Talenti Casa Astor TC-MT05CLR User manual

ASSEMBLY INSTRUCTIONS
Thank your for selecting one of our pieces to become part of your home. We are here to guide you during the assembly.
If you need help or need extra hardware simply contact our support team at [email protected] or call us at
1(800) 652-6344. Mon-Fri 9:00am - 5:00pm EST. Talenti Casa is Registered Trademark distributed by Casabianca Home.
• Assemble this product on a soft surface to prevent scratching
the product.
• Hardware can be found inside drawers or underneath the product.
• Do not discard any of the packaging until you have successfully
assembled the product.
Unpack Box #4; the base of
the table, and place it in the
area where you would like to
set the table.
ASSEMBLY TIPS
STEP 1
Unpack Box #3; the frame of
the table.When unpacking it,
do NOT remove the four (4)
plastic tie straps.
STEP 2
Care Instructions Case goods (C): Dust with a soft, dry cloth.
All spills should be cleaned up immediately. Use glass cleaners
on glass only. DO NOT use any abrasive cleaning supplies.
CARE INSTRUCTIONS
1
WARNING: DO NOT LEAVE
CHILDREN UNATTENDED
WHILE INSTALLING OR
OPERATING THE MOTORIZED
TABLE. THIS IS NOT A TOY
AND SHOULD NOT BE
MANAGED BY CHILDREN.
TABLE COULD CLOSE
UNEXPECTEDLY.
PLEASE USE CAUTION.
hey!
im not your
typical table
I am motorized

Insert screw #M8 x 12mm and
tighten it with the Hex key
provided.
Place the frame upside
down on top of a blanket
or foam.
STEP 5
STEP 3
Then place the base
on top and align the
four (4) holes of the
base with the four (4)
holes on the frame on
each end.
.
STEP 4
Adjust the bottom levelers if
the table is not leveled.(This
step is only available with
certain bases).
STEP 7
Open Box #1; Main center
top. Turn it upside down and
screw the 4 level wheels all
the way to the end.
STEP 8
Flip the table
STEP 6
2

Locate the key hole under
the table, insert the safety
key and turn on power.
Instruct the user this key is
for CHILD SAFETY.
Place the center glass on
top of the rails and make
sure the pins go inside
the four (4) cylinders on
the frame. .
STEP 11
STEP 9
Remove the four
(4) plastic tie raps
and make sure the
extension bars are
down.
.
STEP 10
Unpack Box #2; the side extensions.
Place screw M8 x 25mm with no
Head on each extension and tighten.
STEP 13
Place the adjusting
wheel on the screw
(This adjusting wheel
will dictate the height
of the glass and later
will be used to align
with the glass top)
STEP 14
Extend the table
extensions by pressing
and holding the
buttons on the table.
STEP 12
3

Tighten the extensions
with the M8 Cap screw.
Tighten center top with
small Hex key provided
Place each extension
carefully on top of the
metal frame, align the
sides with the center
top.
STEP 16 STEP 17
STEP 15
1. Locate the receiver and battery pack box from under the table.
2.Make sure power is on. Then unscrew only highlighted screws, this
will release the box out.
4
TROUBLESHOOT MANUAL
1. 2.
