Tanaka TCG 31 EBS User manual

G
B
T
W
K
R
T
H
R
O
S
I
R
U
N
O
F
I
TCG 31EBS
Brush Cutter
肩掛式割草機
견착식 예초기
เครื่องตัดหญา
TCG 31EBS/TCG 31EBS (L)
Read through carefully and understand these instructions before use.
使用前務請詳加閱讀
본 설명서를 자세히 읽고 내용을 숙지한 뒤 제품을 사용하십시오.
 
Handling instructions
使用說明書
취급 설명서

000BookTCG31EBSTha.indbA000BookTCG31EBSTha.indbA 2010/02/2318:47:082010/02/2318:47:08

2
123
456
789
10 11
1
4
2
3
5
000BookTCG31EBSTha.indb2000BookTCG31EBSTha.indb2 2010/02/2318:47:092010/02/2318:47:09

3
12 15
13 14 16
17 18 19
9
11
10
12
6
8
7
000BookTCG31EBSTha.indb3000BookTCG31EBSTha.indb3 2010/02/2318:47:092010/02/2318:47:09

4
20 21 22
23 24 25
26 27 28
29 30 31
13
14
15 18 14
16
17
13
ab
9
T
19
000BookTCG31EBSTha.indb4000BookTCG31EBSTha.indb4 2010/02/2318:47:092010/02/2318:47:09

5
32 33 34
35 36 37
38 39 40
41 42
000BookTCG31EBSTha.indb5000BookTCG31EBSTha.indb5 2010/02/2318:47:092010/02/2318:47:09

6
MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning
before use.
It is important that you read, fully
understand and observe the
following safety precautions and
warnings.
Careless or improper use of the unit
may cause serious or fatal injury.
Shows maximum shaft speed. Do
not use the cutting attachment
whose max speed is below the
shaft speed.
Read, understand and follow all
warnings and instructions in this
manual and on the unit.
Gloves should be worn
when necessary, e.g., when
assembling cutting equipment.
Always wear eye, head and ear
protectors when using this unit. Use anti-slip and sturdy footwear.
Keep all children, bystanders and
helpers 15 m away from the unit.
If anyone approaches you, stop
the engine and cutting attachment
immediately.
Blade thrust may occur when
the spinning blade contacts a
solid object in the critical area.
A dangerous reaction may occur
causing the entire unit and
operator to be thrust violently.
This reaction is called blade
thrust. As a result, the operator
may lose control of the unit which
may cause serious or fatal injury.
Blade thrust is more likely to
occur in areas where it is difficult
to see the material to be cut.
Be careful of thrown objects.
Be careful of the engine.
Engine gets hot by running engine.Indicate handle location. Do not
attach handle above this point.
Contents
WHAT IS WHAT .................................................................7
WARNINGS AND SAFETY INSTRUCTIONS.................... 8
SPECIFICATIONS.............................................................. 9
ASSEMBLY PROCEDURES............................................ 10
OPERATING PROCEDURES .......................................... 11
MAINTENANCE............................................................... 12
000BookTCG31EBSTha.indb6000BookTCG31EBSTha.indb6 2010/02/2318:47:092010/02/2318:47:09

7
G
B
10
5
14
6
2
9
11
8
13
7
12
3
1
15
16
4
13
11
9
8
2
7
6
4
14
5
WHAT IS WHAT
Since this manual covers several models, there may be
some difference between pictures and your unit. Use the
instructions that apply to your unit.
1. Fuel cap
2. Throttle lever
3. Starter handle
4. Blade guard
5. Cutting attachment
6. Drive shaft tube
7. Ha n dl e
8. Suspension eyelet
9. Ignition switch
10. Harness
11. Clutch ca s e
12. Choke lever
13. Engine
14. Angle transmission
15. Combi box spanner
16. Handling instructions
000BookTCG31EBSTha.indb7000BookTCG31EBSTha.indb7 2010/02/2318:47:102010/02/2318:47:10

