Taiden HCL Series User manual

HCL series Line Array Column Loudspeaker
Installation and Operating Manual
V 1.0

HCL series Line Array Column Loudspeaker
HCL-1200A Line Array Column Loudspeaker
Features:
■Compact design, natural and high- quality sound
■Built-in 8 2.5-inch full-frequency drivers
■Wide frequency range and enhanced performance:
Characterized with wider bandwidth, has the lowest frequency
at 80 Hz. Constant resistance (8 Ω) power mode for higher
output level
■Switchable Speech/Music mode
■Built-in 70V/100V transformer, plus 8 Ωdirect capability
■Coverage pattern: Horizontal: 150°, Vertical: 20°
■Professional line array sound column, with uniform sound field
coverage, higher transmission gain and hardly howling. Solve
the sound reinforcement requirement in the environment with
sound defect
■Enclosure designed IP-54 rate, per IEC529 allows use in a wide
of adverse conditions
■Fiberglass reinforced ABS cabinet with UV resistant
■Wall-mount (with swivel (pan)/tilt wall bracket) or stand-mount
Overview:
HCL-1200A Line Array Column Loudspeaker, composed of eight
full-range drivers, features natural and high-quality sound in a
compact and exquisite enclosure. It offers rich and nice middles,
and crisp and sweet highs. Thanks to its wide and even sound field,
HCS-1200A can be used for various applications such as in
conference room, lecture hall, ballroom, auditorium and classroom.
The internal speaker units arrayed vertically in close proximity form
a linear sound source, which guarantees better coverage and less
susceptibility to feedback at a longer throw distance. A multi-way full
range loudspeaker characterized with wider bandwidth, has the
lowest frequency at 80 Hz. Default constant resistance mode (8 Ω)
for higher output level.
HCL-1200A is versatile by accommodating different applications
with enhanced mid-range output in Speech mode and more flat
response in Music mode.
Enclosure designed IP-54 rate IEC 529 allows use in a wide range
of adverse conditions such as wet, dirty or corrosive environments.
Specifications:
Components
Eight 2.5 inch full-range
Frequency response
80 Hz ~ 18 kHz (-10 dB)
Coverage pattern Horizontal: 150°
Vertical: 20
°
Sensitivity
(2.83 V@1 m)
93 dB (speech mode)
89 dB (music mode)
Specifications:
Impedance
8 Ω
Power capacity (8 Ω) 200 W (800 W peak), 2 hrs
120 W (480 W peak), 100 hrs
Max. SPL 120 dB (speech mode)
117 dB (music mode)
70V/100V
transformer taps
60 W, 30 W, 15 W, 7.5 W at 70V only,
and 8 Ωthru, via switch
EQ
Speech v. Music: 2.5-4 dB
（
@2-5 kHz
）
Enclosure Fiberglass reinforced ABS cabinet,
painted aluminum grille
Outdoor capability IP-54 rated, per IEC529, moisture- and
water-proof, dust-proof, water-proof
cable gland
Colors
Black or White
Insert Eight M6 swivel (pan)/tilt insert points
on back panel
Mounting Included swivel (pan) / tilt wall bracket
provides continuously variable ±80
degree left-right swivel aiming,
continuously adjustable ±15 degree tilt,
as well as 5 degree fixed increment
points within the range.
Dimensions (
h
× w × d)
620×102×155 mm
Weight
5.3 kg
Accessories
Swivel (pan)/tilt wall bracket
HCL-1200A_B Line Array Column Loudspeaker (8 Ω, 200 W, 70V/100V transformer & 8 ohm direct capability, black)
HCL-1200A_W Line Array Column Loudspeaker (8 Ω, 200 W, 70V/100V transformer & 8 ohm direct capability, white)
1

