tahoe gear TGT-ZION-9-B User manual

1.Spread the tent out flat, floor side down. Assemble
the three shorter fiberglass poles and insert into the
sleeves on the top of the tent. (pic 1,3) Insert poles
top into the star shaped hub on the top of tent. (pic 2)
2.Insert poles ends into the corresponding pin rings.
(pic 4,5)
5.Assemble the shortest fiberglass pole and insert
through the front sleeve. (pic 10) Insert poles ends
into the corresponding pin rings. (pic 11, 12)
6.Secure the PE sheet by hooking the plastic S hooks
on the PE sheet corners to the corresponding rings at
the tent corners. (pic 13)
7.Fix stakes into the rings on the corners of the tent
to secure the inner tent to the ground.(pic 14,15,16)
8.Place the fly over the tent. Attach the fly to the tent
by hooking the plastic S-hook on the fly to the corres-
ponding rings at the tent corners.(pic 17, 18, 19)
9.Wrap the Velcro fasteners of the fly around the
fiberglass tent poles.(pic 20)
10.Finally secure the tent in place with the guy ropes
and extra tent stakes. (pic 21, 22, 23)
11. Tent assembled. (pic 24)
3.Assemble the two longest fiberglass poles and insert
into the two side sleeves. Insert poles ends into the
corresponding pin rings. (pic 7,8) Clip the plastic
hooks sewn to the tent to the fiberglass poles. (pic 6)
4.Fix stakes into the rings on the corners of the tent
to secure it to the ground. (pic 7,8,9)
pic.1
pic.2
pic.4
pic.5
pic.6
pic.7
pic.8
pic.9
pic.10
pic.11
pic.12
pic.13
pic.14
pic.15
pic.16
pic.17
pic.18
pic.19
pic.20
pic.21
pic.23 pic.22
pic.24
pic.3
210*285MM
20MM
TENT ASSEMBLY INSTRUCTION
Model- TGT-ZION-9-B

Model- TGT-ZION-9-B
WARNING!
DO NOT LEAVE YOUR TENT SET UP IN DIRECT
SUNLIGHT LONGER THAN NECESSARY.The sun’s
ultraviolet(UV)light degrades almost every fabric and
material.If left in sunlight for prolonged periods of
time,fabric will fade and weaken.UV damage is not
covered by the manufacturer’s warranty.Do not store
tent on concrete floor.
Your tent is water repellent. However, it is not
waterproof.During heavy rain,some leakage may
occur.Keep objects from touching the inside of the
tent.Such objects may cause leakage at point of
contact.If seam leakage occurs,it can be controlled
by applying a seam sealer compound.
Although our tents and screen houses are constructed
to rigid specifications,periods of wind or rain soaking
the ground may loosen the stakes and cause the frame
to sink into the ground.This will weaken the rigidity of
the overall structure.Water pockets may also form in
the roof if the unit is not assembled taut,possibly
causing broken frames and torn fabric.
DANGER:
Stove,lanterns,candles,grills,heaters and other fuel
burning devices produce carbon monoxide and will
consume the available oxygen in this tent.Use of such
devices in this tent will cause asphyxiation,carbon
monoxide poisoning,and death or serious
and permanent injuries.For this reason:
- DO NOT use fuel burning devices inside or near this
tent.
- Your failure to follow this warning will cause death
or serious and permanent injury to you or others
using this tent.
KEEP ALL FLAME AND HEAT SOURCES AWAY
FROM THIS TENT FABRIC.This tent is made with
flame-resistant fabric,which meets CPAI-84
specifications.IT IS NOT FIRE PROOF! The fabric
will burn if let in continuous contact with any flame
source. The application of any foreign substance to
the tent fabric may render the flame resistant
properties ineffective.
DO NOT...
- Pitch tent near open fire.
- Use candles,matches or open flames of any kind on
or near a tent.
- Leave campfire unattended.
- Leave children unattended inside a tent.
- Use fuel-burning,oxygen-consuming devices (heaters,
lanterns,cooking stoves or other flame sources) inside
your tent.
- Build campfires upwind of a tent.
- Refuel lamps,heaters or stoves inside a tent.
- Smoke inside a tent.
- Store flammable liquids inside a tent.
- Use water repellent compounds on your tent other
than those recommended for use on outdoor
equipment.
- Spray the tent with insecticide.
- Store tent on concrete floor.
DO...
- Always extinguish campfire before sleeping or
leaving the area.
- Exercise care when using electricity and lighting in
and near tents.
- Make certain your tent is properly ventilated in all
weather conditions.In extreme weather conditions,
snow could obstruct airflow and cause asphyxiation
unless cleared frequently.
- Anchor your tent securely to provide additional
security in changing conditions.Snow pegs,skis and/
or heavy rocks may be necessary to supplement
tent stakes and guy cords.
- Take your tent down and store properly after
camping.
20MM
Two Year Warranty
This tent carries a two years manufacturer's warranty against
defects in workmanship and materials. Should this tent become
defective within two years of purchase, please contact us. You
will be required to provide proof of purchase.
What is not covered by the warranties:
Warranties DO NOT cover normal wear and tear,misuse,mildew
and rotting caused by storage of a damp tent,or damaged and
fading caused by prolonged exposure to UV rays.
REPLACEMENT PARTS
For missing parts or broken poles,
please call customer service at:
Website: Visit www.tahoegear.com
Toll Free: 855-TAHOE-20
(855-824-6320)
Email: [email protected]
TENT STAKES
1
1
1
1
1
6
6
20
POLES
GUY ROPES
2STEEL POLES
QUANTITY
ITEMS
TENT BAG
POLE BAG
PEG BAG
FLY
TENT
DTP019-17C-1(TGT-ZION-9-B) COMPONENT CHECK LIST
