TapFlo Steinle Filter Press Pump Series Operation instructions

Steinle Filter Press Pump Series
edition 2020 rev 1
Original Instruction
Read this instruction manual carefully,
before you install and operate the pump
Pump models:
FP/FH 25
FP/FH 40
FP/FH 50
FP/FH 80

CONTENTS
Steinle Filter Press Pump Series 2
0. GENERAL ......................................................................................................................................... 6
0.1. Introduction................................................................................................................................ 6
0.2. Warning symbols ....................................................................................................................... 6
0.3. Qualification and training of personnel................................................................................... 6
1. INSTALLATION ............................................................................................................................... 7
1.1. Operation principle.................................................................................................................... 7
1.2. Receiving inspection.................................................................................................................. 8
1.3. Lifting and transportation......................................................................................................... 8
1.4. Storage........................................................................................................................................ 9
1.5. Foundation ............................................................................................................................... 10
1.6. Suction and discharge piping ................................................................................................. 10
1.6.1. Connection of suction pipe ............................................................................................. 10
1.6.2. Connection of discharge pipe ......................................................................................... 10
1.7. Health and safety ..................................................................................................................... 10
1.7.1. Protection ......................................................................................................................... 10
1.7.2. Air pressure....................................................................................................................... 11
1.7.3. Noise level ........................................................................................................................ 11
1.7.4. Temperature hazards....................................................................................................... 11
1.8. Air connection .......................................................................................................................... 11
1.8.1. Air treatment system ....................................................................................................... 11
1.8.2. Air quality classes............................................................................................................. 12
1.9. Installation example ................................................................................................................ 13
1.10. Recommended installations................................................................................................ 13
1.10.1. Flooded ............................................................................................................................. 13
1.10.2. Self-priming...................................................................................................................... 13
1.11. Electric Connection .............................................................................................................. 13
1.11.1. 24 V DC (Standard) .............................................................................................................. 14
1.11.2.230 V AC................................................................................................................................ 14
1.11.3. Connection diagram ............................................................................................................ 14
1.11.3.1. 24V DC power supply - Standard.................................................................................... 14
1.11.3.2. 230V AC power supply..................................................................................................... 15
1.11.3.3. 24V DC power supply with diaphragm control unit ..................................................... 15
1.11.3.4. 230V AC power supply with diaphragm control unit ................................................... 16
1.12. Diaphragm control unit for FP/FH Pumps Series .............................................................. 16
1.12.1. Installation of the sensors ................................................................................................... 16

CONTENTS
Steinle Filter Press Pump Series 3
1.12.2. Procedure od adjustment.................................................................................................... 16
1.12.3. Control unit signals.............................................................................................................. 17
2. OPERATION .................................................................................................................................. 18
2.1. Before starting the pump........................................................................................................ 18
2.2. Starting and operation ............................................................................................................ 18
2.2.1. Dry running ...................................................................................................................... 18
2.2.2. Optimization of the pump lifetime ................................................................................ 18
2.3. Pump stopping......................................................................................................................... 19
2.4. Residual risks............................................................................................................................ 19
2.5. Disposal after expiration of the expected lifetime ............................................................... 19
2.6. Waste of electrical and electronic equipment (WEEE) directive .......................................... 19
2.7. Actions in emergency .............................................................................................................. 19
3. MAINTENANCE ............................................................................................................................ 21
3.1. When the pump is new or reassembled................................................................................. 21
3.1.1. Performance test.............................................................................................................. 21
3.2. Routine inspection ................................................................................................................... 21
3.3. Complete inspection ................................................................................................................ 21
3.4. Location of faults ..................................................................................................................... 22
3.5. FP/FH 25 – Disassembly of the pump .................................................................................... 23
3.5.1. Before the disassembly procedure ................................................................................. 23
3.5.2. Disassembly procedure.................................................................................................... 23
3.5.3. Test run ............................................................................................................................. 27
3.6. FP/FH 40-80 – Disassembly of the pump............................................................................... 28
3.6.1. Before the disassembly procedure ................................................................................. 28
3.6.2. Disassembly procedure.................................................................................................... 28
3.7. FP/FH – assembly of the pump ............................................................................................... 32
3.8. Changing the parts............................................................................................................... 33
3.8.1. Changing seals.................................................................................................................. 33
3.8.2. Changing the piston and the cylinder ............................................................................ 33
3.8.3. Changing the hose diaphragms ...................................................................................... 33
3.8.3.1. Suction Side .................................................................................................................. 33
3.8.3.2. Discharge Side .............................................................................................................. 34
3.9. Filling of Hydraulic Liquid ................................................................................................... 34
3.9.1. Pump is flooded from the suction side .......................................................................... 34
3.9.2. Pump is not flooded ........................................................................................................ 35
3.9.3. Changing stroke sensors ................................................................................................. 35