8
WARNINGS AND SAFETY INSTRUCTIONS
Operator safety
○Always wear a safety face shield or goggles.
○Always wear heavy, long pants, boots and gloves. Do
not wear loose clothing, jewelry, short pants, sandals
or go barefoot. Secure hair so it is above shoulder
length.
○Do not operate this tool when you are tired, ill or under
the influence of alcohol, drugs or medication.
○Never let a child or inexperienced person operate the
machine.
○Wear hearing protection. Pay attention to your
surroundings. Be aware of any bystanders who may
be signaling a problem. Remove safety equipment
immediately upon shutting offengine.
○Wear head protection.
○Never start or run the engine inside a closed room or
building. Breathing exhaust fumes can kill.
○Keep handles free of oil and fuel.
○Keep hands away from cutting equipment.
○Do not grab or hold the unit by the cutting equipment.
○When the unit is turned off, make sure the cutting
attachment has stopped before the unit is set down.
○When operation is prolonged, take a break from
time to time so that you may avoid possible Hand-
Arm Vibration Syndrome (HAVS) which is caused by
vibration.
WARNING
○Antivibration systems do not guarantee that you will
not sustain Hand-Arm Vibration Syndrome or carpal
tunnel syndrome. Therefore, continual and regular
users should monitor closely the condition of their
hands and fingers. If any symptoms of the above
appear, seek medical advice immediately.
○If you are using any medical electric/electronic devices
such as a pacemaker, consult your physician as well
as the device manufacturer prior to operating any
power equipment.
Unit/machine safety
○Inspect the entire unit/machine before each use.
Replace damaged parts. Check for fuel leaks and
make sure all fasteners are in place and securely
tightened.
○Replace parts that are cracked, chipped or damaged
in any way before using the unit/machine.
○Make sure the safety guard is properly attached.
○Keep others away when making carburetor
adjustments.
○Use only accessories as recommended for this unit/
machine by the manufacturer.
WARNING
Never modify the unit/machine in any way. Do not use
your unit/machine for any job except that for which it is
intended.
Fuel safety
○Mix and pour fuel outdoors and where there are no
sparks or flames.
○Use a container approved for fuel.
○Do not smoke or allow smoking near fuel or the unit/
machine or while using the unit/machine.
○Wipe up all fuel spills before starting engine.
○Move at least 3 m away from fueling site before starting
engine.
○Stop engine before removing fuel cap.
○Empty the fuel tank before storing the unit/machine. It
is recommended that the fuel be emptied after each
use. If fuel is left in the tank, store so fuel will not leak.
○Store unit/machine and fuel in area where fuel vapors
cannot reach sparks or open flames from water
heaters, electric motors or switches, furnaces, etc.
WARNING
Fuel is easy to ignite or get explosion or inhale fumes,
so that pay special attention when handling or filling
fuel.
Cutting safety
○Do not cut any material other than grass and brush.
○Inspect the area to be cut before each use. Remove
objects which can be thrown or become entangled.
○For respiratory protection, wear an aerosol protection
mask when cutting the grass after insecticide is
scattered.
○Keep others including children, animals, bystanders
and helpers outside the 15 m hazard zone. Stop the
engine immediately if you are approached.
○Always keep the engine on the right side of your body.
○Hold the unit/machine firmly with both hands.
○Keep firm footing and balance. Do not over-reach.
○Keep all parts of your body away from the muffler and
cutting attachment when the engine is running.
○Keep cutting attachment below waist level.
○When relocating to a new work area, be sure to shut off
the machine and ensure that all cutting attachments
are stopped.
○Never place the machine on the ground when running.
○Always ensure that the engine is shut offand any
cutting attachments have completely stopped before
clearing debris or removing grass from the cutting
attachment.
○Always carry a first-aid kit when operating any power
equipment.
○Never start or run the engine inside a closed room or
building and/or near inflammable liquids. Breathing
exhaust fumes can kill.
Maintenance safety
○Maintain the unit/machine according to recommended
procedures.
○Disconnect the spark plug before performing
maintenance except for carburetor adjustments.
○Keep others away when making carburetor
adjustments.
○Use only genuine Tanaka replacement parts as
recommended by the manufacturer.
Transport and storage
○Carry the unit/machine by hand with the engine
stopped and the muffler away from your body.
○Allow the engine to cool, empty the fuel tank, and
secure the unit/machine before storing or transporting
in a vehicle.
○Empty the fuel tank before storing the unit/machine. It
is recommended that the fuel be emptied after each
use. If fuel is left in the tank, store so fuel will not leak.
○Store unit/machine out of the reach of children.
○Clean and maintain the unit carefully and store it in a
dry place.
○Make sure engine switch is offwhen transporting or
storing.
○When transporting in a vehicle, cover blade with blade
cover.
If situations occur which are not covered in this manual,
take care and use common sense. Contact your Tanaka
dealer if you need assistance. Pay special attention to
statements preceded by the following words:
WARNING
Indicates a strong possibility of severe personal injury
or loss of life, if instructions are not followed.
000BookTCG31EBSTha.indb8000BookTCG31EBSTha.indb8 2010/02/2318:47:102010/02/2318:47:10

