TAG MIL-BOOK 1000 Series User manual

OPERATOR’ S MANUAL
MIL-BOOK 1000 SERIES NOTEBOOK
22355 TAG Way, Dulles, VA 20166
Tel: [phone] Fax: [phone]

MIL-BOOK™
OPERATORS MANUAL
- ii -

MIL-BOOK™
OPERATORS MANUAL
- iii -
© 2004 Technology Advancement Group®, Inc. (TAG®) All rights reserved. No part of this
publication maybe reproduced by any means for any reason without express written approval
from Technology Advancement Group®, Inc., or its authorized representative.
Technology Advancement Group®, Inc. makes no representations, either express or implied
concerning the accuracy of this manual. All the information contained herein is believed to be
complete and reliable as of the printing date. Technology Advancement Group®, Inc. reserves the
right to make changes to this manual or product specifications without obligation to notify any
person of such changes.
Technology Advancement Group, TAG, and the TAG ball graphic are registered trademarks of
Technology Advancement Group Inc. MIL-BOOK is a trademark of Technology Advancement
Group, Inc.
IBM, IBM PC/AT and OS/2 are registered trademarks of International Business
Machines Corporation.
Intel Pentium is a registered trademark of Intel Corporation.
MS-DOS, Windows 2000/Windows XP are registered trademarks of Microsoft
Corporation.
UNIX is a registered trademark of AT&T Bell Laboratories.
Other brand and product names are trademarks and/or registered trademarks of
their respective holders.

MIL-BOOK™
OPERATORS MANUAL
- iv -
Class B Regulations
Federal Communications Commission Radio Frequency Interference Statement
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are design to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and
receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected. Consult the dealer or an experienced radio/TV technician for help. Any changes or
modifications not expressly approved by the manufacturer could avoid the user’s authority to
operate the equipment.
Please note:
1. The use of a non-shielded interface cable with this equipment is prohibited.
2. A shielded AC power cord must be used with this equipment.

MIL-BOOK™
OPERATORS MANUAL
- v -
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low
Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European
Norms:
•EN50081-1: Electromagnetic compatibility-Generic emission standard
•EN55022: conducted Emission, Radiated Emission
•EN61000-3-2: Current Harmonic
•EN61000-3-3: Voltage Flicker
•EN50082-2: Electromagnetic compatibility-Generic immunity standard
•IEC1000-4-2: Electrostatic Discharge
•IEC1000-4-3: Radiated Susceptibility
•IEC1000-4-4: Electrical Fast Transients
•IEC1000-4-5: Surge Test
•IEC1000-4-6: Conducted Susceptibility
•IEC1000-4-11: Voltage Dip and Interruption

MIL-BOOK™
OPERATORS MANUAL
- vi -
Preface
This is the MIL-BOOK 1000 Series Notebook Operation Guide.
Contents
This manual contains information for personnel using the MIL-BOOK 1000 Series notebook
computer. Readers should have a basic understanding of Windows 2000 or Windows XP
operating system installed on the computer when reading this document. With the exception of
the SETUP configuration program, which is part of the system firmware, this manual does not
explain any of the software or devices used with the system. Supplemental manuals or text-based
documents on the hard disk supply information about any software included with the system.
Audience
All operators using the notebook in or out of the field should read and become
familiar with this manual.
Organization
This manual has four chapters.
Chapter 1 introduces the notebook pointing out its major features.
Chapter 2 explains daily operation.
Chapter 3 gives detailed information about configuring the notebook.
Chapter 4 introduces the notebook Maintenance.
Supplemental Reading
For further information about this computer and computing in general, use these
references:
MIL-BOOK 1000 Series Service Manual for detailed troubleshooting and repair instructions for
serious hardware problems associated with the MIL-BOOK 1000 Series notebook. Various
software manuals offer detailed instructions about individual programs run on the notebook.

MIL-BOOK™
OPERATORS MANUAL
- vii -
Specifications (reference only)
Standard Optional
CPU Intel Pentium M Processor
1.4/1.6Ghz
(µ-FCPGA) package
RAM 256 MB 512MB or above
Display 1. 12.1” color LCD, 64K color
TFT, XGA
2. 13.3” color LCD, XGA TFT
3. 14.1” color LCD, XGA TFT
12.1” for Sun-Light Readable
(Transflective)
Keyboard 87-key shower proof and dust-proof
rubber keyboard
Embedded two-button Track Pad
LED Backlight Rubber Keyboard
Device Point A toucn-senstive control pad with
Microsoft Win Mouse function
coexist
Support Glove hand Touch Pad
Bay-1 Modules Swappable for CD-ROM,
DVD,DVD-RW,FDD, Battery,
2nd HDD, COMBO drive
Bay-2 Modules 2nd PCMCIA-Removable Type
III x 1 or TYPE II x 2 Module
COM port Module- Removable
Sealed Water Proof RS-232, 422, or
485 Module DGPS- DGPS Module
Bay2 Battery Pack- Removable
and Recharge Li-Ion Battery Pack
Bay2 FDD
Wireless Modem (GSM/GPRS)
Expansion Unit (PCI/ISA)
Port replicator (SIOx2,
PIOx1,USBx4,VGAx1, DC input,
Power switch)
Carrying Bag
Shock Mount
External battery charger (2-pcs
and 3-pcs)
11-32VDC 90W car adapter
USB external FDD
802.1 1b Wireless LAN

