Tannoy SFX 5.1 User manual
The setup guide
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 1
Thank you for purchasing this high performance 5.1
home theatre system. The SFX5.1 has been built
and tested with care and precision, to provide first
class performance and reliable operation. To ensure
maximum benefit from ownership and for reasons of
safety, please read the following information before
using for the first time. Please complete and return
the enclosed warranty registration document- this
does not limit your legal rights.
Power Requirements
Check that the voltage rating displayed on the rear
panel is correct for your area before connecting. If it
is incorrect, please refer to your local dealer or
authorised service agent, as no user adjustment
is provided.
Fuse Protection
A mains fuse is provided on the back of the subwoofer,
which can be removed with a screwdriver. Ensure the
power cable is unplugged from the outlet before doing
so, to avoid the risk of electric shock. The correct type
is shown in the specification and on the rear panel.
Introduction
Important safety instructions
Warnings and precautions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install in
accordance with manufacturerʼs instructions.
This apparatus is not suitable for in wall mounting.
Do not install near any sources of heat such as
radiators, heat registers, stoves or other apparatus
(including amplifiers) that produce heat.
The power cable is provided with a moulded
plug appropriate to the country of use. If it is
unsuitable for your power outlet, consult your
local dealer of authorised service agent.
Protect the power cable from being walked on
or pinched, particularly at the plug or where it
exits the apparatus.
Only use attachments/ accessories specified
by the manufacturer.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified personnel.
Servicing is required when the apparatus has
been damaged in any way, such as the power
cable or plug are damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally or has
been dropped.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 2
Warning: To reduce the risk of fire or electric
shock, this apparatus should not be exposed to
rain or moisture and objects filled with liquids,
such as vases, should not be placed on
the apparatus.
To completely isolate this apparatus from the
mains, disconnect the power supply plug from
the receptacle.
The mains plug of the power supply cable shall
remain readily operable.
Store complete packaging in case it is needed
for re-use.
Due to the powerful drive unit magnet, do not
place within 1m (3 feet) of a television or
computer monitor.
Warranty
All of our products have been produced and tested
with care and precision to give first-class service.
All passive components are guaranteed for a
period of five years from the date of purchase from
an authorised Tannoy dealer subject to the
absence or evidence of misuse, overload, or
accidental damage.
All active and electronic components are
guaranteed for a period of one year from the date
of purchase from an authorised Tannoy dealer
subject to the absence of, or evidence of, misuse,
overload or accidental damage.
.14.
15.
16.
17.
18.
If at any time during this warranty period the
equipment proves to be defective for any reason
other than accident, misuse, neglect, unauthorised
modification or fair wear and tear, we will repair
any such manufacturing defect or, at our option,
replace it without charge for labour, parts or
return carriage.
If you suspect a problem with a Tannoy product
then, in the first instance, discuss it with your
Tannoy dealer. If you require further assistance
then we ask that you deal directly with your local
Tannoy distributor. If you cannot locate your
distributor please contact Customer Services,
Tannoy Ltd at the address given below.
Customer Services, Tannoy Ltd., Rosehall
Industrial Estate, Coatbridge, Strathclyde
ML5 4TF, Scotland
Tel: 01236 420199 (National)
+44 1236 420199 (International)
Fax: 01236 428230 (National)
+44 1236 428230 (International)
E-mail: enquiries@tannoy.com
Do not ship any product to Tannoy without
previous authorisation.
Our policy commits us to incorporating
improvements to our products through continuous
research and development. Please confirm current
specifications for critical applications with
your supplier.
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 3
Warning: Failure to follow these safety instructions could result in fire, electric shock, or other injury or damage.
Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain, liquids, moisture,
excessive heat, or naked flame.
The lightning ash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage " within the
product's enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 4
5.1 system setup guide
_
+
_
+
_
+
_
+
_
+
_
+
This high performance 5.1 system has been built
and tested with care and precision, to provide first class
performance and reliable operation. To ensure
maximum benefit from ownership, and for reasons of
safety, please read the following information before
using for the first time.
SUB OUT FRONT
LEFT
REAR
LEFT
AV RECEIVER/DECODER OUTPUT PANEL
CENTRE REAR
RIGHT
FRONT
RIGHT
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 5
The SFX5.1 system subwoofer may be connected in
any one of the following ways:
Line levels
• Using the subwoofer output on your A/V receiver or
decoder connect a single RCA interconnect to either
the left or right line input on the subwoofer rear
panel. This is the ideal connection type as the sub
woofer output contains the low frequency
information from all channels.
• If no subwoofer or spare line outputs exist you may
connect using a Y-split connector on the main pre
amplifier output connections. Use a Y-split on both
right and left outputs and connect these via an RCA
interconnect to the left and right inputs on the
subwoofer rear panel.
• Alternatively, if your preamplifier has a spare set of
line level outputs, connect left and right to the SFX
subwoofer L and R inputs using screened cable.
