Talos Security MBB-10 Manual
WWW.TALOSSECURITY.COM
Head Office
705 Pleasant Valley Drive
Springboro, Ohio 45066 USA
937-550-0239 Office
888-980-8042 Toll Free
Instruction Guide
Mobile Black Box DVR
MBB-10
The Company is not responsible for any consequential damage in connection with use of the
Product as the Product is not contributing to a car accident directly or indirectly. The
Company is responsible for defect on the Product itself only.Product settings while driving is
dangerous and may lead to a road accident and‘Event’management may not function under
a certain type of impact.
3
7
8
9
10
11
15
16
17
19
23
26
27
Caution for Safety
Product Features
ComponentsDetails
Contents
How to Insert Card
Main Functions
Check on Terminal Status
Program Execution
Program Installation
Program Manual
How To Play Recorded
Firmware Update
Measure for Disorder
Product Warranty
28
Safety Cautions
This chapter provides safety information to prevent misuse or abuse of the Product which may lead
to the risks of personal injuries or physical damages by electric shock, fire or explosion.
Please read this chapter before use.
★Contents of this User’s Manual may differ from one to another version of CARPA-10 software,
and are subject to change without prior notice to users. For the latest information, please
refer to our website www.dstelecom.co.kr.
★Illustrations and pictures contained in this Manual may be different to the actual product.
★You can upgrade the software for CARPA-10 firmware by yourself.
www.dstelecom.co.kr ▶Login ▶Support ▶Download ▶Install Program (P17)
★Please refer for firmware upgrade(P26)
Safety Cautions
3
Do not install, dismantle or convert
the Product at your will. It may
cause product breakdown, electric
shock or fire. Please contact the
Service Center for repair.
Do not change the installation
position of the Product. It may
result in creation of blind spots in
recording, and you may apportion
blame for an accident.
Do not operate the Product while
driving. It may cause a road
accident. Park the vehicle in the
designated parking area to operate
the Product.
Always use the correct type of fuse.
Wrong type of fuse may cause fire.
If you experience a trouble with the
Product, do not attempt to operate
the Product. If any foreign material
or water got into the Product, or
there is smoke from the Product,
contact the Service Center for
repair.
For connection to the main power
using a power cable, let an
authorized technician to do the
work. The connection may vary by
car, and wrong connection may
lead to breakdown of the car or the
Product.
Take care that the power cable of the Product is not damaged or cut during installation
of other electric device inside the car. It may cause product breakdown, electric shock
or fire. Please contact the Service Center for repair.
Warning
Warning
4
Do not remove the SD card while
the power is connected. It may
cause breakdown of the card.
Do not use water, benzene or
alcohol to clean the Product. It
may cause Product failure. Use a
dry soft cloth.
Do not exert excessive impact on
the Product. It may cause damage
to or breakdown of the Product
Always use the original or
recommended card only to
prevent data loss.
The GPS module requires a
warming up period for the initial
operation. It may take from several
seconds to a few minutes upon
turning the power ON depending
on the transmission environment.
Communication error or GPS transmission error
may be experienced if the windshield is metal
coated.
Do not touch the SD card with oily
or wet hand. It may cause damage
to or breakdown of the Product
Do not insert any foreign material
in the opening of the card slot on
the Product. It may cause blockage
or breakdown of the Product.
Take care that connection is
properly made if the cigar jack is
in use. Improper connection may
cause data loss or card failure.
Caution
Caution
5
1. Do not install, dismantle or convert the Product at your will.
2. If any part is used in addition to the parts provided by the Company, please use the original or the Company
recommended parts only.
3. Do not operate the Product outside the recommended power range.
4. Remove any material or heavy coating which may hinder video recording.
5. A change in position of the Product may lead to changes in camera angles. Adjust the camera angle and
check the recorded image.
6. Product damage or power disconnection by major accident may disable video recording.
7. In case of an accident, remove the power jack and remove the SD memory card. The corresponding incident
may have been stored as an erasable normal recording instead of an Event recording. Please check the
recorded file.
8. Do not remove the SD memory card or turn the power off while data is stored to, or loaded or deleted from
the SD memory card.
9. Check data stored in the SD memory card to see if the Product is operating properly. Format the SD
memory card regularly.
10. Always use the recommended SD memory card to prevent data loss or product failure.
11. Do not dismantle or convert the SD memory card.
12. The battery level monitoring function may be turned off unexpectedly due to an abnormality of the car,
battery or by accessories fitted to the car.
