TAD TAD-D700 User manual

TAD-D700
DISC PLAYER
LECTEUR DE DISQUE
DISC-PL AYER
LE T TORE CD / SACD
REPRODUCT OR DE DISCOS
光碟播放機
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
MANUALE D’ISTRUZIONI
MANUAL DE INSTRUCCIONES
用戶手冊

2
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on
. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your dealer for a replacement.
S002*_A1_En
WARNING
This equipment is not waterproof
. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which requires
repair will be charged for even during the warranty
period.
K041_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 10 cm at top, 10 cm at rear
, and 10 cm at each
side)
.
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating.
To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
CAUTION
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER
-SERVICEABLE
PA
RTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL. D3-4-2-1-1_B1_En
WARNING
To
prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
Operating Environment
Operating environment temperature and humidity
:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
CAUTION
The switch on this unit will not completely shut off
all power from the AC outlet. Since the power plug
serves as the main disconnect device for the unit,
you will need to unplug it from the AC outlet to shut
down all power. Therefore, make sure the unit has
been installed so that the power plug can be easily
disconnect from the AC outlet in case of an accident.
To avoid fire hazard, the power plug should also be
disconnect from the AC outlet when left unused for a
long period of time (for example, when on vacation).
D3-4-2-2-2a*_A1_En
CAUTION
This product is a class 1 laser product classified
under the Safety of laser products, IEC 60825-1:2007.
CLASS 1 LASER PRODUCT
D58-5-2-2a_A1_En

3
English
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
U.S. model only
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT
D3-4-2-1-1b_A1_En

4
U.S. model only
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD.
D58-5-1-2a_A1_En
TAD-D700
Information to User
Alterations or modifications carried out without
appropriate authorization may invalidate the user’s
right to operate the equipment.
D8-10-2_A1_En
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
European model only
U.S., Canada model only

5
English
European model only
U.S., Canada model only

6
PRECAUTIONS IN USE
Installation Location
For installation, select a stable location near the stereo
system with which the unit will be used.
To ensure long product life, avoid installing this
unit in the following locations:
• Locations exposed to direct sunlight
• Humid or poorly ventilated areas
• Areas of extreme temperatures
• Areas with vibration
• Dusty or smoky areas
• Areas exposed to grease fumes, steam or heat
(such as a kitchen)
Do not place objects on top of the unit
Do not place objects on top of the unit.
To prevent adverse affects of heat
Do not install the unit on top of amplifiers or other
components that generate heat. When installing in a
rack, try by all means to install the unit in a position below
amplifiers or other components that generate heat.
Turn off power when not in use
Depending on the signal condition of television broadcasts,
if the television is turned on when the unit is already on, a
noise may appear on the television screen. Audible noise
may likewise occur when listening to the radio when unit
is already turned on. This phenomenon does not indicate a
malfunction of either the television, radio tuner, or the unit.
In this event, turn off the power to the unit.
Moving the unit
If you must move the unit, first remove any disc loaded and
close the disc tray. Press the main unit’s  power button
(or the remote control unit’s DISC PLAYER button) so that
the [OFF] indicator in the display goes out, then unplug the
power cord. Never move the unit with a disc loaded, since
damage may result.
Caution for when the unit is installed in a rack
with a glass door
Do not press the hOPEN/CLOSE button on the remote
control to open the disc tray while the glass door is closed.
The door will hamper the movement of the disc tray, and the
unit could be damaged.
Maintenance
To clean the unit, use a polishing cloth to gently wipe the
unit’s surface to remove dust. If the surface is extremely
dirty, wipe with a soft cloth dipped in neutral cleanser diluted
five to six times with water and wrung out well. Do not use
volatile chemicals such as paint thinner or benzenes, as
these may corrode the surface of the panels. Do not use
sprays such as insecticides around the unit. If you plan on
using a chemical cleaning cloth, read the precautionary
statements of the chemical cleaning cloth before using.
Regarding condensation
During the winter or cool seasons, condensation may form
inside the player if it is brought into a warm room from
outside or other cold location, or if the temperature of the
room where the player is installed is raised too quickly.
When condensation forms inside the player, it may not
operate properly or at all. In this event, turn on the unit’s
power and allow it to stand for 1 to 2 hours so that the
condensation evaporates as the player acclimatizes to the
room’s temperature, and the unit will become playable
again. Condensation may also form in the summer if a
room’s air conditioner is directed directly at the unit. In
this event, change the location of the player away from the
airstream of the air conditioner.

