Tangent T9i User manual

To Connect Barcode Scanner Module
T9i
OPERATION GUIDE
The Barcode Scanner is preinstalled as an option for the T9i series.
The default scanner trigger button is on the right side. To assign the Scanner Trigger
button, follow the steps below.
1. Start Button Manager by clicking on in the system tray.
2. Select an available unused button marked with the icon .
3. Click on to go to the second screen of Button Manager.
4. Click on the icon to assign the Scanner Trigger to the unused button.
5. Click OK to apply configuration settings and close the window.
Button Management
To connect the Barcode Scanner, you can use the Keyboard Wedge. Tap on the icon in the
task bar, a menu displays as shown in the picture below. Select Connect Scanner.
Mobile POS Tablet Barcode Scanner
Installation

To Test Barcode Scanner Module
1.Click Start | All Programs | Accessories | NotePad to run the Notepad.
Scan one of the several supported barcodes.
2. The output will appear in the Notepad screen.
3.Verify the captured data.
SPECIFICATIONS
The Internal battery pack should only be replaced by an authorized Tangent service
representative. Please contact your product and/or service provider for internal battery
replacement service.
The Default Port Parameters for Barcode Scanner Module
The CMOS Camera is preinstalled as an option for the series.
Note: Please refer to Hyper Terminal Settings to confirm or change the port parameters.
Note: Specifications are subject to change without notice.
Linear Imager Compliance and Precaution
This product complies with the following standards for laser and LED safety.
IEC 60825-1 Class2 LASER Product
Installation
To assign Camera Trigger button, follow the steps below.
1. Start Button Manager by clicking on in the system tray.
2. Select an available unused button marked with the icon .
3. Click on to go to the second screen of Button Manager.
4. Click on the icon to assign the Camera Trigger to the unused button.
5. Click OK to apply configuration settings and close the window.
Button Management
To test the CMOS Camera, launch DTSMCap Utility from Start | All Programs |
Utilities. Select File | Set Capture File to assign the location of the captured files.
To Test CMOS Camera
Module
> Click Options | Preview to preview the
capture screen.
> Click Devices to select your camera device.
>Take a picture from Snap | Go
> Capture the Video from Capture | Start
Capture to start and Stop Capture to end it.
> You also can trigger from the assigned
button, then edit the captured files
Mobile POS Tablet CMOS Camera

SPECIFICATIONS
Front Camera
Back Camera
The RFID reader is preinstalled as an
option for the T9i.
Installation
The Default Port Parameter for RFID Module
To Connect RFID Reader Module
To connect the RFID, you can use the Keyboard Wedge. Tap on the icon in the task
bar, a menu displays as shown in the picture below. Select Connect RFID.
1.Click Start | All Programs | Accessories | NotePad to run
the Notepad.
2.Place an RFID tag or RFID card within range of the RFID
Reader. (see reading range in specifications). The output
will appear in the Notepad screen.
3.Verify the captured data.
To Test RFID Reader Module
Mobile POS Tablet RFID Reader
SPECIFICATIONS
Note: Specifications are subject to change without notice.
