces it with a separate mono pfl bus. Pfl should always be
used for gain setting.
(14) BUS ON/OFF
This switch, when push, put the signal into bus and output from alt3-4
(15).CHANNEL FADER
You can adjust the volume of signalsources which connected to the relevant channel.
(16), (17),STEREO RECORDER &PHONO JACK
(16), these jacks can be connected with cassette cleek. When playing back recorded.
(16), these jack are can be connected with cassette cleek. When recording the MIXED output.
(18), (19), (22), (23) LINE IN
(18) line in for channel 7/8 (19) line in for channel 9/10.
(22) line in for channel 11/12 (23) line in for channel 13/14.
(20) CTRL ROOM CUT
(21) MAIN OUT
The output signal can be connected with the external main speaker and amplifier.
(24) HI MID
Adjusting the knob, you can have up to 15dB cut and boost at 3KHz mid and hi frequency.
(25) LO MID
Adjusting the knob, it have up to 15dB cut and boost at 500Hz mid and low frequency.
PM SERIES PROFESSIONAL MIXING CONSOLE PM SERIES PROFESSIONAL MIXING CONSOLE

B:MASTER SECTION
(1) FX PROCESSOR DIRECT IN
The external signals can be connected with the DSP input
(2) AUX SEND
Aux signal output jack
(3) FX SEND
FX signal output jack
(4) AUX RETURN
FX output signal return jack
(5) FX RETURN
FX output signal return jack
(6) DIGITAL EFFECTS PROCESSOR
24-bit stereo 32-effect processor with ultra-high resolution 46KHz, 20-bit AD/DAconverters, for internal and external use.
(7) SEVEN-BAND GRAPHIC EQ
It can adjust input sensity from-10dB to +10dB at the following frequencies: 60Hz, 160Hz, 410Hz, 1.1KHz, 2.3KHz, 6.2KHz and 15.6KHz.
(8) EQ IN
When pushing the switch, it can release the output signal from EQ. The switch is off, then the signal is not from EQ.
(9) AUX SENDS GAIN CONTROL
You can have a further +15dB available from these outputs
(10) FX SENDS GAIN CONTROL
You can have a further +15dB available from them
(11) AUX PFL
(12) FX PFL
(13) AUX OUTPUT CONTROL
Adjusting the fader, you can get different output level fromAUX
(14) FX OUTPUT CONTROL,
You can adjust the output level of aux.
(15) ALT3-4 OUTPUT LEVELCONTROL
You can control theALT3-4 signals separately.
(16)(17) L. R MASTER OUTPUT CONTROL
You can control the L. R signal by adjusting the two fades.
(18) 2-TRACK INPUT
It is primarily for auditioning mix playback from tape.
(19) ALT3-4 OUTPUT PFL
(20) ALT3-4 BUS
(21) HEADPHONE VOLUME CONTROL
Using the control, you can control the output level of headphone and monitor the signals reverb from speaker.
(22) 2-TRACK OUTPUT
(23) MAIN MIX
7
PM SERIES PROFESSIONAL MIXING CONSOLE
4
All channels of powered mixers & mixing consoles are the same. Therefore ,this manualhows the control functions of only one
channel.
(1)MICROPHONE
Electronically Microphone inputs accept a standard XLR male connector.
1.GROUND=shield, 2.HOT=signal input, 3.COLD=ground(shield).
You can use max 10-60dB according to signallevel by GAIN control.
(2)LINE INPUT
USING BY 1/4"standard line connector,You can use unbalance(tip/signal) and balance(tip/ring/signal). It can be connected with
keyboards orother electric instruments.
Tip=positive ring=negative sleeve=ground.
(3)LOW CUT
This switch, when push, cut the input signal below 75Hz.
(4)GAIN CONTROL
Adjust input sensitivity from 10dB to 60dB with the 60dB pad switch in the out position and -40dB to +10dB when the 60dB pad
switch is pushed.
A.CHANNEL SECTON
CHARACTORS
6 mono input channels with gold plated XLRs, balanced line inputs and inserts.
ultra-low noise discrete mic preamps with +48V phantom power.
4 stereo input channels with balanced jacks.
2 additional multi-functional stereo channels with 60mm faders.
switchable 7-band graphic equalizer for ultimate main mix equalization.