7
English
TAD-D700
CONTENTS
PRECAUTIONS IN USE .........................................................................................................................................6
Installation Location.........................................................................................................................................................................6
Maintenance .....................................................................................................................................................................................6
Regarding condensation..................................................................................................................................................................6
INTRODUCTION ...................................................................................................................................................8
Inspiring the joy of listening ............................................................................................................................................8
Features.............................................................................................................................................................................8
BEFORE YOU START............................................................................................................................................9
Checking what’s in the box..............................................................................................................................................9
Inserting the battery .........................................................................................................................................................9
USABLE DISCS....................................................................................................................................................10
Types of discs that can be played on this unit.............................................................................................................10
NAMES OF PARTS AND THEIR FUNCTIONS .....................................................................................................11
Main unit front panel......................................................................................................................................................11
Power unit rear panel / Main unit rear panel...............................................................................................................12
Remote control unit .......................................................................................................................................................13
INSTALLATION AND CONNECTIONS ................................................................................................................14
Installation.......................................................................................................................................................................14
Connecting up ................................................................................................................................................................15
PLAYING.............................................................................................................................................................16
To play a disc...................................................................................................................................................................16
Taking care of your player and discs ............................................................................................................................16
SPECIAL SETTINGS.............................................................................................................................................17
Using the ECO (energy-saving) mode...........................................................................................................................17
Suppress SACD output level for listening....................................................................................................................17
High Sampling Mode Output ........................................................................................................................................17
Using the unit as a D/A converter.................................................................................................................................17
ALL RESET.......................................................................................................................................................................17
TROUBLESHOOTING..........................................................................................................................................18
SPECIFICATIONS ................................................................................................................................................20
Thank you for buying this TAD product. Please read through these operating instructions so you will know how to operate your
model properly. After you have finished reading the instructions, put them away in a safe place for future reference.

8
INTRODUCTION
Inspiring the joy of listening
Technical Audio Devices Laboratories, Inc. (TADL) grew from the spirit to discover technologies to perfectly recreate the pure
sound of live performances with uncompromising craftsmanship. We have inherited our philosophy from Bart Locanthi—
recognized across the globe as the ultimate sound technologist—who believed that genuine technology is true to the basics
and that genuine technology places greater importance on sound quality than on technology for its own sake.
At TADL, we are honing our technology to create equipment that reproduces musical sounds that evoke both the energy and
impact of live music.
Features
Containing the “ultra-high speed C/N * master clock circuit” and the “third-generation UPCG**”
There has been a lot of effort put into reducing the total amount of jitters in order to achieve high sound quality. But here at
the TAD lab, we have focused on suppressing jitters in the low-frequency sideband ranges relative to the center frequencies.
We tried to further improve the sound quality and C/N by adopting the "SC-cut crystal piece" and subsequently succeeded in
letting the "UPCG" evolve to the third generation.
Based on technologies developed for high-speed digital base-station relay facilities, the master clock with its dedicated
oscillators and high-purity conductivity deliver the ultimate performance demanded by a CD player, allowing it to reproduce to
perfection the signals engraved on the disc.
*C/N: Carrier-to-Noise ratio
**UPCG: Ultra-high-Precision Crystal Generator
Purification of the power circuit
We tried to minimize power circuit’s contact with the outgoing lines by using the pigtail type inner winding for the power
transformer for the sake of high-level purification. We also suppressed the magnetostriction thoroughly by soldering with non-
magnetic materials and using OFC pure copper for the terminals for the pigtail-style lines, terminals for mounting substrates
and fastening screws.
Twin Differential D/A Converters
The D/A converters of Burr-Brown (192 kHz/24 bit) are used in parallel to improve audio performance, including S/N ratio,
linearity, dynamic range and distortion rate. These features allow even delicate audio signals to be played back faithfully,
creating a greater degree of breadth in musical reproduction.
Independent Power Supply
The unit features a power unit housed independently from the CD player itself. We separated the power unit from the main
unit, which could eliminate the harmful effects of extraneous vibration and magnetic flux leakage from the power unit on the
CD transport mechanism and audio circuits. Further, the audio and digital sections feature independent toroidal transformers
with super-powerful 400 VA performance (on a par with the performance found in a power amp), producing the high response
necessary to follow virtually any signal, and achieving both high power and low noise.
Original CD mechanism with high-precision loading facility and excellent quietness
In order to pursue high-precision and accurate replay, we are developing original ideas at TAD. Our newly designed “High-rigidity
CD/SACD mechanism” enables operations with excellent vibration-damping properties due to the high-precision loading
mechanism using metal bearings. The pickup part employing infinite optical path shows highly stable performance and high
reading precision.
High-Rigidity Construction with Low Center of Gravity
In order to suppress the deleterious influence of external vibrations, a highly rigid cast-aluminum chassis with three-point
suspension has been introduced. Placement of the massive heavy base has been designed to lower the center of gravity, thus
further reducing vibrations. These design elements have made it possible to reproduce music signals with great stability while
avoiding the vibration caused by speaker pressure and other sources.
DAC Mode
With its high-precision D/A converters and high-purity master clock oscillators, the unit demonstrates equally high
performance as a D/A converter unit. A sampling rate converter and ultra-high C/N master clock for reclocking make possible
high-precision conversion.

