TLM-A025-T/T-1611
SP70-200mm F/2.8 Di VC USD G2
(
for Nikon, Canon)
Model:
A 025
Owner’s manual
* The Marking is a directive conformity mark of the European Community (EC).
* Das -Zeichen entspricht der EC Norm.
* La marquage est un marquage de conformité à la direcive CEE (CE).
* La marca es marca de conformidad segun directiva de la Comunidad Europea (CE).
* Il marchio attesta la conformita alla directtiva della Comunità Europea (CEE).
* 标志表示符合欧州共同体(EC)指标
The EEC Conformity Report applies to the Council
Directive 2014/30/EU, 2011/65/EU and is used by
Tamron Co., Ltd., manufacturer of this product.
󱦯
󱦱
󱦹󱦷
󱦻 󱦽
󱦳
󱦵
󱧁󱦿
󱧃󱧂
󱧄
󱧆
󱧅
Canon
Nikon
3
2
1
7
8
4
5
12
6
9
13
14
11
10
23
24 25
16
15
2021 18 19
15
22 17
2021 18 19
15
22
17

ENGLISH
Thank you for purchasing the Tamron lens as the latest addition to your photographic equipment.
Before using your new lens, please read the contents of this Owner’s Manual thoroughly to
familiarize yourself with your lens and the proper techniques for creating the highest quality
images possible. With proper handling and care, your Tamron lens will give you many years of
photographing beautiful and exciting pictures.

Explains precautions that help to prevent problems.

Explains things you should know in addition to basic operations.
PART NAMES (Refer to Fig. 󱦯, if not specied)
① Lens hood ② Hood attaching alignment mark
③ Hood locking mark ④ Filter ring
⑤ Hood release mark ⑥ Zooming ring
⑦ Focal length scale ⑧ Focal length mark
⑨ Focus ring ⑩ Distance scale
⑪ Distance mark ⑫ Tripod mount
⑬ Tripod mount mark ⑭ Tripod mount locking screw
⑮ Tripod mount release mark (lens side) ⑯ Tripod mount release mark (tripod side)
⑰ Lens attachment mark ⑱ VC (Vibration Compensation) switch
⑲ AF/MF switch ⑳ Focus limiter
㉑ VC mode switch ㉒ Lens-camera interface contacts
㉓ Screw hole for safety lock screw ㉔ Safety lock screw (×2)
㉕ Hexagonal wrench
MAIN SPECIFICATIONS
A025
Focal Length 70-200 mm
Maximum Aperture F/2.8
Angle of View 34
˚ 21 ' - 12 ˚ 21 '
Lens Construction 17/23
Minimum Focus Distance 0.95 m (37.4
" )
Maximum Magnication Ratio 1:6.1
Filter Size
ø 77 mm
Length 191.3 mm (7.5
" ) *
Diameter ø 88 mm (3.5 " )
Weight (with tripod mount) 1,490 g (52.6 oz)
*
Lens Hood HA025

* Values are specications of Nikon products.
Length: Distance from lens front to mount surface.
Features and appearances of lenses listed in this owner's manual are subject to change without
notice.
ATTACHING AND REMOVING THE LENS
Remove the rear cap of the lens. Align the lens attachment mark ⑰ and mounting mark on the
camera, and then insert the lens.
Rotate the lens clockwise until it clicks and locks. (For Nikon models, rotate counterclockwise.)
To remove the lens, turn the lens in the opposite direction while pressing the lens release button
on the camera.

Turn off the power of the camera before attaching or removing the lens.

In the case of Canon cameras, align with the EF lens mark (red circle).

For details, please read the instruction manual of your camera.
SWITCHING FOCUS MODE (Ref. Figs. 󱦯, 󱦳& 󱦵)
To shoot using autofocus (AF), set the AF/MF switch ⑲ to “AF”.
To shoot using manual focus (MF), set the AF/MF switch
⑲ to “MF”, and then use your hand to
turn the focus ring and focus the image.

The distance scale ⑩ is provided as a guideline. It may differ from the actual focus location.

In AF mode, it may be difcult for autofocus to work depending on the subject.

Through the full-time manual mechanism, when focusing with AF, it is possible to switch to MF by turning
the focus ring while the AF/MF switch is set to AF. AF can be resumed by releasing your nger from the
shutter button and then repressing the shutter button halfway.

To ensure focus under various conditions, the focus ring ⑨ rotates past the innity ( ∞ ) position.
Accordingly, always check the focus in the viewnder when shooting with manual focus, even when the
focus is aligned with innity.

