TAG PA-223 User manual

PA-223 User’s Manual
16
Route de Lavérune
Montée du Terral
34430 Saint Jean de Védas
FRANCE
Tel : [phone]
Fax : [phone]
[e-mail]
www.tag-fr.com
Techniques Audio Groupe
USER’S MANUAL
Example of one PA-223
NOTES
NOTES

PA-223 User’s Manual 15
PA-223 User’s Manual
2
SUMMARY
SUMMARY
INTRODUCTION
INTRODUCTION Page 3
ADVICE FOR A GOOD USE
ADVICE FOR A GOOD USE Page 3
BASIC EQUIPMENT
BASIC EQUIPMENT Pages 4-5
- Preamplifier Page 4
- ON/OFF button Page 4
- Talk Overs Page 4
- Volume Controls Page 4
- Tone adjustment Page 4
- Inputs Page 5
-Outputs Page 5
OPTIONS
OPTIONS Pages 5-12
- Amplifier Page 5
- Wireless receiver SDR-6216M Page 6
- Handheld microphone SQ-5016 + Charger Pages 6-7
- Beltpack transmitter SM-5016 + Charger Pages 8-9
- Audio transmitter RP-6016M Page 10
- Digital player T-EM040 Pages 11-12
TECHNICAL DATA
TECHNICAL DATA Page 13
NOTES
NOTES Page 14-16
NOTES
NOTES

PA-223 User’s Manual
14 PA-223 User’s Manual 3
INTRODUCTION
INTRODUCTION
Thank you for choosing PA-223. To ensure the best performance and get the maximum life out of
the equipment, we recommend that you read this manual carefully.
PA-223 is an automatic mixer which can be equipped with 1 MP3/USB player, 1 audio transmitter
or/and 1 UHF wireless module. This product only functions on AC main 100-240V, 47-63 Hz.
ADVICE FOR A GOOD USE
ADVICE FOR A GOOD USE
The exclamation point inside an equilateral triangle indicates the existence of internal
components whose substitution may effect safety. Also indicates important operating
instructions.
The lightning and arrowhead symbol warns about the presence of uninsulated dange-
rours voltage. To reduce the risk of electric shock, do not remove the cover. Refer servi-
cing to qualified personnel.
3Do not use the sound system in a humid or dusty place, or near any heat sources such as radia-
tors, heat registers, neither under the sun or at very low temperatures.
3Place the sound system in a ventilated place.
3Be careful when moving this unit in order not to damage the electronics.
3Carry the sound system with caution.
3Do not forget to decrease the volume switch before turning off the sound system.
3Handle the control switches carefully.
3Clean the sound system regularly.
3Keep the carton in case of return.Transport will be safe and without any risk of damage.
NOTES
NOTES

PA-223 User’s Manual 13
TECHNICAL DATA
TECHNICAL DATA
Basic Equipment
Basic Equipment PA-223
Power Requirements Operates on AC 240V
Inputs Mixable inputs:
2 RCA Line control inputs
2 MIC control inputs on XLR (3 pins)
2 RCA auxiliary control inputs
Switch ON/OFF
Power Supply Input
Volume controls 5 independent volume controls:
- MIC/LINE1
- MIC/LINE2
- Aux1
- Aux2
- Master volume control
Voice Priorities Voice Priority for wireless system SDR-6216M
Voice Priority for 1st MIC/Line input for AUX1
Bands EQ Bass, Mid, Treble
Outputs 1 RCA Rec output
1 Master output on XLR
More Information Dimensions: 19” x 2U x 190 mm
Weight : 3 kg / 6.6 lbs
Options
Options
RMS Power 70 Watts 1 way amplified
or
70 Watts 2 ways amplified
Wireless System 1 UHF 16 Frequency Receiver SDR-6216M
Audio Transmitter 1 Transmitter Module RP-6016M to link to cabinets
Player USB/MMC Card player T-EM040
PA-223 User’s Manual
4
BASIC EQUIPMENT
BASIC EQUIPMENT
PREAMPLIFIED
The automatic mixer PA-223 is preamplified.
ON/OFF BUTTON
Use this button to switch on/off the device.
TALK OVER
PA-223 is equipped with 2 voice priorities: 1 for the 1st MIC/Line input, the 2nd for the wireless sys-
tem.
This function allows to speak while music is playing > Priority of speech over
music. If this feature is activated the level of sound will decrease automatically
as soon as the mic is open. The voice priority for the MIC/Line input overrides
external music through the AUX1 input.
VOLUME CONTROLS
PA-223 is equipped with 5 independent volume controls: MIC/Line1, MIC/Line2, Aux1, Aux2 and
the master volume control. It is the general volume control output. This setting allows to balance
the different levels of each input.
TONE ADJUSTMENTS
PA-223 is equipped with 3 highly performing tone adjustments.
1 bass frequency tone control on 100 Hz with +/- 12 dB efficiency.
1 treble frequency tone control on 10000 Hz with +/- 12 dB efficiency.
1 voice adjustment especially designed for use in medium frequency which allows for a sharp
increase of voice presence on the mic inputs.
To avoid the larsen effect when you switch on mics, do not turn the gain if you are
not far from PA-223. ADVICE : We strongly recommend that you switch off the mic,
adjust the volume of the PA-223 to the desired volume, then be a few meters away
before switching on the mic again.
LCAUTION : MIC Adjustment