Cautions
Cautions
6
Product Features
This Product is a device (the black box) to be installed inside the car, for recording of sounds and views at the front of the car
and inside the car to secure evidences of road accident, parking damage, theft or violence of passengers as well as to induce
safe driving.
Product Features
7
Optimum Image Quality
1.3 Mega pixel
SD/SDHC Flash Memory
Shock Detection
3D G-Sensor
Continuous Recording
Event Recording
Private PC software
Print out picture
convert to JPEG file
Built in battery for data
secure
Free Voltage
Emergency Recording
Button
No. Name Description
Inside LED Inner side Red, Blue, Purple LED Steady & Flashing
illumination sensor LED
Camera Vehicle’s front side recording (1.3Mega CMOS)
SD Card slot To save recorded data into a SD card
Emergency record Button Driver Panic & Emergency recording S/W
Front LED Front Blue LED Steady & Flashing
GPS Terminal To receive satellite radio (global positioning information)
AV-out Terminal To connect the AV cable
Power jack To connect the external power port
Recording sensitivity control by Automatically
Brightness sensor detected.
Compenents
8
Components
간단설치 설명서
TheCompany is not responsible for any consequential damage in connection with use of the
Product as the Product is not contributing to a car accident directly or indirectly.The
Companyis responsible for defect on the Product itself only.Product settings while driving is
dangerousand may lead to a road accident and‘Event’ management may not function under
acertain type of impact.
User’sManual
Product
Content
Product Content
9
Instruction Guide
Digital Video Recorder
CARPA-10
TheCompany is not responsible for any consequential damage in connection with use of the
Product as the Product is not contributing to a car accident directly or indirectly.The
Companyis responsible for defect on the Product itself only.Product settings while driving is
dangerousand may lead to a road accident and‘Event’ management may not function under
acertain type of impact.
※The warranty period for the SD memory card is 6 months, and for all other parts is 1 month.
※ Pictures of the parts may differ from the actual. Some parts may change in certain circumstances.
CARPA-10 Main Body User’s Manual SD Card reader SD memory card
Quick Installation
Guide
Installation
components
Cigar jack
Options
(sold separately)
DC fuse power cable
(Optional Item)
AV OUT cable
Window
Mount & GPS
To Insert Card
10
To Insert Card
Insert the SD card before supplying power. The cut corner of the card should face downward when inserting.
Lower the slot cover and insert the card to the end. (you will feel the card locking when fully inserted.)
Check the direction of SD Card. You should
insert by turning it over for invisible label
and facing a cut-off corner part upward.
Caution
Insert the card to the end to avoid card
failure. The golden area (the connection
area) on the card should not be touched by
hand or foreign materials to avoid card
damage. Do not use the card for any other
application than its original purposes.
Some of the recommended SD cards may
not be compatible if their (production) lots
are not original.
If you require more memory than the SD card provided with the Product package, we recommend
Transcend and SanDisk. For SD cards of 4G ~ 32G, please refer to the recommended list.
Compatible cards: 2G ~ 32G SD, SDHC, CLASS 6
Always use the recommended SD memory card!
Main Functions
Main Functions
11
※Insert a SD card, connect the power supply, and the front side recording will begin.
(Red color LED flashingbeeper soundLED flashing(Inner: Purple, front: Blue)
※If the SD card is to be removed, wait until the lamp is completely turned off to avoid card failure.
In case of a car accident, turn the power off on the Product and remove the SD card for safe keeping.
(Otherwise, old data may be written off by new recordings.
Data containing the accident should be kept safely as evidence.)
Options
(sold separately)
Video recording
Inner side LED
Power jack Power
jack
Front side LED
SD memory card
(2GB~32GB
Main Functions
Emergency Saving Switch Installation on Mount (GPS Antenna)
Inner side LED
GPS
Connection Jack
12
If emergency saving switch (REC button) is pressed,
relevant video is saved as event and will not be
deleted unless random deletion is done. The relevant
file is saved as event file.
Installation on Mount with a built-in GPS
Tighten connection bolts of main body and mount.
Then, connect is GPS in slot at right upper part of
main body.
(DC FUSE POWER CABLE)
Main Functions
13
DC Fuse power cable(Option)
Power jack
Shock sensor sees collision while driving as main issue. Since shock sensor is weak during parking lot collision,
compared with collision while driving, to supplement its weakness, there is a function, with which user can adjust
sensor sensitivity. Enough SD card memory should be secured to save general recording files enough.