HCL series Line Array Column Loudspeaker
HCL-1200 Line Array Column Loudspeaker
Features:
■Compact design, natural and high- quality sound
■Built-in 8 2.5-inch full-frequency drivers
■Wide frequency range and enhanced performance:
Characterized with wider bandwidth, has the lowest frequency
at 80 Hz. Constant resistance (8 Ω) power mode for higher
output level
■Switchable Speech/Music mode
■Coverage pattern: Horizontal: 150°, Vertical: 20°
■Professional line array sound column, with uniform sound field
coverage, higher transmission gain and hardly howling. Solve
the sound reinforcement requirement in the environment with
sound defect
■Enclosure designed IP-54 rate, per IEC529 allows use in a wide
of adverse conditions
■Fiberglass reinforced ABS cabinet with UV resistant
■Wall-mount (with swivel (pan)/tilt wall bracket) or stand-mount
Overview:
HCL-1200 Line Array Column Loudspeaker, composed of eight
full-range drivers, features natural and high-quality sound in a
compact and exquisite enclosure. It offers rich and nice middles,
and crisp and sweet highs. Thanks to its wide and even sound field,
HCS-1200 can be used for various applications such as in
conference room, lecture hall, ballroom, auditorium and classroom.
The internal speaker units arrayed vertically in close proximity form
a linear sound source, which guarantees better coverage and less
susceptibility to feedback at a longer throw distance. A multi-way full
range loudspeaker characterized with wider bandwidth, has the
lowest frequency at 80 Hz. Default constant resistance mode (8 Ω)
for higher output level.
HCL-1200 is versatile by accommodating different applications with
enhanced mid-range output in Speech mode and more flat
response in Music mode.
Enclosure designed IP-54 rate IEC 529 allows use in a wide range
of adverse conditions such as wet, dirty or corrosive environments.
Specifications:
Components
Eight 2.5 inch full-range
Frequency response
80 Hz ~ 18 kHz (-10 dB)
Coverage pattern Horizontal: 150°
Vertical: 20
°
Sensitivity
(2.83 V@1 m)
93 dB (speech mode)
89 dB (music mode)
Impedance
8 Ω
Power capacity (8 Ω) 200 W (800 W peak), 2 hrs
120 W (480 W peak), 100 hrs
Max. SPL 120 dB (speech mode)
117 dB (music mode)
EQ
Speech v. Music: 2.5-4 dB
（
@2-5 kHz
）
Enclosure Fiberglass reinforced ABS cabinet,
painted aluminum grille
Outdoor capability IP-54 rated, per IEC529, moisture- and
water-proof, dust-proof, water-proof
cable gland
Colors
Black or White
Insert Eight M6 swivel (pan)/tilt insert points
on back panel
Mounting Included swivel (pan) / tilt wall bracket
provides continuously variable ±80
degree left-right swivel aiming,
continuously adjustable ±15 degree tilt,
as well as 5 degree fixed increment
points within the range.
Dimensions (
h
× w × d)
620×102×155 mm
Weight
5.3 kg
Accessories
Swivel (pan)/tilt wall bracket
HCL-1200_B Line Array Column Loudspeaker (8 Ω, 200 W, black)
HCL-1200_W Line Array Column Loudspeaker (8 Ω, 200 W, white)
2