CONTENTS
Steinle Filter Press Pump Series 4
3.9.4. Test run ............................................................................................................................. 35
4. SPARE PARTS................................................................................................................................ 36
4.1. FP-FH 25 – Spare parts drawings............................................................................................ 36
4.2. FP-FH 25 – Spare parts list ...................................................................................................... 39
4.3. FP-FH 40 – Spare parts drawing ............................................................................................. 41
4.4. FP-FH 40 – Spare parts list ...................................................................................................... 44
4.5. FP-FH 50/80 – Spare parts drawing........................................................................................ 47
4.6. FP-FH 50/80 – Spare parts list................................................................................................. 50
4.7. Stocking recommendation ...................................................................................................... 53
4.8. How to order parts................................................................................................................... 54
4.9. Pump code................................................................................................................................ 55
5. DATA ............................................................................................................................................. 56
5.1. Capacity curves......................................................................................................................... 56
5.2. Capacity changes...................................................................................................................... 57
5.3. Dimensions ............................................................................................................................... 57
5.4. Technical data .......................................................................................................................... 59
5.5. Tightening torques .................................................................................................................. 60
5.6. Permitted manifold loads........................................................................................................ 61
6. WARRANTY .................................................................................................................................. 62
6.1. Warranty form.......................................................................................................................... 62
6.2. Returning parts ........................................................................................................................ 63
6.3. Warranty ................................................................................................................................... 63

DECLARATION OF CONFORMITY 01/EC/FP/2019
Series:
FP/FH 25(…); FP/FH 40(…); FP/FH 50(…); FP/FH 80(…)
Serial numbers:
2019 - … (from 1907-…)
Manufactured by:
Tapflo AB
Filaregatan 4
4434 Kungälv, Sweden
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Object of declaration: Filter Press Pumps
The object of the declaration described above is in conformity with the relevant Union
harmonization legislation:
•Directive 2006/42/EC of European Parliament and of the Council of 17 May 2006 on
machinery, amending Directive 95/16/EC;
Mr Michał Śmigiel is authorized to compile the technical file.
Tapflo Sp. z o.o.
ul. Czatkowska 4b
83-110 Tczew
Signed for and on behalf of
Tapflo AB
Håkan Ekstrand
Managing Director
Tapflo AB, 01.07.2019r

0. GENERAL
Steinle Filter Press Pump Series 6
0.
GENERAL
0.1. Introduction
The FP/FH Air Operated Filter Press Pump range is a complete series of pumps for industrial
applications. The pumps are designed to be safe, simple and easy to use and maintain. The
construction is seal-less and without rotating parts. The pumps are suitable for a variety of
duties in filter press installations.
With proper attention to maintenance, Tapflo Pumps will give efficient and trouble-free
operation. This instruction manual will familiarise operators with detailed information about
installing, operating and maintaining of the pump.
The design and function allow the user a straightforward pressing of slurries.
When installing, operating and maintaining of the pump unit you must strictly follow the
IOM manual. Otherwise injury or life hazard may occur.
0.2. Warning symbols
The following warning symbols are present in this instruction manual. This is what they say:
This symbol stands next to all safety instructions in this instruction manual where
danger to life and limb may occur. Observe these instructions and proceed with
utmost caution in these situations. Inform also other users of all safety
instructions. In addition to the instructions in this instruction manual, the general
safety and accident prevention regulations must be observed.
This signal stands at points in this instruction manual of particular importance
for compliance with regulations and directives, for correct workflow and for the
prevention of damage to and destruction of the pump or its subassemblies.
0.3. Qualification and training of personnel
The personnel in charge of installation, operation and maintenance of the pumps we
produce must be qualified to carry out the operations described in this manual. Tapflo shall
not be held responsible for the training level of personnel and for the fact that they are not
fully aware of the contents of this manual. In case any instructions in this manual are unclear
or any information is lacking, please contact Tapflo before handling the pump.