9
English
TAD-D700
BEFORE YOU START
Checking what’s in the box
Please check whether or not the following items are contained in the package.
'Remote control unit x 1
REPEAT
VOLUME
AMP
DISC PLAYER OPEN/CLOSE
TIME DISPLAY OFF
DAC MODE
SACD/CD
CLEAR ENTER
123
456
78
0
9
MUTE
'DC cords
(CDF1340 150 cm/59.06 in.) x 2
'Polishing cloth x 1
'Felts x 2
'Operating Instructions
(this document)
'Power cord (U.S., Canada model)
'Power cord (Europe, Asia model)
2 pins plug type (For use in Europe
except in the UK)
3 pins plug type (For use in the UK,
Singapore, Malaysia, Hong Kong)
Inserting the battery
1 2 3
Replace the batteries when you notice a reduction in the operating range of the remote control unit.
WARNING
'Do not use or store batteries in direct sunlight or other excessively hot place, such as inside a car or near a heater. This can
cause batteries to leak, overheat, explode or catch fire. It can also reduce the life or performance of batteries.
'Do not place batteries in locations accessible to infants or small children. If accidentally swallowed, consult medical
attention immediately.
CAUTION
Incorrect use of batteries may result in such hazards as leakage and bursting. Observe the following precautions:
'Never use new and old batteries together.
'Whenloadingbatteriesintothebatterycase,donotbendthebatterycase’sminus(−)terminalwiththeendofthebattery,
since it could cause a short circuit, leakage of battery fluid, and/or unnatural heating.
'Insert the plus and minus sides of the batteries properly according to the marks in the battery case.
'Use type AAA (SUM-4) Manganese (R03) or Alkaline (LR03) dry cell batteries.
'When not using the remote control for a long period of time (1 month or more), remove the batteries from the remote
control, to prevent damage from inadvertent leakage. If battery leakage occurs, wipe up any battery exudate from inside the
case and replace with new fresh batteries.
'When disposing of used batteries, please comply with governmental regulations or environmental public institution’s rules
that apply in your country or area.
Use type AAA (SUM-4) Manganese (R03) or Alkaline (LR03) dry cell batteries.

