Talos Security VD960AW User manual

Note: Before providing power to the camara, please read this user guide in detail.
Do not attempt to disassemble the camera. If problems persist, please contact your local dealer or Talos Security.
VD960AW
AHD/960H Fixed 3.6mm Vandal IR Dome Camera
Introduction
Packing List
1
No Name Model Number
2
Thank you for your purchase of Talos product VD960AW.
Please read this instruction manual carefully to ensure proper use of
this equipment.
To prevent fire or shock hazard, do not expose the
unit to excessive rain or moisture.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
User Guide VD960AW 1
Vandalproof Dome Camera VD960AW 1
Unit : mm
94
69
Dimensions
- 1/4" 1MP CMOS Sensor
- AHD 720P and 960H Resolution
- 3.6mm Fixed Lens
Overview
52dB
DC 12V
WDR
DIGITAL
0
● 1/4" 1MP CMOS Sensor
● Built-in auto gain
● 130° ~ 28° angle field of view
● D-WDR (Digital Wide Dynamic Range)
● IR illuminators for seeing in the dark!
● Water resistance: IP66
Features
S/ N Ratio
Auto Gain Control
IR Distance
3-DNR & AGC
Operating Temp/Humidity
Storage Temp/Humidity
Dimensions
Weight
MECHANICAL
ENVIRONMENTAL
-10~50°C RH95% Max
Auto
OPERATIONAL
Angle Field of View
ELECTRICAL
VIDEO
Gama Characteristics 0.45
Model:
0.01 Lux/F1.2, 0 Lux (with IR LED ON )
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Auto Electronic Shutter
Specifications
VD960AW
12V DC (±10%), 500mA –650mA
3.6mm Fixed Lens
1/4" 1.0 Megapixel CMOS Sensor
Progressive
Internal, Negative sync
720p
Less than 50dB
1.0Vp-p, 75
450 g (1 lbs)
260 (W) x 98 (H) x 95 (D)
-30~+60°C RH95% Max
20 meters
8 Watt
70°
Input Voltage
Image Pick-up Device
Focal Length
Power Consumption
Scanning System
Synchronization
Horizontal Resolution
Min. Illumination
(Y signal)
On / Off (Low / Middle / High) Selectable
Video Output
LENS

VD960AW
AHD/960H Fixed 3.6mm Vandal IR Dome Camera
Troubleshooting
Connecting
Notes:
● The power supply must be installed in a dry location. Only use a
power supply with the proper voltage, current and polarity as
required by this camera.
● During severe weather, it is recommended that the product be
disconnected from the power source to prevent damage from
voltage spikes.
● For proper operation, avoid excessive cable lengths.
● Only use the camera in the proper operating temperature range
of -10º to 115ºF.
● Avoid installing in direct sunlight as this can damage the image sensor.
● Do not mount the camera near any heat source.
CAUTION:
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER OR BACK.
NO USER SERVICABLE PARTS INSIDE.
TO PREVENT ELECTRIC SHOCK AND RISK OF FIRE HAZARDS,
DO NOT USE OTHER THAN SPECIFIED POWER SOURCE.
DC12V
VIDEO
DC12V
Power Supply
Monitor/DVR
VIDEO
POWER
Connection Polarity:
GND VIDEO
OSD CONTROL
UP
DOWN
ENTER - PUSH DOWN
LEFT RIGHT
VD960AW
1. No Picture after providing power
~ Check that the power supply is the proper voltage and polarity.
~ Check all connections to DVR.
~ Check the video signal type.
2. The picture has rolling lines or ripples
~ Check for AC power lines running in close proximity to the camera
or its cabling.
~ Check that all connections are securely connected to the DVR.
3. Innaccurate/changing color balance
~ External lighting sources such as fluorescent lamps can confuse
the image sensor. Move the camera or change the light source
in the monitored area.
4. Blurred or hazy image
~ Check that the camera lens is clean and free of any dirt,
fingerprints, moisture.
~ Check that camera lens has not been adjusted out of its focus range.
~ Check that camera has not been disassembled or missing
any moisture seals.
OSD Menu Settings
960H MODE: Hold “left” key 5 sec. AHD MODE: Hold “right” key 5 sec.
System Menu: Push “depress” joystick 5 sec.
MAIN
MENU
MANUAL/DC
LENS
EXPOSURE
BACK LIGHT
WHITE BAL
DAY &
NIGHT
NR
SPECIAL
ADJUST
SHUTTER
AGC
SENS-UP
BRIGHTNESS
D-WDR
DEFOG
OFF
BLC:LEVEL/AREA/DEFAULT
HSBLC:SELECT AREA/DISPLAY/BLACK MASK/
LEVEL/MODE/DEFAULT
ATW/ATC→SET/INDOOR/OUTDOOR/MANUAL/AWB
EXT
AUTO D→N(AGC)/D→N(DELAY)/
N→D(AGC)/N→D(DELAY)
D→N(DELAY)/N→D(DELAY)
COLOR
B/W BURST/IR SMART/IR PWM
AUTO, 1/30, 1/60, FLK, 1/240, 1/480, 1/1000
1/2000, 1/5000, 1/10000, 1/50000, X2, X4,
X6, X8, X10, X15, X20, X25, X30
0 – 15
AUTO (X2 - X30)/OFF
0 – 100
OFF/ON
OFF/AUTO
2DNR
3DNR
OFF/LOW/MIDDLE/HIGH
OFF/LOW/MIDDLE/HIGH
CAM TITLE OFF/ON
D-EFFECT
FREEZE/MIRROR/NEG.IMAGE
MOTION SELECT AREA1-4/DISPLAY/SENSITIVITY/
COLOR/TRANS/ALARM/DEFAULT
PRIVACY
OFF/ON
LANGUAGE ENG/CHN1/CHN2/GER/FRA/ITA/
SPA/POL/RUS/POR/NED/TUR
DEFECT
LIVE DPC
WHITE DPC
BLACK DPC
RS485
CAM ID:0-255
ID DISPLAY
BAUDRATE:2400/4800/9600/19200/38400
SHARPNESS
AUTO/OFF
LCD/CRT
MONITOR
LSC
OFF/ON
VIDEO.OUT
PAL/NTSC