1. INSTALLATION
Steinle Filter Press Pump Series 7
1.
INSTALLATION
1.1. Operation principle
Double Piston-Diaphragm Pump
The FP/FH pump series FP is a double acting piston-diaphragm pump with a hose as
the diaphragm. This hose is compressed by a hydraulic liquid which also restores its original
shape. While the hose is compressed, the slurry inside is displaced and flows out. Ball valves
on the top and bottom of the hose ensure that the flow is in one direction only.
a: open b: compressed
The two extreme deformation conditions of the hose

1. INSTALLATION
Steinle Filter Press Pump Series 8
The hose only has to separate the hydraulic liquid from the slurry and is pressure neutral. The
pressure inside and outside the hose is always the same. This is why the diaphragm has an
extremely long service life besides the fact that it is never compressed totally. It only flexes in
the elastic range of the material.
Pneumatic Drive
Compressed air is moving the pneumatic piston which is attached to the hydraulic piston. The
hydraulic piston is moving the hydraulic liquid which is acting on the diaphragm hose. Pressure
transmission ratio is created by the difference in surface area size between pneumatic and
hydraulic pistons. The endpoint in the movemen
t of the air piston is registered by two
electronic sensors without any mechanical contact. The signal of these switches controls an
electric 5/2 solenoid valve which leads the air to the opposite side of the piston.
Self-Regulating
The pneumatic drive system of the pump results in a continuous balance between the flow
rate of the pump and the quantity of slurry required by the filter press. The pump system thus
regulates itself. Even if a valve on the discharge side is closed, the pump simply stops and has
no energy consumption. When the valve is opened, the pump starts to operate again. Thanks
to this feature, no additional pump control units, such as pressure switches, are required.
Diaphragm failure control
Damage to the hose can be detected by an optional sensor unit. Once sensor will detect
diaphragm fracture, alarm will appear. In this case service must be carried out immediately.
Please note that even if the hose is damaged, the pump will continue to work as a simple
piston pump.
1.2. Receiving inspection
Although precaution is taken by us when packing and shipping, we urge you to carefully check
the shipment on receipt. Make sure that all parts and accessories listed on the packing list are
accounted for. Immediately report any damage or shortage to the transport company and to
us.
1.3.
Lifting and transportation
Before handling the pump check the weight of the pump (see 5.4. Technical data). Refer to
Your local standards on how to handle the pump. If the weight is excessive to transport by
hand it must be lifted using slings and a suitable lifting device e.g. a crane or forklift.
Always use at least two slings and make sure they are secured in such a way to prevent the
pump from slipping and that the pump unit is hanging straight.
Never lift the pump with only one sling. Incorrect lifting can cause serious injury and/or
damage to the pump.

1. INSTALLATION
Steinle Filter Press Pump Series 9
Never lift the pump under pressure.
Be careful that nobody passes under the pump when lifted.
Never try to lift the pump by the hoses attached to the pump.
As an option pumps can be equipped with lifting eyebolts connected with the pump housing.
1.4. Storage
If the equipment is to be stored prior to installation, place it in a clean location. The pump
should be stored in an ambient temperature of 15°C (59°F) to 25°C (77°F) and relative humidity
below 65%. It should not be exposed to any heat source e.g. radiator, sun as this could result
in a negative way on the tightness of the pump. Do not remove the protective covers from the
suction, discharge and air connections which have been fastened to keep pump internals free
of debris. Clean the pump thoroughly before installation.

1. INSTALLATION
Steinle Filter Press Pump Series 10
1.5. Foundation
The pump is furnished with vibration absorbing base frame. The pump will operate properly
without additional shock absorbers. Make sure the foundation is able to absorb vibrations and
fix the base frame with screws to the foundation. It is essential for the operation of the pump
to mount the pump vertical. (see sketch in chapter 1.10“Recommended installations”).
1.6. Suction and discharge piping
Suction and discharge piping should be fully supported and anchored near to but independent
of the pump. The piping to the pump should be connected with rubber compensator, to
prevent undue stress and strain on the pump connections and the piping.
1.6.1.
Connection of suction pipe
Remember that the suction pipe/connection is the most critical point, especially if the pump
is priming. Just a small leakage will dramatically reduce the suction capability of the pump.
When connecting the suction pipe, following is recommended.
1)
For satisfactory operation, use reinforced hose (the suction power may otherwise
shrink the hose) or other flexible piping. The internal diameter of the hose should be
the same as on the suction connection (at the bottom of the pump) to have best
suction capability.
2)
Make sure that the connection hose - pump is completely tight, otherwise the suction
capability will be reduced.
3)
Always use as short suction pipe as possible. Avoid air pockets which can arise with
long piping.
1.6.2. Connection of discharge pipe
For this connection it is only recommended a simple and positive flow connection. Use rubber
compensator between the discharge connection and any rigid fixed piping. All components
(hose, pipe, valves etc.) on the discharge piping must be designed for minimum PN 16 for FP
pumps and pumps with PP manifold, PN 25 for FH pumps.
1.7.
Health and safety
The pump must be installed according to local and national safety rules.
The pumps are constructed for particular applications. Do not use the pump on
applications different from that for which it was sold without consulting us to ascertain
its suitability.
1.7.1. Protection
In the interest of health and safety it is essential to wear protective clothing and safety goggles
when operating, and/or working in the vicinity of Tapflo pumps.