10
Types of discs that can be played on this unit
Playable discs will feature one of the following marks either on the disc label, package, or jacket.
SACD CD CD-R CD-RW
“Super Audio CD” is a registered trademark.
About SACD play
SACD can be played in 2 channel sound only.
Copy control CDs
This player is designed to comply with music CD standards. No warranty is made for proper operation or performance when
playing discs not in compliance with music CD standards.
About DualDisc playback
A DualDisc is a new two-sided disc, one side of which contains DVD content video, audio, etc. while the other side contains
non-DVD content such as digital audio material. The non-DVD, audio side of the disc is not compliant with the CD Audio
specification and therefore may not play. For more detailed information on the DualDisc specification, please refer to the disc
manufacturer or disc retailer.
Playing CD-R/CD-RW discs
The unit can play CD-R/CD-RW discs formatted in music CD format and containing musical data. Depending on the disc,
however, some may not be playable, or may exhibit noise or distortion.
The unit is a dedicated disc player, and cannot record on CD-R/CD-RW discs.
CD-R/CD-RW discs that have not been finalized cannot be played on this player.
* For details, consult the operating instructions for your disc recorder.
CAUTION
'Some CD-R/CD-RW discs recorded on a disc recorder or personal computer may not be playable on this player. Reasons
may include disc characteristics, scratches, dirt, dirt on the player’s lens, condensation, etc.
'Discs recorded on a personal computer may not be playable due to vagaries in the recording settings or system
environment. Be sure to record discs with the correct format (for details, consult the vendor of your disc recording
application).
'Discs recorded with packet-write format cannot be played on this player.
Discs that cannot be played on the unit:
BD, BD-ROM, DVD, CD-G, video CD, 8 cm CD
USABLE DISCS

11
English
TAD-D700
Main unit front panel
1 3 4 75 6
2
NAMES OF PARTS AND THEIR FUNCTIONS
1 Power indicator
It lights orange when the power is on.
2 Power indicator
Lights to indicate the unit’s (POWER) status.
Light orange: ON (unit can be operated).
Light red: Standby (waiting status).
3 Display
The display provides graphic information about the unit’s many operations and functions.
4 Disc tray
5 Operation key
Touch the center of each character or icon to operate.
– Return to beginning of currently playing track.
– Skip to beginning of next track.
– Set power to ON/standby.
DAC
– Switch to digital/analog converter input.
– Play. When pressed during playback, enters pause mode.
g– Stops playback.
SACD
– Switches play area of hybrid disc.
h
OPEN/CLOSE
– Open/Close disc tray.
* The OPEN/CLOSE button of the unit is effective only when the SACD/CD function is active.
6 SACD indicator
This indicator lights when an SACD disc has been inserted, or when the SACD layer of an SACD/CD hybrid disc has been
selected.
7 Remote control sensor
Point remote control unit at this sensor to operate. Effective distance is within about 7 meters.
Note
When a disc is stopped, repeat mode is canceled.
CAUTION
You must unplug the power cord (disconnect device) to stop the power supply completely. Please locate the unit near
the electrical outlet so that you can easily access the power plug (disconnect device).
Power unit Main unit

12
Power unit rear panel / Main unit rear panel
DC2
POWER
ON
OFF
AC IN
DC1XLR
D1
DC2DC1
RUNBALANCED
BALANCED
L
R L
XLR
DIGITAL INPUT
DC INPUT
COAXIAL
D2
DIGITAL OUTPUT
ANALOG OUTPUT
COAXIAL
12
3
DC OUTPUT
2 4 63 7
5
1
1 Main power switch (POWER ON/OFF)
Use to switch main power ON/OFF. Press upper side to turn power ON, then press the button on the remote control or
main unit to set the unit to standby/ON mode. Press the lower side of this switch to turn the main power OFF.
2 AC IN connector
Connect the supplied power cord here.
3 DC OUTPUT connectors (DC1/DC2)
Connect the supplied DC cord to the main unit.
4 DIGITAL INPUT connectors
Connect to a component equipped with a digital output connector.
•XLR (balanced) type (D1)
•COAXIAL type (D2)
5 DIGITAL OUTPUT connector
Connect to a component equipped with a digital input connector.
•XLR (balanced) type
•COAXIAL type
6 DC INPUT connectors (DC1/DC2)
Connect the supplied DC cord to the power unit.
7 ANALOG OUTPUT connectors
Connect to Pre-Amplifier.
•UNBALANCED RCA type
•BALANCED XLR type
Power unit Main unit