In case of connection to continuous power, shooting can be made continuously 24 hours. Battery monitoring
function shuts off power prior to battery discharge. Since installation method varies depending upon the vehicle in
case of installation on continuous power or A/S. check with professional engineer to see if there is no trouble on
safety and function. This is required for safety and protection of consumer.
Power Consumption: 1.5 W based on 12 V
AV Out Function
AV Out Function
Connect the power
after pressing emergency
saving button
( Only after perchasing AV CABLE )
14
Current screen can be seen at navigator (Monitor Output: PAL / NTSC compatible)
Audio Guide: Tti~ Dick Dick(Beeper sound)
After audio guide, take your hand off from the button after 3 seconds later.
If power is removed, AV Out Function is released.
Navigation Cable
AV CABLE (option sales)
0.5 sec.
0.3 sec.
1 Sec.
0.1 Sec., 3 times
Status Voice Message
Status Buzzer Buzzer Sd. Interval Repetition
Rear Front
Power ON
Continuous Recording
Event Recording
SD Card Trouble
Install Mode
Power “on”
When power is authorized initially, one time for 0.5 seconds
Event Full
In case of data deletion by event is necessary
Device Trouble
Event Formation
When shock is detected and event is formed
No insertion or wrong insertion of SD card /
Insufficient storage capacity / other errors
Initial one time
5 Sec.
If “yes,” one time
None
Repetition 10 seconds each for 3 minutes
10 times per hour
None
Two times with
0.5 sec. interval
Red LED inside is turned on.
Violet LED inside and Blue LED outside blink.
Violet LED inside and Blue LED outside are turned on.
Violet LED inside and Blue LED outside blink fast.
Violet LED inside and Blue LED outside are turned on.
Device Status Check (Check LED blinking display part)
Device Status Check
15
LED
Red Blue Blue
Steady
Flashing
Steady
Flashing
Steady
Flashing
0.5 sec.
0.3 sec.
1 Sec.
0.1 Sec., 3 times
PC Software
16
CPU: Pentium 4/1 GHz or up Memory: 512 MB RAM or up OS : WINDOWS XP, VISTA(partial) HDD : 500MB or up support
PC Software
Recommended PC Specification
Company Logo
Car Plate Number and Date & Time
Play Video
Speed Display
Direction Display
Play Hour
Play Speed
Play Volume
Minimization / End
List Deleting
File Opening
File List
Map Screen
Setup
Viewer Control
CARPA PC Software is provide insert SD card file folder.
If you removed pc software then please download on our website (www.dstelecom.co.kr)
Installation is complete.
The carpa-10 icon is created on the background screen on the PC
PC Software Installation
PC Software Installation
17
2
3
4
Playback List
18
▪ 1View file location. / Select Directory
▪ 2 The selected files can be added to a Playlist.
▪ 3 View all files / Sort of Event files
▪ 4 If a file list exists, it is shown in the blue box area.
▪ The G-Sensor detected by the sensors located vertically, horizontally and on right and left, is
converted to numbers to indicate driving direction, turning direction and size and direction of
impact in an accident.
▪ To move to a previous or next file during playback of the selected file from the File List.
▪ To move to a previous or next file during playback of the selected file from the Event List.
Playback List
Playback List To delete all playback lists
To select a file to playback
Select file location ▶Select a mobile disk (SD card).
To open a file ▶Select file location ▶Select a mobile disk. ▶Confirm ▶Select a movie file to playback and click on the [▶] button.
The selected movie file is added to a
Playback List. Select a movie file to
playback and click on the [▶] button.
To run the program
To run the program
19
General
G sonsor
Button
To run the program
20
To identify type of recording files
To view Event
Files are saved at 1-minute intervals by hour and day for easy retrieval. Files are also
designated with letter (General) for normal recording, (Event) for event (such as
accident and impact) and (Button) for emergency outdoor recording by button, for
easy search.
Year/Month/Date_Hour,Mins_Second
Normal recording (N): A normal video recording
is saved by the unit of 1-minute. Files are sorted
by date and hour for easy search. If the memory
space is fully used, the oldest file is erased to
provide space for new recordings.
A video recording of impact of accident is saved
in the Event list.
An external switch button is used to record an
emergency event, and the file is saved as an
Event file.
Instead of viewing all files, only the Event files
can be viewed as the files are marked with
either (Event) or (Button) for easy and quick
search
Table of contents