HCL series Line Array Column Loudspeaker
HCL-1400A Line Array Column Loudspeaker
Features:
■Compact design, natural and high- quality sound
■Built-in 16 2.5-inch full-frequency drivers
■Wide frequency range and enhanced performance:
Characterized with wider bandwidth, has the lowest frequency
at 80 Hz. Constant resistance (8 Ω) power mode for higher
output level
■Switchable Speech/Music mode
■Built-in 70V/100V transformer, plus 8 Ωdirect capability
■Coverage pattern: Horizontal: 150°, Vertical: adjustable
board/narrow
■Professional line array sound column, with uniform sound field
coverage, higher transmission gain and hardly howling. Solve
the sound reinforcement requirement in the environment with
sound defect
■Enclosure designed IP-54 rate, per IEC529 allows use in a wide
of adverse conditions
■Fiberglass reinforced ABS cabinet with UV resistant
■Wall-mount (with swivel (pan)/tilt wall bracket) or stand-mount
Overview:
HCL-1400A Line Array Column Loudspeaker, composed of sixteen
full-range drivers, features natural and high-quality sound in a
compact and exquisite enclosure. It offers rich and nice middles,
and crisp and sweet highs. Thanks to its wide and even sound field,
HCS-1400A can be used for various applications such as in
conference room, lecture hall, ballroom, auditorium and classroom.
The internal speaker units arrayed vertically in close proximity form
a linear sound source, which guarantees better coverage and less
susceptibility to feedback at a longer throw distance. A multi-way full
range loudspeaker characterized with wider bandwidth, has the
lowest frequency at 80 Hz. Default constant resistance mode (8 Ω)
for higher output level.
HCL-1400A is versatile by accommodating different applications
with enhanced mid-range output in Speech mode and more flat
response in Music mode.
Enclosure designed IP-54 rate IEC 529 allows use in a wide range
of adverse conditions such as wet, dirty or corrosive environments.
Specifications:
Components
Sixteen 2.5 inch full-range
Frequency response
80 Hz ~ 18 kHz (-10 dB)
Coverage pattern Horizontal: 150°
Vertical: narrow: 15°, board: 40°
Sensitivity
(2.83 V@1 m) Narrow: 96 dB (speech mode) 93 dB (music mode)
Broad: 93 dB (speech mode)
90 dB (music mode)
Impedance
8 Ω
Power capacity (8 Ω) 400 W (1600 W peak), 2 hrs
240 W (960 W peak), 100 hrs
Specifications:
Max. SPL Narrow: 132 dB (speech mode)
129 dB (music mode)
Broad: 129 dB(speech mode)
126 dB (music mode)
70V/100V
transformer taps
120 W, 60 W, 30 W, 15 W at 70V only,
and 8 Ωthru, via switch
EQ
Speech v. Music: 2.5-4 dB
（
@2-5 kHz
）
Enclosure Fiberglass reinforced ABS cabinet,
painted aluminum grille
Outdoor capability IP-54 rated, per IEC529, moisture- and
water-proof, dust-proof, water-proof
cable gland
Colors
Black or White
Insert Ten M6 swivel (pan)/tilt insert points on
back panel
Mounting Included swivel (pan) / tilt wall bracket
provides continuously variable ±80
degree left-right swivel aiming,
continuously adjustable ±15 degree tilt,
as well as 5 degree fixed increment
points within the range.
Dimensions (
h
× w × d)
1180×102×155 mm
Weight
9.0 kg
Accessories
Swivel (pan)/tilt wall bracket
HCL-1400A_B Line Array Column Loudspeaker (8 Ω, 400 W, 70V/100V transformer & 8 ohm direct capability, black)
HCL-1400A_W Line Array Column Loudspeaker (8 Ω, 400 W, 70V/100V transformer & 8 ohm direct capability, white)
3

