T&C TC30 User manual

PART# TC30.NG01.C
For TC30 Series C
IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER
These instructions are supplementary to the Installation
and Operating Instructions supplied with the replace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
TC30 CHALET
BURNER KIT
INSTRUCTIONS
140708-16 TC30.NG01.C 5056.429.01

2
TC30.NG01.C 140708
Notes

1. Attach the burner assembly to the oor of
the rebox with two screws. (Fig. # 1).
2. Attach the manifold supply tube to the
bulk head tting and tighten. (Fig. # 2)
Ensure that there are no leaks.
NOTE: Primary air shutter must
be fully closed for Natural gas or
fully open for Propane.
BURNER ASSEMBLY
EMBER MATERIAL
7 PCS LOG SET
HARDWARE PACKAGE
LOG GRATE
Fig #1
Fig #2
AIR SHUTTER
3
TC30.NG01.C 140708
Contents of Package
Burner/Grate Installation

5. Position the grate over the burner tray
and attach to the oor with two screws
through holes located behind the front
legs of the grate.
(Fig. # 5)
6. Attach air deector to rear of grate with
two screws (Fig. # 6)
3. Attach the pilot supply tube to the bulk
head tting and tighten. (Fig. # 3)
Ensure there are no leaks.
4. Connect spark electrode wire
(ORANGE) to the rear electrical bulk
head tting. Connect the ame sensor
wire to the front electrical bulk head
tting. (Fig. # 4)
If appliance is to used with
propane gas see propane
conversion instructions on page
#6 before proceeding.
Fig #3
Fig #4
Fig #5
Fig #6
4
TC30.NG01.C 140708

A large bag of ember material is shipped
with the replace and needs to be installed
to ensure optimum performance and ame
appearance.
1. Pull apart the material into ember size
pieces (approximately 1” squares) and
gently place them into the burner pan.
Do not compress, leave them loose for
best performance.
2. Fill the burner pan with embers until
level with the top of the pan at rear, and
gradually slope forward to the rebox
oor at the front, covering both burner
tubes.
3. Place remaining ember material outside
of the burner pan as desired to cover-up
gas lines and brackets.
Note:
Ember material placement and
amount will affect ame
appearance.
More ember material results in
lower ame height.
Add or remove as needed until
desired ame affect is achieved.
Reduce the amount used on
Propane models, as too much will
create soot.
Fig #7
5
TC30.NG01.C 140708
Ember Material

BASE LOG #1
PIN HOLE
PIN HOLE
PINS
TOP RIGHT LOG #2
PIN
STOP TAB
Fig #8
Fig #9 Fig #10
Fig #11 Fig #12
The logs are packaged in a foam pack inside the box. They are
fragile and should be handled with care. Unpack and inspect log
set. There should be a total of 7 logs. Gas plumbing and vent con-
nections should be completed before proceeding.
Position the logs as indicated by the following pictures. The three
main logs have holes and /or pins. Engage each pin in the cor-
responding holes. The remaining logs do not have holes or pins.
They rest in position. Locate as per the diagrams.
(Figs. #8 – #18)
6
TC30.NG01.C 140708
Log Set Assembly

PIN HOLE
TOP LEFT LOG #3
BOTTOM RHS CHUNK #4 BOTTOM CENTER CHUNK #5
BOTTOM LHS CHUNK #6 CENTER CHUNK #7
Fig #13
Fig #15
Fig #14
Fig #16
Fig #17 Fig #18
7
TC30.NG01.C 140708

If the unit is to be used on propane
convert as follows using the
components supplied with this
burner:
CAUTION
The gas supply and electrical power
shall be shut off before proceeding
with the conversion.
Note: Factory supplied components must be
used to ensure correct input.
After conversion conrm proper manifold
pressure.
1. Ensure the burner, pilot and gas
supply are turned off, and the
appliance has cooled.
2. Remove the two screws securing the
the burner grate.
(Fig. #19)
3. Remove the two screws securing the
manifold assembly to the burner.
(Fig. #20)
4. Remove the manifold assembly from the
burner. (Fig. #21)
5. With a ½”wrench remove the natural gas
orice (#32) and replace with propane
orice (#48)(our part # 5021.3407)
(Fig. #22)
WARNING
This conversion kit
shall be installed by a
qualied service agency
in accordance with the
manufacturer's instructions
and all applicable codes
and requirements of
the authority having
jurisdiction.
If the information in these
instructions is not followed
exactly, a re, explosion
or production of carbon
monoxide may result
causing property damage,
personal injury or loss of
life.
The qualied service
agency is responsible for
the proper installation of
this kit.
The installation is not
proper and complete
until the operation of the
converted appliance is
checked as specied in the
manufacturer's instructions
supplied with the kit.
Fig #19
Fig #20
Fig #21
Fig #22
8
TC30.NG01.C 140708
Propane Conversion

The minimum rate screw is sealed with
an o-ring.Use a thin bladed screwdriver
to back the screw out to the limit of the
threads.
A groove on the screw body will be
visibe just above the valve body.Insert a
thin tool (knife blade or thin screwdriver
blade) into the groove and gently pry
the screw up.
Fig #25
Fig #26
Minimum
rate screw
6. Fully open the primary air shutter.
7. Reinstall the manifold and air deector
8. Witha7/16”wrenchloosenthe pilothead
on the pilot assembly by a half-turn
(Fig. #25)
9. Slide the pilot adjustment band over and
ensure that the hole in the orice band is
showing. (Fig. #26 shows NG position,
Fig. # 27 shows LP position)
Retighten pilot head.
10. Remove right hand brick panel (if
installed) and access panel located on
right hand side of rebox
(See Fig. #27).
11. Remove the minimum rate screw located
in the valve.
(Fig. #32)
NOTE: Primary air shutter must
be fully closed for Natural gas or
fully open for Propane.
Fig #23
Fig #24
Fig #27
Fig #28
9
TC30.NG01.C 140708