High levels
• Use your amplifier's speaker out terminals.
To accommodate the connection of two sets of
cables, red (+) goes to red (+), and black (-) to
black (-), twist wires together and connect to the
amplifier terminals.
• Alternatively use the 'A & B' speaker outputs on the
amplifier if provided - A to your main speakers and B
to the SFX subwoofer. Do this using a length of
speaker cable for each channel, wire your amplifier
outputs to the HIGH LEVEL input terminals, on the
subwoofer amplifier panel. Ensure there are no
stray wire strands that could possibly short together
and damage both the amplifier and subwoofer.
Warnings
• Double-check all connections before switching on
the SFX system and your amplifier.
• Ensure that the polarity of the speaker cables from
your amplifier to the subwoofer is correct - failure to
observe this will result in damage to your amplifier.
• When using the HIGH LEVEL inputs, ensure
that your amplifier is not configured in bridge mode;
damage could result to either the amplifier or the
subwoofer. If in doubt consult your dealer.
Connecting the subwoofer
to your system
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 6
Setting up
Ensure the POWER switch is in the OFF position. You
can operate the SFX subwoofer in two modes, AUTO
and ON. Set to AUTO, the unit remains switched off until
a signal is present (power saving), set to ON the unit
runs continuously. Connect the SFX subwoofer to a con-
venient mains socket using the lead and plug supplied.
Set the SFX subwoofer VOLUME to MIN, PHASE
SWITCH to 0°, CROSSOVER to AV/LFE. Set your 5.1
or 6.1 receiver/decoder to SMALL SPEAKERS, LFE or
SUB output to ON and play a favourite disc. Switch the
SFX subwoofer to ON and set the VOLUME to AV/LFE.
Assess the bass signal strength and adjust VOLUME
accordingly. The purpose of a subwoofer is to enhance
the bass or low frequencies but not to overpower the
music or film dialogue. Set up can be checked by using
the noise signal calibration facility in most 5.1 or 6.1
receivers/decoders.
Positioning
As the SFX subwoofer produces low frequencies only,
it is difficult to detect its location by ear. It can therefore
be placed anywhere in the room, but optimum perform-
ance will be gained by locating the subwoofer between
the front pair of speakers. Bass output will increase
next to a wall or especially in a corner; so use the
volume control to compensate if moving your sub-
woofer around.
Auto power/Sleep functions
The SFX subwoofer can be left permanently on in
AUTO mode, under which conditions it will revert to
'sleep' mode after approximately 20 minutes. If not
using your subwoofer for some time, switch off and
remove the power cable from the mains outlet.
Power requirements
Check that the voltage rating displayed on the rear
panel is correct for your area before connecting. If it is
incorrect, move the voltage selector on the rear panel
to the appropriate voltage. The panel mounted fuse
should also be changed to the correct rating (see
below, under FUSE PROTECTION). If in any doubt,
consult your Dealer or Authorised Service Agent.
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 7
Centre & Satellites
PERFORMANCE
Recommended amplifier power
Maximum Sensitivity (2.83Volts @ 1m)
Nominal impedance
Frequency response (-6dB)
Drivers
Crossover frequency
Magnetic shielding
Satellite Weight
Satellite Dimensions H x W x D
Centre Weight
Centre Dimensions H x W x D
Finish
Supplied accessories
Optional accessories
15 - 100 Watts
85dB
6 Ohms
140Hz - 78kHz
HF: 15mm (0.59”) titanium dome, neodymium magnet system
LF: 75mm (2.95”) paper cone
4.5kHz (mid to high) 140Hz (to subwoofer)
Yes
750gms (1.65lbs)
140 x 97 x 95mm (5.51 x 3.82 x 3.74”)
1.5kg (3.3lbs)
120 x 230 x 95mm (4.72 x 9.06 x 3.74”)
Black
White
Wall mounting brackets
25 metres (82ft 6”) speaker cable
Satellite floor stands available in black
Subwoofer
PERFORMANCE
Power output
Frequency response (-6dB)
Driver
Inputs
Power requirements
Fuse ratings
Additional features
Weight
Dimensions H x W x D
Finish
100 Watts
45Hz - 140Hz
200mm (8.00”) paper cone
Twin line or speaker level
160VA max
AC100-120V / 60Hz - Fuse: T1.6A L /250V
AC 220-240V / 50Hz - Fuse: T800mA L /250V
ON / OFF/ AUTO power function
9.0kg (20.0lbs)
345 x 250 x 370 mm (13.58 x 9.84 x 14.57”)
Black
White
Tannoy adopts a policy of continuous improvement and product specification is subject to change.
6481 0521 / 0311
How it all adds up
tannoy.com
SFX 5.1 Manual AW.qxd:Layout 1 17/3/11 13:00 Page 8
Table of contents
Other Tannoy Home Theater System manuals