1. INSTALLATION
Steinle Filter Press Pump Series 11
1.7.2. Air pressure
The maximum air pressure for FP/FH series pumps is 7 bar. Higher air pressure than 7 bar can
damage the pump and may cause injury to personnel in vicinity of the pump. If you intend to
apply a higher air pressure than 7 bar, please consult us.
1.7.3.
Noise level
At tests, the noise level from a FP/FH pump has not exceeded 80 dB(A). Under some
circumstances, for example if the pump is operating under high air pressure at low discharge
head, the noise can be inconvenient or hazardous for personnel staying for long periods in
the vicinity of the pump. This hazard can be prevented by:
using suitable ear protection;
lowering the air pressure and/or raising the discharge head;

leading out the outgoing air from the room by connecting a hose to the muffler
connection of the pump;
1.7.4.
Temperature hazards

Raised temperature can cause damage on the pump and/or piping and may also be
hazardous for personnel in the vicinity of the pump/piping. Avoid quick temperature
changes and do not exceed the maximum temperature specified when the pump was
ordered. See also general max temperatures based on water in chapter 5. “DATA”.
When the pump is exposed to ambient temperature variations or if there is big difference
between the temperature of the product and the surrounding, the tightening torques of
the housing nuts should be checked periodically as part of preventive maintenance. Please
contact Tapflo for tightening intervals recommendation.
Below 0°C (32°F) plastic materials become more fragile what can cause accelerated wear
of parts made of these materials. This is a hazard that has to be accepted when pumping
such cold products. Also, in such case, when a pump is not operational it should be drained
of all liquid.
Bear in mind that the viscosity of the product changes with temperature. This has to be
taken into consideration when selecting the pump.
1.8.
Air connection
Screw the air hose into the air intake of the pump with for example a bayonet coupling. For
best efficiency, use the same hose diameter as the internal diameter of the connection on the
air intake.
1.8.1. Air treatment system
Maximum air pressure is 7 bar. As prevention purpose, a filtration of the air by means of a 5-
micron filter or finer is recommended. Recommended air quality according to PN-ISO8573-
1:2010 is particles class 7, water class 4 and oil class 4. Dirt in the air can under unfortunate
circumstances be the cause of a breakdown. The air valve is constructed for oil free air.
Lubrication of the air increases the lifetime of the pneumatic parts. But when the air once is
lubricated, the lubrication never may be interrupted. For more details please contact your
Tapflo representative.

1. INSTALLATION
Steinle Filter Press Pump Series 12
To facilitate the operation of the pump we recommend an air treatment system connected to
the air supply. These components should be included:
1) Regulator to adjust the air pressure;
2) Manometer to read the actual pressure;
3) Needle valve to adjust the air flow (especially when operating the pump in the lower range
of performance);
4) Filter.
These components are included in Tapflo’s Air treatment system which can be ordered from
us.
1.8.2.
Air quality classes
ISO 8573-1:2010 Compressed Air Contaminants and Purity Classes
Class
Solid particles Water Oil
Maximum number of particles
per m³
Mass
concentration
[mg/m³]
Pressure
dew point
[°C]
Liquid
[g/m³]
Total oil content
(liquid, aerosol and
vapour)
[mg/m³]
0.1 – 0.5
µm
0.5 – 1
µm
1 – 5 µm
0
As specified by the equipment user or supplier and more stringent than class 1
1
≤ 20,000
≤ 400
≤ 10
−
≤ −70
−
0.01
2
≤ 400,000
≤ 6,000
≤ 100
−
≤ −40
−
0.1
3
−
≤ 90,000
≤ 1,000
−
≤ −20
−
1
4
−
−
≤ 10,000
−
≤ +3
−
5
5
−
−
≤ 100,000
−
≤ +7
−
−
6
−
−
−
≤ 5
≤ +10
−
−
7
−
−
−
5 – 10
−
≤ 0.5
−
8
−
−
−
−
−
0.5 – 5
−
9
−
−
−
−
−
5 – 10
−
X
−
−
−
> 10
−
> 10
> 10