12. Replacetheminimumratescrewwiththe
one provided in the propane conversion
kit supplied with this replace. Ensure
that the screw is fully installed.
(Fig. #29)
13. Pull off the rubber cap from the top of
the pressure regulator. (Fig. #30)
14. Press down on the center post and
rotate 90°. The center post should
stay down. (Fig. #31). Replace the
rubber cap.
15. Fill in the date and the name of the
person who performed the conversion in
the white area on the conversion label.
Peel off the protective backing and apply
the conversion label directly over the
gas specications on the rating label.
16. Attach the access panel to the side of
the rebox with the previously removed
screws. (Fig. #32)
Note:
Gasket must be installed with access
panel.
Minimum
rate screw
NG LP
Fig #29
Fig #30
Fig #31
Fig #32
10
TC30.NG01.C 140708

1. Remove the plug from the pressure
test port using a 7/16” socket
and extension . The plug is located
between the right side lintel and
rebox side (bottom port). (Fig. #33)
2. Thread the extension test tting into the
open test port. (Fig. #34)
3. Attach a pressure gauge onto the
tting.
4. When testing is complete remove the
extension test tting and replace the
plug. Thread sealant will be required to
ensure a gas tight connection.
Correct gas pressure requirement:
Supply Pressure Natural Gas Propane
Min. Pressure 5.0" WC 12.5" WC
(For purpose of input adjustment)
Max. Pressure 13.9" WC 13.9" WC
Manifold Pressure
Maximum 3.8" WC 11" WC
Minimum 2.1" WC 5.5" WC
SUPPLY
PRESSURE
MANIFOLD
PRESSURE
Fig #29a
Note:To test the gas pressure, turn off the gas supply before removing the plug from
the supply pressure test port or manifold pressure test port.
Verify gas pressures with the replace lit and on the highest setting.
Fig #33
Fig #34
11
TC30.NG01.C 140708
Gas Pressure Check

Caution:
Proper air shutter setting is a
must.
The ame should be just orange
and “lazy”.
It should NEVER be set to create
sooting on internal parts and glass.
Caution: Burner area may be hot!
Turn off the replace and allow the unit to cool before proceeding.
To Adjust:
1. Open and remove window frame and set aside. See “Window Frame Removal” section
found in the Installation and Operating Instructions manual.
2. Remove the logs and set aside.
3. Remove air deector from log grate (2 screws)
4. Loosen the Primary Air Shutter screw.
5. Rotate the shutter to increase or decrease the amount of primary air.
6. Reassemble in reverse order.
The air shutter on the burner tube controls the primary combustion air to the gas burner
and is preset at the factory for natural gas fuel. Some adjustment may be necessary to
obtain desired ame and to eliminate carbon deposits. Evaluate ame appearance after
the replace has reached operating temperature. See Fig. #35 for proper ame pattern.
Open primary air shutter if the logs, glass, and rebox have carbon accumulation and/or
the ames are long, dark and stringy. The shutter may also be opened to enhance the
ember material glow and lessen the ame height.
Fig #35
12
TC30.NG01.C 140708
Burner Flame Adjustment

4
5
6
1a
1b
1c
1d
1e
1f
1g
1h
1i
1j
2a
2b
2c
2d
2e
2f 2g
ITEM.......DESCRIPTION............................................PART NO.
#1..........CHALET BURNER ASSEMBLY ......... TC30.NG01.C
#2..........7 PCS LOG SET ................................. 5098.746148
#3..........ORIFICE, NATURAL GAS (#32)......... 5021.332.A
ITEM.......DESCRIPTION............................................PART NO.
#4..........PILOT ASSEMBLY.............................. 5005.025
#5..........MAIN SUPPLY TUBE.......................... 5019.223
#6..........PILOT TUBE ...................................... 5019.225
#7..........PROPANE CONVERSION KIT........... TC36.LPCE01
#1.... BURNER ASSEMBLY
1a GRATE
1b AIR DEFLECTOR
1c BURNER TRAY
1d PILOT SHIELD
1e BLOCKER PLATE
1f MANIFOLD
1g 1/2 PIPE TO 1/2 TUBE CONNECTION
1h PILOT BRACKET
1i HEAT SHIELD
1j HEAT SHIELD INSULATION
2a BASE LOG
2b TOP LEFT LOG
2c TOP RIGHT LOG
2d CENTER CHUNK
2e BOTTOM LHS CHUNK
KIT CONTENTS:
2f BOTTOM CENTER CHUNK
2g BOTTOM RHS CHUNK
3 ORIFICE, NATURAL GAS
4 PILOT ASSEMBLY
5 MAIN SUPPLY TUBE
6 PILOT TUBE
#2.... 7 PCS LOG SET
2a BASE LOG
2b TOP LEFT LOG
2c TOP RIGHT LOG
2d CENTER CHUNK
2e BOTTOM LHS CHUNK
2f BOTTOM CENTER CHUNK
2g BOTTOM RHS CHUNK
#3.... ORIFICE, NATURAL GAS (#32)
#4.... PILOT ASSEMBLY, CONVERTIBLE
#5.... MAIN SUPPLY TUBE
#6.... PILOT TUBE
#7.... PROPANE CONVERSION KIT (Not shown)
(WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION)
*
NOT SHOWN
*
13
TC30.NG01.C 140708
Replacement Parts

14
TC30.NG01.C 140708
Notes

15
TC30.NG01.C 140708
Notes

Printed in Canada
Technical support: 1-877-715-2664
Web site: www.townandcountryreplaces.net
2975 Allenby Rd., Duncan, BC V9L 6V8