For details, please read the instruction manual of your camera.
VC MECHANISM (Ref. Figs. 󱦯, 󱦷& 󱦹)
The VC (Vibration Compensation) mechanism reduces image blur caused by hand-held shooting.
 How to use VC
When you use VC, set the VC switch ⑱ to ON.
Press the shutter button halfway and conrm that the viewnder image is stable before taking
a picture.
 Switching VC mode
You can switch the VC mode by using the VC mode switch ㉑ .
MODE 1 Basic mode that balances nder-image stability and compensation effects
MODE 2 Panning mode
MODE 3 Mode that prioritizes compensation effects, compensating only at the moment the
shutter is released.
* MODE 1 and MODE 3 do not support panning.
* For shooting with live view, use MODE 1.
* Settings can be made using TAP-in Utility only for MODE 1.

VC is effective under the following conditions

Dimly lit locations

Locations where ash photography is prohibited

Locations where the footing is unstable

VC may not perform sufciently under the following conditions

When a photograph is taken from a vehicle that is shaking greatly

Shooting during excessive movement of the camera

When shooting while using a tripod
Set the VC switch to OFF when taking pictures with bulb photography (long exposures).
Otherwise, VC may cause a malfunction.

The viewnder image may become blurred immediately after the shutter button is pressed
halfway. This is due to the principles of VC and not a malfunction.

When the VC switch is set to ON, the number of recordable images is reduced due to the power
used from the camera.

Set the VC switch to OFF when you are shooting while the camera is secured by something other
than your hand (such as a tripod).

Do not remove the lens from the camera while VC is on. If the lens is removed while VC is on, the lens
may make a clicking sound if the lens is shaken. This is not a malfunction. If the lens is installed on the
camera, and the camera’s power is switched on, the sound stops.

In MODE 2 and MODE 3, the effects of VC at the nder may be reduced, but this is not a malfunction.

For Nikon cameras equipped with a built-in ash, VC will be turned off while the built-in ash is charging.
USING THE FOCUS LIMITER (Ref. Figs. 󱦯, 󱦻& 󱦽)
When autofocus is set, switching the focus limiter switch ⑳ can speed up focusing.
 To limit the autofocus range to distant (innity to 3 m) subjects (Ref. Fig. 󱦻 )
Set the focus limiter switch to “ ∞ -3 m”.
 When not using the focus limiter (Ref. Fig. 󱦽 )
Set the focus limiter switch to “FULL”.
ZOOMING (Ref. Figs. 󱦯& 󱦱)
While looking through the camera’s viewnder, rotate the zooming ring ⑥ of the lens to set the
focal length suitable for the image, and then shoot.
LENS HOOD (Ref. Figs. 󱦯, 󱦿to 󱧂)
A bayonet-type lens hood is provided as standard equipment.
We recommend shooting with the hood properly attached because the lens hood eliminates stray
light that may affect the picture.
 Using the lens hood (Ref. Figs. 󱦿 & 󱧁 )
Align the hood attaching alignment mark ② of the hood with the hood release mark ⑤ of the
lens.
Rotate the hood in the direction of the arrow until the hood locking mark
③ meets the hood
release mark
⑤ .
 Stowing the lens hood (Ref. Fig. 󱧂 )
You can stow the lens hood by attaching it in reverse.
Align the hood locking mark
③ of the hood with the hood release mark ⑤ of the lens.
Rotate the hood in the direction of the arrow until the hood attaching alignment mark
② meets
the hood release mark
⑤ .

Be aware that the perimeter of the photographed image may be darkened if the hood is not
attached properly.
TRIPOD MOUNT (Ref. Figs. 󱦯, 󱧃to 󱧅)
The A025 model comes with a tripod mount. When you use a tripod, lock the lens rmly to the
tripod using the tripod mount.
 Changing the directional position of the camera (Ref. Fig. 󱧃 )
When you change the directional position of the camera, you can rotate the lens by loosening
the tripod mount locking screw
⑭ .
After determining the shooting position, tightly secure the tripod mount locking screw
⑭ .
 Attaching and removing the tripod mount (Ref. Figs. 󱧄 & 󱧅 )
You can mount and dismount the lens by loosening the tripod mount locking screw ⑭ , rotating
the lens, and then aligning the release marks
⑮ and ⑯ to the same position.
After attachment, tightly secure the tripod mount locking screw
⑭ .