9
G
B
SPECIFICATIONS
Model TCG 31EBS TCG 31EBS (L)
Engine Size (ml) 30.8
Spark Plug NGK BMR7A or equivalent
Fuel Tank Capacity
(l) 0.67
Dry Weight (kg) 6.7 6.3
Sound pressure
level
LpA (dB (A))
(EN27917)
98.6 98.4 98.6 98.4
Measured sound
power level LwA
(dB (A))
Guaranteed sound
power level LwA
(dB (A))
105.6
108
106.5
108
105.6
108
106.5
108
Vibration level (m/s2)
(ISO7916)
Front handle
Rear handle
Left handle
Right handle
—
—
6.4
6.1
—
—
6.5
5.5
6.3
4.7
—
—
4.9
6.1
—
—
NOTE
Equivalent noise level/vibration level are calculated as the time-weighted energy total for noise/vibration levels under
various working conditions with the following time distribution: 1/2 Idle, 1/2 racing.
* All data is subject to change without notice.
CAUTION
Indicates a possibility of personal injury or equipment
damage, if instructions are not followed.
NOTE
Helpful information for correct function and use.
CAUTION
Do not disassemble the recoil starter. You may get a
possibility of personal injury with recoil spring.
000BookTCG31EBSTha.indb9000BookTCG31EBSTha.indb9 2010/02/2318:47:102010/02/2318:47:10