ALT 3-4 bus routable to main mix and control room with insert, PFLand 60mm masterfader.
extremely high headroom-offering more dynamic range.
balanced inputs and main outputs for highest signal integrity.
ultra-musical 4-band EQ (stereo channels) and 3-band EQ with sweepable mid band (mono channels).
peak LEDS and switchable low-cut filter on all mono channels.
2 AUX sends (AUX 1 pre/post)per channel, for internal or external effects and monitoring.
master AUX sends with gain control and PFL.
mute/ALT 3-4, solo-in-place and pre-fader-listen function on all channels.
separate main mix, ALT 3-4, control room and headphone outputs.
2-track inputs assignable to main mix or control room/headphone outputs.
highly accurate 12-segment bargraph meters.
high quality 60mm panasonic faders and sealed potentiometers.
PM SERIES PROFESSIONAL MIXING CONSOLE

C:REAL PANEL
(1) CHANNEL INSERTS
Pre-fader/pre-EQ tip=send/Ring=return
ALT3-4 INSERTS
(3) ALT 3-4 OUTPUTS
(4) MAIN INSERTS
(5) MAIN OUTPUTS(UNBALANCED)
(6) MAIN OUTPUTS(BALANCED)
(7)BALANCED MAIN OUTPUT LEVEL SWITCHES
Via the switches, you can choose between the two different operating level settings-10dBV and +4dBU.
(8) PHANTOM POWER
When you push the switch, all mics outputs have +48V phantom power present.
(9) POWER ON FOR MIXING SECTIONS
(10) AMPLIFIER LEVEL IT CAN ADJUST THE SIGNALS LEVEL WHICHARE SENT TO THE AMPLIFIER
(11) BALANCED INPUT FOR SIGNALS FROM AMPLIFIER
Users can get the different signals from the source according to their requirements.
LEFT binding output
red+ black-
RIGHT binding output
red+ black-
LEFT Speakon output
1+ 2+ , 1- 2-
RIGHT Speakon output
1+ 2+ , 1- 2-
POWER AND VOLTAGE SELECTIVE SWITCH
115V or 230V optinal.
POWER SUPPLY/FUSE SOCKET
Must ensure the correct specifications before replace the fuse
(18) POWER SWITCH
When it is turned on, the amplifier begins to work.
(2)
(12)
(13)
(14)
(15)
(16)
(17)
9
PM SERIES PROFESSIONAL MIXING CONSOLE
The exclamation point
triangle is used to alert the
user to important operating or
maintenance instructions.
TO TREVENT ELECTRIC SHOCK
DO NOT REMOVE COVER OR
BACK.NO USER SERVICEABLE
PARTS INSIDE REFER SERVICING
TO QUALFIED SERVICE PERSON-NEL
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION!DO not locate sensitive high-gain equipment such as
preamplifiers or tape decks drecity above or below the
unit,Because this amplifier has a high power density,it has strong
magnetic field which can induce hum into unshielded devices that
are locatednearby.Thefieldisstrongestjustabove andbelowthe
unit.
If an equipment rack is used ,we recommend locating the
amplifiers in the bottom of the rack and the preamplifier or other
sensitive equipment at the top.
Magnetic Field
TO REDUCE THE RISK OF ELECTRIC
SHOCK,DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE
The lightning bolt
triangle is used to
alert the user to the
risk of electric shock.
WATCH FOR THESE SYMBOLS:
WARNING
PM SERIES MIXERS ARE SOUND IN FUNCTION, ADVANCED IN WORKMANSHIP AND SMALL IN SIZE.ADOPTING
THE ADVANCED SMT TECHNOLOGY MAKES THE SIZE OF THE MIXERS MUCH SMALLERAND IMPROVES THE
RELIABILITY AND S/N RATIO OF THE MIXERS.
IT IS VERY EASY TO MOVE BECAUSETHEY ARE UNIQUE HANDLES. THEY CANALSO BE PUT INTO THE 19' RACK
BY TAKING OFFTHE HANDLES. THEY ARETHE BEST DEVICES FOR YOUR MOBILE PERFORMANCE.
USING HIGH QUALITY COMPONENTS FROM FAMOUS COMPANIES TO GUARANTEE THE QUALITY OF SIGNAL.
LOW NOISE AND HIGH GAIN 4580 OPAND 32-EFFECT DSP. POWER MIXERS WITH 2X400W AMPLIFIER