MIL-BOOK™
OPERATORS MANUAL
- viii -
Standard Optional
Communication
ports
One serial port
One parallel port, support EPP/ECP
RJ-11 port
RJ-45 port
One VGA monitor port
Two USB 2.0
One Port Replicator port
One DC input port
One infrared port
IEEE 1394 port
Mic-In and Line-Out
Battery pack Removable & rechargeable main
Li-ion battery pack with the
functions of on-line charge and hot
swap.
Primary battery pack 97 watts.
Removable & rechargeable
Bay 1 Li-ion battery pack in
Bay 1, total 65 watts
Removable & rechargeable
Bay 2 Li-ion battery pack in
Bay 2, total 65 watts
Power adapter I/P: AC 100-240 V, 50-60 Hz
O/P: DC 19V, ±5%, 4.74A, 90W ,
CV mode
9-12 VDC direct input
without charging function
12-32 VDC external car
adaptor/ charger
Operating
system
Windows 2000
Windows XP
Temperature • Operating: 0°C to +55°C
• Non-operating: -40°C to 70°C
(tested)
• Option: -20°C to +55°C
(tested)
Open Size:
(With Rubber
Bumper)
315mm W
70mm H
260mm D
Weight 14.3 lbs (6.5 kg)

MIL-BOOK™
OPERATORS MANUAL
- ix -
Safety Summary
1. Read these instructions before using or working on this computer.
2. Follow all warnings and instructions in this manual or marks on the computer and its
components.
3. Avoid submerging the system unit in liquids.
4. Avoid stacking papers or other flammable objects on top of, underneath, or next to the
system unit.
5. Use only batteries supplied with the system.
6. Make sure any external power source connected to the adapter or system conforms with
adaptor or system ratings.
7. The external power adapter has a two-pronged grounding plug. If an adapter is needed to
plug the system into a power source, make sure the system is properly grounded.
8. Arrange all cables so that they are out of traffic and unobstructed by personnel or
equipment.
9. Avoid using extension cords with this product. If an extension cord is needed, make sure
it is rated for at least 10 amperes.
10. Make sure amperage drawn by all items plugged into an outlet with this system does not
exceed 15 amperes.
11. Do not put any objects except those designed for use with this system inside the
computer.
12. Observe proper electrical safety precautions when performing system maintenance.
13. Replace any cables with identically rated cables as those included with the original
equipment.
14. Improper handling of the battery can cause personal injury or fires. Do not attempt to
disassemble or replace individual cells in the battery pack. Do not expose the battery to
open flames. Do not short the positive and negative ends together even if the battery is
fully discharged. Keep the battery away from children.

MIL-BOOK™
OPERATORS MANUAL
- x -
Table of Contents
CHAPTER 1. SYSTEM OVERVIEW 1-1
1.1 Introduction 1-1
1.2 System Description 1-1
1.3 System Configuration 1-1
1.3.1 Standard Configuration 1-1
1.3.2 Options and Accessories 1-3
1.3.2.1 Carrying Bag 1-3
1.3.3 System Identification 1-3
1.4 Unpacking 1-3
1.5 Notebook Features 1-4
1.5.1 Feature Description 1-5
1.5.2 Rear Components 1-6
1.5.3 The Keyboard 1-6
1.5.3.1 Keyboard Keys 1-7
1.5.3.2 Cursor Control Keys 1-8
1.5.3.3 Keyboard Touchpad 1-9
1.5.4 Additional Keyboard Functions 1-9
1.5.4.1 Volume Control 1-9
1.5.4.2 Brightness Control 1-10
1.5.4.3 Toggle Key (Option for RS485) 1-10
1.5.4.4 Keyboard Backlight (Option) 1-10
1.5.4.5 CRT/LCD/Simulscan Toggle 1-10
1.5.4.6 Panel On/Off 1-10
1.5.4.7 Toggle LCD Backlight On/Off (Option) 1-10
1.5.4.8 1-5.4.1 Hot Key Function 1-11
1.5.5 Status Row Indicators 1-11
1.5.6 Status Row Descriptions 1-12
1.5.7 The AC Power Adapter 1-12
1.5.8 Status Row 1-12
1.5.9 Battery Pack 1-13
1.5.10 Low Battery Indication 1-13
1.5.11 Battery Charger 1-14
1.5.12 CHARGE LED Indicator Status 1-14
1.5.13 Connections 1-14
1.5.14 Serial Port 1-14
1.5.15 Parallel Port 1-15
1.5.16 VGA Port 1-15
1.5.17 USB2.0 Port 1-15
1.5.18 IrDA Port 1-16
1.5.19 Replicator Port 1-16
1.5.20 Power Port 1-16
1.5.21 IEEE 1394 Port 1-16
1.5.22 Audio Connections 1-16
1.5.23 1-5.5 Battery Pack 1-16
1.5.24 Diskette Drive and CD-ROM/DVD/COMBO /DVD-RW 1-17
1.5.24.1 1-5.6.1 PCMCIA Slot and Diskette Drive and CD-ROM/DVD /COMBO/DVD RW Door
1-17
