tado° Wireless Smart Thermostat V3+ User manual

This manual is meant exclusively for professional installers. It includes generic instructions to install the Wireless
Receiver and the Wireless Temperature Sensor.
Manual for Professional
Installers
For the Starter Kit - Wireless Smart Thermostat V3+
English International
Manual version 3.2
EN
DE
IT
FR
ES
NL
DIY Installation
If you are not a professional installer, please download the tado˚ app. There you will find specific installation instructions.

A. Remove the battery
protection strip.
B. Press the button for
3 sec to start pairing.
C. Pairing may take up
to 2 min.
D. The static icon below
indicates successful pairing.
If pairing fails (E0), make sure the distance between the devices is approximately 3 meters. Pair again by pressing the
button for 3 sec.
2. Pair the Wireless Temp. Sensor
1. Install the Internet Bridge
A. Connect the Internet Bridge to the router.
If no free USB port is available on the router, use the
included 5V power adapter.
B. Press and hold the pairing button until the pairing LED
starts blinking.
2
min
3
sec
Solid on
Blinking

Power supply Connection with other
tado˚ devices
Device errors Heat request
When tado˚ is requesting heat, the Heat request symbol will either fade in and out or be solid ON. When OFF, tado°
is not requesting heat.
Unfold to check:
Step 4: Wire the Wireless Receiver
Step 5: Pair the Wireless Receiver
Step 6: Configuration
Extra information: Wireless Receiver Symbols
A. Mount the Wireless Temperature Sensor to the wall
using the included screws or the adhesive pads.
B. Mount the Wireless Receiver to the wall using the
included screws.
3. Mount tado˚ devices
Click
Don‘t plug in
to power until
the cover is on.
or

4. Wire the Wireless Receiver
Caution!
Turn OFF the power
before wiring!
Always use the included strain
reliefs and position them on the
outer insulation layer of the cable.
Check the boiler manual before
Potential Free Relay
RTRT
230V Relay
LSL
Manufacturer Config.
Menu ID
Hot Water
control
Control Interface
Various
Various
The factory default configuration is Relay. If the Wireless Receiver is wired via Relay, step 6 (configuration) can be
skipped.
R01
R01
RT
L
RT
SL
Potential Free Relay
230V Relay
tado˚ terminals
COM NO
Common terminal
labels on the boiler.
wiring. Identify the control interface and
check if it is supported by tado .

Common terminal
labels on the boiler.
Digital
BUSBUS
*VR33 OpenTherm translation module (in the Netherlands) should be removed.
**Only compatible with one heating circuit. Any existing fit-in controller should be removed.
***Special configuration is needed on the boiler for KM-Bus interface, see table on backpage.
Wolf
Viessmann
Elco, Brötje, Atlantic,
Chappee, Baxi, BaxiRoca
D45
D37
D62
eBus(1)
KM-Bus
CL-
eBus(2)
KM-Bus
CL+
Wolf-eBus
KM-Bus***
BS-Bus
Manufacturer Config.
Menu ID
Hot Water
control
tado˚ terminals
- +
Control interface
Various
Vaillant, Glowworm,
Heatline, Saunier Duval,
AWB, Bulex, Hermann
Buderus, Nefit, Sieger,
Bosch
Chaffoteaux, Ariston
Junkers, Worcester, e.l.m.
leblanc, Bosch
D01
D07
D31
D27
D57
D05
D17
D24
OT(-)
eBUS(-)
EMS (1)
EMS (1)
T
eBUS(-)
B
3
OT(+)
eBUS(+)
EMS (2)
EMS (2)
B
eBUS(+)
B
4
Opentherm
Vaillant-e-Bus *,**
EMS-Bus**
EMS+ Bus
Chaffoteaux Ebus/BridgeNet
Vaillant-e-Bus*
(with VRC 430/470)
HT-Bus**
UBA-Bus

Common terminal labels on the
boiler.
Manufacturer Config.
Menu ID
Hot Water
control
tado˚ terminals
A - +
Control interface
Junkers
Vaillant
Wolf
A01
A07
A08
2
7
4 1
9 8
0V 24V
Junkers 1-2-4 24V
Vaillant 7-8-9 24 V
Wolf 1-2-3 24V
Analog
XXX

3
sec 3 sec
6. Conguration
Use the Wireless Temperature Sensor to configure the Wireless Receiver interface according to the tables above
(Hot Water control & Config. Menu ID).
B. Press the button
for 3 sec again and
release.
A. Press the button
for 3 sec and release.
G. Based on
interface, activate
Hot Water control.
C. Press the button
for 3 sec again and
release.
H. Press the button
when EK is displayed
to continue.
D. Please wait while
the installer menu
loads.
I. Select the Config
Menu ID according
to the table.
E. Press the button
when TS is displayed
to continue.
J. Save configuration
by pressing the
button.
F. Press the button
when HC01 is
displayed to confirm.
5. Pair the Wireless Receiver
Fast
blinking
Solid on
A. Put the cover on the
device. Tight the housing
screw to secure it.
B. Plug in the power
supply cable and turn the
power back ON.
C. Wait 30 sec, then press
the button for 3 sec to
start pairing.
D. Solid on indicates
successful pairing.
On
Wait
30 sec
2
min
3
sec
3
sec

Get expert advice on our tado° installer hotline: [phone]
Register on our tado°
Professional site for help, tips,
and more information.
tado.com/installers
Find more information on error
codes in our Help Center.
tado.com/support
Find additional Professional
Installer Manuals here.
tado.com/professional-manuals
Need help?
7. Test the system
A. Adjust to maximum
temperature.
B. Wait 3 min and
check if the heating is ON.
C. Turn the heating back
OFF and check after 3 min.
D. Your tado° installation is
complete.
Controller Heating system parameter Heating system setting
Vitotronic 200 /300
(GW..., HO..., KW...,
KO...)
90: Time constant for calculating the adjusted outside temperature 12
A0: Remote Control 1 (or 2)
b0: Room Temperature Hook-up 3
b2: Room Influence Factor 64 (or 31)
b5: Heating Circuit Pump Logic 5 (or 1)
FA: Increase of the set flow temperature 0
Boiler Configuration ONLY for Viessmann KM-Bus
Wait
3 min
104204 V3