HCL series Line Array Column Loudspeaker
HCL-1400 Line Array Column Loudspeaker
Features:
■Compact design, natural and high- quality sound
■Built-in 16 2.5-inch full-frequency drivers
■Wide frequency range and enhanced performance:
Characterized with wider bandwidth, has the lowest frequency
at 80 Hz. Constant resistance (8 Ω) power mode for higher
output level
■Switchable Speech/Music mode
■Coverage pattern: Horizontal: 150°, Vertical: adjustable
board/narrow
■Professional line array sound column, with uniform sound field
coverage, higher transmission gain and hardly howling. Solve
the sound reinforcement requirement in the environment with
sound defect
■Enclosure designed IP-54 rate, per IEC529 allows use in a wide
of adverse conditions
■Fiberglass reinforced ABS cabinet with UV resistant
■Wall-mount (with swivel (pan)/tilt wall bracket) or stand-mount
Overview:
HCL-1400 Line Array Column Loudspeaker, composed of sixteen
full-range drivers, features natural and high-quality sound in a
compact and exquisite enclosure. It offers rich and nice middles,
and crisp and sweet highs. Thanks to its wide and even sound field,
HCS-1400 can be used for various applications such as in
conference room, lecture hall, ballroom, auditorium and classroom.
The internal speaker units arrayed vertically in close proximity form
a linear sound source, which guarantees better coverage and less
susceptibility to feedback at a longer throw distance. A multi-way full
range loudspeaker characterized with wider bandwidth, has the
lowest frequency at 80 Hz. Default constant resistance mode (8 Ω)
for higher output level.
HCL-1400A is versatile by accommodating different applications
with enhanced mid-range output in Speech mode and more flat
response in Music mode.
Enclosure designed IP-54 rate IEC 529 allows use in a wide range
of adverse conditions such as wet, dirty or corrosive environments.
Specifications:
Components
Sixteen 2.5 inch full-range
Frequency response
80 Hz ~ 18 kHz (-10 dB)
Coverage pattern Horizontal: 150°
Vertical: narrow: 15°, board: 40°
Sensitivity
(2.83 V@1 m) Narrow: 96 dB (speech mode) 93 dB (music mode)
Broad: 93 dB (speech mode)
90 dB (music mode)
Impedance
8 Ω
Power capacity (8 Ω) 400 W (1600 W peak), 2 hrs
240 W (960 W peak), 100 hrs
Specifications:
Max. SPL Narrow: 132 dB (speech mode)
129 dB (music mode)
Broad: 129 dB(speech mode)
126 dB (music mode)
EQ
Speech v. Music: 2.5-4 dB
（
@2-5 kHz
）
Enclosure Fiberglass reinforced ABS cabinet,
painted aluminum grille
Outdoor capability IP-54 rated, per IEC529, moisture- and
water-proof, dust-proof, water-proof
cable gland
Colors
Black or White
Insert Ten M6 swivel (pan)/tilt insert points on
back panel
Mounting Included swivel (pan) / tilt wall bracket
provides continuously variable ±80
degree left-right swivel aiming,
continuously adjustable ±15 degree tilt,
as well as 5 degree fixed increment
points within the range.
Dimensions (
h
× w × d)
1180×102×155 mm
Weight
9.0 kg
Accessories
Swivel (pan)/tilt wall bracket
HCL-1400_B Line Array Column Loudspeaker (8 Ω, 400 W, black)
HCL-1400_W Line Array Column Loudspeaker (8 Ω, 400 W, white)
4