1. INSTALLATION
Steinle Filter Press Pump Series 13
1.9. Installation example
1.10. Recommended installations
The FP/FH pump is flexible in the way you are able to install it.
1.10.1. Flooded
The piping system is designed with a positive suction head. This is the best way of installation
where it is necessary to completely evacuate all liquid from the container, or where viscous
(thick) products are transferred.
1.10.2. Self-priming
The FP/FH pump is designed to pull a vacuum. It is able to evacuate an empty suction pipe
without any damage to the pump. The suction lift is up to 2 meters (6.6 ft.) from an empty
suction pipe and up to 5 meters (16.4 ft.) from a wetted pipe. The suction capability depends
on the pump size (see chapter 5. “Data”).
NOTE!
Even if all above safety instructions are met and complied with, there still exists a minor danger
in the event of a leakage or mechanical damage of the pump. In such case the pumped product
can emerge on sealing areas and connections.
1.11. Electric Connection
The pump needs a power supply for the operation of the solenoid valve. Please keep care,
that the installation is done properly according to the national standards. Tight the cable
fittings to avoid the ingress of water. All internal cable wiring is done.

1. INSTALLATION
Steinle Filter Press Pump Series 14
1.11.1. 24 V DC (Standard)
The power supply is connected to the clamps inside the control box, marked with + and -.
Keep care for the right poles. The power consumption is 12 W.
1.11.2. 230 V AC
The power supply is connected to the clamps inside the control box, marked with L, N, and
PE (ground connection). Keep care, that the ground connection is installed properly.
1.11.3.
Connection diagram
1.11.3.1. 24V DC power supply - Standard

1. INSTALLATION
Steinle Filter Press Pump Series 15
1.11.3.2. 230V AC power supply
1.11.3.3.
24V DC power supply with diaphragm control unit

1. INSTALLATION
Steinle Filter Press Pump Series 16
1.11.3.4. 230V AC power supply with diaphragm control unit
1.12. Diaphragm control unit for FP/FH Pumps Series
The diaphragm control unit is designed to detect an early break of the diaphragm in the FP/FH
pumps series. Only a small hole in the diaphragm will cause a mixing of slurry with hydraulic
liquid and so a damage of the hydraulic parts in the pump. A break of the diaphragm can’t
been recognised, because the pump works as a simple piston pump even without a
diaphragm. The hydraulic liquids we use are not electrically conductive, but the slurries have
a high conductivity. These different characteristics are used to detect the contamination of the
hydraulic liquid by a slurry. Between the two electrodes of the sensor an electric currency of
8V is connected. When a conductive liquid allows the low of the power, the electronic device
will recognise and switch a relay. With the potential free contacts of this relay an alarm signal
can be connected or the pump can be switched off.
1.12.1. Installation of the sensors
The sensors are screwed in the draining valves on the bottom of the hydraulic chambers. For
the sealing a tape of Teflon. The pump sizes 25 need only one sensor, all others need two
sensors.
1.12.2. Procedure of adjustment
Closing the drain valve and screwing off the plug. Screw in the sensor instead of the plug and
open the drain valve. For testing the function of the unit, the sensor can be dipped into the
slurry. When all parts are connected well, the electronic must switch in this case. If no function
is to recognise, first the wiring has to be checked. When the wiring seems to be correct, the
adjustment screw on the electronic has to turned clockwise, till the relay switches. After taking
the sensor out of the slurry, the relay must go back to neutral position again. If not, clean the
surface of the sensor. This can be done while power is switched on.