13
English
TAD-D700
Remote control unit
REPEAT
VOLUME
AMP
DISC PLAYER OPEN/CLOSE
TIME DISPLAY OFF
DAC MODE
SACD/CD
CLEARENTER
123
456
78
0
9
MUTE
1 8
9
10
11
12
2
3
4
6
7
5
1 DISC PLAYER

button
Use to set power to ON/standby mode.
2 TIME button
Press to display the disc’s elapsed and remaining
playing time. Each time the button is pressed, the display
alternates as follows: [track remaining time] / [disc
remaining time] / [elapsed time].
3 SACD/CD button
Press to switch between play areas of hybrid discs. Each
time the button is pressed, the playing area alternates
between “CD area” and “SACD area”.
4 Number buttons
Use to designate specific tracks for playback. Press the
desired number button to select, followed by the ENTER
button to confirm the selection.
30°
30°
7 m (23 ft.)
Remote sensor
Remote
control unit
Remote control operating range
When using the remote control unit to operate the unit, point the remote control at the
main unit’s remote sensor within the ranges shown in the accompanying illustration.
'The remote control may not operate properly if obstructions exist between the
remote control unit and the remote sensor, or if the angle between the remote
control and the remote sensor is poor.
'Malfunctions may occur if the
unit is used nearby other appliances that emit
infrared light, or if remote control units for other devices utilizing infrared light are
used nearby. Alternately, using this remote control unit near other appliances that also utilize infrared light may cause
those appliances to malfunction.
'Replace the batteries when you notice a reduction in the operating range of the remote control unit.
'The remote control may not operate correctly if strong sunlight or light from fluorescent lamps is allowed to strike the
remote sensor directly. In such cases, change the installation location, or remove the fluorescent lamps to a more
distant location.
5 CLEAR button
Press to cancel a currently input item. For example, this is
useful when an improper track number has been input.
6 Play operation buttons
– Play disc.
g– Stop disc play.
e– When pressed during playback, pauses the disc play
at its current position. Press the button again to resume
playback.
m– Press during playback to perform quick reverse.
– Press during playback to return to the beginning of
the currently playing track.
n– Press during playback to perform fast forward.
– Press to advance to beginning of next track.
7 REPEAT button
Each time the button is pressed the repeat play mode
alternates in the following order:
All track repeat
Repeat OFF
1 track repeat
A track is repeated.
8
h
OPEN/CLOSE button
Press to open and close the disc tray.
9 DISPLAY OFF button
Press to turn off display.
10 DAC MODE button
Press to switch DAC mode. Each time you press this
button, the mode is switched over between “D1 input
(XLR)” / “D2 input (coaxial)” / “Disc play mode”.
11 ENTER button
Press to confirm settings and selections.
12 Amplifier operation buttons
These buttons can be used to operate a TAD amplifier.
AMP  – Amplifier power ON/standby
VOLUME – Use to adjust sound volume.
MUTE – Press to temporarily mute the sound.

14
Installation
INSTALLATION AND CONNECTIONS
CAUTION
'When installing the
unit , allow a minimum 10 cm clearance from adjacent walls or barriers. In order to facilitate heat
dispersion, the
unit should be installed at some distance from other electric components. When installing the unit
on a rack, a minimum of 10 cm clearance should be provided above, behind, and to the sides of the
unit . Leaving
insufficient ventilation space around the
unit may lead to excessive heat buildup and the potential for fire.
'Never install the
unit on a rug, cushion or other soft surface, or in a narrow location that may interfere with natural air
flow around the
unit .
Installation notes:
'Both the power unit and main unit of the unit are mounted on three spike-type supports which may scratch the surface of
the installation location. To prevent scratching of the installation location, place the provided felts underneath the unit.
WARNING
'Install the
unit in a flat, level and stable location that provides fully sufficient strength to support the unit ’s weight,
since damage or personal injury may occur if the
unit falls from its installation. When installing on a bookshelf or
similar structure, be sure to confirm first that the shelf structure has sufficient strength.
'Never set other items on top of the
unit , or cover the unit with cloths or sheets, since heat dispersion may be
impaired, leading to unnatural heat buildup and potential damage.