HCL series Line Array Column Loudspeaker
HCL-1800U+HCL-1800D Line Array Column Loudspeaker
Features:
■Compact design, natural and high- quality sound
■Built-in 32 2.5-inch full-frequency drivers
■Wide frequency range and enhanced performance:
Characterized with wider bandwidth, has the lowest frequency
at 80 Hz. Constant resistance (4 Ω) power mode for higher
output level
■Switchable Speech/Music mode
■Coverage pattern: Horizontal: 150°, Vertical: adjustable
board/narrow
■Professional line array sound column, with uniform sound field
coverage, higher transmission gain and hardly howling. Solve
the sound reinforcement requirement in the environment with
sound defect
■Enclosure designed IP-54 rate, per IEC529 allows use in a wide
of adverse conditions
■Fiberglass reinforced ABS cabinet with UV resistant
■Wall-mount (with swivel (pan)/tilt wall bracket)
Overview:
HCL-1800 Line Array Column Loudspeaker, composed of thirty-two
full-range drivers, features natural and high-quality sound in a
compact and exquisite enclosure. It offers rich and nice middles,
and crisp and sweet highs. Thanks to its wide and even sound field,
HCS-1800 can be used for various applications such as in
conference room, lecture hall, ballroom, auditorium and classroom.
The internal speaker units arrayed vertically in close proximity form
a linear sound source, which guarantees better coverage and less
susceptibility to feedback at a longer throw distance. A multi-way full
range loudspeaker characterized with wider bandwidth, has the
lowest frequency at 80 Hz. Default constant resistance mode (4 Ω)
for higher output level.
HCL-1800 is versatile by accommodating different applications with
enhanced mid-range output in Speech mode and more flat
response in Music mode.
Enclosure designed IP-54 rate IEC 529 allows use in a wide range
of adverse conditions such as wet, dirty or corrosive environments.
Specifications:
Components
Thirty-two 2.5 inch full-range
Frequency response
80 Hz ~ 18 kHz (-10 dB)
Coverage pattern Horizontal: 150°
Vertical: narrow: 15°, board: 30°
Sensitivity
(2 V@1 m) Narrow: 95 dB (speech mode) 92 dB (music mode)
Broad: 92 dB (speech mode)
89 dB (music mode)
Impedance
4 Ω
Power capacity (4 Ω) 800 W (3200 W peak), 2 hrs
480 W (1920 W peak), 100 hrs
Specifications:
Max. SPL Narrow: 135 dB (speech mode)
132 dB (music mode)
Broad: 132 dB(speech mode)
129 dB (music mode)
EQ
Speech v. Music: 2.5-4 dB
（
@2-5 kHz
）
Enclosure Fiberglass reinforced ABS cabinet,
painted aluminum grille
Outdoor capability IP-54 rated, per IEC529, moisture- and
water-proof, dust-proof, water-proof
cable gland
Colors
Black or White
Configuration Two pieces (HCL-1800U (top half) and
HCL-1800D (bottom half, with TAIDEN
logo) half), each 1180 m
m tall,
connected together via Coupler Plate.
Top/bottom orientation of each piece
must be observed.
Insert Eight M6 coupler plate insert points on
back panel,
Four M6 swivel (pan)/tilt insert points
on coupler plate
Mounting Included swivel (pan) / tilt wall bracket
(must be mounted to threaded points
on coupler plate) provides continuously
variable ±80 degree left-right swivel
aiming, continuously adjustable ±5
degree tilt, as well as 5 degree fixed
increment points within the range.
Dimensions (h
× w × d)
2360×102×155 mm
Weight
9.0 kg
Accessories Swivel (pan)/tilt wall bracket,
coupler plate
HCL-1800U_B + HCL-1800D_B Line Array Column Loudspeaker (4 Ω, 800 W, black)
HCL-1800U_W + HCL-1800D_W Line Array Column Loudspeaker (4 Ω, 800 W, white)
5

HCL series Line Array Column Loudspeaker
CBL-SPK Speaker Cable
Features:
■Audio cable for HCL-1200 series and HCL-1400 series Line Array Column
Loudspeaker
■Length of per roll: 305 meter
■Weight of per roll: 14 kg
■Color: white
CBL-SPK Speaker cable (For HCL-1200 series and HCL-1400 series Line Array Column Loudspeaker, 305 m per roll, white, unit: meter )
CBL-SPK3 Speaker Cable
Features:
■Audio cable for HCL-1800U+HCL-1800D Line Array Column Loudspeaker
■Length of per roll: 150 meter
■Weight of per roll: 18 kg
■Color: white
CBL-SPK3 Speaker cable (For HCL-1800U+HCL-1800D Line Array Column Loudspeaker, 150 m per roll, white, unit: meter)
6

HCL series Line Array Column Loudspeaker
Dimensions (unit: mm):
Dimensions of HCS-1200 series Line Array Column Loudspeaker (unit: mm)
Dimensions of swivel (pan) / tilt wall bracket (unit: mm)
7

HCL series Line Array Column Loudspeaker
Dimensions of HCS-1400 series Line Array Column Loudspeaker (unit: mm)
8