1. INSTALLATION
Steinle Filter Press Pump Series 17
1.12.3. Control unit signals

LED green:
Operation, on as soon as power supply is on
LED yellow:
On when no signal is given (no diaphragm break)
Off as soon as current flows from 16/18 to 17/19 - (diaphragm break)
Signals (terminal contacts short circuited):
No Power: 21 - 22
No Alarm, LED green: 20 - 21
Alarm, LED green off: 21 - 22

2. OPERATION
Steinle Filter Press Pump Series 18
2. OPERATION
2.1. Before starting the pump

Make sure the pump is installed according to the installation instruction (chapter 1).
Filling of the pump with liquid before start is not necessary. Only at high suction lift it
may help to fill the pump with water on the suction side to increase the suction
capability.
When installation is new or reinstalled, a test run of the pump with water should be
conducted to make sure that the pump operates normally and does not leak.
2.2. Starting and operation

Open the discharge valve.
Pull out the red button on the control box to switch the control power.

Note! Considering the suction capacity when air is still in the suction pipe, it is
recommended to start with low air pressure/flow (slowly) at the beginning. This
is not necessary if the pump is filled with liquid before start.
When the pump has been filled with liquid, the air pressure/flow may be raised in order
to increase the suction capacity of the pump.
Below maximum allowable stroke frequency for cycles. Please run the pump with the
lowest possible speed. Stroke - One move of single diaphragm. Two strokes per cycle.
FP25: 60 1/min
FP40: 83 1/min
FP50: 58 1/min
FP80: 75 1/min
The performance of the pump can be adjusted through the air supply by using a needle
valve and a pressure regulator. The performance can also be adjusted by normal flow
control on the discharge side of the system.
2.2.1.
Dry running
Although the pump is prepared for dry running it is important to have in mind that long
periods of dry run may increases the wear. Also, an empty pump should operate at low
speeds – controlled by a needle-valve.
2.2.2. Optimization of the pump lifetime

Running at full frequency (maximum air pressure/flow) continuously will cause
premature wear of the components.
As stated in chapter 1.8.1 Tapflo recommends using an appropriate air treatment system
in order to extend the pump’s lifetime.
If the air humidity is high, use of a water separator or air dryer is recommended.
Otherwise on the air discharge side due to decompression, icing on the muffler can
appear causing it to shrink and eventually it can shoot out of its socket.

2. OPERATION
Steinle Filter Press Pump Series 19

If the ambient air is humid, icing can occur outside of the muffler. In such case it is
recommended to use a longer exhaust of the compressed air (ca. 500 mm / 19,7’’).
Operate the pump as slow as possible.
2.3. Pump stopping
The pump can be stopped in three ways:
1) Close the discharge valve. The
pressure from the system will stop the pump
automatically. This will not do any damage to the pump. The pump restarts easy when
the valve is opened again.
2) By cutting off the air supply.
3) Switch off control panel
2.4. Residual risks
Even with proper application and observance of all points listed in this operating manual,
there is still an estimable and unexpected residual risk when using the pumps. It may leak,
fail due to wear, application-related causes or system-related circumstances.
2.5. Disposal after expiration of the expected lifetime
The metallic components like aluminium, stainless steel and carbon steel can be recycled.
Plastic parts are not recyclable and must be disposed of as residual waste. The pump must
be disposed of properly, according to local regulations. It should be noted that potentially
dangerous fluid residues may remain in the pump and can create a hazard to the operator
or the environment, therefore the pump has to thoroughly cleaned before disposal.
The hydraulic liquid is biodegradable; however, it must be recycled according to national
regulations.
2.6. Waste of electrical and electronic equipment (WEEE) directive
Users of electrical and electronic equipment (EEE) with the WEEE
marking per Annex IV of the WEEE Directive must not dispose of end
of life EEE as unsorted municipal waste, but use the collection
framework available to them for the return, recycle, recovery of WEEE
and minimize any potential effects of EEE on the environment and
human health due to the presence of hazardous substances. The WEEE
marking applies only to countries within the European Union (EU) and Norway. Appliances
are labelled in accordance with European Directive 2002/96/EC. Contact your local waste
recovery agency for a designated collection facility in your area.
2.7.
Actions in emergency
In case of a leakage of an unknown fluid, respiratory protection should be worn and
contact with the fluid avoided. During firefighting, keep in mind that hydraulic part of
pump is filled with oil and control unit is connected to electricity. In addition, the currently

2. OPERATION
Steinle Filter Press Pump Series 20
handled fluid and the corresponding safety data sheet must be taken into account. In the
event of personal injury, the appropriate emergency number or 112 must be chosen.