15
English
TAD-D700
Connecting up
CAUTION
'Do not turn on the power switch to the unit or the other components until all connections have been completed.
'When connecting components or changing connections, always set the power switch to OFF and disconnect the power
cord from its AC outlet. When making connections, connect the power cord last.
1. Use the supplied DC cords to connect the main unit to the power unit.
2. Connect other components.
3. Connect the supplied power cord to the unit’s AC IN connector.
4. Connect the power cord to a standard electrical outlet (USA: AC 120 V; Europe: AC 220 - 240 V).
Power cord
(supplied)
To AC
Power outlet
Power unit Main unit
DC cords (supplied)
When connecting the DC cable,
press the cable’s DC plug into the
connector firmly, then rotate the
locking ring to secure the
connection.
Select one of these connection methods.
INPUT
(UNBALANCED)
INPUT
(BALANCED)
OUTPUT
(COAXIAL)
Select one of these connection methods.
OUTPUT
(BALANCED)
Component with
digital input connector Pre-Amplifier
Component with
digital output connector
(D/A converter, etc.)
XLR balanced
cable
(commercially
available)
RCA cable
(commercially
available)
Coaxial cable
(commercially
available)
OUTPUT
(COAXIAL)
OUTPUT
(BALANCED)
XLR
D1
DC2DC1
RUNBALANCED
BALANCED
L
RL
XLR
DIGITAL INPUT
DC INPUT
COAXIAL
D2
DIGITAL OUTPUT
ANALOG OUTPUT
12
3
DC2
POWER
ON
OFF
AC IN
DC1
DC OUTPUT
L
R
L
R
1
2
3
1
2
COAXIAL

16
To play a disc
To play a disc on the unit, operate the unit as instructed below:
'Turn on the power by pressing the main unit’s front-panel 
power button (or the

DISC PLAYER button on the remote
control unit)
.
Confirm that the main unit’s front-panel power indicator is lighted orange.
1. Press the hOPEN/CLOSE button.
When the disc tray opens, load a disc on the tray.
With the disc in place, press the h
OPEN/CLOSE button
again to close the
disc tray.
2. Press the button.
Disc playback will begin.
•Press the
button
(or the ebutton on the remote control unit) to
suspend the replay.
•To stop play, press the gbutton during playback.
•To turn off the main unit (set to standby mode), press the main unit’s
front-panel power button (or the DISC PLAYER button on the remote control unit).
Taking care of your player and discs
General
'Hold discs by the edge or by the center hole and edge.
'When you’re not using a disc, return it to its case and store upright. Avoid leaving discs in excessively cold,
humid, or hot environments (including under direct sunlight).
'Don’t glue paper or put stickers on to discs. Do not use a pencil, ball-point pen or other sharp-tipped writing
instrument to write on the disc.
'Don’t use self-adhesive disc labels on discs as these can cause the disc to warp slightly during playback causing distortion
in the sound.
Damaged and shaped discs
'Do not use cracked, chipped, warped, or otherwise damaged discs as they may damage the player.
'This player is designed to be used only with conventional, fully circular discs. Do not use shaped discs.
TAD disclaims all liability arising in connection with the use of shaped discs.
Cleaning discs
'Fingerprints and dust on discs can affect playback performance. Clean using a soft, dry cloth, wiping the
disc lightly from the center to the outside edge as shown below.
'If necessary, use a cloth soaked in alcohol, or a commercially available CD/DVD cleaning kit to clean a
disc more thoroughly. Never use benzine, thinner or other cleaning agents, including products designed
for cleaning vinyl records.
Cleaning the pickup lens
'The player’s lens should not become dirty in normal use, but if for some reason it should malfunction due to dust or dirt,
consult your dealer. We do not recommend using commercially available lens cleaners for CD players.
Always load discs
with the printed or
label surface facing up.
PLAYING

17
English
TAD-D700
SPECIAL SETTINGS
Using the ECO (energy-saving) mode
In this mode, if no playback occurs or no input signal is detected for 20 minutes, the unit will automatically enter the standby
mode.
Factory default is “ECO OFF”.
1. Press the main unit’s front panel

button (or the remote control unit’s DISC PLAYER

button) to set the unit to the
standby mode.
The main unit’s front panel power indicator will light red.
2. While holding the main unit’s front panel hOPEN/CLOSE button depressed, press the main unit’s front panel

button.
You can change to “ECO OFF” (no automatic switching to the standby mode) by pressing
the main unit’s front panel

button or to “ECO ON” (automatic switching to the standby mode) by pressing
the main unit’s front panel