The A025 tripod mount can be attached to an ARCA-SWISS camera platform.
SAFETY LOCK SCREW
We recommend attaching the lock screws in accordance with the camera platform type when you
use an ARCA-SWISS-standard compatible camera platform or clamp.
 How to use safety lock screws
The safety lock screws ㉔ prevent the lens/camera from falling from the camera platform
when a tripod mount is attached to an ARCA-SWISS-standard compatible camera platform or
clamp.
As shown on the gure, use the hexagonal wrench to tighten the safety lock screws
㉔ to the
two screw holes
㉓ .

After attaching the safety lock screws, the screw heads protrude from the tripod mount bottom surface to
prevent the lens/camera from falling. For this reason, if you are using a camera platform or a clamp other
than ARCA- SWISS-standard compatible, you usually do not need to have them attached.
PRECAUTIONS WHEN SHOOTING

An internal focusing (IF) system is employed to achieve the minimum focus distance. Because of
this, the shooting range is wider than that of lenses using other focusing systems when shooting
at a distance less than innity.

Always remove the hood when you use the built-in ash on the camera for ash photography.
Otherwise, the hood or lens may darken the perimeter of the image. With close-up photography,
the lens itself blocks the ash, and dark semicircle may appear at the bottom of the screen, even
when the lens hood is not used. For ash photography, we recommend that you use an external
ash unit provided by the camera manufacturer.

Differences in the display systems of cameras may result in the display of values different from
the maximum and minimum aperture values in the specications. This is not an indication of an
error.

Use with mirrorless interchangeable-lens cameras is not guaranteed.

Disposal of Electrical and Electronic Equipment in Private Households.
Disposal of used Electrical & Electronic Equipment (Applicable in the
European Union and other European countries with separate collection
systems)
This symbol indicates that this product shall not be treated as household waste.
Instead it shall be collected separately for the recycling of electrical and
electronic equipment.
If the new products are purchased, this product might be handed over to the distributor or
the collection system of waste electrical and electronic equipment eventually.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product or components of this product.
If this product is disposed illegally, it might cause a possibility of penalties. For more detailed
information about recycling of this product, please contact your local Civic Ofce, your
household waste disposal service or the shop where you purchased the product.
TO ENSURE LONG-TERM SATISFACTION

Remove dust and soiling on the lens by using a blower or soft brush. Do not touch the lens with
your ngers.

When ngerprints or oil have adhered to the lens, lightly wipe with commercially available lens
cleaning paper, soak a well-washed cotton cloth, or microber cloth (cleaning cloth for glasses,
etc.) in lens cleaner, and then lightly wipe the lens surface starting from the center. Do not use a
silicone cloth.

Clean the lens barrel using a silicone cloth. Never use benzene, thinner, or other organic
solvents.

The front element has been coated to prevent water and oily substances from adhering. This
coating will repel liquids such as lens cleaners. To clean the lens, we recommend at the end to
wipe it with a dry cloth.

Mildew is a major problem for lenses. Store your lens in a clean, cool, and dry place. When you
store the lens in a lens case, store it with a commercially available drying agent and replace the
drying agent occasionally.

Do not touch the lens-camera interface contacts. If dust or stains cause contact problems,
signals are not transmitted properly between the lens and camera, and malfunctions may occur.

If the temperature changes suddenly, moisture may form within the camera and lens and cause
malfunctions.
To prevent this, seal your equipment in a plastic bag or similar container. After your equipment
has adjusted to the ambient temperature, remove it from the bag and use it as usual.

For safe operation be sure to carefully read the "Precautions for Safe Use of Tamron Lenses" and the
manual before using the product.
After reading them, store them in a place where they can easily be reviewed whenever needed.
Caution instructions are divided into the following two categories according to the degree of danger
involved.
Do not directly view the sun or other strong light source using this lens or a camera to which the
lens is attached.
Doing such could cause loss of vision or other damage.
Do not dissemble, repair, or modify the lens.
This could damage the lens or camera.
Keep the lens out of the reach of small children.
There is a risk of injury if the lens is dropped or falls down.
Do not place lens in direct sunlight or leave it in an extremely hot place such inside a car. Doing such
could damage the internal parts of the lens or cause a fire.
Always attach the lens cap whenever the lens is not in use.
When attaching the lens to the camera, ensure that the lens has been properly attached to the
camera and firmly locked.
If the lens is not attached properly, it could be difficult to remove or it could fall off causing damage
or injury.
Do not use this lens for any application other than photography.
Do not transport the lens while it is still attached to a tripod.
TPL-E N- L en s-T-16 07
This indicates instructions which if not followed or if performed
incorrectly could lead to death or serious injury.
This indicates instructions which if not heeded or if performed
incorrectly could lead to bodily injury or physical damage
Precautions for Safe Use of Tamron Lenses
ENGLISH
WARNING
CAUTION