10
ASSEMBLY PROCEDURES
Drive shaft to engine (Fig. 1)
Loosen tube locking bolt (1) about ten turns so that the
bolt point will not obstruct drive shaft tube to be inserted.
When inserting drive shaft tube, hold the tube locking bolt
outward preventing inside fitting from obstructing as well.
Some models may come with the drive shaft already
installed.
NOTE
When it is hard to insert drive shaft up to the marked
position on the drive shaft tube, turn drive shaft by the
cutter mounting end clockwise or counter-clockwise.
Tighten tube locking bolt lining up the hole in the shaft
tube. Then tighten clamp bolt securely (1).
Installation of handle
WARNING
When you use steel/rigid blades on straight shaft
trimmers or brush cutters, always use a barrier bar (2)
and shoulder harness with the loop handle. (Fig. 2)
Attach the handle to the drive shaft tube with the angle
towards the engine.
Adjust the location to the most comfortable position before
operation.
NOTE
If your unit has handle location label on drive shaft
tube, follow indication.
Remove the handle bracket (3) from the assembly. (Fig. 3)
Place the handles and attach the handle bracket with four
bolts lightly. Adjust to appropriate position. Then attach it
firmly with the bolts.
Attach the protection tube to the drive shaft or handle
using cord clamps (4). (Fig. 4)
NOTE
If the protection tube is set apart from the handle or
pipe, it will be caught by something during operation
and it may cause serious injury. Do not set the
protection tube apart from the handle or pipe.
Throttle wire / stop cord
Remove air cleaner cover. (Fig. 5)
Loosen and remove the screw from the throttle wire
holder. (Fig. 7)
Connect the terminals of the stop cords coming out from
the engine and shaft. (Fig. 6)
Hook the throttle wire end on the throttle of the carburetor.
Make sure that the throttle trigger shown in Fig. 18 has
returned to the starting position.
Put the throttle outer end into the groove, and then cover
it with the throttle wire holder and fix the holder with the
screw. (Fig. 8)
Then, install the cleaner cover.
Fix the protection tube which the stop cords and throttle
wire are passing through, on the pipe with the hip pad.
Then, as shown in the figure, fix the protection tube on the
pipe and handle with the bands in the bag.
After fixing, cut offthe extra part of the band not to
obstruct the operation. (Fig. 4)
NOTE
If the protection tube is set apart from the handle or
pipe, it will be caught by something during operation
and it may cause serious injury.
Do not set the protection tube apart from the handle or
pipe.
Some models may come with the parts pre-installed.
Installation of blade guard (Fig. 10)
The guard bracket already mounted to the drive shaft tube.
Attach the gear case cover with the three screws.
Install the blade guard on drive shaft tube against angle
transmission (5). Tighten the guard bracket firmly so that
the blade guard does not swing or move down during
operation.
CAUTION
The blade guard must be in place during operation.
If the blade guard is not in place, there is a possibility
of serious injury.
Blade guards are equipped with sharp line limiter. Be
careful with handling it.
NOTE
○When attaching the guard extension to the blade
guard, the sharp line limiter must be removed from the
blade guard.
○To remove the guard extension, refer to the drawings.
Wear gloves as the extension has a sharp line limiter,
then push the two square tabs on the guard one by one
in order after removed the screw. (Fig. 12)
Installation of cutting blade (Fig. 13)
When installing a cutting blade, make sure that there are
no cracks or any damage in it and that the cutting edges
are facing the correct direction.
Align the notch hole of the cutter holder with the hole on
the gear case (Top the gear case) and insert the Allen
wrench to stop turning. Turn the fixing nut clockwise and
remove the fixing nut, cutter holder cap, and toothed lock
washers.
The installation of the cutting blade is as follows: insert the
Allen wrench into the notch hole of the cutter holder and
the hole on the gear case. Then, install the cutting blade
(check the installing direction, as referring to Fig. 15), the
cutter holder cap and toothed lock washers onto the cutter
holder in this order. Finally, tighten the fixing nut securely
by turning counterclockwise with the Combi box spanner.
(Fig. 13)
CAUTION
○When installing the cutting blade, set its center hole to
the convex part of the cutter holder and hold it with the
concave surface of the cutter holder cap. Then, tighten
the fixing nut to prevent the cutting blade from being
eccentric. (Fig. 14)
After installing the cutting blade, be sure to remove the
Allen wrench and Combi box spanner.
○Before operation, make sure the blade has been
properly installed.
○Cutter holder cap under a cutting blade, check it
for wear or cracks before operation. If any damage
or wear is found, replace it, as it is an article of
consumption.
NOTE
The blade must be retained with a new cotter pin each
time installed. (Fig. 13)
Installation of nylon head (Fig. 16)
Attach cutter holder (7) to the gear case. Insert an Allen
wrench into the hole in the gear case to attach winding
protector (6) and attach nylon head (8) by turning it
clockwise.
NOTE
Since cutter holder cap is not used here, keep it for
next metal blade use.
000BookTCG31EBSTha.indb10000BookTCG31EBSTha.indb10 2010/02/2318:47:112010/02/2318:47:11