button.
CAUTION
'When you set the ECO mode on (ECO ON), you can avoid unnecessary power consumption caused by forgetting to switch
off the power.
Suppress SACD output level for listening
When playing SACD, if the output is too high and produces distorted sound, this setting will lower the output level to make for
easier listening. At the time of purchase, the factory default setting is DSD modulation 50 % (high output level).
'While holding the main unit’s front panel
g
button depressed, press the main unit’s front panel

button.
Each time the button is pressed, the DSD modulation rate alternates between 50 % (high output level) and 100 % (low output
level).
High Sampling Mode Output
Allows conversion of digital music sampling rate to 44.1 kHz for digital output. At time of purchase, the factory default
sampling rate is set by the upsampling converter to 88.2 kHz.
'While holding the
g
button depressed, press the

button.
Each time the button is pressed, the sampling rate alternates between 44.1 kHz and 88.2 kHz. Note that in the case of SACD,
the sampling rate is fixed at 44.1 kHz.
Using the unit as a D/A converter
'With the play mode set to stop, press the main unit’s front panel DAC button (or the remote control unit’s DAC
MODE button).
Each time the button is pressed, the mode alternates between
“D1 input (XLR)”
,
“D2 input (coaxial)”
, and
“Disc play mode”
.
When an input signal is received,
“In”
is displayed; when no signal is being received,
“- -”
is displayed.
ALL RESET
Set to disk replay mode.
ECO mode is set to “ECO OFF”.
Set to “DSD modulation 50%" (high-output level).
High-sampling mode is set to 88.2 kHz.
SACD hybrid disk setting is set to the SACD layer.
'With the unit in standby mode, press the power button while holding the gbutton depressed.

18
TROUBLESHOOTING
Incorrect operations are often mistaken for trouble and malfunctions. If you think that there is something wrong with this
component, check the points below. Sometimes the trouble may lie in another component. Investigate the other components
and electrical appliances being used. For information regarding computer settings, consult the TAD website (http://tad-labs.
com). If the trouble cannot be rectified even after exercising the checks listed below, ask your dealer.
Symptom Possible cause Remedy
Settings have been
erased.
'When the unit’s power is turned on, if the
power cord is suddenly disconnected or a
power interruption occurs, the contents of
recorded settings may be lost.
'The power cord is disconnected from the
unit’s AC IN connector.
'Only disconnect the power cord after setting
the power switch to OFF, and confirming that
the display contents have disappeared. Take
particular precautions if the unit’s power cord
is connected to the auxiliary power connector
on another component, and the unit’s power
supply is linked to the ON/OFF switch of the
other component. If at all possible, connect
the unit’s power cord to its own dedicated
wall outlet.
'Be sure to connect the power cord securely
to the AC IN connector.
No sound Confirm that the audio cable plugs are
connected securely.
Connect audio cables securely.
Are the connected audio cables broken or cut?
Or is there soiling on the connectors?
Check the plugs and jacks on the audio cables
and the unit’s audio output connectors, as well
as on the audio input connectors of the amplifier
to which it is connected. Clean the connectors if
necessary.
Is the disc dirty? Clean the disc.
Is the play operation set to pause? Set to play.
Is the sound volume of the connected amplifier
set too low?
When connecting to an amplifier, check the
input settings and speaker settings.
The line output volume level of this device is
low.
Adjust the sound volume.
This device is muted (The bar “−” is blinking). Press the MUTE button of the remote controller
to cancel the mute status.
No sound is produced
even when input is
correctly set.
Input connector is not connected correctly. Check the connection.
Amplifier’s mute function is ON. Press the amplifier’s MUTE button to disengage
it.
Sound is too low. Adjust the volume.
Noise is audible even
when no input is
selected.
Noise is present in the power source itself. Check your computer’s power wiring; are too
many plugs connected to the same power
outlet?
Sound is distorted. Is the unit connected to the amplifier’s PHONO
connector?
Do not connect the unit to an amplifier’s
PHONO connector.
In the case of a SACD disc, the recording level
is set higher than proper ratings.
Lower the SACD output level (page 17).