HCL series Line Array Column Loudspeaker
Dimensions of HCS-1800U+HCL-1800D Line Array Column Loudspeaker (unit: mm)
HCL-1800D
with TAIDEN logo
HCL-1800U
9

HCL series Line Array Column Loudspeaker
Installation of HCL-1200 series, HCL-1400 series and HCL-1800
Explanation: wall bracket consists of a speaker bracket and a wall bracket.
Speaker bracket 1 PM6×12 mm screws 4 M6×70 mm screws 4 Wall bracket 1
Flat washers 4 Lock washers 4
Coupler Plate 1 PM6×25 mm screws 8, only for HCL-1800U+HCL-1800D
1. Wiring: run the wiring between the amplifier and the location desired for mounting the loudspeakers;
2. Attach wall bracket to wall: secure the wall bracket to the wall according the following dimensions, please using a level to ensure the wall
bracket is straight. Use the appropriate wall anchors for attaching the bracket, the provided screws (M6×70 mm) are for hard wall such
as cement wall. Be sure that the slot feature is at the top.
Note: installation must be done by qualified persons using safe rigging standards, and please use all four screw holes for maximum
integrity and safety.
3. Attach speaker bracket to speaker: mount the speaker bracket to the speaker with four provided PM6×12 mm screws, lock washers
and flat washers.
HCL-1200: there are two optional mounting locations for attach speaker bracket, top and middle locations, as shown in the
following figure, and all the mounting locations support ±80 degree swivel (pan) and ±15 degree tilt angles. Middle mounting
location is recommended.
Toward down
Toward up
Top mounting location
Middle mounting location
10

HCL series Line Array Column Loudspeaker
HCL-1400: there are three optional mounting locations for attach speaker bracket, top, middle and bottom locations, as shown in
the following figure, and all the mounting locations support ±80 degree swivel (pan) and different tilt angles. Middle mounting
location is recommended.
Top mounting location: 15 degree down-tilt and 15 degree up-tilt
Middle mounting location: 15 degree down-tilt and 15 degree up-tilt
Bottom mounting location: 15 degree down-tilt and 10 degree up-tilt
Bottom mounting location
Middle mounting location
Top mounting location
11

HCL series Line Array Column Loudspeaker
HCL-1800U (top half) and HCL-1800D(bottom half) Line Array Column Loudspeaker needs to be firmly connected by coupler
plate, and then fixed the speaker bracket onto the coupler plate (ONLY fixed on coupler plate, not on other mounting location), and
it supports ±80 degree swivel (pan) and ±5 degree tilt angles
Note: because HCL-1800U (top half) and HCL-1800D(bottom half) Line Array Column Loudspeaker is too long, it should not be
moved after fixed with the coupler plate without fixed onto the speaker bracket, so as not to damage the box.
Coupler plate
PM6×25 mm PM6×12 mm
HCL-1800U, toward up
HCL-1800D, toward down
12

HCL series Line Array Column Loudspeaker
4. Slide speaker with speaker bracket onto wall bracket: when the above steps have finished, slide the speaker forward so that the speaker
bracket engages into the wall bracket, dropping the hook slot of the speaker bracket onto the pivot bolt (PM6×35) (which will already be
installed loosely in the wall bracket)
5. Set the tilt angle: if the speaker has nested securely on the pivot bolt, disassemble the PM6×35 mm bolt in the top of the bracket, and
then slide it into one of the holes in the top of the wall bracket.
13

HCL series Line Array Column Loudspeaker
6. Set the swivel (pan) angle: loosen the top and bottom bolts on the pivot, adjust swivel aiming angle of the speaker, then tighten the bolts
again.
Tighten bolt
Tighten bolt
14

Copyright by TAIDEN
Last Revision: 07/2019
TAIDEN INDUSTRIAL CO., LTD.
6/F, Block B, Future Plaza, 6060 Qiaoxiang Rd, Nanshan District, Shenzhen, China
P.C.: 518053
Website: http://www.taiden.com
