CS mount is equipped with Tamron CCTV lens. Before you use the lens, please make sure that the mount type matches that on your camera.
Please read the user's manual for the devices such as the camera and controller before wiring. Then please follow the chart below to insure the right connection.
CCTV/ IP LENS OWNER’S MANUAL
TM13VG-E-U-1206
M13VG850 IR
Thank you very much for purchasing our CCTV lens.
In order to understand the lens specifications and performances, please read this manual thoroughly and handle the lens with care.
MOUNT-TYPE
If the camera has a selection switch between Video and DC, please set it to DC.
IRIS
The lens can be installed by screwing it clockwise into CS-mount on the CCTV camera. Once the lens is screwed in completely to its mechanical stop position, you will then be able to rotate
lens chassis back to suit the set-up position of the camera.
INSTALLATION ON CAMERA
(1) Please remove dust on the lens by using a blower or soft brush. Avoid touching the lens surface directly with fingers.
(2) In order to remove finger prints or oil stains on the lens surface, use lens cleaning paper or clean cotton cloth with a little cleaning liquid. Then, wipe off the stains lightly starting from
the center of the lens surface. Please wipe the lens body with a silicon cloth. Avoid using any organic solvents such as thinner or benzene.
TO INSURE LONG TERM USE
CS mount
M13VG850 IR
WIRING DIAGRAM
M13VG850 IR
Supplied with 4-Pin Square Connector (JEITA Standards) 1——Control (
-
) 2——Control (+) 3——Drive (+) 4——Drive (
-
)
When adding plus voltage to Drive (+), will move to the opening direction.
SPECIFICATION
MODEL M13VG850IR
Imager Size 1/3”
Focal Length 8-50mm
Aperture Range Auto Iris 1.6-360
Angle of View Horizontal (TELE) 5.6º (WIDE) 33.5º
Vertical (TELE) 4.2º (WIDE) 25.1º
Filter Size ——
Mount-Type CS-Mount
DC Auto Iris M13VG850IR
Resistance of Drive coil 190
±10% (20ºC)
Resistance of Control coil 700
±10% (20ºC)
Max Voltage 6V
Specifications are subject to change without notice.
TAMRON CO.,LTD. Industrial Optics Unit
1385 Hasunuma, Minuma-ku, Saitama-shi, Saitama 337-8556 JAPAN Tel: +81-48-684-9129 Fax: +81-48-683-8594 http://www.tamron.co.jp