PA-223 User’s Manual
12
Key Explanation Front cover
of the player
FOLDER
DOWN
Press this button to select the previous folder.
In stop mode: Skips the starting play folder and selects the previous
folder It cyclics to the last folder if it is the first folder.
In normal play mode: Skips the current file and selects the previous
folder's first file.
REPEAT [repeat] mode is changed cyclically shown below
Repeat off repeat one track repeat all
RST System reset.
RANDOM All titles are played in a random sequence
VOL.-
VOL.+
Decrease volume
Increase volume
FUNC This button alows to select CARD or USB mode.
+10 When this key is pushed during playback, pause or stop, the device
selects the 10th MPR3 file which is following the current file.
If less than 10 files are left during playback, the device plays the first
file..
INPUTS
2 MIC INPUTS equipped with XLR(3 pins) connectors. The balanced inputs allow use of long
cables. One condition: use high quality cables.
2 LINE INPUTS equipped with 2 dual RCA connectors, allowing to connect auxiliary product such
as tuner, CD or Tape player. If both inputs are connected, you can use them simultaneously.
2 AUXILIARY INPUTS equipped with 2 dual RCA connectors, allowing to connect auxiliary pro-
duct such as tuner, CD or Tape player. Both inputs have an independent volume control on the
front panel.
POWER SUPPLY INPUT
12 Volts power supply input. Allows working on AC main. It is recommended to use the
provided cable.
OUTPUTS
1 REC OUTPUT equipped with 2 dual RCA connectors, allowing to connect
auxiliary product and to register for example a speech.
1 MASTER OUTPUT: PA-223 is equipped with 1 XLR line output so as to link it
to another sound system. You just have to connect the PA-223 Line out to the
Line in of the other correspondent product.
OPTIONS
OPTIONS
PA-223.A: The mixer PA-223 can be amplified: 1 x 70 W RMS or 2 x 70 W RMS.
PA-223 User’s Manual 5

PA-223 User’s Manual 11
DIGITAL PLAYER
The PA-223 can be equipped with one USB/MP3 and MMC Card player which can read MP3 and
WMA format.
Key Explanation Front cover
of the player
PLAY/
PAUSE
Starts/
Pauses playback
STOP Stops playback.
UP/CUE
Skip
This function allows you to select a specific title.
In stop mode:
Changes the starting play track (file) during stop mode or cyclics to the
first track, if it is the last track.
In play mode, pause mode, random play mode:
Selects the next titel (file).
DOWN/
REV
Skip
This function allows you to select a specific title.
In stop mode:
Changes the starting play track (file) during stop mode or cyclics to the
last track, if it is the first track.
In play mode, pause mode, random play mode:
Selects the previous titel (file).
FOLDER UP Press this button to select the next folder.
In stop mode: Skips the starting play folder and selects the next folder
It cyclics to the first folder if it is the last folder.
In normal play mode: Skips the current file and selects the next folder's
first file.
PA-223 User’s Manual
6
RECEIVER SDR-6216M
Technical caracteristics of receiver SDR-6216M
UHF receiver, True Diversity, with Pilotone.
3Switch on the receiver:
The switch on the right is power switch and volume control
3Switch on the handheld microphone/beltpack transmitter:
The LEDS A and B are lightning when the UHF link between transmitter and receiver is ok.
Channel can be changed with the switch on the left side.
HANDHELD MICROPHONE TRANSMITTER SQ-5016 (UHF)
The microphone is equipped with 16 frequencies
1. Microphone capsule
2. Battery status led
3. Power switch (ON/OFF)
4. LCD display
5. Battery compartment
6. Rotative protective cap for controls
7. Lock/Unlock
8. Set
9. UP
10.DOWN
11.Charging Port
12.Name plate
55001166
On/Off + Volume
Selection of the channel LED A et B