19
English
TAD-D700
Symptom Possible cause Remedy
Volume level is
different when playing
SACD compared to
CDs.
A difference may occur due to different
recording formats for the two kinds of discs.
This is not a malfunction of this unit.
No sound is produced
for digital input.
Digital connection is not correct. Check the digital connection.
On a CD player equipped with digital output
level adjustment, the output level is set too low.
Adjust the player’s digital output level to an
appropriate level.
The file format is not supported by the
computer’s digital playback software.
If the output device is set to a non-PCM audio
signal format (Dolby Digital, DTS, etc.), set it to
PCM.
Digital recording can’t
be performed from
digital outputs.
'Some recorders may be unable to record
output when connected to 88.2 kHz output.
'Recording may not be possible when playing
CD-R or other discs with copy protection.
'Try switching to 44.1 kHz output.
'Can’t record.
The power turns off by
itself.
If the ECO (power-saving) mode is turned ON,
the unit will automatically enter standby mode
if no operation is performed on the unit for 20
minutes.
Set the ECO (power-saving) mode to OFF
(page 17).
Display is not visible. The display viewing angle is within 45° to right/
left from the front of the unit.
View the display from immediately in front of the
unit.
The unit is set to display off. Press the DISP OFF button of the remote control
unit to reset the lighting-off function.
The remote control
doesn’t work.
'The remote control’s batteries are expended.
'The remote control is being used too far
away from the main unit.
'Angle is bad.
'Line of sight to the main unit is blocked.
'Strong light from a fluorescent lamp or other
light source is directly striking the signal
receiver.
'Replace the batteries with new ones.
'Use the remote control from within a distance
of 7 meters (23 ft.), and within an 30° arc to
right/left of the unit’s front panel.
'Remove obstacles between the main unit
and remote control, or change to a different
location when operating the remote control.
'Readjust the position of lamps or other light
sources so that strong light does not strike
the signal receiver.
Static electricity or other external influences may cause malfunctioning of this unit. In this case, unplug the power cord and
then plug back in. This will usually reset the unit for proper operation. If this does not correct the problem, please consult your
dealer.
This unit is designed as a consumer audio product (audio/video component). It is not designed for long continuous
use as a commercial BGM source, nor for use in automobiles, ships, or outdoors.

20
SPECIFICATIONS
Model Type ................................................................Disc player
Power:
USA.................................................................AC 120 V, 60 Hz
Europe ...................................AC 220 V to 240 V, 50 Hz/60 Hz
Power consumption ........................................................... 43 W
Power consumption on Standby..........................0.5 W or less
External dimensions:
Main unit........... 450 mm (W) × 185 mm (H) × 440 mm (D)
17 23/32 in. (W) × 7 9/32 in. (H) × 17 11/32 in. (D)
Power unit......... 220 mm (W) × 185 mm (H) × 430 mm (D)
8 11/16 in. (W) × 7 9/32 in. (H) × 16 15/16 in. (D)
Weight:
Main unit.....................................................26.5 kg (58 lb 7oz)
Power unit................................................14.0 kg (30 lb 14 oz)
Analog audio output (2 ch)
Audiooutputlevel(Loadimpedance100kΩ):
Balanced output........................450mVrms(1kHz,−20dB)
Unbalanced output ...................220mVrms(1kHz,−20dB)
Output connectors:
Balanced output...............................................XLR stereo x 1
Unbalanced output .........................................RCA stereo x 1
Frequencyresponse(Loadimpedance100kΩ):
CD......................................................................4 Hz to 20 kHz
SACD .................................................................4 Hz to 40 kHz
S/N ratio:
CD..................................................................................115 dB
SACD .............................................................................110 dB
Digital input (24 bit)......................................................115 dB
Digital audio input/output
Input sampling frequency.............................32 kHz to 192 kHz
Balanced input .............................................XLR connector x 1
Coaxial input ................................................RCA connector x 1
Output sampling frerquency ..........................32 kHz to 96 kHz
Balanced output ...........................................XLR connector x 1
Coaxial output..............................................RCA connector x 1
Accessories
Remote control unit...................................................................1
DC cords (150 cm/59.06 in.) .....................................................2
Power cord
Polishing cloth...........................................................................1
Felts............................................................................................2
Operating Instructions (This document)
Note
'Specifications and the design are subject to possible
modifications without notice, due to improvements.