PA-223 User’s Manual
10
2
1
3456
UHF TRANSMITTER RP-6016M
Technical specifications of transmitter RP-6016M
UHF 16 frequencies , True Diversity, with Pilotone
1. Power switch (ON/OFF)
2. Antenna socket (TNC)
3. Channel
4. Audio sensitivity: clockwise to increase sensitivity and anti-clockwise to decrease.
5. Output power switch. L for LOW power and H for HIGH power. Low Output power will reduce
the RF transmission distance and High Output power will extend the possible RF transmission dis-
tance.
The RP-6016M transmitter enables the link between PA-223 and other active sound systems
(XPresso, Nomade UHF, Premio UHF,...) Furthermore, PA-223 can be linked via cable to other pas-
sive annex cabinets.
UHF amplified sound system
Nomade
UHF amplified sound system
Premio
UHF amplified sound system
Xpresso
PA-223 User’s Manual 7
Microphone settings
1. Making changes to CHANNEL/FREQUENCY
Press on Set for 2 seconds to enter into Settings.
Use UP or DOWN button to go to the Channel/Frequency page. Pressing UP or DOWN button
will increase of decrease the channel number. The corresponding frequency will change accor-
dingly. When a desired channel is being selected, it will automatically be saved and stored in the
memory.
2. Making changes to SENSITIVIY
Use UP or DOWN button to go to the Set page.. Use UP or DOWN to decrease or increase sensi-
tivity. Level: 1 - 4 . for singing, Level 4 for speech or if microphone is used with a stand
3. Making changes to battery selection
Use UP or DOWN to go to the Battery selection page. Press UP or DOWN to move the cursor to
either: NiMH (rechargeable battery) or AKLN (alkaline). When the battery has been selected it is
saved and stored in the memory.
Changing Batteries
2 pieces of AA batteries are used. Unscrew the tap of battery com-
partment and insert the new batteries. BEWARE OF THE POLARITY
HC-30 Charger
Handheld microphones and beltpack transmitters can be reloaded.The charger HC-30 is for the
handheld microphone SQ-5016. Before loading check that the batteries are rechargeable ones.
For rechargeable batteries we strongly recommend NiMH batteries, no alkanies.
Wrong batteries can damage the microphone functions. Check battery status. Many
batteries are known to have leakage problem of conductive and corrosive liquid.
Remove the batteries if you do not plan to use the microphone for a few days. Also
check that transmitter and receiver are on the same channel.
LCAUTION: BATTERY

PA-223 User’s Manual 9
PA-223 User’s Manual
8
Battery Installation
SM-5016 uses 2 pieces of " AA " size batteries (Alkaline battery is recommended ).
To install or remove the batteries, press the release buttons at the edges of the
transmitter to open or close the cover as illustrated below.
HC-37 Charger
The beltpack transmitter SM-5016 can be reloaded with the charger HC-37.
Before loading check that the batteries are rechargeable ones.
For rechargeable batteries we strongly recommend NiMH batteries, no alkanies.
Wrong batteries can damage the microphone functions. Check battery status. Many
batteries are known to have leakage problem of conductive and corrosive liquid.
Remove the batteries if you do not plan to use the belt transmitter for a few days.
Also check that transmitter and receiver are on the same channel.
LCAUTION: BATTERY
BELT TRANSMITTER SM-5016 (UHF)
Belt transmitter settings
1. Making changes to CHANNEL / FREQUENCY
Press on Set for 2 seconds to enter into Settings.
Use UP or DOWN button to go to the CHANNEL /FREQUENCY page. The
cursor will flash to allow changes to be made. Pressing UP or DOWN but-
ton will increase or decrease the channel number. The corresponding fre-
quency will change accordingly. When a desired channel(frequency) is being selected, it will be
automatically saved and stored in the memory.
2. Input Level Gain Control Adjustment
Low impedance (Lo-Z) " MT" & high impedance (Hi-Z) " GT" gain controls are situated inside the
transmitter. Gain controls are adjustment ports that enable you touse microphones of differing
output levels and Guitar or instruments with Hi-Z output. To adjust microphone (Lo-Z) input
levels, turn the "MT" control and to adjust the Guitar or instrument (Hi-Z) input, adjust the "GT"
gain control to set the transmitter's desired audio input level.
3. Making changes to Battery selection
Use UP or DOWN button to go to the Battery selection page. Press SET for
about 2 seconds to activate the cursor. Press UP or DOWN button to move
the cursor to either NiMH (rechargeable battery) or AKLN (Alkaline bat-
tery) position.When the desired option has been selected, press SET for about 2 seconds to save
and store the data in the memory.
1. Antenna
2. Battery weak indicator
3. Audio mute switch
4. Mini-XLR connector
5. Power ON / OFF switch
6. LCD display
7. Charging port
8. Cover release button
9. Charging contacts
10. Lavalier microphone
11. Mic clip
12. SET
13. UP
14. DOWN
15. GT
16. MT
2
1
3
4
9
7
8
56
10
11
12
13 14
15 16
